Abstract
The Lenovo ThinkSystem SR250 V2 is a high-value single-socket 1U rack server for growing businesses that need optimized performance and flexibility for future growth, along with enterprise-class reliability, management, and security. The server supports the new Intel Xeon E-2300 Series processors, formerly codenamed "Rocket Lake".
This product guide provides essential presales information to understand the ThinkSystem SR250 V2 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR250 V2 and consider its use in IT solutions.
Change History
Changes in the December 5, 2023 update:
- New 2.5-inch SATA SSD drive options - Internal drive options section:
- ThinkSystem 2.5" Multi Vendor 240GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90872
- ThinkSystem 2.5" Multi Vendor 480GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90873
- ThinkSystem 2.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90874
- ThinkSystem 2.5" Multi Vendor 1.92TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90875
- ThinkSystem 2.5" Multi Vendor 3.84TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90876
- ThinkSystem 2.5" Multi Vendor 7.68TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90877
- ThinkSystem 2.5" Multi Vendor 480GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90884
- ThinkSystem 2.5" Multi Vendor 960GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90885
- ThinkSystem 2.5" Multi Vendor 1.92TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90886
- ThinkSystem 2.5" Multi Vendor 3.84TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90887
- New 3.5-inch SATA SSD drive options - Internal drive options section:
- ThinkSystem 3.5" Multi Vendor 240GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90878
- ThinkSystem 3.5" Multi Vendor 480GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90879
- ThinkSystem 3.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90880
- ThinkSystem 3.5" Multi Vendor 1.92TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90881
- ThinkSystem 3.5" Multi Vendor 3.84TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90882
- ThinkSystem 3.5" Multi Vendor 7.68TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90883
- ThinkSystem 3.5" Multi Vendor 480GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90888
- ThinkSystem 3.5" Multi Vendor 960GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90889
- ThinkSystem 3.5" Multi Vendor 1.92TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90890
- ThinkSystem 3.5" Multi Vendor 3.84TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90891
- New M.2 drive options - Internal drive options section:
- ThinkSystem M.2 ER3 240GB Read Intensive SATA 6Gb NHS SSD, 4XB7A89422
- ThinkSystem M.2 ER3 480GB Read Intensive SATA 6Gb NHS SSD, 4XB7A90049
- ThinkSystem M.2 ER3 960GB Read Intensive SATA 6Gb NHS SSD, 4XB7A90230
Introduction
The Lenovo ThinkSystem SR250 V2 is a high-value single-socket 1U rack server for growing businesses that need optimized performance and flexibility for future growth, along with enterprise-class reliability, management, and security. The server supports one Intel Xeon E-2300 Series processor (formerly codenamed "Rocket Lake") or Intel Pentium ("Comet Lake Refresh") and up to 128 GB of 3200 MHz TruDDR4 ECC memory.
Flexible and scalable internal storage configurations include up to ten 2.5-inch or four 3.5-inch drives with affordable software RAID or advanced hardware RAID protection and a wide selection of drive sizes and types, including NVMe PCIe SSDs, SAS/SATA SSDs, and SAS/SATA HDDs. Also, it features integrated dual-port 1 Gb Ethernet NIC and additional PCIe expansion slots for hardware RAID protection, network scalability, and external storage connectivity.
The next-generation Lenovo XClarity Controller, which is built into the SR250 V2 server, provides advanced service processor control, monitoring, and alerting functions.
The following figure shows the Lenovo ThinkSystem SR250 V2 with ten 2.5-inch hot-swap drives.
Did you know?
The ThinkSystem SR250 V2 is an entry-level server with enterprise-grade management features and support for hot-swap power supplies and drives. It offers full support of Lenovo XClarity Administrator for comprehensive systems management and includes the next generation UEFI-based Lenovo XClarity Provisioning Manager for system setup and diagnosis, and the Lenovo XClarity Controller management processor for ongoing systems management and alerting. These tools make the SR250 V2 easy to deploy, integrate, service, and manage.
Key features
The SR250 V2 server is a compact, cost-effective, single-processor 1U rack server that has been optimized to provide enterprise-class features to small-to-medium-sized businesses, retail stores, or distributed enterprises.
Scalability and performance
The SR250 V2 offers the following features to boost performance, improve scalability, and reduce costs:
- Improved single-socket processor performance:
- Intel Xeon E-2300 Series processors ("Rocket Lake-E") up to to 8 cores and core speeds up to 3.7 GHz
- Intel Pentium G6405, G6505 and G6605 processors ("Comet Lake Refresh") with 2 cores and core speeds up to 4.3 GHz
- Up to four 3200 MHz DDR4 ECC UDIMMs provide speed and capacity of up to 128 GB
- Offers flexible and scalable internal storage in a 1U rack form factor with up to 10x 2.5-inch drives for performance-optimized configurations or up to 4x 3.5-inch drives for capacity-optimized configurations
- Up to three PCIe slots for I/O expansion, one of which has the new PCIe Gen4 interface to maximize I/O performance
- The use of solid-state drives (SSDs) instead of, or along with, traditional hard disk drives (HDDs) can significantly improve I/O performance. An SSD can support up to 100 times more I/O operations per second (IOPS) than a typical HDD.
- New high-speed RAID controllers from Lenovo and Broadcom provide 12 Gb SAS connectivity to the drive backplanes
- Supports two M.2 drives for OS boot support with VROC RAID redundancy
- The server has two integrated Gigabit Ethernet ports
- Support for a NVIDIA GPU for enhanced workload performance
Availability and serviceability
The SR250 V2 server provides many features to simplify serviceability and increase system uptime:
- Designed to run 24 hours a day, 7 days a week
- The SR250 V2 supports UDIMM memory with ECC protection which provides error correction not available in PC-class "servers" that use parity memory. Avoiding system crashes (and data loss) due to soft memory errors means greater system uptime.
- Provides easy access to upgrades and serviceable parts (such as memory DIMMs and adapter cards) with tool-less cover removal.
- Much like hot-swap drives, simple-swap drives are mounted on an easy-to-remove tray and work with the same RAID options. Simple-swap require a system power-down before adding or replacing, however simple-swap drives are less expensive than hot-swap drives.
- Offers data protection and greater system uptime with a choice of affordable onboard SATA RAID or advanced hardware RAID redundancy, along with hot-swap drives (select models).
- The server supports hot-swap power supplies; with two installed, they form a redundant pair to provide availability for business-critical applications.
- The built-in XClarity Controller continuously monitors system parameters, triggers alerts, and performs recovery actions in case of failures to minimize downtime.
- Allows preventive actions in advance of possible failure, thereby increasing server uptime and application availability with Proactive Platform Alerts (including PFA and SMART alerts) for memory, internal storage (SAS/SATA HDDs and SSDs, NVMe SSDs, M.2 SSDs), RAID controllers, and server ambient and sub-component temperatures.
- Provides quick access to system status, firmware, network, health, and alerts information via Virtual Operator Panel from the XClarity Mobile App running on the Android or iOS mobile device that is connected to the front USB port with XClarity Controller access.
- Built-in diagnostics in UEFI, using Lenovo XClarity Provisioning Manager, speed up troubleshooting tasks to reduce service time.
- Lenovo XClarity Provisioning Manager supports diagnostics and can save service data to a USB key drive or remote CIFS share folder for troubleshooting and reduce service time.
- Support for the XClarity Administrator Mobile app running on a supported smartphone and connected to the server through the service-enabled USB port, enables additional local systems management functions.
- Auto restart in the event of a momentary loss of AC power (based on power policy setting in the XClarity Controller service processor)
- One-year or three-year customer-replaceable unit (CRU) and onsite limited warranty with next business day response. Optional service upgrades are available.
Manageability and security
Powerful systems management features simplify local and remote management of the SR250 V2 server and deliver enterprise-class data protection:
- The server includes an XClarity Controller (XCC) to monitor server availability. Optional upgrade to XCC Advanced to provide remote control (keyboard video mouse) functions. Optional upgrade to XCC Enterprise enables the additional support for the mounting of remote media files (ISO and IMG image files), boot capture, and power capping.
- Lenovo XClarity Administrator offers comprehensive hardware management tools that help to increase uptime, reduce costs and improve productivity through advanced server management capabilities.
- New UEFI-based Lenovo XClarity Provisioning Manager, accessible from F1 during boot, provides system inventory information, graphical UEFI Setup, platform update function, RAID Setup wizard, operating system installation function, and diagnostic functions.
- Support for Lenovo XClarity Energy Manager which captures real-time power and temperature data from the server and provides automated controls to lower energy costs.
- Integrated Trusted Platform Module (TPM) 2.0 support enables advanced cryptographic functionality, such as digital signatures and remote attestation.
- Industry-standard Advanced Encryption Standard (AES) NI support for faster, stronger encryption.
- Intel Execute Disable Bit functionality can prevent certain classes of malicious buffer overflow attacks when combined with a supported operating system.
- Intel Trusted Execution Technology (Intel Xeon E processors only) provides enhanced security through hardware-based resistance to malicious software attacks, allowing an application to run in its own isolated space, protected from all other software running on a system.
- Helps prevent unauthorized software from running on the server by protecting against boot block-level malicious software with Intel Boot Guard technology.
- Protects application code and data from disclosure or modification with Intel Software Guard Extensions (SGX), enabling high-assurance security use cases, such as blockchain, identity and records privacy, secure browsing, and digital rights management (DRM).
- Optional lockable front security bezel for additional physical security
Energy efficiency
The SR250 V2 server offers the following energy saving features to save energy, reduce operational costs, increase energy availability, and contribute to the green environment:
- Delivers optimized compute power per watt, featuring 80 PLUS Gold (fixed) and Platinum (hot-swap) AC power supplies.
- Reduces power drawn with Intel Intelligent Power Capability that powers individual processor elements on and off as needed.
- Helps reduce power consumption with variable speed fans.
- Helps achieve lower heat output and reduced cooling needs with Lenovo XClarity Energy Manager that provides advanced data center power notification, analysis, and policy-based management.
Comparing the SR250 V2 to the SR250
The ThinkSystem SR250 V2 improves on the previous generation SR250, as summarized in the following table.
Feature | SR250 | SR250 V2 | Benefits |
---|---|---|---|
Form Factor |
|
|
|
Processor |
|
|
|
GPU |
|
|
|
Memory |
|
|
|
Storage |
|
|
|
RAID |
|
|
|
Cooling |
|
|
|
Networking |
|
|
|
PCIe Slots |
|
|
|
Front I/O |
|
|
|
Rear I/O |
|
|
|
Management and Security |
|
|
|
Power Supply |
|
|
|
Components and connectors
There are four different base drive configurations available for the SR250 V2, as shown in the following figure:
- 10x 2.5-inch hot-swap drive bays, SAS/SATA
- 8x 2.5-inch hot-swap drive bays, either SAS only or SAS/SATA
- 4x 3.5-inch hot-swap drives, either SAS only or SAS/SATA
- 4x 3.5-inch simple-swap drives, either SATA only or 3x SATA + 1x NVMe
Figure 2. Front configurations of the ThinkSystem SR250 V2
The following figure shows the components on the front of the SR250 V2 server.
System architecture
Standard specifications
The following table lists the standard specifications.
Components | Specification |
---|---|
Machine type | 7D7R - 1 year warranty 7D7Q - 3 year warranty |
Form factor | 1U rack-mount |
Processor |
One Intel processor. Choose from:
|
Chipset | Intel C256 chipset ("Tiger Lake") part of the "Tatlow" platform |
Memory | Four DIMM sockets supporting Lenovo TruDDR4 DIMMs at 3200 MHz (Xeon processors) or 2666 MHz (Pentium processors). Support ECC UDIMMs. |
Memory maximum | Up to 128 GB using 4x 32 GB UDIMMs. |
Memory protection | Error-correcting code (ECC) |
Disk drive bays |
Available configurations:
In addition, the SR250 V2 supports two M.2 drives installed in an M.2 adapter which is installed in PCIe slot. |
Maximum internal storage |
|
Storage controller |
|
Optical drive bays | No support. Use an external optical drive. |
Tape drive bays | No support |
Network interfaces | Two integrated Gigabit Ethernet 1000BASE-T ports (RJ-45) based on Broadcom BCM5720 embedded controller, one can be shared with XCC for systems management. Third dedicated Gigabit Ethernet port for XCC systems management. |
PCI Expansion slots |
Two or three PCIe slots depending on the riser selected:
Note: Slots 1 and 2 are PCIe Gen 4 with a Xeon processor, and PCIe Gen 3 with a Pentium processor |
Ports |
|
Cooling | Four non-hot-swap system fans |
Power supply |
Model dependent choices:
|
Hot-swap parts | Hard drives and hot-swap power supplies |
Systems management | Operator panel with status LEDs. XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XClarity Controller Advanced to enable remote control functions. |
Security features | Power-on password, administrator's password, Trusted Platform Module, supporting TPM 2.0. Optional lockable front bezel for physical security. |
Video | G200 graphics with 16 MB memory, integrated into the XClarity Controller. For use with local Administrator functions (not designed for workstation use). Maximum resolution is 1920x1200 32bpp at 60Hz. |
Operating systems supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating system support section for specifics. |
Limited warranty | Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
Service and support | Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications. |
Dimensions | Width: 435 mm (17.1 in.), height: 43 mm (1.7 in.), depth: 545 mm (21.5 in.). See Physical and electrical specifications for details. |
Weight | Maximum configuration: 12.3 kg (27.1 lb) |
The SR250 V2 server is shipped with the following items:
- Documentation flyer
- Power cords (model and region dependent)
Models
ThinkSystem SR250 V2 models can be configured by using the Lenovo Data Center Solution Configurator (DCSC).
Preconfigured server models may also be available for the SR250 V2, however these are region-specific; that is, each region may define their own server models, and not all server models are available in every region.
The following table lists the base CTO models of the ThinkSystem SR250 V2 server.
Machine Type/Model | Description |
---|---|
7D7QCTO1WW | ThinkSystem SR250 V2 – 3-year Warranty |
7D7RCTO1WW | ThinkSystem SR250 V2 – 1-year Warranty |
Models of the SR250 V2 are defined based on whether the server has 2.5-inch drive bays at the front (called the 2.5-inch chassis) or whether it has 3.5-inch drive bays at the front (called the 3.5-inch chassis). For models, the feature codes for these chassis bases are as listed in the following table.
Feature code | Description |
---|---|
B404 | ThinkSystem SR250 2.5" Chassis |
B403 | ThinkSystem SR250/SR150 3.5"x4 Chassis |
The following tables list the available models, grouped by region.
- Models for Asia Pacific region
- Models for Australia and New Zealand
- Models for Brazil
- Models for EMEA countries
- Models for Hong Kong, Taiwan, Korea (HTK)
- Models for India
- Models for Japan
- Models for Latin American countries (except Brazil)
- Models for USA and Canada
Refer to the Specifications section for information about standard features of the server.
Models for Asia Pacific region
The following table lists the models for the Asia Pacific region: Australia, Bangladesh, Brunei, Hong Kong, India, Japan, Korea, Sri Lanka, Malaysia, New Zealand, Philippines, Singapore, Thailand, Taiwan, Vietnam
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with a 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA01TAP | Xeon E-2324G 4C 65W 3.1G | 1x 8GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (N) | Std | Opt | Fric |
7D7QA01VAP | Xeon E-2324G 4C 65W 3.1G | 1x 8GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA01UAP | Xeon E-2356G 6C 80W 3.2G | 1x 8GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA01WAP | Xeon E-2356G 6C 80W 3.2G | 1x 8GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (N) | Std | Opt | Fric |
7D7QA01SAP | Xeon E-2386G 6C 95W 3.5G | 1x 8GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA01XAP | Xeon E-2386G 6C 95W 3.5G | 1x 8GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (N) | Std | Opt | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for Australia and New Zealand
AP models: Customers in Australia and New Zealand also have access to the Asia Pacific region models.
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
TopSeller models with a 3-year model (machine type 7D7Q) | ||||||||||
7D7QA03DAU | Xeon E-2324G 4C 65W 3.1GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Adv | Yes | Fric |
7D7QA01EAU | Xeon E-2324G 4C 65W 3.1G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
7D7QA01GAU | Xeon E-2356G 6C 80W 3.2G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
7D7QA01JAU | Xeon E-2378G 8C 80W 2.8G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
7D7QA03SAU | Xeon E-2378G 8C 80W 2.8GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for Brazil
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with a 3-year warranty (machine type 7D7Q) | ||||||||||
7D7Q1005BR | Xeon E-2324G 4C 65W 3.1GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Ent | Opt | Fric |
7D7QA03JBR | Xeon E-2324G 4C 65W 3.1GHz | 2x 8GB | SATA | 4x 3.5-in HS / 2x 2TB SATA HDD | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 2x 450W HS / 2 (N) | Ent | Opt | Fric |
7D7Q1006BR | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 2x 450W HS / 2 (N) | Ent | Opt | Fric |
TopSeller models with a 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA03GBR | Xeon E-2324G 4C 65W 3.1GHz | 2x 8GB | SATA | 4x 3.5-in HS / 2x 2TB SATA HDD | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 2x 450W HS / 2 (N) | Ent | Opt | Fric |
7D7QA03KBR | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 2x 450W HS / 2 (N) | Ent | Opt | Fric |
7D7QA03LBR | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 2x 450W HS / 2 (N) | Ent | Opt | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for EMEA countries
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA00LEA | Xeon E-2314 4C 65W 2.8GHz | 1x 8GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (Y) | Std | Opt | Fric |
7D7QA013EA | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA01KEA | Xeon E-2314 4C 65W 2.8GHz | 1x 8GB | SATA | 4x 3.5-in SS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (Y) | Std | Opt | Fric |
7D7QA00PEA | Xeon E-2334 4C 65W 3.4GHz | 1x 8GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (Y) | Std | Opt | Fric |
7D7QA00YEA | Xeon E-2334 4C 65W 3.4G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA017EA | Xeon E-2334 4C 65W 3.4GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA02DEA | Xeon E-2334 4C 65W 3.4GHz | 1x 8GB | SATA | 8x 2.5-in HS / 1x 480GB MV SSD | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA03EEA | Xeon E-2334 4C 65W 3.4GHz | 1x 32GB | SATA | 8x 2.5-in HS / 2x 960GB 5400 PRO | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS TT / 2 (Y) | Ent | Opt | Fric |
7D7QA03QEA | Xeon E-2334 4C 65W 3.4GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS TT / 2 (Y) | Ent | Opt | Fric |
7D7QA011EA | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA01LEA | Xeon E-2356G 6C 80W 3.2GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA03PEA | Xeon E-2356G 6C 80W 3.2GHz | 1x 32GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS TT / 2 (Y) | Ent | Opt | Fric |
7D7QA014EA | Xeon E-2374G 4C 80W 3.7GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA01MEA | Xeon E-2374G 4C 80W 3.7GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA016EA | Xeon E-2378 8C 65W 2.6G | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA01REA | Xeon E-2378 8C 65W 2.6GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA02CEA | Xeon E-2378 8C 65W 2.6GHz | 1x 8GB | SATA | 8x 2.5-in HS / 2x 480GB MV SSD | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA031EA | Xeon E-2378 8C 65W 2.6GHz | 1x 32GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS TT / 2 (Y) | Ent | Opt | Fric |
7D7QA03REA | Xeon E-2378 8C 65W 2.6GHz | 1x 32GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS TT / 2 (Y) | Ent | Opt | Fric |
7D7QA01NEA | Xeon E-2378G 8C 80W 2.8GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA015EA | Xeon E-2386G 6C 95W 3.5GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA01PEA | Xeon E-2388G 8C 95W 3.2GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for Hong Kong, Taiwan, Korea (HTK)
AP models: Customers in Hong Kong, Taiwan, and Korea also have access to the Asia Pacific region models.
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA037CN | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 4x1Gb 5719 | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA038CN | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | 9350-8i | 8x 2.5-in HS / 2x 480GB 5400 PRO | x8 LP, x8 FH, x8 Int | 1x 4x1Gb 5719 | 2x 450W HS / 2 (Y) | Std | Opt | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for India
AP models: Customers in India also have access to the Asia Pacific region models.
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
TopSeller models with 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA027SG | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | SATA | 4x 3.5-in SS / 1x 2TB HDD | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (N) | Std | Opt | Fric |
7D7QA02ASG | Xeon E-2314 4C 65W 2.8GHz | 1x 8GB | SATA | 4x 3.5-in SS / 1x 2TB HDD | x8 LP, x8 FH, x8 Int | Opt | 300W fixed (N) | Std | Opt | Fric |
7D7QA024SG | Xeon E-2378 8C 65W 2.6GHz | 1x 8GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA025SG | Xeon E-2378 8C 65W 2.6GHz | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA026SG | Xeon E-2378 8C 65W 2.6GHz | 1x 8GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA028SG | Xeon E-2378 8C 65W 2.6GHz | 1x 8GB | SATA | 8x 2.5-in HS / 1x 480GB MV SSD | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
7D7QA029SG | Xeon E-2378 8C 65W 2.6GHz | 1x 8GB | 5350-8i | 8x 2.5-in HS / 1x 480GB MV SSD | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Opt | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for Japan
AP models: Customers in Japan also have access to the Asia Pacific region models.
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA00RJP | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00WJP | Xeon E-2314 4C 65W 2.8G | 1x 16GB | 9350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA01BJP | Xeon E-2314 4C 65W 2.8G | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA01QJP | Xeon E-2314 4C 65W 2.8G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00SJP | Xeon E-2324G 4C 65W 3.1GHz | 1x 16GB | 9350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00TJP | Xeon E-2324G 4C 65W 3.1GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00ZJP | Xeon E-2324G 4C 65W 3.1G | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA01HJP | Xeon E-2324G 4C 65W 3.1G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00MJP | Xeon E-2334 4C 65W 3.4GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00UJP | Xeon E-2334 4C 65W 3.4GHz | 1x 16GB | 9350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA012JP | Xeon E-2334 4C 65W 3.4G | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA01DJP | Xeon E-2334 4C 65W 3.4G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00NJP | Xeon E-2374G 4C 80W 3.7GHz | 1x 16GB | 9350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00QJP | Xeon E-2374G 4C 80W 3.7GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00XJP | Xeon E-2374G 4C 80W 3.7G | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA01FJP | Xeon E-2374G 4C 80W 3.7G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00KJP | Xeon E-2378 8C 65W 2.6GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00VJP | Xeon E-2378 8C 65W 2.6GHz | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA01CJP | Xeon E-2378 8C 65W 2.6G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA00JJP | Xeon E-2388G 8C 95W 3.2GHz | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
7D7QA019JP | Xeon E-2388G 8C 95W 3.2G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Opt | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for Latin American countries (except Brazil)
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Additional Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with 3-year warranty (machine type 7D7Q) | ||||||||||
7D7Q100BLA | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 1x 450W HS / 2 (Y) | Std | Yes | Fric |
7D7Q1001LA | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | SATA | 4x 3.5-in SS / Open bay | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 1x 450W HS / 2 (Y) | Std | Yes | Fric |
7D7Q1002LA | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 1x 450W HS / 2 (Y) | Std | Yes | Fric |
7D7QA02GLA | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | 5350-8i | 4x 3.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Yes | Fric |
7D7Q100ALA | Xeon E-2336 6C 65W 2.9GHz | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 2x1Gb 5720 | 1x 450W HS / 2 (Y) | Std | Yes | Fric |
7D7QA02HLA | Xeon E-2378 8C 65W 2.6GHz | 1x 32GB | 9350-16i | 10x 2.5-in HS / Open bay | x16 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Adv | Yes | Fric |
7D7Q1000LA | Xeon E-2388G 8C 95W 3.2GHz | 1x 16GB | 5350-8i | 8x 2.5-in HS / Open bay | x8 LP, x8 FH, x8 Int | 1x 4x1Gb 5719 | 1x 450W HS / 2 (Y) | Ent | Opt | Fric |
7D7QA02BLA | Xeon E-2388G 8C 95W 3.2GHz | 1x 32GB | 9350-16i | 10x 2.5-in HS / Open bay | x16 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Ent | Opt | Fric |
7D7QA02ELA | Xeon E-2388G 8C 95W 3.2GHz | 1x 32GB | 9350-16i | 10x 2.5-in HS / Open bay | x16 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Yes | Fric |
7D7QA02FLA | Xeon E-2388G 8C 95W 3.2GHz | 1x 32GB | 2x 5350-8i | 10x 2.5-in HS / Open bay | x16 FH, x8 Int | Opt | 1x 450W HS / 2 (N) | Std | Yes | Fric |
TopSeller models with a 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA03TLA | Xeon E-2314 4C 65W 2.8GHz | 1x 16GB | SATA | 4x 3.5-in SS / Open bay | x8 LP, x8 FH, x8 Int | Opt | 1x 450W HS TT / 2 (Y) | Std | Opt | Option |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Models for USA and Canada
Model | Intel processors† |
Memory | Drive C'troller |
Drive bays Drives |
Slots | Add'l Cards |
Power supply (cord) |
XCC | Front VGA |
Rail kit* |
---|---|---|---|---|---|---|---|---|---|---|
Standard models with 3-year warranty (machine type 7D7Q) | ||||||||||
7D7QA01ZNA | Xeon E-2334 4C 65W 3.4G | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 Int (open riser) | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
7D7QA021NA | Xeon E-2336 6C 65W 2.9G | 1x 16GB | SATA | 4x 3.5-in HS / Open bay | x8 Int (open riser) | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
7D7QA020NA | Xeon E-2378 8C 65W 2.6G | 1x 16GB | SATA | 8x 2.5-in HS / Open bay | x8 Int (open riser) | Opt | 1x 450W HS / 2 (Y) | Ent | Yes | Fric |
† Processor detail: Model, number of cores, TDP, core frequency
* Rail kit "Fric" refers to ThinkSystem Toolless Friction Rail v2, 4M17A13564
Processors
The SR250 V2 supports one processor from the following Intel product families:
- Intel Xeon E-2300 Series processors ("Rocket Lake-E")
- Intel Pentium G6405, G6505 and G6605 processors ("Comet Lake Refresh")
All supported processors have the following characteristics:
- LGA 1200 socket (Socket H5)
- 14 nm semiconductor process technology
- Direct Media Interface (DMI) 3.0 connection to PCH
- Xeon E-2300: DMI 3.0 x8 connection
- Pentium: DMI 3.0 x4 connection
- Two DDR4 memory channels
- Support for ECC memory
- Xeon E-2300: Up to 3200 MHz memory speed
- Pentium: Up to 2666 MHz memory speed
- PCIe lanes:
- Xeon E-2300: 20x PCIe 4.0 I/O lanes
- Pentium: 16x PCIe 3.0 I/O lanes
The following table lists the supported processors.
Integrated graphics and management: Xeon processors with a G suffix include integrated graphics, however, this functionality is not used in the SR250 V2. Instead, graphics support is provided by XClarity Controller (XCC), or by an GPU add-in card. Similarly system management of the SR250 V2 is handled by XCC and as a result, the AMT management processor is disabled.
Feature code |
Intel model |
TDP | Cores / threads |
HT | Core speed / Max TB |
Cache | Max memory speed |
VT | Intel SGX / Enclave† |
---|---|---|---|---|---|---|---|---|---|
Intel Pentium processors | |||||||||
BMDN | G6405 | 58W | 2 / 4 | Yes | 4.1 GHz / No TB | 4 MB | 2666 MHz | Yes | No |
BMDQ | G6405T | 35W | 2 / 4 | Yes | 3.5 GHz / No TB | 4 MB | 2666 MHz | Yes | No |
BMDM | G6505 | 58W | 2 / 4 | Yes | 4.2 GHz / No TB | 4 MB | 2666 MHz | Yes | No |
BMDP | G6505T | 35W | 2 / 4 | Yes | 3.6 GHz / No TB | 4 MB | 2666 MHz | Yes | No |
BMDL | G6605 | 58W | 2 / 4 | Yes | 4.3 GHz / No TB | 4 MB | 2666 MHz | Yes | No |
Intel Xeon E processors | |||||||||
BMDD | E-2314 | 65W | 4 / 4 | No | 2.8 GHz / 4.5 GHz | 8 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDK | E-2324G | 65W | 4 / 4 | No | 3.1 GHz / 4.6 GHz | 8 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDC | E-2334 | 65W | 4 / 8 | Yes | 3.4 GHz / 4.8 GHz | 8 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDB | E-2336 | 65W | 6 / 12 | Yes | 2.9 GHz / 4.8 GHz | 12 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDH | E-2356G | 80W | 6 / 12 | Yes | 3.2 GHz / 5.0 GHz | 12 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDJ | E-2374G | 80W | 4 / 8 | Yes | 3.7 GHz / 5.0 GHz | 8 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDA | E-2378 | 65W | 8 / 16 | Yes | 2.6 GHz / 4.8 GHz | 16 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDF | E-2378G | 80W | 8 / 16 | Yes | 2.8 GHz / 5.1 GHz | 16 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDG | E-2386G | 95W | 6 / 12 | Yes | 3.5 GHz / 5.1 GHz | 12 MB | 3200 MHz | Yes | Yes / 512 MB |
BMDE | E-2388G | 95W | 8 / 16 | Yes | 3.2 GHz / 5.1 GHz | 16 MB | 3200 MHz | Yes | Yes / 512 MB |
† Intel SGX with Intel SPS / Intel SGX Enclave Page Cache size.
Configuration notes:
- For customers in the UK and in EU countries, Intel Pentium processors are not offered due to ERP Lot 9 requirements
- Energy Star certification only applies to Intel Xeon E processors. Intel Pentium processors are not Energy Star compliant
UEFI operating modes
The SR250 V2 offers preset operating modes that affect energy consumption and performance. These modes are a collection of predefined low-level UEFI settings that simplify the task of tuning the server to suit your business and workload requirements.
The following table lists the feature codes that allow you to specify the mode you wish to preset in the factory for CTO orders.
Feature code | Description |
---|---|
BFYB | Operating mode selection for: "Maximum Performance Mode" |
BFYE | Operating mode selection for: "Efficiency - Favoring Performance Mode" |
The preset modes for the SR250 V2 are as follows:
- Maximum Performance Mode (feature BFYB): Achieves maximum performance but with higher power consumption and lower energy efficiency.
- Efficiency Favoring Performance Mode (feature BFYE): Maximize the performance/watt efficiency with a bias towards performance. This is the favored mode for Energy Star certification, for example.
Memory options
The SR250 V2 supports Lenovo TruDDR4 memory. TruDDR4 memory uses the highest-quality components sourced from Tier 1 DRAM suppliers and only memory that meets strict requirements is selected. It is compatibility-tested and tuned to maximize performance and reliability.
TruDDR4 memory has a unique signature programmed into the DIMM, which enables ThinkSystem servers to verify whether the memory installed is qualified and supported. From a service and support standpoint, TruDDR4 memory automatically assumes the system's warranty, and service and support provided worldwide.
The processors have 2 memory channels and support 2 DIMMs per channel. The SR250 V2 supports 1, 2 or 4 DIMMs. 3 installed DIMMs is not supported. All DIMMs installed must be identical.
DIMMs installed in the SR250 V2 operate at a speed based on the processor installed, the number of DIMMs installed, and whether the DIMMs are single-rank or dual-rank:
- When connected to a Xeon processor:
- 1 or 2 DIMMs: 3200 MHz
- 4 single-rank (1R) DIMMs: 3200 MHz
- 4 dual-rank (2R) DIMMs: 2933 MHz
- When connected to a Pentium processor:
- 1 or 2 DIMMs (1 DPC): 2666 MHz
- 4 single-rank (1R) DIMMs: 2666 MHz
- 4 dual-rank (2R) DIMMs: 2400 MHz
The following table lists the memory options that are available for the SR250 V2 server.
Part number | Feature code | Description | Maximum supported |
---|---|---|---|
4X77A77494 | BMDV | ThinkSystem 8GB TruDDR4 3200 MHz (1Rx8, 1.2V) ECC UDIMM | 4 |
4X77A77495 | BMDW | ThinkSystem 16GB TruDDR4 3200 MHz (2Rx8, 1.2V) ECC UDIMM | 4 |
4X77A77496 | BMT4 | ThinkSystem 32GB TruDDR4 3200MHz (2Rx8, 1.2V) ECC UDIMM | 4 |
The following rules apply when selecting the memory configuration:
- The server only supports UDIMMs
- Quantities of 1, 2 or 4 DIMMs are supported. 3 DIMMs is not supported.
- All DIMMs must be identical (same part number)
- When installing two DIMMs, install one in each memory channel (DIMM slots 1 and 3)
- Memory mirroring and memory rank sparing are not supported
Internal storage
The SR250 V2 supports 2.5-inch hot-swap, 3.5-inch hot-swap, and 3.5-inch simple-swap drives in a variety of drive bay configurations.
In this section:
Drive bays and backplanes
The server supports 3.5-inch or 2.5-inch drive bays in the following configurations:
- 3.5-inch drive bays:
- 4x 3.5-inch hot-swap bays supporting 4x SATA drives (no SAS support)
- 4x 3.5-inch hot-swap bays supporting 4x SAS or SATA drives
- 4x 3.5-inch simple-swap bays supporting 4x SATA drives (no SAS support)
- 4x 3.5-inch simple-swap bays supporting 3x SATA drives and 1x NVMe drive (no SAS support)
- 2.5-inch drive bays
- 8x 2.5-inch hot-swap bays supporting 8x SATA drives (no SAS support)
- 8x 2.5-inch hot-swap bays supporting 8x SAS or SATA drives
- 10x 2.5-inch hot-swap bays supporting 10x SAS or SATA drives
Drive bays required: It is not supported to configure the SR250 V2 server without drive bays.
There are four different base drive configurations available for the SR250 V2, as shown in the following figure.
Figure 7. Storage configurations of the ThinkSystem SR250 V2
The following table lists the available hot-swap backplanes and simple-swap backplates for configure-to-order builds. See the Field upgrades section for option part numbers.
Feature code |
Description | Maximum supported |
Purpose |
---|---|---|---|
BMWR | ThinkSystem SR250 V2 3x3.5" Simple Swap SATA + 1x3.5" Simple Swap NVMe Backplane Kit | 1 | 3.5-inch 4-bay simple-swap backplane (3x SATA, 1x NVMe) connected to onboard SATA and NVMe |
BMWS | ThinkSystem SR250/SR150/SR250 V2 4x3.5" Simple Swap Backplane Kit v2 | 1 | 3.5-inch 4-bay simple-swap backplane (4x SATA) connected to onboard SATA |
BM7L | ThinkSystem SR250/SR150/SR250 V2 4x3.5" Simple Swap Backplane Kit for X40 RAID/HBA | 1 | 3.5-inch 4-bay simple-swap backplane (4x SATA) connected to X40 RAID/HBA |
BN11 | ThinkSystem SR250 V2 4x3.5" Simple Swap SATA Backplane Kit for X350/X40 RAID/HBA | 1 | 3.5-inch 4-bay simple-swap backplane (4x SATA) connected to X350 RAID/HBA |
BMPX | ThinkSystem SR250 V2 4x3.5" Hot Swap SAS/SATA Backplane Kit for X350/X40 RAID/HBA | 1 | 3.5-inch 4-bay hot-swap backplane |
BPRM | ThinkSystem SR250 V2 10x2.5" Hot Swap SAS/SATA Backplane Kit for X350/X40 RAID/HBA | 1 | 2.5-inch 10-bay hot-swap backplane |
BMPU | ThinkSystem SR250/SR250 V2 8x2.5" Hot Swap SAS/SATA Backplane Kit for X350/X40 RAID/HBA v2 | 1 | 2.5-inch 8-bay hot-swap backplane |
Storage configurations
The following table lists the supported combinations of drives, drive backplanes and storage controllers.
M.2 support: Config 6 does not support the use of the M.2 adapter, because the M.2 adapter uses 2 of the onboard SATA ports.
Cfg | Description | Base | Drive tray | Drive support | Backplane (feature) | Controller | Extra cables (derived feature or option kit) |
---|---|---|---|---|---|---|---|
1 | 4x 3.5" SS SATA to OB SATA | 3.5-inch | Simple-swap | SATA | 4x SATA SS to Onboard (BMWS) | Onboard SATA | None |
2-1 | 4x 3.5" SS SAS/SATA to HW RAID X350 | 3.5-inch | Simple-swap | SAS, SATA | 4x SAS SS to X350 RAID/HBA (BN11) | Onboard SATA | None |
2-2 | 4x 3.5" SS SAS/SATA to HW RAID X40 | 3.5-inch | Simple-swap | SAS, SATA | 4x SAS SS to X40 RAID (BM7L) | Onboard SATA | None |
3 | 4x 3.5" SS SATA+NVMe to OB SATA+NVMe | 3.5-inch | Simple-swap | SATA+NVMe | 3x SATA + 1x NVMe SS to OB (BMWR) | Onboard SATA+NVMe | None |
4 | 4x 3.5" HS to OB SATA | 3.5-inch | Hot-swap | SATA | 4x 3.5-inch SAS/SATA HS (BMPX) | Onboard SATA | Onboard SATA to BP (B405) |
5-1 | 4x 3.5" HS to HW RAID X350 | 3.5-inch | Hot-swap | SAS, SATA | 4x 3.5-inch SAS/SATA HS (BMPX) | RAID/HBA X350-8i | Gen3 RAID to BP (B415) |
5-2 | 4x 3.5" HS to HW RAID X40 | 3.5-inch | Hot-swap | SAS, SATA | 4x 3.5-inch SAS/SATA HS (BMPX) | RAID/HBA X40-8i | Gen4 RAID to BP (BM7M) |
6 | 8x 2.5" HS to OB SATA | 2.5-inch | Hot-swap | SATA | 8x 2.5-inch SAS/SATA HS (BMPU) | Onboard SATA | Onboard SATA multi to BP (BMX4) |
7-1 | 8x 2.5" HS to HW RAID X350 | 2.5-inch | Hot-swap | SAS, SATA | 8x 2.5-inch SAS/SATA HS (BMPU) | RAID/HBA X350-8i | 2x Gen3 RAID to BP (B415) |
7-2 | 8x 2.5" HS to HW RAID X40 | 2.5-inch | Hot-swap | SAS, SATA | 8x 2.5-inch SAS/SATA HS (BMPU) | RAID/HBA X40-8i | Gen4 RAID to BP dual (BMX3) |
8-1 | 10x 2.5" HS to HW RAID X350-16i | 2.5-inch | Hot-swap | SAS, SATA | 10x 2.5-inch SAS/SATA HS (BPRM) | RAID/HBA X350-16i | 3x Gen3 RAID to BP (B415) |
8-2 | 10x 2.5" HS to HW RAID X350-8i | 2.5-inch | Hot-swap | SAS, SATA | 10x 2.5-inch SAS/SATA HS (BPRM) | 2x RAID/HBA X350-8i | 3x Gen3 RAID to BP (B415) |
* For config 8-2, the use of 2x 9350-8i or 2x 940-8i is not supported as the server only supports 1x supercap
Field upgrades
The following table lists the supported field upgrades. The table refers to configurations which are described in the Storage configurations section.
Note: If upgrading to a configuration with a RAID adapter or HBA, you will need to order the adapter in addition to the backplanes and cables listed.
Starting configuration | Target configuration | Options needed (Backplanes and cables) | ||
---|---|---|---|---|
1 | 4x 3.5" SS SATA to OB SATA | 2-1 | 4x 3.5" SS SAS/SATA to HW RAID X350 |
|
1 | 4x 3.5" SS SATA to OB SATA | 2-2 | 4x 3.5" SS SAS/SATA to HW RAID X40 |
|
1 | 4x 3.5" SS SATA to OB SATA | 3 | 4x 3.5" SS SATA+NVMe to OB SATA+NVMe |
|
1 | 4x 3.5" SS SATA to OB SATA | 4 | 4x 3.5" HS to OB SATA |
|
1 | 4x 3.5" SS SATA to OB SATA | 5-1 | 4x 3.5" HS to HW RAID X350 |
|
1 | 4x 3.5" SS SATA to OB SATA | 5-2 | 4x 3.5" HS to HW RAID X40 |
|
2 | 4x 3.5" SS SAS/SATA to HW RAID X350 | 3 | 4x 3.5" SS SATA+NVMe to OB SATA+NVMe |
|
2 | 4x 3.5" SS SAS/SATA to HW RAID X350 | 4 | 4x 3.5" HS to OB SATA |
|
2 | 4x 3.5" SS SAS/SATA to HW RAID X350 | 5-1 | 4x 3.5" HS to HW RAID X350 |
|
2 | 4x 3.5" SS SAS/SATA to HW RAID X350 | 5-2 | 4x 3.5" HS to HW RAID X40 |
|
3 | 4x 3.5" SS SATA+NVMe to OB SATA+NVMe | 4 | 4x 3.5" HS to OB SATA |
|
3 | 4x 3.5" SS SATA+NVMe to OB SATA+NVMe | 5-1 | 4x 3.5" HS to HW RAID X350 |
|
3 | 4x 3.5" SS SATA+NVMe to OB SATA+NVMe | 5-2 | 4x 3.5" HS to HW RAID X40 |
|
4 | 4x 3.5" HS to OB SATA | 5-1 | 4x 3.5" HS to HW RAID X350 |
|
4 | 4x 3.5" HS to OB SATA | 5-2 | 4x 3.5" HS to HW RAID X40 |
|
6 | 8x 2.5" HS to OB SATA | 7-1 | 8x 2.5" HS to HW RAID X350 |
|
6 | 8x 2.5" HS to OB SATA | 7-2 | 8x 2.5" HS to HW RAID X40 |
|
6 | 8x 2.5" HS to OB SATA | 8 | 10x 2.5" HS to HW RAID X350-16i or 2x X350-8i |
|
7 | 8x 2.5" HS to HW RAID X350 | 8 | 10x 2.5" HS to HW RAID X350-16i or 2x X350-8i |
|
The following table lists the contents of the option part numbers for field upgrades.
Part number | Description |
---|---|
Backplane kits | |
4X97A81452 |
ThinkSystem SR250/SR150/SR250 V2 4x3.5" Simple Swap Backplane Kit v2
|
4M17A80601 |
ThinkSystem SR250/SR150/SR250 V2 4x3.5" Simple Swap Backplane Kit for X40 RAID/HBA
|
4X97A81453 |
ThinkSystem SR250 V2 3x3.5" Simple Swap SATA + 1x3.5" Simple Swap NVMe Backplane Kit
|
4C57A81454 |
ThinkSystem SR250 V2 3.5" SATA/SAS 4-Bay X30/X40 Backplane Kit
|
4C57A81456 |
ThinkSystem SR250 V2 2.5" SATA/SAS 10-Bay X30/X40 Backplane Kit
|
Cable kits | |
4X97A81455 |
ThinkSystem SR250 V2 X30/X40 RAID Cable Kit
|
RAID flash power module (supercap) support
Some high-performance RAID adapters include a RAID flash power module (supercap). The adapters that include a supercap are listed in the table in the Controllers for internal storage section.
The supercap is installed in the supercap holder than is located inside the server as shown in Components and connectors section.
The supercap holder is integrated into components of the chassis. No additional components are required.
M.2 drives
The SR250 V2 server supports two M.2 form-factor SATA drives installed in an M.2 adapter attached to a dummy PCIe adapter. The PCIe adapter is in turn installed in a PCIe slot. The M.2 adapter is connected via cables to the system board; the edge connector of the PCIe adapter only provides physical support and does not provide PCIe signals or power.
The following figure shows the M.2 adapter for the SR250 V2.
Figure 8. M.2 adapter with an M.2 drive
The following table lists the ordering information.
Supported drives are listed in the Internal drive options section.
Part number |
Feature code |
Description | Maximum supported |
Slots supported |
---|---|---|---|---|
4C57A85377 | B5XJ + BMTU |
ThinkSystem M.2 SATA/NVMe 2-Bay Enablement Adapter
|
1 | 2, 3 |
4X97A82303 | BMTD | ThinkSystem SR250/ST250 Series M.2 Signal & Power Cable Kit | 1 | Not applicable |
Configuration rules:
- The SR250 V2 does not support NVMe M.2 drives
- M.2 is not supported with the server is configured with 8x 2.5-inch SATA drives using the onboard SATA controller (config 6 in Storage configurations). This is because the M.2 adapter uses the same SATA ports.
The M.2 SATA/NVMe 2-Bay Enablement Kit has the following features when installed in the SR250 V2:
- Supports one or two M.2 SATA drives
- Support 42mm, 60mm, 80mm and 110mm drive form factors (2242, 2260, 2280 and 22110)
- JBOD native support; no built-in RAID support (RAID can be enabled via Intel VROC)
- Supports monitoring and reporting of events and temperature through I2C
- Firmware update via Lenovo firmware update tools
For details about M.2 components, see the ThinkSystem M.2 Drives and M.2 Adapters product guide:
https://lenovopress.com/lp0769-thinksystem-m2-drives-adapters
SED encryption key management with ISKLM
The server supports self-encrypting drives (SEDs) as listed in the Internal drive options section. To effectively manage a large deployment of these drives in Lenovo servers, IBM Security Key Lifecycle Manager (SKLM) offers a centralized key management solution. A Lenovo Feature on Demand (FoD) upgrade is used to enable this SKLM support in the management processor of the server.
The following table lists the part numbers and feature codes for the upgrades.
Part number | Feature code | Description |
---|---|---|
Security Key Lifecycle Manager - FoD (United States, Canada, Asia Pacific, and Japan) | ||
00D9998 | A5U1 | SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 1 year S&S |
00D9999 | AS6C | SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 3 year S&S |
Security Key Lifecycle Manager - FoD (Latin America, Europe, Middle East, and Africa) | ||
00FP648 | A5U1 | SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 1 year S&S |
00FP649 | AS6C | SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 3 year S&S |
The IBM Security Key Lifecycle Manager software is available from Lenovo using the ordering information listed in the following table.
Part number | Description |
---|---|
7S0A007FWW | IBM Security Key Lifecycle Manager Basic Edition Install License + SW Subscription & Support 12 Months |
7S0A007HWW | IBM Security Key Lifecycle Manager For Raw Decimal Terabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months |
7S0A007KWW | IBM Security Key Lifecycle Manager For Raw Decimal Petabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months |
7S0A007MWW | IBM Security Key Lifecycle Manager For Usable Decimal Terabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months |
7S0A007PWW | IBM Security Key Lifecycle Manager For Usable Decimal Petabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months |
Controllers for internal storage
The SR250 V2 supports the use of the onboard 6Gb SATA ports to connect SATA drives. Hot-swap and simple-swap SATA drives are supported. These onboard SATA ports support RSTe mode for RAID functionality or AHCI mode for JBOD support.
In addition to the onboard SATA controller, the SR250 V2 with hot-swap drives supports the use of an internal RAID adapter or HBA. The following table lists the supported adapters.
Part number |
Feature code |
Description | Slots supported |
Maximum quantity |
Supercap included |
---|---|---|---|---|---|
12 Gb SAS/SATA RAID controllers | |||||
4Y37A72482 | BJHK | ThinkSystem RAID 5350-8i PCIe 12Gb Adapter | 2, 3 | 2 | No |
4Y37A72483 | BJHL | ThinkSystem RAID 9350-8i 2GB Flash PCIe 12Gb Adapter | 2, 3 | 1 | Yes |
4Y37A72485 | BJHN | ThinkSystem RAID 9350-16i 4GB Flash PCIe 12Gb Adapter | 2, 3 | 1 | Yes |
12 Gb SAS/SATA HBAs (non-RAID) | |||||
4Y37A72480 | BJHH | ThinkSystem 4350-8i SAS/SATA 12Gb HBA | 2, 3 | 2 | No |
For a comparison of the functions of the supported storage adapters, see the ThinkSystem RAID Adapter and HBA Reference:
https://lenovopress.com/lp1288-thinksystem-raid-adapter-and-hba-reference#sr250-v2-support=SR250%20V2
Configuration notes:
- Virtualization support: The onboard SATA ports can be used with virtualization hypervisors, including VMware ESXi, Linux KVM, Xen, and Microsoft Hyper-V, however support is limited to AHCI (non-RAID) mode. RSTe mode is not supported with virtualization hypervisors.
- Windows support: Windows only supports a RSTe-based RAID array of no more than 6 drives.
- E810 Ethernet and X350 RAID/HBAs: The use of both an Intel E810 network adapter and an X350 HBA/RAID adapter (9350, 5350 and 4350) is currently not supported in ThinkSystem servers. For details see Support Tip HT513226. Planned support for this combination of adapters is 4Q/2023 (SI 23-2).
Internal drive options
The following tables list the drive options for internal storage of the server.
2.5-inch hot-swap drives:
3.5-inch hot-swap drives:
Simple-swap drives:
M.2 drives:
M.2 drive support: The use of M.2 drives requires an additional adapter as described in the M.2 drives subsection.
SED support: The tables include a column to indicate which drives support SED encryption. The encryption functionality can be disabled if needed. Note: Not all SED-enabled drives have "SED" in the description.
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
2.5-inch hot-swap HDDs - 12 Gb SAS 10K | ||||
7XB7A00025 | AULZ | ThinkSystem 2.5" 600GB 10K SAS 12Gb Hot Swap 512n HDD | No | 10 |
7XB7A00027 | AUM1 | ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD | No | 10 |
7XB7A00028 | AUM2 | ThinkSystem 2.5" 1.8TB 10K SAS 12Gb Hot Swap 512e HDD | No | 10 |
4XB7A83970 | BRG7 | ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD v2 | No | 10 |
2.5-inch hot-swap SED HDDs - 12 Gb SAS 10K | ||||
7XB7A00031 | AUM5 | ThinkSystem 2.5" 600GB 10K SAS 12Gb Hot Swap 512n HDD SED | Support | 10 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
2.5-inch hot-swap SSDs - 6 Gb SATA - Mixed Use/Mainstream (3-5 DWPD) | ||||
4XB7A90884 | BYM2 | ThinkSystem 2.5" Multi Vendor 480GB Mixed Use SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90885 | BYM4 | ThinkSystem 2.5" Multi Vendor 960GB Mixed Use SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90886 | BYM5 | ThinkSystem 2.5" Multi Vendor 1.92TB Mixed Use SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90887 | BYM6 | ThinkSystem 2.5" Multi Vendor 3.84TB Mixed Use SATA 6Gb HS SSD v2 | No | 10 |
4XB7A82289 | BQ21 | ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD | Support | 10 |
4XB7A82290 | BQ24 | ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD | Support | 10 |
4XB7A82291 | BQ22 | ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD | Support | 10 |
4XB7A82292 | BQ23 | ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD | Support | 10 |
4XB7A17125 | BA7Q | ThinkSystem 2.5" S4620 480GB Mixed Use SATA 6Gb HS SSD | No | 10 |
4XB7A17126 | BA4T | ThinkSystem 2.5" S4620 960GB Mixed Use SATA 6Gb HS SSD | No | 10 |
4XB7A17087 | B8J1 | ThinkSystem 2.5" 5300 240GB Mainstream SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A17088 | B8HY | ThinkSystem 2.5" 5300 480GB Mainstream SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A17089 | B8J6 | ThinkSystem 2.5" 5300 960GB Mainstream SATA 6Gb Hot Swap SSD | No | 10 |
2.5-inch hot-swap SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD) | ||||
4XB7A90872 | BYLQ | ThinkSystem 2.5" Multi Vendor 240GB Read Intensive SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90873 | BYLR | ThinkSystem 2.5" Multi Vendor 480GB Read Intensive SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90874 | BYLS | ThinkSystem 2.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90875 | BYLT | ThinkSystem 2.5" Multi Vendor 1.92TB Read Intensive SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90876 | BYLU | ThinkSystem 2.5" Multi Vendor 3.84TB Read Intensive SATA 6Gb HS SSD v2 | No | 10 |
4XB7A90877 | BYLV | ThinkSystem 2.5" Multi Vendor 7.68TB Read Intensive SATA 6Gb HS SSD v2 | No | 10 |
4XB7A89423 | BXDY | ThinkSystem 2.5" CM893a 1.92TB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A82258 | BQ1Q | ThinkSystem 2.5" 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A82259 | BQ1P | ThinkSystem 2.5" 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A82260 | BQ1R | ThinkSystem 2.5" 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A82261 | BQ1X | ThinkSystem 2.5" 5400 PRO 1.92TB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A82262 | BQ1S | ThinkSystem 2.5" 5400 PRO 3.84TB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A82263 | BQ1T | ThinkSystem 2.5" 5400 PRO 7.68TB Read Intensive SATA 6Gb HS SSD | Support | 10 |
4XB7A17072 | B99D | ThinkSystem 2.5" S4520 240GB Read Intensive SATA 6Gb HS SSD | No | 10 |
4XB7A17101 | BA7G | ThinkSystem 2.5" S4520 480GB Read Intensive SATA 6Gb HS SSD | No | 10 |
4XB7A17102 | BA7H | ThinkSystem 2.5" S4520 960GB Read Intensive SATA 6Gb HS SSD | No | 10 |
4XB7A38271 | BCTC | ThinkSystem 2.5" Multi Vendor 240GB Entry SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A38272 | BCTD | ThinkSystem 2.5" Multi Vendor 480GB Entry SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A38273 | BCTE | ThinkSystem 2.5" Multi Vendor 960GB Entry SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A17075 | B8HV | ThinkSystem 2.5" 5300 240GB Entry SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A17076 | B8JM | ThinkSystem 2.5" 5300 480GB Entry SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A17077 | B8HP | ThinkSystem 2.5" 5300 960GB Entry SATA 6Gb Hot Swap SSD | No | 10 |
4XB7A38185 | B9AC | ThinkSystem 2.5" 5210 960GB Entry SATA 6Gb Hot Swap QLC SSD | No | 10 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
3.5-inch hot-swap HDDs - 12 Gb NL SAS | ||||
7XB7A00042 | AUU5 | ThinkSystem 3.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD | No | 4 |
7XB7A00043 | AUU6 | ThinkSystem 3.5" 4TB 7.2K SAS 12Gb Hot Swap 512n HDD | No | 4 |
7XB7A00044 | AUU7 | ThinkSystem 3.5" 6TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
7XB7A00045 | B0YR | ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
7XB7A00046 | AUUG | ThinkSystem 3.5" 10TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
7XB7A00067 | B117 | ThinkSystem 3.5" 12TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
4XB7A13906 | B496 | ThinkSystem 3.5" 14TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
4XB7A13911 | B7EZ | ThinkSystem 3.5" 16TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
4XB7A38266 | BCFP | ThinkSystem 3.5" 18TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
4XB7A80353 | BPKU | ThinkSystem 3.5" 20TB 7.2K SAS 12Gb Hot Swap 512e HDD | No | 4 |
4XB7A83766 | BTR7 | ThinkSystem 3.5" 22TB 7.2K SAS 12Gb Hot Swap 512e HDD | Support | 4 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
3.5-inch hot-swap HDDs - 6 Gb NL SATA | ||||
7XB7A00049 | AUUF | ThinkSystem 3.5" 1TB 7.2K SATA 6Gb Hot Swap 512n HDD | No | 4 |
7XB7A00050 | AUUD | ThinkSystem 3.5" 2TB 7.2K SATA 6Gb Hot Swap 512n HDD | No | 4 |
7XB7A00051 | AUU8 | ThinkSystem 3.5" 4TB 7.2K SATA 6Gb Hot Swap 512n HDD | No | 4 |
7XB7A00052 | AUUA | ThinkSystem 3.5" 6TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
7XB7A00053 | AUU9 | ThinkSystem 3.5" 8TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
7XB7A00054 | AUUB | ThinkSystem 3.5" 10TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
7XB7A00068 | B118 | ThinkSystem 3.5" 12TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
4XB7A13907 | B497 | ThinkSystem 3.5" 14TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
4XB7A13914 | B7F0 | ThinkSystem 3.5" 16TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
4XB7A38130 | BCFH | ThinkSystem 3.5" 18TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
4XB7A80354 | BPKV | ThinkSystem 3.5" 20TB 7.2K SATA 6Gb Hot Swap 512e HDD | No | 4 |
4XB7A83765 | BTR8 | ThinkSystem 3.5" 22TB 7.2K SATA 6Gb Hot Swap 512e HDD | Support | 4 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
3.5-inch hot-swap SSDs - 6 Gb SATA - Mixed Use/Mainstream (3-5 DWPD) | ||||
4XB7A90888 | BYM3 | ThinkSystem 3.5" Multi Vendor 480GB Mixed Use SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90889 | BYM7 | ThinkSystem 3.5" Multi Vendor 960GB Mixed Use SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90890 | BYM8 | ThinkSystem 3.5" Multi Vendor 1.92TB Mixed Use SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90891 | BYLX | ThinkSystem 3.5" Multi Vendor 3.84TB Mixed Use SATA 6Gb HS SSD v2 | No | 4 |
4XB7A87202 | BURK | ThinkSystem 3.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD | Support | 4 |
4XB7A17137 | BA4W | ThinkSystem 3.5" S4620 480GB Mixed Use SATA 6Gb HS SSD | No | 4 |
4XB7A17138 | BA4X | ThinkSystem 3.5" S4620 960GB Mixed Use SATA 6Gb HS SSD | No | 4 |
3.5-inch hot-swap SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD) | ||||
4XB7A90878 | BYLW | ThinkSystem 3.5" Multi Vendor 240GB Read Intensive SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90879 | BYLJ | ThinkSystem 3.5" Multi Vendor 480GB Read Intensive SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90880 | BYLY | ThinkSystem 3.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90881 | BYLZ | ThinkSystem 3.5" Multi Vendor 1.92TB Read Intensive SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90882 | BYM0 | ThinkSystem 3.5" Multi Vendor 3.84TB Read Intensive SATA 6Gb HS SSD v2 | No | 4 |
4XB7A90883 | BYM1 | ThinkSystem 3.5" Multi Vendor 7.68TB Read Intensive SATA 6Gb HS SSD v2 | No | 4 |
4XB7A17118 | BA7K | ThinkSystem 3.5" S4520 240GB Read Intensive SATA 6Gb HS SSD | No | 4 |
4XB7A17119 | BA7L | ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb HS SSD | No | 4 |
4XB7A17120 | BA7M | ThinkSystem 3.5" S4520 960GB Read Intensive SATA 6Gb HS SSD | No | 4 |
4XB7A38276 | BCTH | ThinkSystem 3.5" Multi Vendor 240GB Entry SATA 6Gb Hot Swap SSD | No | 4 |
4XB7A38277 | BCTJ | ThinkSystem 3.5" Multi Vendor 480GB Entry SATA 6Gb Hot Swap SSD | No | 4 |
4XB7A38278 | BCTK | ThinkSystem 3.5" Multi Vendor 960GB Entry SATA 6Gb Hot Swap SSD | No | 4 |
4XB7A17081 | B8JB | ThinkSystem 3.5" 5300 240GB Entry SATA 6Gb Hot Swap SSD | No | 4 |
4XB7A17082 | B8J9 | ThinkSystem 3.5" 5300 480GB Entry SATA 6Gb Hot Swap SSD | No | 4 |
4XB7A17083 | B8JC | ThinkSystem 3.5" 5300 960GB Entry SATA 6Gb Hot Swap SSD | No | 4 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
3.5-inch simple-swap HDDs - 6 Gb NL SATA | ||||
7XB7A00055 | AUZS | ThinkSystem 1TB 7.2K 6Gbps SATA 3.5" Simple Swap 512n HDD | No | 4 |
7XB7A00056 | AUZT | ThinkSystem 2TB 7.2K 6Gbps SATA 3.5" Simple Swap 512n HDD | No | 4 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
3.5-inch simple-swap SSDs - 6 Gb SATA - Mixed Use/Mainstream (3-5 DWPD) | ||||
4XB7A17134 | BK7M | ThinkSystem 3.5" S4620 480GB Mixed Use SATA 6Gb SS SSD | No | 4 |
4XB7A17135 | BK7N | ThinkSystem 3.5" S4620 960GB Mixed Use SATA 6Gb SS SSD | No | 4 |
3.5-inch simple-swap SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD) | ||||
4XB7A17109 | BK7C | ThinkSystem 3.5" S4520 240GB Read Intensive SATA 6Gb SS SSD | No | 4 |
4XB7A17110 | BK7D | ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb SS SSD | No | 4 |
4XB7A17111 | BK7E | ThinkSystem 3.5" S4520 960GB Read Intensive SATA 6Gb SS SSD | No | 4 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
3.5-inch SSDs - U.2 PCIe 4.0 NVMe - Read Intensive/Entry (<3 DWPD) | ||||
4XB7A79664 | BNHZ | ThinkSystem 3.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 SS SSD | Support | 1 |
4XB7A82993 | BQ1G | ThinkSystem 3.5" U.2 P5500 1.92TB Read Intensive NVMe PCIe 4.0 x4 SS SSD | No | 1 |
Part number | Feature code |
Description | SED support |
Max Qty |
---|---|---|---|---|
M.2 SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD) | ||||
4XB7A89422 | BYF7 | ThinkSystem M.2 ER3 240GB Read Intensive SATA 6Gb NHS SSD | Support | 2 |
4XB7A90049 | BYF8 | ThinkSystem M.2 ER3 480GB Read Intensive SATA 6Gb NHS SSD | Support | 2 |
4XB7A90230 | BYF9 | ThinkSystem M.2 ER3 960GB Read Intensive SATA 6Gb NHS SSD | Support | 2 |
4XB7A90105 | BXMK | ThinkSystem M.2 ER2 240GB Read Intensive SATA 6Gb NHS SSD (China only) | Support | 2 |
4XB7A90106 | BXMJ | ThinkSystem M.2 ER2 480GB Read Intensive SATA 6Gb NHS SSD (China only) | Support | 2 |
4XB7A82286 | BQ1Z | ThinkSystem M.2 5400 PRO 240GB Read Intensive SATA 6Gb NHS SSD | Support | 2 |
4XB7A82287 | BQ1Y | ThinkSystem M.2 5400 PRO 480GB Read Intensive SATA 6Gb NHS SSD | Support | 2 |
4XB7A82288 | BQ20 | ThinkSystem M.2 5400 PRO 960GB Read Intensive SATA 6Gb NHS SSD | Support | 2 |
7N47A00130 | AUUV | ThinkSystem M.2 128GB SATA 6Gbps Non-Hot Swap SSD | No | 2 |
4XB7A17071 | B8HS | ThinkSystem M.2 5300 240GB SATA 6Gbps Non-Hot Swap SSD | No | 2 |
4XB7A17073 | B919 | ThinkSystem M.2 5300 480GB SATA 6Gbps Non-Hot Swap SSD | No | 2 |
4XB7A17074 | B8JJ | ThinkSystem M.2 5300 960GB SATA 6Gbps Non-Hot Swap SSD | No | 2 |
Optical drives
The server supports the external USB optical drive listed in the following table.
Part number | Feature code | Description |
---|---|---|
7XA7A05926 | AVV8 | ThinkSystem External USB DVD RW Optical Disk Drive |
The drive is based on the Lenovo Slim DVD Burner DB65 drive and supports the following formats: DVD-RAM, DVD-RW, DVD+RW, DVD+R, DVD-R, DVD-ROM, DVD-R DL, CD-RW, CD-R, CD-ROM.
I/O expansion
The SR250 V2 server supports up to three PCIe slots: one slot on the system planar that supports an internal storage controller and up to two PCIe slots on a riser card.
Slot numbering is as follows:
- Using a riser with two x8 slots (feature BMWQ):
- Slot 1: PCIe G4 x8 (x8 slot, open-ended) 25W full-height half-length
- Slot 2: PCIe G4 x8 (x16 slot, closed-ended) 25W full-height half-length
- Slot 3 (internal slot): PCIe G3 x4 (x8 slot, closed-ended) 25W full-height half-length
- Using a riser with one x16 slot (feature BMWU):
- Slot 1: Not connected
- Slot 2: PCIe G4 x16 (x16 slot, closed-ended) 75W full-height half-length
- Slot 3 (internal slot): PCIe G3 x4 (x8 slot, closed-ended) 25W full-height half-length
PCIe 4.0 support: Slots 1 and 2 are PCIe Gen 4 with a Xeon processor, and PCIe Gen 3 with a Pentium processor
The locations of the PCIe slots are shown in the following figure.
The following table lists available PCIe riser card options.
Part number | Feature code | Description |
---|---|---|
4C57A81451 | BMWQ | ThinkSystem SR250 V2 x8/x8 PCIe Gen4 Riser |
4C57A81450 | BMWU | ThinkSystem SR250 V2 x16 PCIe Gen4 Riser |
Network adapters
The SR250 V2 server supports two onboard Gigabit Ethernet network ports that are based on the Broadcom BCM5720 network interface controller (NIC) chip.
The BCM5720 embedded controller has the following features:
- Two 10/100/1000 Mb Ethernet RJ-45 ports
- NIC Teaming (load balancing and failover)
- IEEE 802.3ad Link Aggregation
- I/O Virtualization (IOV) for VMWare NetQueue and Microsoft VMQ
- IEEE 802.1Q Virtual Local Area Networks (VLANs)
- IEEE 802.3x flow control
- TCP, IP, and UDP checksum offload
- Large Send Offload (LSO) and TCP Segmentation Offload (TSO)
- Receive Side Scaling (RSS) and Transmit Side Scaling (TSS)
- Jumbo frames up to 9600 bytes
- IEEE 802.3az-2010 Energy Efficient Ethernet (EEE) compliant
- Hardware assist for IEEE 1588 and IEEE 802.1AS time synchronization implementations
- Preboot eXecution Environment (PXE) remote boot
- Wake on LAN (WOL) support
The following table lists the network adapters that are supported with the SR250 V2 server.
Part number | Feature code | Description | Maximum quantity |
Slots supported |
---|---|---|---|---|
Gigabit Ethernet | ||||
7ZT7A00484 | AUZV | ThinkSystem Broadcom 5719 1GbE RJ45 4-Port PCIe Ethernet Adapter | 1 | 2 |
7ZT7A00482 | AUZX | ThinkSystem Broadcom 5720 1GbE RJ45 2-Port PCIe Ethernet Adapter | 2 | 1, 2 |
7ZT7A00534 | AUZY | ThinkSystem I350-T2 PCIe 1Gb 2-Port RJ45 Ethernet Adapter | 2 | 1, 2 |
7ZT7A00535 | AUZW | ThinkSystem I350-T4 PCIe 1Gb 4-Port RJ45 Ethernet Adapter | 1 | 2 |
10 GbE 10GBASE-T Ethernet | ||||
7ZT7A00496 | AUKP | ThinkSystem Broadcom 57416 10GBASE-T 2-Port PCIe Ethernet Adapter | 2 | 1, 2 |
00MM860 | ATPX | Intel X550-T2 Dual Port 10GBase-T Adapter | 2 | 1, 2 |
4XC7A79699 | BMXB | ThinkSystem Intel X710-T4L 10GBase-T 4-Port PCIe Ethernet Adapter | 1 | 2 |
10 GbE SFP+ | ||||
7XC7A05525 | B0YL | Intel X710-DA4 4x10Gb SFP+ Adapter | 1 | 2 |
25 Gb Ethernet | ||||
4XC7A08238 | BK1H | ThinkSystem Broadcom 57414 10/25GbE SFP28 2-port PCIe Ethernet Adapter | 2 | 1, 2 |
4XC7A08295 | BCD6 | ThinkSystem Intel E810-DA2 10/25GbE SFP28 2-Port PCIe Ethernet Adapter | 2 | 1, 2 |
Configuration notes:
- For more information, including the transceivers and cables that each adapter supports, see the list of Lenovo Press Product Guides in the Ethernet adapters category:
http://lenovopress.com/servers/options/ethernet#rt=product-guide
- E810 Ethernet and X350 RAID/HBAs: The use of both an Intel E810 network adapter and an X350 HBA/RAID adapter (9350, 5350 and 4350) is currently not supported in ThinkSystem servers. For details see Support Tip HT513226. Planned support for this combination of adapters is 4Q/2023 (SI 23-2).
SAS adapters for external storage
The following table lists the adapters suitable for connectivity to external SAS storage.
Part number |
Feature code |
Description | Slots supported |
Maximum quantity |
---|---|---|---|---|
7Y37A01090 | AUNR | ThinkSystem 430-8e SAS/SATA 12Gb HBA | 1, 2 | 1 |
4Y37A78837 | BNWK | ThinkSystem 440-8e SAS/SATA PCIe Gen4 12Gb HBA | 1, 2 | 2 |
For a comparison of the functions of the supported external storage adapters, see the ThinkSystem RAID Adapter and HBA Reference:
https://lenovopress.com/lp1288#sr250-v2-support=SR250%20V2&internal-or-external-ports=External
Mixing storage adapter families: The following HBA/RAID adapter combinations are supported:
- X30 external adapters with other X30 adapters (internal or external)
- X40 external adapters with other X40 adapters (internal or external)
- X40 external adapters with X350 internal adapters
The following HBA/RAID adapter combinations are not supported:
- X30 adapters (internal or external) with X40 adapters (internal or external)
- X30 adapters (internal or external) with X350 internal adapters
Fibre Channel host bus adapters
The SR250 V2 does not currently support Fibre Channel host bus adapters.
Flash Storage adapters
The SR250 V2 does not currently support Flash Storage adapters.
GPU adapters
The SR250 V2 server supports the graphics processing units (GPUs) listed in the following table.
Part number |
Feature code |
Description | Slots supported |
Maximum quantity |
---|---|---|---|---|
4X67A79777 | BMXD | ThinkSystem NVIDIA T1000 8GB PCIe Active GPU | 2 | 1 |
4X67A79778 | BMXE | ThinkSystem NVIDIA T400 4GB PCIe Active GPU | 2 | 1 |
The following rules applies:
- The use of a GPU requires 450W hot-swap power supplies
- A GPU is supported in slot 2, supplied by either the x8/x8 or x16 riser card. Note, however, performance will be degraded when the GPU is installed in a x8 slot.
For information about GPUs, see the ThinkSystem GPU Summary:
https://lenovopress.com/lp0768-thinksystem-gpu-summary
Cooling
The SR250 V2 server has four non-hot-swap variable-speed system fans. The fans have a single rotor and are not redundant.
Configurator tip: In the DCSC configurator, 3.5-inch drive configurations will show a single SR250 Fan Module (feature B40F) in the list of unselectable features, whereas the 2.5-inch drive configurations do not show this feature. Regardless, all configurations include four fans.
Note: The server performance might be impacted in case of a system fan failure.
Power supplies
The SR250 V2 server supports one fixed power supply or up to two redundant hot-swap power supplies. With two power supplies, the server is capable of N+N redundancy depending on the configuration. A second power supply can be added to the models that come with one hot-swap power supply.
Part number |
Feature code |
Description | Maximum quantity |
80 PLUS certification |
ErP Lot 9 compliant |
110V AC | 220V AC | 240V DC China only |
---|---|---|---|---|---|---|---|---|
CTO only | B40Q | ThinkSystem SR250/SR150 Fixed 300W PSU | 1 | Gold | No | Yes | Yes | No |
4P57A12649 | B40R | ThinkSystem 450W(230V/115V) Platinum Hot-Swap Power Supply | 2 | Platinum | No | Yes | Yes | No |
4P57A78356 | BMXC | ThinkSystem 450W 230V Titanium Hot-Swap Power Supply | 2 | Titanium | Yes | No | Yes | No |
Power supply options do not include a line cord.
For server configurations, the inclusion of a power supply is model dependent. Configure-to-order models can be configured without a power cord if desired.
The following table lists the maximum configuration for the 300W power supply.
Subsystem | 300W fixed power supply |
---|---|
Processor | Up to 80W TDP (6 cores) |
Memory | No restriction |
Drives |
|
M.2 | No restriction |
Adapters (except GPU) | 1 or 2 adapters up to PCIe x8 |
GPU | Not supported |
To ensures that the properly sized power supply is chosen for optimal performance, it is highly recommended to validate system configuration for specific power requirements by using the latest version of the Lenovo Capacity Planner:
https://datacentersupport.lenovo.com/us/en/products/solutions-and-software/software/lenovo-capacity-planner/solutions/ht504651
Power cords
Line cords and rack power cables with C13 connectors can be ordered as listed in the following table.
Part number | Feature code | Description |
---|---|---|
Rack cables - C13 to C14 | ||
SL67B08593 | BPHZ | 0.5m, 10A/100-250V, C13 to C14 Jumper Cord |
00Y3043 | A4VP | 1.0m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable |
4L67A08367 | B0N5 | 1.0m, 13A/100-250V, C13 to C14 Jumper Cord |
39Y7937 | 6201 | 1.5m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable |
4L67A08368 | B0N6 | 1.5m, 13A/100-250V, C13 to C14 Jumper Cord |
4L67A08365 | B0N4 | 2.0m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable |
4L67A08369 | 6570 | 2.0m, 13A/100-250V, C13 to C14 Jumper Cord |
4L67A08366 | 6311 | 2.8m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable |
4L67A08370 | 6400 | 2.8m, 13A/100-250V, C13 to C14 Jumper Cord |
39Y7932 | 6263 | 4.3m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable |
4L67A08371 | 6583 | 4.3m, 13A/100-250V, C13 to C14 Rack Power Cable |
Rack cables - C13 to C14 (Y-cable) | ||
00Y3046 | A4VQ | 1.345m, 2X C13 to C14 Jumper Cord, Rack Power Cable |
00Y3047 | A4VR | 2.054m, 2X C13 to C14 Jumper Cord, Rack Power Cable |
Rack cables - C13 to C20 | ||
39Y7938 | 6204 | 2.8m, 10A/100-250V, C13 to IEC 320-C20 Rack Power Cable |
Rack cables - C13 to C20 (Y-cable) | ||
47C2491 | A3SW | 1.2m, 16A/100-250V, 2 Short C13s to Short C20 Rack Power Cable |
47C2492 | A3SX | 2.5m, 16A/100-250V, 2 Long C13s to Short C20 Rack Power Cable |
47C2493 | A3SY | 2.8m, 16A/100-250V, 2 Short C13s to Long C20 Rack Power Cable |
47C2494 | A3SZ | 4.1m, 16A/100-250V, 2 Long C13s to Long C20 Rack Power Cable |
Line cords | ||
39Y7930 | 6222 | 2.8m, 10A/250V, C13 to IRAM 2073 (Argentina) Line Cord |
81Y2384 | 6492 | 4.3m 10A/220V, C13 to IRAM 2073 (Argentina) Line Cord |
39Y7924 | 6211 | 2.8m, 10A/250V, C13 to AS/NZ 3112 (Australia/NZ) Line Cord |
81Y2383 | 6574 | 4.3m, 10A/230V, C13 to AS/NZS 3112 (Aus/NZ) Line Cord |
69Y1988 | 6532 | 2.8m, 10A/250V, C13 to NBR 14136 (Brazil) Line Cord |
81Y2387 | 6404 | 4.3m, 10A/250V, C13 - 2P+Gnd (Brazil) Line Cord |
39Y7928 | 6210 | 2.8m, 220-240V, C13 to GB 2099.1 (China) Line Cord |
81Y2378 | 6580 | 4.3m, 10A/220V, C13 to GB 2099.1 (China) Line Cord |
39Y7918 | 6213 | 2.8m, 10A/250V, C13 to DK2-5a (Denmark) Line Cord |
81Y2382 | 6575 | 4.3m, 10A/230V, C13 to DK2-5a (Denmark) Line Cord |
39Y7917 | 6212 | 2.8m, 10A/230V, C13 to CEE7-VII (Europe) Line Cord |
81Y2376 | 6572 | 4.3m, 10A/230V, C13 to CEE7-VII (Europe) Line Cord |
39Y7927 | 6269 | 2.8m, 10A/250V, C13(2P+Gnd) (India) Line Cord |
81Y2386 | 6567 | 4.3m, 10A/240V, C13 to IS 6538 (India) Line Cord |
39Y7920 | 6218 | 2.8m, 10A/250V, C13 to SI 32 (Israel) Line Cord |
81Y2381 | 6579 | 4.3m, 10A/230V, C13 to SI 32 (Israel) Line Cord |
39Y7921 | 6217 | 2.8m, 220-240V, C13 to CEI 23-16 (Italy/Chile) Line Cord |
81Y2380 | 6493 | 4.3m, 10A/230V, C13 to CEI 23-16 (Italy/Chile) Line Cord |
46M2593 | A1RE | 2.8m, 12A/125V, C13 to JIS C-8303 (Japan) Line Cord |
4L67A08362 | 6495 | 4.3m, 12A/200V, C13 to JIS C-8303 (Japan) Line Cord |
39Y7926 | 6335 | 4.3m, 12A/100V, C13 to JIS C-8303 (Japan) Line Cord |
39Y7922 | 6214 | 2.8m, 10A/250V, C13 to SABS 164 (S Africa) Line Cord |
81Y2379 | 6576 | 4.3m, 10A/230V, C13 to SABS 164 (South Africa) Line Cord |
39Y7925 | 6219 | 2.8m, 220-240V, C13 to KETI (S Korea) Line Cord |
81Y2385 | 6494 | 4.3m, 12A/220V, C13 to KSC 8305 (S. Korea) Line Cord |
39Y7919 | 6216 | 2.8m, 10A/250V, C13 to SEV 1011-S24507 (Swiss) Line Cord |
81Y2390 | 6578 | 4.3m, 10A/230V, C13 to SEV 1011-S24507 (Sws) Line Cord |
23R7158 | 6386 | 2.8m, 10A/125V, C13 to CNS 10917-3 (Taiwan) Line Cord |
81Y2375 | 6317 | 2.8m, 10A/240V, C13 to CNS 10917-3 (Taiwan) Line Cord |
81Y2374 | 6402 | 2.8m, 13A/125V, C13 to CNS 60799 (Taiwan) Line Cord |
4L67A08363 | AX8B | 4.3m, 10A 125V, C13 to CNS 10917 (Taiwan) Line Cord |
81Y2389 | 6531 | 4.3m, 10A/250V, C13 to 76 CNS 10917-3 (Taiwan) Line Cord |
81Y2388 | 6530 | 4.3m, 13A/125V, C13 to CNS 10917 (Taiwan) Line Cord |
39Y7923 | 6215 | 2.8m, 10A/250V, C13 to BS 1363/A (UK) Line Cord |
81Y2377 | 6577 | 4.3m, 10A/230V, C13 to BS 1363/A (UK) Line Cord |
90Y3016 | 6313 | 2.8m, 10A/120V, C13 to NEMA 5-15P (US) Line Cord |
46M2592 | A1RF | 2.8m, 10A/250V, C13 to NEMA 6-15P Line Cord |
00WH545 | 6401 | 2.8m, 13A/120V, C13 to NEMA 5-15P (US) Line Cord |
4L67A08359 | 6370 | 4.3m, 10A/125V, C13 to NEMA 5-15P (US) Line Cord |
4L67A08361 | 6373 | 4.3m, 10A/250V, C13 to NEMA 6-15P (US) Line Cord |
4L67A08360 | AX8A | 4.3m, 13A/120V, C13 to NEMA 5-15P (US) Line Cord |
Systems management
The SR250 V2 contains an integrated service processor, XClarity Controller (XCC), which provides advanced service-processor control, monitoring, and alerting functions. The XCC is based on the Pilot4 XE401 baseboard management controller (BMC) using a dual-core ARM Cortex A9 service processor.
System status with XClarity Mobile
The XClarity Mobile app includes a tethering function where you can connect your Android or iOS device to the server via USB to see the status of the server.
The steps to connect the mobile device are as follows:
- Enable USB Management on the server, by holding down the ID button for 3 seconds (or pressing the dedicated USB management button if one is present)
- Connect the mobile device via a USB cable to the server's USB port with the management symbol
- In iOS or Android settings, enable Personal Hotspot or USB Tethering
- Launch the Lenovo XClarity Mobile app
Once connected you can see the following information:
- Server status including error logs (read only, no login required)
- Server management functions (XClarity login credentials required)
Remote management
The server offers a dedicated RJ45 port at the rear of the server for remote management via the XClarity Controller management processor. The port supports 10/100/1000 Mbps speeds.
Remote server management is provided through industry-standard interfaces:
- Intelligent Platform Management Interface (IPMI) Version 2.0
- Simple Network Management Protocol (SNMP) Version 3 (no SET commands; no SNMP v1)
- Common Information Model (CIM-XML)
- Representational State Transfer (REST) support
- Redfish support (DMTF compliant)
- Web browser - HTML 5-based browser interface (Java and ActiveX not required) using a responsive design (content optimized for device being used - laptop, tablet, phone) with NLS support
IPMI via the Ethernet port (IPMI over LAN) is supported, however it is disabled by default. For CTO orders you can specify whether you want to the feature enabled or disabled in the factory, using the feature codes listed in the following table.
Part number | Feature code | Description |
---|---|---|
CTO only | B7XZ | Disable IPMI-over-LAN (default) |
CTO only | B7Y0 | Enable IPMI-over-LAN |
There are two XClarity Controller upgrades available for the server, Advanced and Enterprise.
Lenovo XClarity Controller Advanced adds the following remote control functions:
- Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz with up to 23 bits per pixel, regardless of the system state
- Remotely accessing the server using the keyboard and mouse from a remote client
- Capturing blue-screen errors
- International keyboard mapping support
- LDAP-based authentication
Lenovo XClarity Controller Enterprise enables the following additional features:
- Boot Capture
- Remote mounting of CD-ROM (ISO) and diskette (IMG) files as virtual drives
- Virtual console collaboration - Ability for up to 6 remote users to be log into the remote session simultaneously
- Power capping
- License for XClarity Energy Manager
Preconfigured models come with either XClarity Controller Standard, Advanced or Enterprise, depending on the model. See the Models section for details. The following table shows the field upgrades available for preconfigured models.
Part number | Feature code | Description |
---|---|---|
4L47A09132 | AVUT | ThinkSystem XClarity Controller Standard to Advanced Upgrade (for servers that have XCC Standard) |
4L47A09133 | AVUU | ThinkSystem XClarity Controller Advanced to Enterprise Upgrade (for servers that have XCC Advanced) |
For configure-to-order (CTO) models, you can elect to have one of the following XCC functionality by selecting the appropriate XCC feature codes as listed in the following table:
- XCC Standard - select neither feature listed in the table
- XCC Advanced - select feature AVUT
- XCC Enterprise - select feature AUPW
Feature code | Description |
---|---|
AVUT | ThinkSystem XClarity Controller Standard to Advanced Upgrade |
AUPW | ThinkSystem XClarity Controller Standard to Enterprise Upgrade |
Lenovo XClarity Provisioning Manager
Lenovo XClarity Provisioning Manager (LXPM) is a UEFI-based application embedded in ThinkSystem servers and accessible via the F1 key during system boot.
LXPM provides the following functions:
- Graphical UEFI Setup
- System inventory information and VPD update
- System firmware updates (UEFI and XCC)
- RAID setup wizard
- OS installation wizard (including unattended OS installation)
- Diagnostics functions
Lenovo XClarity Administrator
Lenovo XClarity Administrator is a centralized resource management solution designed to reduce complexity, speed response, and enhance the availability of Lenovo systems and solutions. It provides agent-free hardware management for ThinkSystem servers, in addition to ThinkServer, System x, and Flex System servers. The administration dashboard is based on HTML 5 and allows fast location of resources so tasks can be run quickly.
Because Lenovo XClarity Administrator does not require any agent software to be installed on the managed endpoints, there are no CPU cycles spent on agent execution, and no memory is used, which means that up to 1GB of RAM and 1 - 2% CPU usage is saved, compared to a typical managed system where an agent is required.
Lenovo XClarity Administrator is an optional software component for the SR250 V2. The software can be downloaded and used at no charge to discover and monitor the SR250 V2 and to manage firmware upgrades.
If software support is required for Lenovo XClarity Administrator, or premium features such as configuration management and operating system deployment are required, Lenovo XClarity Pro software subscription should be ordered. Lenovo XClarity Pro is licensed on a per managed system basis, that is, each managed Lenovo system requires a license.
The following table lists the Lenovo XClarity software license options.
Part number | Feature code | Description |
---|---|---|
00MT201 | 1339 | Lenovo XClarity Pro, per Managed Endpoint w/1 Yr SW S&S |
00MT202 | 1340 | Lenovo XClarity Pro, per Managed Endpoint w/3 Yr SW S&S |
00MT203 | 1341 | Lenovo XClarity Pro, per Managed Endpoint w/5 Yr SW S&S |
7S0X000HWW | SAYV | Lenovo XClarity Pro, per Managed Endpoint w/6 Yr SW S&S |
7S0X000JWW | SAYW | Lenovo XClarity Pro, per Managed Endpoint w/7 Yr SW S&S |
Lenovo XClarity Administrator offers the following standard features that are available at no charge:
- Auto-discovery and monitoring of Lenovo systems
- Firmware updates and compliance enforcement
- External alerts and notifications via SNMP traps, syslog remote logging, and e-mail
- Secure connections to managed endpoints
- NIST 800-131A or FIPS 140-2 compliant cryptographic standards between the management solution and managed endpoints
- Integration into existing higher-level management systems such as cloud automation and orchestration tools through REST APIs, providing extensive external visibility and control over hardware resources
- An intuitive, easy-to-use GUI
- Scripting with Windows PowerShell, providing command-line visibility and control over hardware resources
Lenovo XClarity Administrator offers the following premium features that require an optional Pro license:
- Pattern-based configuration management that allows to define configurations once and apply repeatedly without errors when deploying new servers or redeploying existing servers without disrupting the fabric
- Bare-metal deployment of operating systems and hypervisors to streamline infrastructure provisioning
For more information, refer to the Lenovo XClarity Administrator Product Guide:
http://lenovopress.com/tips1200
Lenovo XClarity Integrators
Lenovo also offers software plug-in modules, Lenovo XClarity Integrators, to manage physical infrastructure from leading external virtualization management software tools including those from Microsoft and VMware.
These integrators are offered at no charge, however if software support is required, a Lenovo XClarity Pro software subscription license should be ordered.
Lenovo XClarity Integrators offer the following additional features:
- Ability to discover, manage, and monitor Lenovo server hardware from VMware vCenter or Microsoft System Center
- Deployment of firmware updates and configuration patterns to Lenovo x86 rack servers and Flex System from the virtualization management tool
- Non-disruptive server maintenance in clustered environments that reduces workload downtime by dynamically migrating workloads from affected hosts during rolling server updates or reboots
- Greater service level uptime and assurance in clustered environments during unplanned hardware events by dynamically triggering workload migration from impacted hosts when impending hardware failures are predicted
For more information about all the available Lenovo XClarity Integrators, see the Lenovo XClarity Administrator Product Guide: https://lenovopress.com/tips1200-lenovo-xclarity-administrator
Lenovo XClarity Essentials
Lenovo offers the following XClarity Essentials software tools that can help you set up, use, and maintain the server at no additional cost:
- Lenovo Essentials OneCLI
OneCLI is a collection of server management tools that uses a command line interface program to manage firmware, hardware, and operating systems. It provides functions to collect full system health information (including health status), configure system settings, and update system firmware and drivers.
- Lenovo Essentials UpdateXpress
The UpdateXpress tool is a standalone GUI application for firmware and device driver updates that enables you to maintain your server firmware and device drivers up-to-date and help you avoid unnecessary server outages. The tool acquires and deploys individual updates and UpdateXpress System Packs (UXSPs) which are integration-tested bundles.
- Lenovo Essentials Bootable Media Creator
The Bootable Media Creator (BOMC) tool is used to create bootable media for offline firmware update.
For more information and downloads, visit the Lenovo XClarity Essentials web page:
http://support.lenovo.com/us/en/documents/LNVO-center
Lenovo XClarity Energy Manager
Lenovo XClarity Energy Manager (LXEM) is a power and temperature management solution for data centers. It is an agent-free, web-based console that enables you to monitor and manage power consumption and temperature in your data center through the management console. It enables server density and data center capacity to be increased through the use of power capping.
LXEM is a licensed product. A single-node LXEM license is included with the XClarity Controller Enterprise upgrade as described in the Remote Management section. If your server does not have the XCC Enterprise upgrade, Energy Manager licenses can be ordered as shown in the following table.
Part number | Description |
---|---|
4L40E51621 | Lenovo XClarity Energy Manager Node License (1 license needed per server) |
For more information about XClarity Energy Manager, see the following resources:
- Lenovo Support page:
https://datacentersupport.lenovo.com/us/en/solutions/lnvo-lxem - Lenovo Information Center:
https://sysmgt.lenovofiles.com/help/topic/LXEM/lxem_overview.html?cp=4
Security
Topics in this section:
Security features
The SR250 V2 offers the following security features:
- Electronic security measures:
- Administrator and power-on passwords
- Secure firmware updates
- Trusted Platform Module (TPM) supporting TPM 2.0
- For China customers, the Nationz TPM plug-in module
- Self-encrypting drives with support for IBM Security Key Lifecycle Manager
- Mechanical security measures
- Optional lockable front bezel
The server is NIST SP 800-147B compliant.
The following table lists the security options that are available for the SR250 V2 server.
Part number | Feature code | Description |
---|---|---|
Lockable front bezel | ||
7Z17A02581 | BMWP | SR250 V2 Security Bezel |
Trusted Platform Module (PRC only) | ||
CTO only | B22N | ThinkSystem Nationz Trusted Platform Module v2.0 |
Platform Firmware Resiliency - Lenovo ThinkShield
Lenovo's ThinkShield Security is a transparent and comprehensive approach to security that extends to all dimensions of our data center products: from development, to supply chain, and through the entire product lifecycle.
The ThinkSystem SR250 V2 includes Platform Firmware Resiliency (PFR) hardware Root of Trust (RoT) which enables the system to be NIST SP800-193 compliant. This offering further enhances key platform subsystem protections against unauthorized firmware updates and corruption, to restore firmware to an integral state, and to closely monitor firmware for possible compromise from cyber attacks.
PFR operates upon the following server components:
- UEFI image – the low-level server firmware that connects the operating system to the server hardware
- XCC image – the management “engine” software that controls and reports on the server status separate from the server operating system
- FPGA image – the code that runs the server’s lowest level hardware controller on the motherboard
The Lenovo Platform Root of Trust Hardware performs the following three main functions:
- Detection – Measures the firmware and updates for authenticity
- Recovery – Recovers a corrupted image to a known-safe image
- Protection – Monitors the system to ensure the known-good firmware is not maliciously written
These enhanced protection capabilities are implemented using a dedicated, discrete security processor whose implementation has been rigorously validated by leading third-party security firms. Security evaluation results and design details are available for customer review – providing unprecedented transparency and assurance.
The SR250 V2 includes support for Secure Boot, a UEFI firmware security feature developed by the UEFI Consortium that ensures only immutable and signed software are loaded during the boot time. The use of Secure Boot helps prevent malicious code from being loaded and helps prevent attacks, such as the installation of rootkits. Lenovo offers the capability to enable secure boot in the factory, to ensure end-to-end protection. Alternatively, Secure Boot can be left disabled in the factory, allowing the customer to enable it themselves at a later point, if desired.
The following table lists the relevant feature code(s).
Part number | Feature code | Description | Purpose |
---|---|---|---|
CTO only | AUK7 | TPM 2.0 and Secure Boot | Configure the system in the factory with Secure Boot enabled. |
CTO only | B0MK | Enable TPM 2.0 | Configure the system without Secure Boot enabled. Customers can enable Secure Boot later if desired. |
Tip: If Secure Boot is not enabled in the factory, it can be enabled later by the customer. However once Secure Boot is enabled, it cannot be disabled.
Intel Transparent Supply Chain
Add a layer of protection in your data center and have peace of mind that the server hardware you bring into it is safe authentic and with documented, testable, and provable origin.
Lenovo has one of the world’s best supply chains, as ranked by Gartner Group, backed by extensive and mature supply chain security programs that exceed industry norms and US Government standards. Now we are the first Tier 1 manufacturer to offer Intel® Transparent Supply Chain in partnership with Intel, offering you an unprecedented degree of supply chain transparency and assurance.
To enable Intel Transparent Supply Chain for the Intel-based servers in your order, add the following feature code in the DCSC configurator, under the Security tab.
Feature code | Description |
---|---|
BB0P | Intel Transparent Supply Chain |
For more information on this offering, see the paper Introduction to Intel Transparent Supply Chain on Lenovo ThinkSystem Servers, available from https://lenovopress.com/lp1434-introduction-to-intel-transparent-supply-chain-on-thinksystem-servers.
Rack installation
The following table lists the rack installation options that are available for the SR250 V2 server.
The VGA Connector Kit allows you to upgrade your server by adding a VGA video port to the front of the server (if the server does not already come with a front VGA port). When the front VGA is in use, the rear VGA port is automatically disabled.
Part number | Feature code | Description |
---|---|---|
Front VGA port | ||
4Z57A80508 | BMQ0 | ThinkSystem SR250/SR150/SR250 Series Front VGA Connector Kit v2 |
4-post rail kits | ||
4M17A13564 | BK7W | ThinkSystem Toolless Friction Rail v2 |
4M17A37605 | B7L3 | ThinkSystem Short Rack Rail Kit |
2-post rail kits | ||
4M17A37105 | B6H2 | ThinkSystem Friction 2-Post Screw-in Rail Kit |
The following table summarizes the rail kit features and specifications.
Feature | 4-Post Tool-less Rail Kit | 4-Post Short Rail Kit | 2-Post Screw-in Rail Kit |
---|---|---|---|
Part number | 4M17A13564 | 4M17A37605 | 4M17A37105 |
CMA | None | None | None |
Rail length | 751.2 mm (29.6 in.) | 484.0 mm (19.1 in.) | 486.2 mm (19.2 in.) |
Rail type | Half-out slide (friction) | Half-out slide (friction) | Half-out slide (friction) |
Tool-less installation | Yes | Yes | No |
In-rack server maintenance | No | No | No |
1U PDU support | Yes | Yes | Yes |
0U PDU support | Limited* | Yes | Not applicable |
Rack type | IBM or Lenovo 4-post, EIA standard-compliant |
4-post, EIA standard-compliant |
2-post, EIA standard-compliant |
Mounting holes | Square or round | Square or round | Square, round, or threaded |
Mounting flange thickness | 2 mm (0.08 in.) – 3.3 mm (0.13 in.) |
2 mm (0.08 in.) – 3.3 mm (0.13 in.) |
2 mm (0.08 in.) – 3.3 mm (0.13 in.) |
Distance between front and rear mounting flanges^ |
609.6 mm (24 in.) – 863.6 mm (34 in.) |
355.6 mm (14 in.) – 609.6 mm (24 in.) |
Not applicable |
* If a 0U PDU used, the rack cabinet must be at least 1000 mm (39.37 in.) deep.
^ Measured when mounted on the rack cabinet, from the front surface of the front mounting flange to the rear most point of the rail.
Operating systems
The server supports the following operating systems:
- Microsoft Windows Server 2019
- Microsoft Windows Server 2022
- Red Hat Enterprise Linux 8.4
- Red Hat Enterprise Linux 8.5
- Red Hat Enterprise Linux 8.6
- Red Hat Enterprise Linux 8.7
- Red Hat Enterprise Linux 8.8
- Red Hat Enterprise Linux 8.9
- Red Hat Enterprise Linux 9.0
- Red Hat Enterprise Linux 9.1
- Red Hat Enterprise Linux 9.2
- Red Hat Enterprise Linux 9.3
- SUSE Linux Enterprise Server 15 SP3
- SUSE Linux Enterprise Server 15 SP4
- SUSE Linux Enterprise Server 15 SP5
- SUSE Linux Enterprise Server 15 Xen SP3
- SUSE Linux Enterprise Server 15 Xen SP4
- SUSE Linux Enterprise Server 15 Xen SP5
- Ubuntu 22.04 LTS 64-bit
- VMware ESXi 7.0 U3
- VMware ESXi 8.0
- VMware ESXi 8.0 U1
- VMware ESXi 8.0 U2
For a complete list of supported, certified and tested operating systems, plus additional details and links to relevant web sites, see the Operating System Interoperability Guide: https://lenovopress.com/osig
Virtualization support: The onboard SATA ports of the server can be used with virtualization hypervisors, including VMware ESXi, Linux KVM, Xen, and Microsoft Hyper-V, however support is limited to AHCI (non-RAID) mode. RSTe mode is not supported with virtualization hypervisors.
For configure-to-order (CTO) configurations, the server can be preloaded with VMware ESXi installed on an M.2 drive. Ordering information is listed in the following table.
Part number | Feature code | Description |
---|---|---|
CTO only | BMT5 | VMware ESXi 8.0 (Factory Installed) |
CTO only | BQ8S | VMware ESXi 8.0 U1 (Factory Installed) |
CTO only | BYC7 | VMware ESXi 8.0 U2 (Factory Installed) |
Physical specifications
The SR250 V2 has the following overall physical dimensions, excluding components that extend outside the standard chassis, such as EIA flanges, front security bezel (if any), and power supply handles:
- Width: 435 mm (17.1 inches)
- Height: 43 mm (1.7 inches)
- Depth: 545 mm (21.5 inches)
The following table lists the detailed dimensions. See the figure below for the definition of each dimension.
Dimension | Description |
---|---|
482 mm | Xa = Width, to the outsides of the front EIA flanges |
435 mm | Xb = Width, to the rack rail mating surfaces |
435 mm | Xc = Width, to the outer most chassis body feature |
43 mm | Ya = Height, from the bottom of chassis to the top of the chassis |
501 mm | Za = Depth, from the rack flange mating surface to the rearmost I/O port surface |
509 mm | Zb = Depth, from the rack flange mating surface to the rearmost feature of the chassis body |
523 mm | Zc = Depth, from the rack flange mating surface to the rearmost feature such as power supply handle |
36 mm | Zd = Depth, from the forwardmost feature on front of EIA flange to the rack flange mating surface |
47 mm | Ze = Depth, from the front of security bezel (if applicable) or forwardmost feature to the rack flange mating surface |
The shipping dimensions (cardboard packaging) of the SR250 V2 are as follows:
- Width: 610 mm (24.0 inches)
- Height: 196 mm (7.7 inches)
- Depth: 860 mm (33.9 inches)
The SR250 V2 server has the following weight:
- Base configuration: 9.1 kg (20.1 lb)
- Maximum configuration: 12.3 kg (27.1 lb)
Electrical requirements are as follows:
- Models with a 300 W AC fixed power supply:
- 100-127 (nominal) V ac; 50 Hz or 60 Hz, 3.37 A
- 200-240 (nominal) V ac; 50 Hz or 60 Hz, 1.49 A
- Models with 450 W AC hot-swap power supplies:
- 100-127 (nominal) V ac; 50 Hz or 60 Hz; 5.09 A
- 200-240 (nominal) V ac; 50 Hz or 60 Hz; 2.20 A
Note for customers in China: 240V DC is not supported.
Operating environment
The server is designed to operate in ASHRAE A2 environments (10-35°C). With certain configurations, the server can also operate within ASHRAE Class A3 and A4 specifications. System performance may be impacted when operating temperature is outside ASHRAE A2 specification.
The server can be configured to operate in ASHRAE A3 environments (5-40°C) or ASHRAE A4 environments (5-45°C), provided the following restrictions are met:
- Processor with a maximum TDP as follows:
- ASHRAE A3: 80W TDP maximum
- ASHRAE A4: 70W TDP maximum
- No support for GPUs
- No support for M.2 drives
- No support for NVMe drives
- No support for 25Gb Ethernet adapters
Temperature and humidity
The SR250 V2 server is supported in the following environment:
- ASHRAE A2:
- Temperature: 10°C to 35°C
- Humidity: 8% to 80%
- Altitude 0-3000 m (10,000 ft), derated 1°C per 300 m above 950 m
- ASHRAE A3:
- Temperature: 5°C to 40°C
- Humidity: 8% to 85%
- Altitude 0-3000 m (10,000 ft), derated 1°C per 175 m above 950 m
- ASHRAE A4:
- Temperature: 5°C to 45°C
- Humidity: 8% to 90%
- Altitude 0-3000 m (10,000 ft), derated 1°C per 175 m above 950 m
Non-operating environment support:
- Without packaging:
- Temperature: -10 °C to 60 °C
- Humidity: 8 to 90%
- Storage with packaging:
- Temperature: -40 °C to 70 °C
- Humidity: 8 to 90%
Thermal/Heat output
The server generates the following heat:
- Minimum configuration: 379.1 BTU per hour (111 watts)
- Maximum configuration : 802.5 BTU per hour (235 watts)
Acoustical noise emissions
The server has the following acoustic noise emissions declaration:
- Sound power level (LWAd):
- Idling: 4.7 Bel (Typical), 5.7 Bel (Max)
- Operating: 6.6 Bel (Typical), 6.8 Bel (Max)
- Sound pressure level (LpAm):
- Idling: 33.1 dBA (Typical), 43.3 dBA (Max)
- Operating: 52.6 dBA (Typical), 53.6 dBA (Max)
Notes:
- These sound levels were measured in controlled acoustical environments according to procedures specified by ISO7779 and are reported in accordance with ISO 9296, SPL is measured by bystander position (1m).
- The declared acoustic sound levels are based on the following configurations, which may change depending on the configuration or conditions, for example M.2 drive, Broadcom 57414 25Gb NIC, Broadcom 57416 10Gb NIC, T1000
- Typical: 1x 80W CPU, 4x 32GB DIMM, 2x HDD or SSD, RAID 5350-8i, 1x 300W PSU
- Max: 1x 95W CPU, 4x 32GB DIMM, 2x HDD or SSD, 2x 450W PSU
Shock and vibration
The server has the following vibration and shock limits:
- Vibration:
- Operating: 0.21 G rms at 5 Hz to 500 Hz for 15 minutes across 3 axes
- Non-operating: 1.04 G rms at 2 Hz to 200 Hz for 15 minutes across 6 surfaces
- Shock:
- Operating: 15 G for 3 milliseconds in each direction (positive and negative X, Y, and Z axes)
- Non-operating:
- 4 kg - 11 kg: 50 G for 167 in./sec velocity change across 6 surfaces
- 12 kg - 22 kg: 50 G for 152 in./sec velocity change across 6 surfaces
Particulate contamination
Airborne particulates (including metal flakes or particles) and reactive gases acting alone or in combination with other environmental factors such as humidity or temperature might damage the system that might cause the system to malfunction or stop working altogether.
The following specifications indicate the limits of particulates that the system can tolerate:
- Reactive gases:
- The copper reactivity level shall be less than 200 Angstroms per month (Å/month)
- The silver reactivity level shall be less than 200 Å/month
- Airborne particulates:
- The room air should be continuously filtered with MERV 8 filters.
- Air entering a data center should be filtered with MERV 11 or preferably MERV 13 filters.
- The deliquescent relative humidity of the particulate contamination should be more than 60% RH
- Environment must be free of zinc whiskers
For additional information, see the Specifications section of the documentation for the server, available from the Lenovo Documents site, https://pubs.lenovo.com/
Warranty and support
The SR250 V2 has a 1-year or 3-year warranty, based on the machine type of the system:
- 7D7R - 1 year warranty
- 7D7Q - 3 year warranty
The standard warranty terms are customer-replaceable unit (CRU) and onsite (for field-replaceable units FRUs only) with standard call center support during normal business hours and 9x5 Next Business Day Parts Delivered.
Lenovo’s additional support services provide a sophisticated, unified support structure for your data center, with an experience consistently ranked number one in customer satisfaction worldwide. Available offerings include:
- Premier Support
Premier Support provides a Lenovo-owned customer experience and delivers direct access to technicians skilled in hardware, software, and advanced troubleshooting, in addition to the following:
- Direct technician-to-technician access through a dedicated phone line
- 24x7x365 remote support
- Single point of contact service
- End to end case management
- Third-party collaborative software support
- Online case tools and live chat support
- On-demand remote system analysis
- Warranty Upgrade (Preconfigured Support)
Services are available to meet the on-site response time targets that match the criticality of your systems.
- 3, 4, or 5 years of service coverage
- 1-year or 2-year post-warranty extensions
- Foundation Service: 9x5 service coverage with next business day onsite response. YourDrive YourData is an optional extra (see below).
- Essential Service: 24x7 service coverage with 4-hour onsite response or 24-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
- Advanced Service: 24x7 service coverage with 2-hour onsite response or 6-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
- Managed Services
Lenovo Managed Services provides continuous 24x7 remote monitoring (plus 24x7 call center availability) and proactive management of your data center using state-of-the-art tools, systems, and practices by a team of highly skilled and experienced Lenovo services professionals.
Quarterly reviews check error logs, verify firmware & OS device driver levels, and software as needed. We’ll also maintain records of latest patches, critical updates, and firmware levels, to ensure you systems are providing business value through optimized performance.
- Technical Account Management (TAM)
A Lenovo Technical Account Manager helps you optimize the operation of your data center based on a deep understanding of your business. You gain direct access to your Lenovo TAM, who serves as your single point of contact to expedite service requests, provide status updates, and furnish reports to track incidents over time. In addition, your TAM will help proactively make service recommendations and manage your service relationship with Lenovo to make certain your needs are met.
- Enterprise Server Software Support
Enterprise Software Support is an additional support service providing customers with software support on Microsoft, Red Hat, SUSE, and VMware applications and systems. Around the clock availability for critical problems plus unlimited calls and incidents helps customers address challenges fast, without incremental costs. Support staff can answer troubleshooting and diagnostic questions, address product comparability and interoperability issues, isolate causes of problems, report defects to software vendors, and more.
- YourDrive YourData
Lenovo’s YourDrive YourData is a multi-drive retention offering that ensures your data is always under your control, regardless of the number of drives that are installed in your Lenovo server. In the unlikely event of a drive failure, you retain possession of your drive while Lenovo replaces the failed drive part. Your data stays safely on your premises, in your hands. The YourDrive YourData service can be purchased in convenient bundles and is optional with Foundation Service. It is bundled with Essential Service and Advanced Service.
- Health Check
Having a trusted partner who can perform regular and detailed health checks is central to maintaining efficiency and ensuring that your systems and business are always running at their best. Health Check supports Lenovo-branded server, storage, and networking devices, as well as select Lenovo-supported products from other vendors that are sold by Lenovo or a Lenovo-Authorized Reseller.
Examples of region-specific warranty terms are second or longer business day parts delivery or parts-only base warranty.
If warranty terms and conditions include onsite labor for repair or replacement of parts, Lenovo will dispatch a service technician to the customer site to perform the replacement. Onsite labor under base warranty is limited to labor for replacement of parts that have been determined to be field-replaceable units (FRUs). Parts that are determined to be customer-replaceable units (CRUs) do not include onsite labor under base warranty.
If warranty terms include parts-only base warranty, Lenovo is responsible for delivering only replacement parts that are under base warranty (including FRUs) that will be sent to a requested location for self-service. Parts-only service does not include a service technician being dispatched onsite. Parts must be changed at customer’s own cost and labor and defective parts must be returned following the instructions supplied with the spare parts.
Lenovo Service offerings are region-specific. Not all preconfigured support and upgrade options are available in every region. For information about Lenovo service upgrade offerings that are available in your region, refer to the following resources:
- Service part numbers in Lenovo Data Center Solution Configurator (DCSC):
http://dcsc.lenovo.com/#/services - Lenovo Services Availability Locator
http://lenovolocator.com/
For service definitions, region-specific details, and service limitations, please refer to the following documents:
- Lenovo Statement of Limited Warranty for Infrastructure Solutions Group (ISG) Servers and System Storage
http://pcsupport.lenovo.com/us/en/solutions/ht503310 - Lenovo Data Center Services Agreement
http://support.lenovo.com/us/en/solutions/ht116628
Services
Lenovo Services is a dedicated partner to your success. Our goal is to reduce your capital outlays, mitigate your IT risks, and accelerate your time to productivity.
Note: Some service options may not be available in all markets or regions. For more information, go to https://www.lenovo.com/services. For information about Lenovo service upgrade offerings that are available in your region, contact your local Lenovo sales representative or business partner.
Here’s a more in-depth look at what we can do for you:
- Asset Recovery Services
Asset Recovery Services (ARS) helps customers recover the maximum value from their end-of-life equipment in a cost-effective and secure way. On top of simplifying the transition from old to new equipment, ARS mitigates environmental and data security risks associated with data center equipment disposal. Lenovo ARS is a cash-back solution for equipment based on its remaining market value, yielding maximum value from aging assets and lowering total cost of ownership for your customers. For more information, see the ARS page, https://lenovopress.com/lp1266-reduce-e-waste-and-grow-your-bottom-line-with-lenovo-ars.
- Assessment Services
An Assessment helps solve your IT challenges through an onsite, multi-day session with a Lenovo technology expert. We perform a tools-based assessment which provides a comprehensive and thorough review of a company's environment and technology systems. In addition to the technology based functional requirements, the consultant also discusses and records the non-functional business requirements, challenges, and constraints. Assessments help organizations like yours, no matter how large or small, get a better return on your IT investment and overcome challenges in the ever-changing technology landscape.
- Design Services
Professional Services consultants perform infrastructure design and implementation planning to support your strategy. The high-level architectures provided by the assessment service are turned into low level designs and wiring diagrams, which are reviewed and approved prior to implementation. The implementation plan will demonstrate an outcome-based proposal to provide business capabilities through infrastructure with a risk-mitigated project plan.
- Basic Hardware Installation
Lenovo experts can seamlessly manage the physical installation of your server, storage, or networking hardware. Working at a time convenient for you (business hours or off shift), the technician will unpack and inspect the systems on your site, install options, mount in a rack cabinet, connect to power and network, check and update firmware to the latest levels, verify operation, and dispose of the packaging, allowing your team to focus on other priorities.
- Deployment Services
When investing in new IT infrastructures, you need to ensure your business will see quick time to value with little to no disruption. Lenovo deployments are designed by development and engineering teams who know our Products & Solutions better than anyone else, and our technicians own the process from delivery to completion. Lenovo will conduct remote preparation and planning, configure & integrate systems, validate systems, verify and update appliance firmware, train on administrative tasks, and provide post-deployment documentation. Customer’s IT teams leverage our skills to enable IT staff to transform with higher level roles and tasks.
- Integration, Migration, and Expansion Services
Move existing physical & virtual workloads easily, or determine technical requirements to support increased workloads while maximizing performance. Includes tuning, validation, and documenting ongoing run processes. Leverage migration assessment planning documents to perform necessary migrations.
Regulatory compliance
The SR250 V2 conforms to the following standards:
- ANSI/UL 62368-1
- IEC 62368-1 (CB Certificate and CB Test Report)
- FCC - Verified to comply with Part 15 of the FCC Rules, Class A
- Canada ICES-003, issue 7, Class A
- CSA C22.2 No. 62368-1
- CISPR 32, Class A, CISPR 35
- Argentina IEC 60950-1
- Japan VCCI, Class A
- Taiwan BSMI CNS13438, Class A; CNS14336-1; Section 5 of CNS15663
- CE, UKCA Mark (EN55032 Class A, EN62368-1, EN55024, EN55035, EN61000-3-2, EN61000-3-3, (EU) 2019/424, and EN50581-1 (RoHS))
- Korea KN32, Class A, KN35
- Russia, Belorussia and Kazakhstan, TP EAC 037/2016 (for RoHS)
- Russia, Belorussia and Kazakhstan, EAC: TP TC 004/2011 (for Safety); TP TC 020/2011 (for EMC)
- Australia/New Zealand AS/NZS CISPR 32, Class A; AS/NZS 62368.1
- UL Green Guard, UL2819
- Energy Star 3.0
- EPEAT (NSF/ ANSI 426) Bronze
- China CCC certificate, GB17625.1; GB4943.1; GB/T9254
- China CECP certificate, CQC3135
- China CELP certificate, HJ 2507-2011
- Japanese Energy-Saving Act
- Mexico NOM-019
- TUV-GS (EN62368-1, and EK1-ITB2000)
- India BIS 13252 (Part 1)
- Germany GS
- Brazil INMETRO
- South Africa NRCS LOA
- Ukraine UkrCEPRO
- Morocco CMIM Certification (CM)
- EU2019/424 Energy Related Product (ErP Lot9)
External drive enclosures
The server supports attachment to external drive enclosures using a RAID controller with external ports or a SAS host bus adapter. Adapters supported by the server are listed in the SAS adapters for external storage section.
Note: Information provided in this section is for ordering reference purposes only. For the operating system and adapter support details, refer to the interoperability matrix for a particular storage enclosure that can be found on the Lenovo Data Center Support web site:
http://datacentersupport.lenovo.com
Model | Description |
---|---|
4587HC1 | Lenovo Storage D1212 Disk Expansion Enclosure (2U enclosure wth 12x LFF drive bays) |
4587HC2 | Lenovo Storage D1224 Disk Expansion Enclosure (2U enclosure wth 24x SFF drive bays) |
6413HC1 | Lenovo Storage D3284 High Density Expansion Enclosure (5U enclosure wth 84x LFF drive bays) |
7DAHCTO1WW | Lenovo ThinkSystem D4390 Direct Attached Storage (4U enclosure wth 90x LFF drive bays) |
For details about supported drives, adapters, and cables, see the following Lenovo Press Product Guides:
- Lenovo Storage D1212 and D1224
http://lenovopress.lenovo.com/lp0512 - Lenovo Storage D3284
http://lenovopress.lenovo.com/lp0513 - Lenovo ThinkSystem D4390
https://lenovopress.lenovo.com/lp1681
External storage systems
Lenovo offers the ThinkSystem DE Series and ThinkSystem DM Series external storage systems for high-performance storage. See the DE Series and DM Series product guides for specific controller models, expansion enclosures and configuration options:
- ThinkSystem DE Series Storage
https://lenovopress.com/storage/thinksystem/de-series#rt=product-guide - ThinkSystem DM Series Storage
https://lenovopress.com/storage/thinksystem/dm-series#rt=product-guide - ThinkSystem DG Series Storage
https://lenovopress.com/storage/thinksystem/dg-series#rt=product-guide
External backup units
The following table lists the external USB backup options that are offered by Lenovo.
Part number | Description |
---|---|
External RDX USB dock | |
4T27A10725 | ThinkSystem RDX External USB 3.0 Dock |
External RDX cartridges | |
7TP7A01601 | ThinkSystem RDX 500GB Cartridge |
7TP7A01602 | ThinkSystem RDX 1TB Cartridge |
7TP7A01603 | ThinkSystem RDX 2TB Cartridge |
7TP7A04318 | ThinkSystem RDX 4TB Cartridge |
For more information, see the list of Product Guides in the Backup units category:
https://lenovopress.com/servers/options/backup
The following table lists the available external SAS tape backup options.
Tip: Verify the end-to-end support of an IBM tape backup solution through the IBM System Storage Interoperation Center (SSIC): http://www.ibm.com/systems/support/storage/ssic
Part number | Description |
---|---|
External SAS tape backup drives | |
6160S6E | IBM TS2260 Tape Drive Model H6S |
6160S7E | IBM TS2270 Tape Drive Model H7S |
6160S8E | IBM TS2280 Tape Drive Model H8S |
6160S9E | IBM TS2290 Tape Drive Model H9S |
External SAS tape backup autoloaders | |
6171S6R | IBM TS2900 Tape Autoloader w/LTO6 HH SAS |
6171S7R | IBM TS2900 Tape Autoloader w/LTO7 HH SAS |
6171S8R | IBM TS2900 Tape Autoloader w/LTO8 HH SAS |
6171S9R | IBM TS2900 Tape Autoloader w/LTO9 HH SAS |
External tape backup libraries | |
6741A1F | IBM TS4300 3U Tape Library-Base Unit |
SAS backup drives for TS4300 Tape Library | |
01KP934 | LTO 6 HH SAS Drive |
01KP937 | LTO 7 HH SAS Drive |
01KP953 | LTO 8 HH SAS Drive |
02JH836 | LTO 9 HH SAS Drive |
For more information, see the list of Product Guides in the Backup units category:
https://lenovopress.com/servers/options/backup
Rack cabinets
The following table lists the supported rack cabinets.
Part number | Description |
---|---|
93072RX | 25U Standard Rack (1000mm) |
93072PX | 25U Static S2 Standard Rack (1000mm) |
7D6DA007WW | ThinkSystem 42U Onyx Primary Heavy Duty Rack Cabinet (1200mm) |
7D6DA008WW | ThinkSystem 42U Pearl Primary Heavy Duty Rack Cabinet (1200mm) |
93604PX | 42U 1200mm Deep Dynamic Rack |
93614PX | 42U 1200mm Deep Static Rack |
93634PX | 42U 1100mm Dynamic Rack |
93634EX | 42U 1100mm Dynamic Expansion Rack |
93074RX | 42U Standard Rack (1000mm) |
7D6EA009WW | ThinkSystem 48U Onyx Primary Heavy Duty Rack Cabinet (1200mm) |
7D6EA00AWW | ThinkSystem 48U Pearl Primary Heavy Duty Rack Cabinet (1200mm) |
Withdrawn rack cabinets | |
201886X | 11U Office Enablement Kit |
93084PX | 42U Enterprise Rack |
93084EX | 42U Enterprise Expansion Rack |
93604EX | 42U 1200mm Deep Dynamic Expansion Rack |
93614EX | 42U 1200mm Deep Static Expansion Rack |
93074XX | 42U Standard Rack Extension |
93634BX | PureFlex System 42U Expansion Rack |
93634DX | PureFlex System 42U Expansion Rack |
93634AX | PureFlex System 42U Rack |
93634CX | PureFlex System 42U Rack |
93624PX | 47U 1200mm Deep Static Rack |
93624EX | 47U 1200mm Deep Static Expansion Rack |
For specifications about these racks, see the Lenovo Rack Cabinet Reference, available from:
https://lenovopress.com/lp1287-lenovo-rack-cabinet-reference
For more information, see the list of Product Guides in the Rack cabinets category:
https://lenovopress.com/servers/options/racks
KVM switches and consoles
The following table lists the supported KVM consoles.
Part number | Description |
---|---|
Consoles | |
4XF7A84188 | ThinkSystem 18.5" LCD Console (with US English keyboard) |
4XF7A73009 | ThinkSystem 18.5" LCD console (with US English keyboard) |
17238BX | 1U 18.5" Standard Console (without keyboard - see the next table) |
The following table lists the keyboards supported with the 1U 18.5" Standard Console (now withdrawn).
Note: These keyboards are not supported with the ThinkSystem 18.5" LCD Console.
Part number | Description |
---|---|
7ZB7A05469 | ThinkSystem Keyboard w/ Int.Pointing Device USB - Arabic 253 RoHS v2 |
7ZB7A05468 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Belg/UK 120 RoHS v2 |
7ZB7A05206 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Czech 489 RoHS v2 |
7ZB7A05207 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Danish 159 RoHS v2 |
7ZB7A05208 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Dutch 143 RoHS v2 |
7ZB7A05210 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Fr/Canada 445 RoHS v2 |
7ZB7A05209 | ThinkSystem Keyboard w/ Int. Pointing Device USB - French 189 RoHS v2 |
7ZB7A05211 | ThinkSystem Keyboard w/ Int. Pointing Device USB - German 129 RoHS v2 |
7ZB7A05212 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Greek 219 RoHS v2 |
7ZB7A05213 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Hebrew 212 RoHS v2 |
7ZB7A05214 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Hungarian 208 RoHS v2 |
7ZB7A05215 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Italian 141 RoHS v2 |
7ZB7A05216 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Japanese 194 RoHS v2 |
7ZB7A05217 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Korean 413 RoHS v2 |
7ZB7A05218 | ThinkSystem Keyboard w/ Int. Pointing Device USB - LA Span 171 RoHS v2 |
7ZB7A05219 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Norwegian 155 RoHS v2 |
7ZB7A05220 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Polish 214 RoHS v2 |
7ZB7A05221 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Portugese 163 RoHS v2 |
7ZB7A05222 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Russian 441 RoHS v2 |
7ZB7A05223 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Slovak 245 RoHS v2 |
7ZB7A05231 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Slovenian 234 RoHS v2 |
7ZB7A05224 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Spanish 172 RoHS v2 |
7ZB7A05225 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Swed/Finn 153 RoHS v2 |
7ZB7A05226 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Swiss F/G 150 RoHS v2 |
7ZB7A05227 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Thai 191 RoHS v2 |
7ZB7A05467 | ThinkSystem Keyboard with Int. Pointing Device USB - Trad Chinese/US 467 RoHS v2 |
7ZB7A05228 | ThinkSystem Keyboard w/ Int. Pointing Device USB - Turkish 179 RoHS v2 |
7ZB7A05229 | ThinkSystem Keyboard w/ Int. Pointing Device USB - UK Eng 166 RoHS v2 |
7ZB7A05470 | ThinkSystem Keyboard w/ Int. Pointing Device USB - US Eng 103P RoHS v2 |
7ZB7A05230 | ThinkSystem Keyboard w/ Int. Pointing Device USB - US Euro 103P RoHS v2 |
The following table lists the available KVM switches and the options that are supported with them.
Part number | Description |
---|---|
KVM Console switches | |
1754D1T | ThinkSystem Digital 2x1x16 KVM Switch (DVI video output port) |
1754A1T | ThinkSystem Analog 1x8 KVM Switch (DVI video output port) |
1754D2X | Global 4x2x32 Console Manager (GCM32) |
1754D1X | Global 2x2x16 Console Manager (GCM16) |
1754A2X | Local 2x16 Console Manager (LCM16) |
1754A1X | Local 1x8 Console Manager (LCM8) |
Cables for ThinkSystem Digital and Analog KVM Console switches | |
4X97A11108 | ThinkSystem VGA to DVI Conversion Cable |
4X97A11109 | ThinkSystem Single-USB Conversion Cable for Digital KVM |
4X97A11107 | ThinkSystem Dual-USB Conversion Cable for Digital KVM |
4X97A11106 | ThinkSystem USB Conversion Cable for Analog KVM |
Cables for GCM and LCM Console switches | |
43V6147 | Single Cable USB Conversion Option (UCO) |
39M2895 | USB Conversion Option Pack |
46M5383 | Virtual Media Conversion Option Gen2 (VCO2) |
46M5382 | Serial Conversion Option (SCO) |
For more information, see the list of Product Guides in the KVM Switches and Consoles category:
http://lenovopress.com/servers/options/kvm
Power distribution units
The following table lists the power distribution units (PDUs) that are offered by Lenovo.
Part number |
Feature code |
Description |
ANZ
|
ASEAN
|
Brazil
|
EET
|
MEA
|
RUCIS
|
WE
|
HTK
|
INDIA
|
JAPAN
|
LA
|
NA
|
PRC
|
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0U Basic PDUs | |||||||||||||||
00YJ776 | ATZY | 0U 36 C13/6 C19 24A 1 Phase PDU | N | Y | Y | N | N | N | N | N | N | Y | Y | Y | N |
00YJ779 | ATZX | 0U 21 C13/12 C19 48A 3 Phase PDU | N | N | Y | N | N | N | Y | N | N | Y | Y | Y | N |
00YJ777 | ATZZ | 0U 36 C13/6 C19 32A 1 Phase PDU | Y | Y | N | Y | Y | Y | Y | Y | Y | N | N | Y | Y |
00YJ778 | AU00 | 0U 21 C13/12 C19 32A 3 Phase PDU | Y | Y | N | Y | Y | Y | Y | Y | Y | N | N | Y | Y |
0U Switched and Monitored PDUs | |||||||||||||||
00YJ783 | AU04 | 0U 12 C13/12 C19 Switched and Monitored 48A 3 Phase PDU | N | N | Y | N | N | N | Y | N | N | Y | Y | Y | N |
00YJ781 | AU03 | 0U 20 C13/4 C19 Switched and Monitored 24A 1 Phase PDU | N | N | Y | N | Y | N | Y | N | N | Y | Y | Y | N |
00YJ782 | AU02 | 0U 18 C13/6 C19 Switched and Monitored 32A 3 Phase PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | N | Y | N | Y |
00YJ780 | AU01 | 0U 20 C13/4 C19 Switched and Monitored 32A 1 Phase PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | N | Y | N | Y |
1U Switched and Monitored PDUs | |||||||||||||||
4PU7A81117 | BNDV | 1U 18 C19/C13 switched and monitored 48A 3P WYE PDU - ETL | N | N | N | N | N | N | N | N | N | N | N | Y | N |
4PU7A77467 | BLC4 | 1U 18 C19/C13 Switched and Monitored 80A 3P Delta PDU | N | N | N | N | N | N | N | N | N | Y | N | Y | N |
4PU7A77469 | BLC6 | 1U 12 C19/C13 switched and monitored 60A 3P Delta PDU | N | N | N | N | N | N | N | N | N | N | N | Y | N |
4PU7A77468 | BLC5 | 1U 12 C19/C13 switched and monitored 32A 3P WYE PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | N | Y | Y | Y |
4PU7A81118 | BNDW | 1U 18 C19/C13 switched and monitored 48A 3P WYE PDU - CE | Y | Y | Y | Y | Y | Y | Y | Y | Y | N | Y | N | Y |
46M4002 | 5896 | 1U 9 C19/3 C13 Switched and Monitored DPI PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
46M4004 | 5894 | 1U 12 C13 Switched and Monitored DPI PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
46M4003 | 5897 | 1U 9 C19/3 C13 Switched and Monitored 60A 3 Phase PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
46M4005 | 5895 | 1U 12 C13 Switched and Monitored 60A 3 Phase PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
1U Ultra Density Enterprise PDUs (9x IEC 320 C13 + 3x IEC 320 C19 outlets) | |||||||||||||||
71763NU | 6051 | Ultra Density Enterprise C19/C13 PDU 60A/208V/3PH | N | N | Y | N | N | N | N | N | N | Y | Y | Y | N |
71762NX | 6091 | Ultra Density Enterprise C19/C13 PDU Module | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
1U C13 Enterprise PDUs (12x IEC 320 C13 outlets) | |||||||||||||||
39M2816 | 6030 | DPI C13 Enterprise PDU Plus Module (WW) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
39Y8941 | 6010 | DPI C13 Enterprise PDU Module (WW) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
1U C19 Enterprise PDUs (6x IEC 320 C19 outlets) | |||||||||||||||
39Y8948 | 6060 | DPI C19 Enterprise PDU Module (WW) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
39Y8923 | 6061 | DPI Three-phase 60A/208V C19 Enterprise PDU (US) | N | N | Y | N | N | N | Y | N | N | N | Y | Y | N |
1U Front-end PDUs (3x IEC 320 C19 outlets) | |||||||||||||||
39Y8938 | 6002 | DPI Single-phase 30A/120V Front-end PDU (US) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
39Y8939 | 6003 | DPI Single-phase 30A/208V Front-end PDU (US) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
39Y8934 | 6005 | DPI Single-phase 32A/230V Front-end PDU (International) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
39Y8940 | 6004 | DPI Single-phase 60A/208V Front-end PDU (US) | Y | N | Y | Y | Y | Y | Y | N | N | Y | Y | Y | N |
39Y8935 | 6006 | DPI Single-phase 63A/230V Front-end PDU (International) | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
1U NEMA PDUs (6x NEMA 5-15R outlets) | |||||||||||||||
39Y8905 | 5900 | DPI 100-127V NEMA PDU | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
Line cords for 1U PDUs that ship without a line cord | |||||||||||||||
40K9611 | 6504 | 4.3m, 32A/380-415V, EPDU/IEC 309 3P+N+G 3ph wye (non-US) Line Cord | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
40K9612 | 6502 | 4.3m, 32A/230V, EPDU to IEC 309 P+N+G (non-US) Line Cord | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
40K9613 | 6503 | 4.3m, 63A/230V, EPDU to IEC 309 P+N+G (non-US) Line Cord | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
40K9614 | 6500 | 4.3m, 30A/208V, EPDU to NEMA L6-30P (US) Line Cord | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
40K9615 | 6501 | 4.3m, 60A/208V, EPDU to IEC 309 2P+G (US) Line Cord | N | N | Y | N | N | N | Y | N | N | Y | Y | Y | N |
40K9617 | 6505 | 4.3m, 32A/230V, Souriau UTG Female to AS/NZ 3112 (Aus/NZ) Line Cord | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
40K9618 | 6506 | 4.3m, 32A/250V, Souriau UTG Female to KSC 8305 (S. Korea) Line Cord | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y | Y |
For more information, see the Lenovo Press documents in the PDU category:
https://lenovopress.com/servers/options/pdu
Uninterruptible power supply units
The following table lists the uninterruptible power supply (UPS) units that are offered by Lenovo.
Part number | Description |
---|---|
55941AX | RT1.5kVA 2U Rack or Tower UPS (100-125VAC) |
55941KX | RT1.5kVA 2U Rack or Tower UPS (200-240VAC) |
55942AX | RT2.2kVA 2U Rack or Tower UPS (100-125VAC) |
55942KX | RT2.2kVA 2U Rack or Tower UPS (200-240VAC) |
55943AX | RT3kVA 2U Rack or Tower UPS (100-125VAC) |
55943KX | RT3kVA 2U Rack or Tower UPS (200-240VAC) |
55945KX | RT5kVA 3U Rack or Tower UPS (200-240VAC) |
55946KX | RT6kVA 3U Rack or Tower UPS (200-240VAC) |
55948KX | RT8kVA 6U Rack or Tower UPS (200-240VAC) |
55949KX | RT11kVA 6U Rack or Tower UPS (200-240VAC) |
55948PX | RT8kVA 6U 3:1 Phase Rack or Tower UPS (380-415VAC) |
55949PX | RT11kVA 6U 3:1 Phase Rack or Tower UPS (380-415VAC) |
55943KT† | ThinkSystem RT3kVA 2U Standard UPS (200-230VAC) (2x C13 10A, 2x GB 10A, 1x C19 16A outlets) |
55943LT† | ThinkSystem RT3kVA 2U Long Backup UPS (200-230VAC) (2x C13 10A, 2x GB 10A, 1x C19 16A outlets) |
55946KT† | ThinkSystem RT6kVA 5U UPS (200-230VAC) (2x C13 10A outlets, 1x Terminal Block output) |
5594XKT† | ThinkSystem RT10kVA 5U UPS (200-230VAC) (2x C13 10A outlets, 1x Terminal Block output) |
† Only available in China and the Asia Pacific market.
For more information, see the list of Product Guides in the UPS category:
https://lenovopress.com/servers/options/ups
Lenovo Financial Services
Lenovo Financial Services reinforces Lenovo’s commitment to deliver pioneering products and services that are recognized for their quality, excellence, and trustworthiness. Lenovo Financial Services offers financing solutions and services that complement your technology solution anywhere in the world.
We are dedicated to delivering a positive finance experience for customers like you who want to maximize your purchase power by obtaining the technology you need today, protect against technology obsolescence, and preserve your capital for other uses.
We work with businesses, non-profit organizations, governments and educational institutions to finance their entire technology solution. We focus on making it easy to do business with us. Our highly experienced team of finance professionals operates in a work culture that emphasizes the importance of providing outstanding customer service. Our systems, processes and flexible policies support our goal of providing customers with a positive experience.
We finance your entire solution. Unlike others, we allow you to bundle everything you need from hardware and software to service contracts, installation costs, training fees, and sales tax. If you decide weeks or months later to add to your solution, we can consolidate everything into a single invoice.
Our Premier Client services provide large accounts with special handling services to ensure these complex transactions are serviced properly. As a premier client, you have a dedicated finance specialist who manages your account through its life, from first invoice through asset return or purchase. This specialist develops an in-depth understanding of your invoice and payment requirements. For you, this dedication provides a high-quality, easy, and positive financing experience.
For your region-specific offers, please ask your Lenovo sales representative or your technology provider about the use of Lenovo Financial Services. For more information, see the following Lenovo website:
https://www.lenovo.com/us/en/landingpage/lenovo-financial-services/
Seller training courses
The following sales training courses are offered for employees and partners (login required). Courses are listed in date order.
-
Lenovo Data Center Product Portfolio
2023-07-21 | 15 minutes | Employees and Partners
DetailsLenovo Data Center Product PortfolioThis course introduces the Lenovo data center portfolio, and covers servers, storage, storage networking, and software-defined infrastructure products. After completing this course about Lenovo data center products, you will be able to identify product types within each data center family, describe Lenovo innovations that this product family or category uses, and recognize when a specific product should be selected.
Published: 2023-07-21
Length: 15 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW1110r6 -
Family Portfolio: ThinkSystem Intel Rack and Tower Servers
2023-01-06 | 10 minutes | Employees and Partners
DetailsFamily Portfolio: ThinkSystem Intel Rack and Tower ServersThis course is designed to give Lenovo sales and partner representatives a foundation for the Intel Dense server family products.
Published: 2023-01-06
After completing this course, you will be able to identify products and features within the family, describe Lenovo innovations that this product family uses, and recognize when a specific product or products should be selected.
Length: 10 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW1204r10 -
Family Portfolio: Edge Solutions
2022-12-06 | 10 minutes | Employees and Partners
DetailsFamily Portfolio: Edge SolutionsThis course describes the Lenovo edge solutions. Edge servers, such as the Lenovo ThinkSystem SE350 and ThinkEdge SE450, are used at the edge of an IoT environment, and may be part of an edge solution. Solutions such as those using software from Scale Computing typically use more traditional Lenovo servers.
Published: 2022-12-06
After completing this course, you will be able to list the edge solutions in the Lenovo portfolio, describe the features of each solution and determine which solution is best suited to a specific environment.
Length: 10 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW1108r4 -
Lenovo Sustainable Computing
2022-09-16 | 4 minutes | Employees and Partners
DetailsLenovo Sustainable ComputingThis Quick Hit describes the Lenovo sustainable computing program, and the many ways in which Lenovo strives to respect and protect the environment.
Published: 2022-09-16
Length: 4 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW2504a -
Quick Hit Video: Family Portfolio ThinkSystem Intel Rack and Tower 1S Update
2022-02-24 | 2 minutes | Employees and Partners
DetailsQuick Hit Video: Family Portfolio ThinkSystem Intel Rack and Tower 1S UpdateThis Quick Hit video introduces three new Lenovo 1S rack and tower servers which are ideal for SMB environments – the ST50 V2, ST250 V2, and SR250 V2.
Published: 2022-02-24
Length: 2 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW1204r9v -
Intel Transparent Supply Chain on Lenovo Servers
2021-12-03 | 12 minutes | Employees and Partners
DetailsIntel Transparent Supply Chain on Lenovo ServersThis course introduces the Intel Transparent Supply Chain (TSC) program, explains how the program works, and discusses the benefits of the Intel TSC program to customers. Adding the Intel TSC feature to an order is explained.
Published: 2021-12-03
Length: 12 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW1230 -
Family Portfolio: Cloud
2021-10-25 | 20 minutes | Employees and Partners
DetailsFamily Portfolio: CloudThis course provides Lenovo sales and business partners an overview of Lenovo cloud solutions. This includes turnkey solutions, building blocks for cloud, engineered solutions, and professional services.
Published: 2021-10-25
Learning Objectives:
• Explain ThinkAgile software-defined infrastructure products
• Explain engineered solution
• Explain the benefits of Lenovo cloud services
• Learn when to select a product, solution or service
Length: 20 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXTW1001r3 -
Family Portfolio: Storage Controller Options
2021-10-19 | 25 minutes | Employees and Partners
DetailsFamily Portfolio: Storage Controller OptionsThis course covers the storage controller options available for use in Lenovo servers. The classes of storage controller are discussed, along with a discussion of where they are used, and which to choose.
Published: 2021-10-19
Learning Objectives:
After completing this course, you will be able to:
• Describe the classes of storage controllers
• Discuss where each controller class is used
• Describe the available options in each controller class
Length: 25 minutes
Employee link: Grow@Lenovo
Partner link: Lenovo Partner Learning
Course code: SXXW1111
Related publications and links
For more information, see these resources:
- ThinkSystem SR250 V2 product page
https://www.lenovo.com/us/en/p/data-center/servers/racks/thinksystem-sr250-v2/len21ts0003 - ThinkSystem SR250 V2 interactive 3D tour
https://lenovopress.com/lp1570-3d-tour-thinksystem-sr250-v2 - ThinkSystem SR250 V2 drivers and support
http://datacentersupport.lenovo.com/products/servers/thinksystem/sr250v2/7d7q/downloads
- ThinkSystem SR250 V2 product publications:
http://thinksystem.lenovofiles.com/help/index.jsp- Quick Start
- Tower-to-Rack Conversion Kit Installation Instructions
- Setup Guide
- Maintenance Manual
- Lenovo XClarity Provisioning Manager User Guide
- ServerProven hardware compatibility:
http://www.lenovo.com/us/en/serverproven
Related product families
Product families related to this document are the following:
Trademarks
Lenovo and the Lenovo logo are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. A current list of Lenovo trademarks is available on the Web at https://www.lenovo.com/us/en/legal/copytrade/.
The following terms are trademarks of Lenovo in the United States, other countries, or both:
Lenovo®
Bootable Media Creator
Flex System
Lenovo Services
ServerProven®
System x®
ThinkShield®
ThinkServer®
ThinkSystem®
TopSeller
TruDDR4
UpdateXpress System Packs
XClarity®
The following terms are trademarks of other companies:
Intel®, Celeron®, Xeon®, and Pentium® are trademarks of Intel Corporation or its subsidiaries.
Linux® is the trademark of Linus Torvalds in the U.S. and other countries.
Microsoft®, ActiveX®, Hyper-V®, PowerShell, Windows PowerShell®, Windows Server®, and Windows® are trademarks of Microsoft Corporation in the United States, other countries, or both.
SPECpower® is a trademark of the Standard Performance Evaluation Corporation (SPEC).
Other company, product, or service names may be trademarks or service marks of others.
Configure and Buy
Please select your market:
Full Change History
Changes in the December 5, 2023 update:
- New 2.5-inch SATA SSD drive options - Internal drive options section:
- ThinkSystem 2.5" Multi Vendor 240GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90872
- ThinkSystem 2.5" Multi Vendor 480GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90873
- ThinkSystem 2.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90874
- ThinkSystem 2.5" Multi Vendor 1.92TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90875
- ThinkSystem 2.5" Multi Vendor 3.84TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90876
- ThinkSystem 2.5" Multi Vendor 7.68TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90877
- ThinkSystem 2.5" Multi Vendor 480GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90884
- ThinkSystem 2.5" Multi Vendor 960GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90885
- ThinkSystem 2.5" Multi Vendor 1.92TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90886
- ThinkSystem 2.5" Multi Vendor 3.84TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90887
- New 3.5-inch SATA SSD drive options - Internal drive options section:
- ThinkSystem 3.5" Multi Vendor 240GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90878
- ThinkSystem 3.5" Multi Vendor 480GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90879
- ThinkSystem 3.5" Multi Vendor 960GB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90880
- ThinkSystem 3.5" Multi Vendor 1.92TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90881
- ThinkSystem 3.5" Multi Vendor 3.84TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90882
- ThinkSystem 3.5" Multi Vendor 7.68TB Read Intensive SATA 6Gb HS SSD v2, 4XB7A90883
- ThinkSystem 3.5" Multi Vendor 480GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90888
- ThinkSystem 3.5" Multi Vendor 960GB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90889
- ThinkSystem 3.5" Multi Vendor 1.92TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90890
- ThinkSystem 3.5" Multi Vendor 3.84TB Mixed Use SATA 6Gb HS SSD v2, 4XB7A90891
- New M.2 drive options - Internal drive options section:
- ThinkSystem M.2 ER3 240GB Read Intensive SATA 6Gb NHS SSD, 4XB7A89422
- ThinkSystem M.2 ER3 480GB Read Intensive SATA 6Gb NHS SSD, 4XB7A90049
- ThinkSystem M.2 ER3 960GB Read Intensive SATA 6Gb NHS SSD, 4XB7A90230
Changes in the November 20, 2023 update:
- The server supports quantity 2 of the following external storage adapter - SAS adapters for external storage section:
- ThinkSystem 440-8e SAS/SATA PCIe Gen4 12Gb HBA
Changes in the November 14, 2023 update:
- New model for Australia/New Zealand
- 7D7QA03SAU
- New models for Latin America
- 7D7Q100ALA, 7D7Q100BLA, 7D7QA03TLA
Changes in the November 10, 2023 update:
- Clarified that when the server has both front and rear video ports, when the front video port is in use, the rear port is disabled - Rack installation section
Changes in the October 31, 2023 update:
- Added the VMware ESXi 8.0 U2 preload - Operating system support section
Changes in the October 24, 2023 update:
- The onboard Gigabit ports support Wake on LAN (WOL) - Network adapters section
Changes in the October 17, 2023 update:
- Add the following models for customers in EMEA - Models section
- 7D7QA03PEA, 7D7QA03QEA, 7D7QA03REA
Changes in the October 4, 2023 update:
- Add the following model for customers in EMEA - Models section
- 7D7QA031EA
Changes in the September 7, 2023 update:
- The following preconfigured models for customers in India are now withdrawn - Models section
- 7D7QA028SG, 7D7QA029SG
Changes in the August 8, 2023 update:
- Added the following SATA SSD - Internal drive options section:
- ThinkSystem 2.5" CM893a 2TB Read Intensive SATA 6Gb HS SSD, 4XB7A89423
- New models for customers in Brazil - Models section:
- 7D7QA03GBR, 7D7QA03JBR, 7D7QA03KBR, 7D7QA03LBR
Changes in the July 4, 2023 update:
- New models for customers in Brazil - Models section:
- 7D7Q1005BR, 7D7Q1006BR
Changes in the June 13, 2023 update:
- New models - Models section:
- New model for A/NZ customers: 7D7QA03DAU
- New model fro EMEA customers: 7D7QA03EEA
Changes in the May 23, 2023 update:
- Added the VMware ESXi 8.0 and ESXi 8.0 U1 preloads - Operating system support section
- New drive options - Internal drive options section:
- ThinkSystem 3.5" 22TB 7.2K SAS 12Gb Hot Swap 512e HDD, 4XB7A83766
- ThinkSystem 3.5" 22TB 7.2K SATA 6Gb Hot Swap 512e HDD, 4XB7A83765
- The server now supports 88TB of internal storage using 4x 22TB 3.5-inch HDDs - Standard specifications section
Changes in the May 5, 2023 update:
- Added the following drive - Internal drive options section:
- ThinkSystem 3.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD, 4XB7A87202
Changes in the March 31, 2023 update:
- Added a note that the Intel Pentium processors are not ERP Lot 9 compliant (UK and EU) and are not Energy Star compliant - Processors section
Changes in the March 14, 2023 update:
- New models for customers in the HTK region - Models section:
- 7D7QA037CN
- 7D7QA038CN
- Clarified that the M.2 adapter uses 2 of the onboard SATA ports - System architecture section
- Config 6 (8x 2.5-inch SATA with onboard SATA) does not support M.2 - Storage configurations section
Changes in the March 3, 2023 update:
- Updated the drive tables - Internal drive options section
Changes in the February 14, 2023 update:
- The 450W Titanium power supply (4P57A78356) only supports 220V input power, not 110V - Power supplies section
Changes in the November 22, 2022 update:
- Added the following drives:
- ThinkSystem 3.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 SS SSD, 4XB7A79664
- ThinkSystem M.2 5400 PRO 240GB Read Intensive SATA 6Gb NHS SSD, 4XB7A82286
- ThinkSystem M.2 5400 PRO 480GB Read Intensive SATA 6Gb NHS SSD, 4XB7A82287
- ThinkSystem M.2 5400 PRO 960GB Read Intensive SATA 6Gb NHS SSD, 4XB7A82288
Changes in the November 8, 2022 update:
- Added three new storage configurations - Storage configurations section:
- Config 2-2: 4x 3.5" SS SAS/SATA with RAID 940-8i
- Config 5-2: 4x 3.5" HS with RAID 940-8i
- Config 7-2: 8x 2.5" HS with RAID 940-8i
- New storage upgrade kit - Field upgrades section:
- ThinkSystem SR250/SR150/SR250 V2 4x3.5" Simple Swap Backplane Kit for X40 RAID/HBA, 4M17A80601
- New support for M.2 adapters and drives - M.2 drives section
- Added the following M.2 drives - Internal drive options section:
- ThinkSystem M.2 128GB SATA 6Gbps Non-Hot Swap SSD, 7N47A00130
- ThinkSystem M.2 5300 240GB SATA 6Gbps Non-Hot Swap SSD, 4XB7A17071
- ThinkSystem M.2 5300 480GB SATA 6Gbps Non-Hot Swap SSD, 4XB7A17073
- ThinkSystem M.2 5300 960GB SATA 6Gbps Non-Hot Swap SSD, 4XB7A17074
- Added the following adapter for external storage - SAS adapters for external storage section
- ThinkSystem 440-8e SAS/SATA PCIe Gen4 12Gb HBA, 4Y37A78837
- Added the following power supply - Power supplies section:
- ThinkSystem 450W 230V Titanium Hot-Swap Power Supply, 4P57A78356
- Added information about UEFI performance presets - Processors section
Changes in the October 12, 2022 update:
- Clarified that the preconfigured models with rail kit "Fric" listed include the following - Models section:
- ThinkSystem Toolless Friction Rail v2, 4M17A13564
Changes in the August 9, 2022 update:
- New model for customers in Latin American countries (except Brazil) - Models section:
- 7D7QA02ELA, 7D7QA02FLA, 7D7QA02GLA, 7D7QA02HLA
Changes in the July 24, 2022 update:
- New models for customers in EMEA - Models section:
- 7D7QA02DEA, 7D7QA02CEA
- New model for customers in Latin American countries (except Brazil) - Models section:
- 7D7QA02BLA
Changes in the July 20, 2022 update:
- Add a section on Platform Firmware Resiliency (PFR) - Security section
Changes in the June 22, 2022 update:
- All models for AP markets now include the Friction Rail Kit instead of the Short Rail Kit - Models section:
- 7D7QA01TAP, 7D7QA01VAP, 7D7QA01UAP, 7D7QA01WAP, 7D7QA01SAP, 7D7QA01XAP
- The server now supports Windows Server 2022 - Operating systems section
Changes in the June 14, 2022 update:
- New models for customers in India - Models section:
- 7D7QA024SG, 7D7QA025SG, 7D7QA026SG, 7D7QA027SG, 7D7QA028SG, 7D7QA029SG, 7D7QA02ASG
Changes in the May 24, 2022 update:
- New support for the following 20TB drives - Internal drive options section:
- ThinkSystem 3.5" 20TB 7.2K SATA 6Gb Hot Swap 512e HDD, 4XB7A80354
- ThinkSystem 3.5" 20TB 7.2K SAS 12Gb Hot Swap 512e HDD, 4XB7A80353
- The server now supports up to 80TB of internal storage using 4x 20TB drives - Standard specifications section
Changes in the May 6, 2022 update:
- 4-port network adapters can only be installed in slot 2 due to physical contraints - Network adapters section
Changes in the April 13, 2022 update:
- The use of both an Intel E810 network adapter and an X350 HBA/RAID adapter is currently not supported in ThinkSystem servers - Controllers for internal storage section and Network adapters section
Changes in the April 12, 2022 update:
- New models for the Latin America market - Models section:
- 7D7Q1000LA, 7D7Q1001LA, 7D7Q1002LA
- M.2 support is now planned for 4Q/2022 - Internal storage section
Changes in the March 23, 2022 update:
- Added details about the rail kit - Rack installation section
- Correction that all configurations have 4 system fans as standard - Cooling section
- Added ASHRAE A3 and A4 support information - Operating environment section
Changes in the March 9, 2022 update:
- Updated the noise data - Operating environment section
First published: March 1, 2022
