ThinkAgile VX630 V3 1U Integrated System and Certified Node

Product Guide

Home
Top

Abstract

The Lenovo ThinkAgile VX630 V3 Integrated System and Certified Node are 2-socket 1U systems that feature the 5th Generation Intel Xeon Scalable processors (formerly code named "Emerald Rapids) and 4th Generation Intel Xeon Scalable processors (formerly code named "Sapphire Rapids). ThinkAgile VX630 provides up to 64 cores per 5th generation processor and up to 60 cores per 4th generation processor and support for the new PCIe 5.0 standard for I/O, the VX systems offer the ultimate in two-socket performance in a 1U form factor. VMware offers a unique, software-defined approach to hyper convergence, leveraging the hypervisor to deliver compute, storage and management in a tightly integrated software stack.

This product guide provides essential pre-sales information to understand the VX630 V3 systems, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the VX630 V3 systems and consider their use in IT solutions.

Change History

Changes in the August 13,  2024 update:

  • Added support for the following Network Adapters- Network adapters section:
    • ThinkSystem Intel I350 1GbE RJ45 4-Port OCP Ethernet Adapter V2, 4XC7A88428
  • Added internal drive support for the following: see Internal drive options section
    • ThinkSystem 2.5" U.3 7500 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD, 4XB7A95055
    • ThinkSystem 2.5" U.3 7500 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD, 4XB7A95056
    • ThinkSystem 2.5" U.3 7500 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD, 4XB7A95057
    • ThinkSystem 2.5" U.3 7500 MAX 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD, 4XB7A95058
    • ThinkSystem 2.5" U.3 7500 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD, 4XB7A95050
    • ThinkSystem 2.5" U.3 7500 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD, 4XB7A95051
    • ThinkSystem 2.5" U.3 7500 PRO 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD, 4XB7A95052
    • ThinkSystem 2.5" U.3 7500 PRO 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD, 4XB7A95053
  • Added support for the following memory- Memory section:
    • ThinkSystem 48GB TruDDR5 4800MHz (2Rx8) RDIMM, 4X77A87033
    • ThinkSystem 96GB TruDDR5 4800MHz (2Rx4) RDIMM, 4X77A87034

Introduction

The Lenovo ThinkAgile VX630 V3 Integrated System and Certified Node are 2-socket 1U systems that feature the 5th Generation Intel Xeon Scalable processors (formerly code named "Emerald Rapids) and 4th Generation Intel Xeon Scalable processors (formerly code named "Sapphire Rapids). ThinkAgile VX630 provides up to 64 cores per 5th generation processor and up to 60 cores per 4th generation processor and support for the new PCIe 5.0 standard for I/O, the VX systems offer the ultimate in two-socket performance in a 1U form factor. VMware offers a unique, software-defined approach to hyper convergence, leveraging the hypervisor to deliver compute, storage and management in a tightly integrated software stack.

Tip: Starting October 1, 2024,  ThinkAgile VX Certified Nodes are available only in limited countries. For more details on country coverage, please contact your Lenovo Sales Representative.

Suggested uses: Inference, virtualization, VDI, HPC,

Lenovo ThinkAgile VX with 2.5-inch drive bays
Figure 1. Lenovo ThinkAgile VX630 V3 with 2.5-inch drive bays

Did you know?

The ThinkAgile VX630 V3 Integrated System and Certified Node are built on the Lenovo ThinkSystem SR630 V3 server that features enterprise-class reliability, management, and security.

The VX630 V3 Integrated Systems comes paired with Premier Support that offers a single point of support for quick 24/7 problem reporting and resolution.

Key features

ThinkAgile features

The ThinkAgile VX630 V3 Integrated System and Certified Node offer the following key features:

  • Factory-integrated, pre-configured ready-to-go integrated systems built on proven and reliable Lenovo ThinkSystem servers that provide compute power for a variety of workloads and applications and powered by industry-leading hyperconverged infrastructure software from VMware.
  • Provide quick and convenient path to implement a hyperconverged solution powered by VMware Cloud Foundation (VCF) or VMware vSphere Foundation (VVF) software stacks with "one stop shop" and a single point of contact provided by Lenovo for purchasing, deploying, and supporting the solution.
  • Meet various workload demands with cost-efficient hybrid or performance-optimized all-flash storage configurations.
  • Deliver fully validated and integrated hardware and firmware that is certified with VMware by Broadcom.
  • ThinkAgile Integrated Systems are bundled with Premier Support providing a single-point-of-contact for quick 24/7 hardware and software support, problem reporting and resolution.
  • They also come with deployment delivered by Lenovo Professional Services and VMware software licenses.*
  • Five-year hardware warranty, bundled with Premier Support that provides a 24x7 Single Point of Support

The VMware software running on ThinkAgile VX630 V3 Integrated System and Certified Node delivers the following key features:

  • Distributed architecture that allows "pay-as-you-grow", non-disruptive scaling by adding new nodes to the cluster (scale-out) to increase capacity and performance.
  • Advanced capacity management, including deduplication, compression, and erasure coding (RAID 5/6), which helps deliver greater storage utilization with dramatically lower storage capacity and costs.
  • Automation of VM storage provisioning and control of storage service levels (capacity, performance, availability) with VM-centric policies to load balance storage resources.
  • Native HCI security solution with two-factor authentication (SecurID and CAC) and data-at-rest encryption that does not require self-encrypting drives (SEDs).
  • Stretched cluster with local and site failure protection between two geographically dispersed sites for higher level of availability with near zero downtime.
  • Centralized management with provisioning, administering, and monitoring virtual resources across multiple hosts and clusters from a centralized interface.
  • Rapid workload provisioning, simplified data center operations, increased business efficiency, and decreased CAPEX and OPEX costs.
  • VM and data protection with agent-less, image-level virtual machine backups and application-aware protection for business-critical Microsoft applications (Exchange, SQL Server, SharePoint) along with WAN-efficient, encrypted backup data replication.
  • Reduced unplanned downtime and virtually eliminated planned downtime for server and storage maintenance with live workload migration, high availability, and fault tolerance.
  • Enhanced application performance and availability with resource management, load balancing, and access prioritization.
  • Intelligent operations management and automation to proactively monitor and manage compute, storage, and networking resources, identify performance bottlenecks, and re-balance workloads by leveraging predictive analytics.
  • Capacity planning and optimization guidance to address future needs with performance trends, projections and extended forecasts.
  • Managing remote offices and branch offices with rapid provisioning of servers through virtualization, minimization of host configuration drift, and enhanced visibility into regulatory compliance, across multiple sites.

*Customers now have the ability to opt out of these features. Please check sections on Software and Deployment Services for more information.

Hardware features

The VX systems are based on the SR630 V3 and have the following hardware features:

Scalability and performance

The VX630 V3 offer numerous features to boost performance, improve scalability and reduce costs:

  • Supports one or two 5th Gen Intel Xeon Processor Scalable processors
    • Up to 64 cores and 128 threads
    • Core speeds of up to 3.9 GHz
    • TDP ratings of up to 350 W
  • Supports one or two 4th Gen Intel Xeon Processor Scalable processors
    • Up to 60 cores and 120 threads
    • Core speeds of up to 3.7 GHz
    • TDP ratings of up to 350 W
  • Support for DDR5 memory DIMMs to maximize the performance of the memory subsystem:
    • Up to 32 DDR5 memory DIMMs, 16 DIMMs per processor
    • 8 memory channels per processor (2 DIMMs per channel)
    • Supports 1 DIMM per channel operating at 5600 MHz (5th Gen processors) or 4800 MHz (4th Gen processors)
    • Supports 2 DIMMs per channel operating at 4800 MHz (5th Gen processors) or 4400 MHz (4th Gen processors)
    • Using 256GB 3DS RDIMMs, the server supports up to 8TB of system memory
  • Supports up to three single-width GPUs, each up to 75W for substantial processing power in a 1U system.
  • Supports up to 12x 2.5-inch hot-swap drive bays, by using combinations of front-accessible (up to 10 bays) and rear-accessible (2 bays).
  • Supports four 3.5-inch drive bays for lower-cost high-capacity HDD storage.
  • Supports up to 12x NVMe drives without oversubscription of PCIe lanes (1:1 connectivity) and without the need for additional NVMe adapters. The use of NVMe drives maximizes drive I/O performance, in terms of throughput and latency.
  • Supports up to two externally accessible 7mm hot-swap drives with RAID functionality for operating system boot functions.
  • Supports M.2 drives for convenient operating system boot functions. Available M.2 adapters support either one M.2 drive or two M.2 drives in a RAID 1 configuration for performance and reliability.
  • The server has a dedicated industry-standard OCP 3.0 small form factor (SFF) slot, with a PCIe 5.0 x16 interface, supporting a variety of Ethernet network adapters. A simple-swap mechanism with a thumbscrew and pull-tab enables tool-less installation and removal of the adapter. The adapter supports shared BMC network sideband connectivity to enable out-of-band systems management.
  • The server offers PCI Express 5.0 I/O expansion capabilities that doubles the theoretical maximum bandwidth of PCIe 4.0 (32GT/s in each direction for PCIe Gen 5, compared to 16 GT/s with PCIe Gen 4 and 8 GT/s with PCIe Gen 3). A PCIe 5.0 x16 slot provides 128 GB/s bandwidth, enough to support a dual-port 200GbE network connection.
  • The server offers up to three PCIe 5.0 slots, all with rear access, plus an internal bay for a cabled RAID adapter or HBA, plus a slot dedicated to the OCP adapter.

Availability and serviceability

The VX630 V3 provide many features to simplify serviceability and increase system uptime:

  • The server offers Single Device Data Correction (SDDC, also known as Chipkill), Adaptive Double-Device Data Correction (ADDDC, also known as Redundant Bit Steering or RBS), and memory mirroring for redundancy in the event of a non-correctable memory failure.
  • The server offers hot-swap drives for greater system uptime.
  • Available M.2 boot adapters support RAID-1 (using Intel VROC) which can enable two NVMe M.2 drives to be configured as a redundant pair.
  • The server has up to two hot-swap redundant power supplies and up to eight hot-swap redundant fans to provide availability for business-critical applications.
  • The light path diagnostics feature uses LEDs to lead the technician to failed (or failing) components, which simplifies servicing, speeds up problem resolution, and helps improve system availability.
  • Solid-state drives (SSDs) offer more reliability and performance than traditional mechanical HDDs for greater uptime.
  • Proactive Platform Alerts (including PFA and SMART alerts): Processors, voltage regulators, memory, internal storage (SAS/SATA HDDs and SSDs, NVMe SSDs, M.2 storage), fans, power supplies, server ambient and subcomponent temperatures. Alerts can be surfaced through the XClarity Controller to managers such as Lenovo XClarity Administrator and VMware vCenter. These proactive alerts let you take appropriate actions in advance of possible failure, thereby increasing server uptime and application availability.
  • The built-in XClarity Controller 2 continuously monitors system parameters, triggers alerts, and performs recovery actions in case of failures to minimize downtime.
  • Built-in diagnostics in UEFI, using Lenovo XClarity Provisioning Manager, speed up troubleshooting tasks to reduce service time.
  • Lenovo XClarity Provisioning Manager supports diagnostics and can save service data to a USB key drive or remote CIFS share folder for troubleshooting and reduce service time.
  • Auto restart in the event of a momentary loss of AC power (based on power policy setting in the XClarity Controller service processor)
  • Offers a diagnostics port on the front of the server to allow you to attach an external diagnostics handset for enhanced systems management capabilities.
  • Support for the XClarity Administrator Mobile app running on a supported smartphone or tablet and connected to the server through the service-enabled USB port, enables additional local systems management functions.
  • Three-year customer-replaceable unit and onsite limited warranty (varies by geography), 9 x 5 next business day. Optional service upgrades are available.

Manageability and security

Systems management features simplify local and remote management of the VX630 V3:

  • The server includes XClarity Controller 2 (XCC2) to monitor server availability. Optional upgrade to XCC Platinum to provide remote control (keyboard video mouse) functions, support for the mounting of remote media files (ISO and IMG image files), boot capture, power capping and new XCC2 Platinum features. New XCC2 Platinum features include System Guard, new security modes including a CNSA-compliant mode, FIPS 140-3 and NIST 800-193 support, and a new Neighbor Group feature.
  • Dedicated Ethernet port at the rear of the server for remote management (BMC management). Optional support for a second dedicated BMC management port, installed in the OCP adapter bay.
  • Lenovo XClarity Administrator offers comprehensive hardware management tools that help to increase uptime, reduce costs and improve productivity through advanced server management capabilities.
  • UEFI-based Lenovo XClarity Provisioning Manager, accessible from F1 during boot, provides system inventory information, graphical UEFI Setup, platform update function, RAID Setup wizard, operating system installation function, and diagnostic functions.
  • Support for Lenovo XClarity Energy Manager which captures real-time power and temperature data from the server and provides automated controls to lower energy costs.
  • An integrated industry-standard Unified Extensible Firmware Interface (UEFI) enables improved setup, configuration, and updates, and simplifies error handling.
  • Support for industry standard management protocols, IPMI 2.0, SNMP 3.0, Redfish REST API, serial console via IPMI
  • An integrated hardware Trusted Platform Module (TPM) supporting TPM 2.0 enables advanced cryptographic functionality, such as digital signatures and remote attestation.
  • Administrator and power-on passwords help protect from unauthorized access to the server.
  • Supports Secure Boot to ensure only a digitally signed operating system can be used. Supported with HDDs and SSDs, as well as 7mm and M.2 drives.
  • Industry-standard Advanced Encryption Standard (AES) NI support for faster, stronger encryption.
  • Intel Execute Disable Bit functionality can prevent certain classes of malicious buffer overflow attacks when combined with a supported operating system.
  • Intel Trusted Execution Technology provides enhanced security through hardware-based resistance to malicious software attacks, allowing an application to run in its own isolated space, protected from all other software running on a system.
  • Additional physical security features are an available chassis intrusion switch and available lockable front bezel.

Energy efficiency

The VX630 V3 offer the following energy-efficiency features to save energy, reduce operational costs, and increase energy availability:

  • Energy-efficient system board components help lower operational costs.
  • Carbon offset is available at click of button. You can project the carbon emissions per device for an average lifecycle (up to 5 years). That information is available here
  • High-efficiency power supplies with 80 PLUS Platinum and Titanium certifications
  • Solid-state drives (SSDs) consume as much as 80% less power than traditional spinning 2.5-inch HDDs.
  • Support for Lenovo XClarity Energy Manager provides advanced data center power notification, analysis, and policy-based management to help achieve lower heat output and reduced cooling needs.
  • The server uses hexagonal ventilation holes, which can be grouped more densely than round holes, providing more efficient airflow through the system and thus keeping your system cooler.

Components and connectors

The ThinkAgile VX630 V3 Integrated System and Certified Node are based on the ThinkSystem SR630 V3 server.

The following figure shows the front of the VX630 V3 with 2.5-inch drives.

Front view of the ThinkAgile VX with 2.5-inch drives
Figure 2. Front view of the ThinkAgile 630 V3 with 2.5-inch drives

The following figure shows the front of the 630 V3 with 3.5-inch drives.

Front view of the ThinkAgile VX with 3.5-inch drives
Figure 3. Front view of the ThinkAgile630 V3 with 3.5-inch drives

The following figure shows the components visible from the rear of the server. As shown, there are four different configurations available, including two with rear-mounted drive bays: two 2.5-inch hot-swap drive bays (SAS, SATA or NVMe) or new 7mm thickness hot-swap drives (SATA or NVMe).

Rear view of the VX systems
Figure 4. Rear view of the VX 630 V3 systems

The following figure shows the locations of key components inside the systems.

Internal view of the Lenovo ThinkAgile VX630 V3 Integrated System and Certified Node
Figure 5. Internal view of the VX630 V3 systems

Standard specifications

The ThinkAgile VX630 V3 Integrated System and Certified Node are based on the ThinkSystem SR630 V3 server.

The following table provides an overview comparison between the VX systems.

Table 1. Comparison of features
  VX630 V3 IS VX630 V3 CN
VX offering type Integrated System Certified Node
Target workloads SMB, ROBO, VDI SMB, ROBO, VDI
Base MTM 7D6XCTO1WW 7D6XCTO2WW
Form Factor 1U 1U
Base platform SR630 V3 SR630 V3
Max Cluster Size 64 Hosts 64 Hosts
CPU 1x or 2x Intel Xeon SP Gen 5 (Emerald Rapids) or Gen 4
(Sapphire Rapids)
1x or 2x Intel Xeon SP Gen 5 (Emerald Rapids) or Gen 4
(Sapphire Rapids)
Memory 32x DDR5 5600 MHz
(8TB maximum)
32x DDR5 5600 MHz
(8TB maximum)
Drive Bays 12x 2.5"
4x 3.5"
12x 2.5"
4x 3.5"
Drive configurations All Flash
Hybrid
All Flash
Hybrid
Disk Groups 1 - 4 1 - 4
HBA 4350-xi
440-xi
4350-xi
440-xi
Boot drives 2x M.2 SATA
2x 7mm SATA or NVMe
2x M.2 SATA
2x 7mm SATA or NVMe
OCP networking 1x OCP 3.0 adapter
1Gb, 10Gb, 25Gb, 100Gb
1x OCP 3.0 adapter
1Gb, 10Gb, 25Gb, 100Gb
PCIe networking Up to 3x adapters
10GBASE-T, 10Gb, 25Gb, 100Gb
Up to 3x adapters
10GBASE-T, 10Gb, 25Gb, 100Gb
GPUs 3x SW GPU up to 75W each
1x SW GPU up to 150W each
3x SW GPU up to 75W each
1x SW GPU up to 150W each
Hypervisor ESXi 8.0 u2 (Factory Installed)
ESXi 7.0 U3 (Factory Installed)
ESXi 8.0u2  (Factory Installed)
ESXi 7.0 U3 (Factory Installed)



The following table lists the standard specifications.

Table 2. Standard specifications
Components Specification
Machine types 7D6X - 3 year warranty
Form factor 1U rack.
Cluster Size With Lenovo ThinkAgile VX Series & VMware Cloud Foundation (VCF), you need a minimum of 4 nodes to create a management domain cluster.
With Lenovo ThinkAgile VX Series & VMware vSphere Foundation (VVF), you can create a vSAN cluster with a minimum 3 hosts and a maximum of 64 hosts. Requires vSAN 7.0 and later releases.
Processor Supports one or two 5th generation Intel Xeon Scalable processor (formerly codenamed "Emerald Rapids") or 4th-generation Intel Xeon Scalable processor (formerly codenamed "Sapphire Rapids"). Supports up to 64 cores per 5th generation processor and up to 60 cores per 4th generation processor, core speeds of up to 3.9 GHz, and TDP ratings of up to 350 W.
Chipset Intel C741 "Emmitsburg" chipset, part of the platform codenamed "Eagle Stream"
Memory 32 DIMM slots with two processors (16 DIMM slots per processor). Each processor has 8 memory channels, with 2 DIMMs per channel (DPC). Lenovo TruDDR5 RDIMMs, 9x4 RDIMMs, and 3DS RDIMMs are supported. DIMM slots are shared between standard system memory and persistent memory. DIMMs operate at up to 5600 MHz at 1 DPC and up to 4400 MHz at 2 DPC.
Memory maximum With RDIMMs: Up to 8TB by using 32x 256GB 3DS RDIMMs
Memory protection ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs excluding 9x4 RDIMMs, requires Platinum or Gold processors), and memory mirroring.
Drive bays

Up to 4x 3.5-inch or 12x 2.5-inch hot-swap drive bays:

  • Front bays can be 3.5-inch (4 bays) or 2.5-inch (4, 6, 8,10 bays)
  • Rear can be  2.5-inch (2 bays)
  • Combinations of SAS/SATA, NVMe, or AnyBay (supporting SAS, SATA or NVMe) are available
  • Internal M.2 module supporting up to two M.2 drives, for OS boot and drive storage support

Note: EDSFF drive bays are currently not supported.

Storage controller
  • Up to 12x Onboard NVMe ports
  • NVMe Retimer Adapter
  • 12 Gb SAS/SATA non-RAID: 440-8i and 440-16i HBAs
Network interfaces Dedicated OCP 3.0 SFF slot with PCIe 5.0 x16 host interface. Supports a variety of 2-port and 4-port adapters with 1GbE, 10GbE, 25GbE and 100GbE network connectivity. One port can optionally be shared with the XClarity Controller 2 (XCC2) management processor for Wake-on-LAN and NC-SI support.
PCI Expansion slots

Up to 3x PCIe 5.0 slots, all with rear access, plus a slot dedicated to the OCP adapter. Slot availability is based on riser selection and rear drive bay selection. Slot 3 requires two processors.

Four choices for rear-access slots:

  • 3x PCIe 5.0 x16 low-profile slots
  • 1x PCIe 5.0 x16 full-height half-length slot + 1x PCIe 4.0 x16 low-profile slot
  • 1x PCIe 5.0 x16 low-profile slot (also supports 2x rear 2.5-inch drive bays)
  • 2x PCIe 5.0 x16 low-profile slot (also supports 2x rear 7mm 2.5-inch drive bays)

For 2.5-inch front drive configurations, the server supports the installation of a RAID adapter or HBA in a dedicated area that does not consume any of the PCIe slots.

GPU support Supports up to 3x single-wide GPUs
Ports

Front: 1x USB 3.1 G1 (5 Gb/s) port, 1x USB 2.0 port (also for XCC local management), External diagnostics port, optional VGA port.

Rear: 2x USB 3.1 G1 (5 Gb/s) ports and 1x USB 2.0 port, 1x VGA video port, 1x RJ-45 1GbE systems management port for XCC remote management. Optional DB-9 COM serial port (installs in slot 3). Optional second RJ-45 1GbE systems management port for XCC remote management (installed in OCP adapter slot).

Internal: 1x USB 3.1 G1 connector for operating system or license key purposes

Cooling Up to 8x N+1 redundant hot swap 40 mm fans, configuration dependent. One fan integrated in each power supply.
Power supply Up to two hot-swap redundant AC power supplies, 80 PLUS Platinum or 80 PLUS Titanium certification. 750 W, 1100 W and 1800 W AC options, supporting 220 V AC. 750 W and 1100 W options also support 110V input supply. In China only, all power supply options support 240 V DC. Also available is a 1100W power supply with a -48V DC input.
Video Embedded graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller 2 management controller. Maximum resolution is 1920x1200 32bpp at 60Hz.
Hot-swap parts Drives, power supplies, and fans.
Systems management Operator panel with status LEDs. Optional External Diagnostics Handset with LCD display. Models with 8x 2.5-inch front drive bays can optionally support an Integrated Diagnostics Panel. XClarity Controller 2 (XCC2) embedded management based on the ASPEED AST2600 baseboard management controller (BMC), XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XCC Platinum to enable remote control functions and other features.
Security features Chassis intrusion switch, Power-on password, administrator's password, Root of Trust module supporting TPM 2.0 and Platform Firmware Resiliency (PFR). Optional lockable front security bezel.
Software

All ThinkAgile VX Series products (Integrated Systems and Certified Nodes) will support the following Primary Software Stack (3-year & 5-year terms) and Add-Ons.

Primary Software

  1.  VMware Cloud Foundation 5 (VCF)
  2.  VMware vSphere Foundation 8 (VVF)

Add-On Options (requires purchase of a Primary Software version)

  1. VMware vSAN 8 (for capacity over TiB allocation from primary SKU)
  2. VMware Live Recovery
  3. VMware Firewall (requires VCF)
  4. VMware Firewall with Advanced Threat Prevention (requires VCF)
  5. VMware Avi Load Balancer
  6. VMware Private AI Foundation (requires VCF)
Hypervisors VMware ESXi. See Operating system support section for details.
Limited warranty Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
Service and support Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications.
Dimensions Width: 440 mm (17.3 in.), height: 43 mm (1.7 in.), depth: 773 mm (30.4 in.).
Weight Maximum: 26.3 kg (58 lb)

Models

Factory-integrated models of the integrated systems and certified nodes are configured by using the Lenovo Data Center Solution Configurator (DCSC), http://dcsc.lenovo.com

To ensure that the controlled GPUs and accelerators are only sold in the supported markets, the following configure-to-order base machine-type models (CTO MTMs) are selectable in DCSC:

  • Standard Open models are available in all markets worldwide. Controlled GPUs cannot be configured using these models. These are CTO1WW models.
  • GPU Controlled models are used to order any of the controlled GPUs and accelerators. Controlled models are not available in affected markets. If you start from a controlled model, your configuration must include a controlled GPUs.

Note:

  • For all models listed in the GPU Controlled models column, one of the controlled GPUs must be selected in the DCSC configurator. DCSC will display an error if you configuration does not include one of the controlled GPUs.
  • It is highly recommended to engage a Lenovo representative early in a project that includes the ThinkAgile VX Series Integrated Systems and Certified Nodes

The following table lists the base CTO models.

Table 3. CTO base models
Server model Standard Open models GPU Controlled models
  These CTO models are available in all markets. Configurations based on these MTMs cannot include controlled GPUs. These CTO models are not available in affected markets. Configurations based on these MTMs must include controlled GPUs.
ThinkAgile VX630 V3 Integrated System 7D6XCTO1WW 7D6XCTOAWW
ThinkAgile VX630 V3 Certified Node 7D6XCTO2WW 7D6XCTOBWW

Comparison with the ThinkSystem SR630 V3

The ThinkAgile VX630 V3 Integrated System and Certified Node are based on the ThinkSystem SR630 V3 server, however there are key differences:

  • No onboard SATA controller support
  • Persistent Memory not supported
  • RAID adapter supported for boot only
  • VROC RAID support for boot only
  • No SATA HDDs
  • Encryption not supported on SED drives
  • Fibre Channel support for data migration only
  • No InfiniBand support
  • Drives are categorized as Cache or Capacity drives and are formed as disk groups (up to 5 disk groups for OSA configurations.  ESA configurations only consist of a storage tier, no cache drives or disk groups required

For details about the ThinkSystem SR630 V3, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server

To verify what specific hardware components are supported with the VX630 V3, see the DCSC configurator:
https://dcsc.lenovo.com

Processors

The VX630 V3 supports processors in either the 5th Gen Intel Xeon Scalable Processor family or the 4th Gen Intel Xeon Scalable Processor family.

Topics in this section:

5th Gen Intel Xeon Scalable processors

The VX630 V3 systems support the following processors. The systems support 1 or 2 processors installed.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#processors

Table 4. Processor choices
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
None BYVT Intel Xeon Bronze 3508U 8C 125W 2.1GHz Processor 1 1
None BYW3 Intel Xeon Silver 4509Y 8C 125W 2.6GHz Processor 2 2
None BYW4 Intel Xeon Silver 4510 12C 150W 2.4GHz Processor 2 2
None BYVS Intel Xeon Silver 4510T 12C 115W 2.0GHz Processor 2 2
None BYVP Intel Xeon Silver 4514Y 16C 150W 2.0GHz Processor 2 2
None BYW6 Intel Xeon Silver 4516Y+ 24C 185W 2.2GHz Processor 2 2
None BYVU Intel Xeon Gold 5512U 28C 185W 2.1GHz Processor 1 1
None BYVW Intel Xeon Gold 5515+ 8C 165W 3.2GHz Processor 2 2
None BYW7 Intel Xeon Gold 5520+ 28C 205W 2.2GHz Processor 2 2
None BYVX Intel Xeon Gold 6526Y 16C 195W 2.8GHz Processor 2 2
None BYWK Intel Xeon Gold 6530 32C 270W 2.1GHz Processor 2 2
None BYW0 Intel Xeon Gold 6534 8C 195W 3.9GHz Processor 2 2
None BYVQ Intel Xeon Gold 6538N 32C 205W 2.1GHz Processor 2 2
None BYW8 Intel Xeon Gold 6538Y+ 32C 225W 2.2GHz Processor 2 2
None BYVY Intel Xeon Gold 6542Y 24C 250W 2.9GHz Processor 2 2
None BYW1 Intel Xeon Gold 6544Y 16C 270W 3.6GHz Processor 2 2
None BYVR Intel Xeon Gold 6548N 32C 250W 2.8GHz Processor 2 2
None BYVZ Intel Xeon Gold 6548Y+ 32C 250W 2.5GHz Processor 2 2
None BYW9 Intel Xeon Gold 6554S 36C 270W 2.2GHz Processor 2 2
None BYVV Intel Xeon Gold 6558Q 32C 350W 3.2GHz Processor 2 2
None BYW5 Intel Xeon Platinum 8558 48C 330W 2.1GHz Processor 2 2
None BYWA Intel Xeon Platinum 8558P 48C 350W 2.7GHz Processor 2 2
None BYWE Intel Xeon Platinum 8558U 48C 300W 2.0GHz Processor 1 1
None BYW2 Intel Xeon Platinum 8562Y+ 32C 300W 2.8GHz Processor 2 2
None BYWF Intel Xeon Platinum 8568Y+ 48C 350W 2.3GHz Processor 2 2
None BYWG Intel Xeon Platinum 8570 56C 350W 2.1GHz Processor 2 2
None BYWD Intel Xeon Platinum 8571N 52C 300W 2.4GHz Processor 1 1
None BYWH Intel Xeon Platinum 8580 60C 350W 2.0GHz Processor 2 2
None BYWC Intel Xeon Platinum 8581V 60C 270W 2.0GHz Processor 1 1
None BYWJ Intel Xeon Platinum 8592+ 64C 350W 1.9GHz Processor 2 2
None BYWB Intel Xeon Platinum 8592V 64C 330W 2.0GHz Processor 2 2

4th Gen Intel Xeon Scalable processors

The VX630 V3 systems support the following processors. The systems support 1 or 2 processors installed.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#processors

Table 5. Processor choices
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
None BXHX Intel Xeon 5423N 20C 145W 2.1GHz Processor 1 1
None BXHY Intel Xeon 5433N 20C 160W 2.3GHz Processor 1 1
None BYQK Intel Xeon 6403N 24C 185W 1.9GHz Processor 1 1
None BYQH Intel Xeon 6423N 28C 195W 2.0GHz Processor 1 1
None BYQJ Intel Xeon 6433N 32C 205W 2.0GHz Processor 1 1
None BYQG Intel Xeon 6443N 32C 195W 1.6GHz Processor 1 1
None BQ68 Intel Xeon Bronze 3408U 8C 125W 1.8GHz Processor 1 1
None BQ64 Intel Xeon Silver 4410T 10C 150W 2.7GHz Processor 2 2
None BQ67 Intel Xeon Silver 4410Y 12C 150W 2.0GHz Processor 2 2
None BQ69 Intel Xeon Silver 4416+ 20C 165W 2.0GHz Processor 2 2
None BQ6J Intel Xeon Gold 5411N 24C 165W 1.9GHz Processor 1 1
None BQ63 Intel Xeon Gold 5415+ 8C 150W 2.9GHz Processor 2 2
None BQ6L Intel Xeon Gold 5416S 16C 150W 2.0GHz Processor 2 2
None BQ6H Intel Xeon Gold 5418N 24C 165W 1.8GHz Processor 2 2
None BQ66 Intel Xeon Gold 5418Y 24C 185W 2.0GHz Processor 2 2
None BQ65 Intel Xeon Gold 5420+ 28C 205W 2.0GHz Processor 2 2
None BPPD Intel Xeon Gold 6414U 32C 250W 2.0GHz Processor 1 1
None BQ6C Intel Xeon Gold 6416H 18C 165W 2.2GHz Processor 2 2
None BQ6B Intel Xeon Gold 6418H 24C 185W 2.1GHz Processor 2 2
None BQ6G Intel Xeon Gold 6421N 32C 185W 1.8GHz Processor 1 1
None BPQF Intel Xeon Gold 6426Y 16C 185W 2.5GHz Processor 2 2
None BQ6F Intel Xeon Gold 6428N 32C 185W 1.8GHz Processor 2 2
None BPPC Intel Xeon Gold 6430 32C 270W 2.1GHz Processor 2 2
None BPQC Intel Xeon Gold 6434 8C 195W 3.7GHz Processor 2 2
None BQ6E Intel Xeon Gold 6434H 8C 195W 3.7GHz Processor 2 2
None BQ6K Intel Xeon Gold 6438M 32C 205W 2.2GHz Processor 2 2
None BQ6D Intel Xeon Gold 6438N 32C 205W 2.0GHz Processor 2 2
None BQ62 Intel Xeon Gold 6438Y+ 32C 205W 2.0GHz Processor 2 2
None BPQE Intel Xeon Gold 6442Y 24C 225W 2.6GHz Processor 2 2
None BPQB Intel Xeon Gold 6444Y 16C 270W 3.6GHz Processor 2 2
None BQ6A Intel Xeon Gold 6448H 32C 250W 2.4GHz Processor 2 2
None BPQD Intel Xeon Gold 6448Y 32C 225W 2.1GHz Processor 2 2
None BPPM Intel Xeon Gold 6454S 32C 270W 2.2GHz Processor 2 2
None BPPH Intel Xeon Platinum 8444H 16C 270W 2.9GHz Processor 2 2
None BPPG Intel Xeon Platinum 8450H 28C 250W 2.0GHz Processor 2 2
None BPPB Intel Xeon Platinum 8452Y 36C 300W 2.0GHz Processor 2 2
None BPPF Intel Xeon Platinum 8454H 32C 270W 2.1GHz Processor 2 2
None BPPT Intel Xeon Platinum 8458P 44C 350W 2.7GHz Processor 2 2
None BPPN Intel Xeon Platinum 8460H 40C 330W 2.2GHz Processor 2 2
None BPPQ Intel Xeon Platinum 8460Y+ 40C 300W 2.0GHz Processor 2 2
None BPPK Intel Xeon Platinum 8461V 48C 300W 2.2GHz Processor 1 1
None BPQA Intel Xeon Platinum 8462Y+ 32C 300W 2.8GHz Processor 2 2
None BPPU Intel Xeon Platinum 8468 48C 350W 2.1GHz Processor 2 2
None BPPE Intel Xeon Platinum 8468H 48C 330W 2.1GHz Processor 2 2
None BPPP Intel Xeon Platinum 8468V 48C 330W 2.4GHz Processor 2 2
None BN0N Intel Xeon Platinum 8470 52C 350W 2.0GHz Processor 2 2
None BPPJ Intel Xeon Platinum 8470N 52C 300W 1.7GHz Processor 2 2
None BPPR Intel Xeon Platinum 8471N 52C 300W 1.8GHz Processor 1 1
None BN0M Intel Xeon Platinum 8480+ 56C 350W 2.0GHz Processor 2 2
None BPPS Intel Xeon Platinum 8490H 60C 350W 1.9GHz Processor 2 2

Memory

5th Generation Memory options

The VX630 V3 systems support the following 5th generation memory options.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#memory-options

Table 6. Memory options
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
RDIMMs - 5600 MHz
4X77A90991 BZ4U ThinkSystem 32GB TruDDR5 Performance+ 5600MHz (2Rx8) RDIMM 32 32
4X77A90992 BZ4V ThinkSystem 64GB TruDDR5 Performance+ 5600MHz (2Rx4) 10x4 RDIMM 32 32
4X77A88050 BWJF ThinkSystem 32GB TruDDR5 5600MHz (1Rx4) 9x4 RDIMM 32 32
4X77A88053 BWHT ThinkSystem 64GB TruDDR5 5600MHz (2Rx4) 9x4 RDIMM 32 32
4X77A88640 BX8Z ThinkSystem 96GB TruDDR5 5600MHz (2Rx4) 9x4 RDIMM 32 32
4X77A88049 BWHW ThinkSystem 32GB TruDDR5 5600MHz (1Rx4) 10x4 RDIMM 32 32
4X77A88052 BWHS ThinkSystem 64GB TruDDR5 5600MHz (2Rx4) 10x4 RDIMM 32 32
4X77A88639 BX8Y ThinkSystem 48GB TruDDR5 5600MHz (1Rx4) 10x4 RDIMM 32 32
4X77A88058 BWHV ThinkSystem 96GB TruDDR5 5600MHz (2Rx4) RDIMM 32 32
4X77A88087 BWJE ThinkSystem 16GB TruDDR5 5600MHz (1Rx8) RDIMM 32 32
4X77A88051 BWJC ThinkSystem 32GB TruDDR5 5600MHz (2Rx8) RDIMM 32 32
4X77A88056 BWSL ThinkSystem 24GB TruDDR5 5600MHz (1Rx8) RDIMM 32 32
4X77A88057 BWJD ThinkSystem 48GB TruDDR5 5600MHz (2Rx8) RDIMM 32 32
3DS RDIMMs - 5600 MHz
4X77A88054 BWHU ThinkSystem 128GB TruDDR5 5600MHz (4Rx4) 3DS RDIMM 32 32

4th Generation Memory options

The VX630 V3 systems support the following 4th generation memory options.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#memory-options

Table 7. Memory options
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
RDIMMs
4X77A77029 BKTL ThinkSystem 16GB TruDDR5 4800MHz (1Rx8) RDIMM 32 32
4X77A87033 C1HB ThinkSystem 48GB TruDDR5 4800MHz (2Rx8) RDIMM 32 32
4X77A77030 BNF6 ThinkSystem 32GB TruDDR5 4800MHz (1Rx4) 10x4 RDIMM 32 32
4X77A77483 BNW5 ThinkSystem 32GB TruDDR5 4800MHz (1Rx4) 9x4 RDIMM 32 32
4X77A77031 BKTM ThinkSystem 32GB TruDDR5 4800MHz (2Rx8) RDIMM 32 32
4X77A77032 BNF9 ThinkSystem 64GB TruDDR5 4800MHz (2Rx4) 10x4 RDIMM 32 32
4X77A77033 BKTN ThinkSystem 64GB TruDDR5 4800MHz (2Rx4) 9x4 RDIMM 32 32
4X77A87034 BZC2 ThinkSystem 96GB TruDDR5 4800MHz (2Rx4) RDIMM 32 32
3DS RDIMMs
4X77A77034 BNFC ThinkSystem 128GB TruDDR5 4800MHz (4Rx4) 3DS RDIMM v2 32 32
CTO Only BY8F ThinkSystem 128GB TruDDR5 4800MHz (4Rx4) 3DS RDIMM v1 32 32
4X77A77035 BNF8 ThinkSystem 256GB TruDDR5 4800MHz (8Rx4) 3DS RDIMM v2 32 32

Disk Groups

The following table lists the supported Disk Groups for each VX system.

Table 8. Disk Groups
Drive Selection Rules VX630 V3 IS VX630 V3 CN
Model Type Hybrid (HY)
All Flash (AF)
Hybrid (HY)
All Flash (AF)
Maximum number of drives 12 12
Number of Disk Groups 1-4 1 - 4
Number of Cache Drives per Disk Group 1 1
Number of Capacity Drives per Disk Group 2 - 7 2 - 7
Allowed Capacity Drive Quantities:
1 Disk Group (1 Cache Drive) 2, 3, 4, 5, 6, or 7 2, 3, 4, 5, 6 or 7
2 Disk Groups (2 Cache Drives) 4, 6, 8 or 10 4, 6, 8 or 10
3 Disk Groups (3 Cache Drives) 6, 9 6, 9
4 Disk Groups (4 Cache Drives) 8 8

Internal storage

The VX630 V3 support 4x 3.5-inch or 12x 2.5-inch drive bays, depending on the selected chassis and backplane configuration.

  • Front drive bays:
    • 12x 2.5-inch SAS/SATA hot-swap bays
    • 12x 2.5-inch NVMe hot-swap bays
  • Rear drive bays
    • 4x 3.5-inch SAS/SATA hot-swap bays
    • 4x 3.5-inch NVMe hot-swap bays
    • Also supports 2x 7mm hot-swap drives bays

The server also supports two M.2 drives, installed in an M.2 adapter internal to the server for boot drives. These are an alternative to the 7mm hot-swap drives.

The choice of backplanes supported varies by system, as listed in the following table.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#internal-storage

Table 9. Drive backplanes
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
Front 3.5-inch drive backplanes
None B8L3 ThinkSystem 1U/2U 4x3.5" SAS/SATA Backplane 1 1
None B8N1 ThinkSystem 1U 4x3.5" AnyBay Backplane 1 1
Front 2.5-inch drive backplanes
None BCGB ThinkSystem 1U 4x2.5" SAS/SATA Backplane 1 1
None BPC9 ThinkSystem 1U 4x 2.5" NVMe Gen 4 Backplane 1 1
None B8N0 ThinkSystem 1U 8x2.5" SAS/SATA Backplane 1 1
None BHU8 ThinkSystem 1U 10x2.5" SAS/SATA Backplane 1 1
None B8MX ThinkSystem 1U 10x2.5" (6x SAS/SATA 4x AnyBay) Backplane 1 1
4XH7A87141 BRQY ThinkSystem 1U 2.5" 6 SAS/SATA 4 AnyBay Gen5 Backplane 1 1
None BCQN ThinkSystem 1U 2.5" 6 SAS/SATA 4 NVMe Backplane 1 1
None BCQP ThinkSystem 1U 10x2.5" (6x SAS/SATA 2x AnyBay 2x NVMe) Backplane 1 1
4XH7A87140 BU1W ThinkSystem 1U 10x2.5" (6x SAS/SATA 2x AnyBay 2x NVMe) Gen5 Backplane 1 1
None BB3T ThinkSystem 1U 10x2.5" AnyBay Backplane 1 1
None BLKC ThinkSystem 1U 10x2.5" AnyBay Gen5 Backplane 1 1
None BCQQ ThinkSystem 1U 10x2.5" NVMe Backplane 1 1
None BRQX ThinkSystem 1U 2.5" 10 NVMe Gen5 Backplane 1 1
Rear - 2.5-inch drive backplanes
None BDY6 ThinkSystem 1U 2x2.5" NVMe Rear Backplane 1 1
None B8MY ThinkSystem 1U 2x2.5" SAS/SATA Rear Backplane 1 1
Rear 7mm backplanes
None BPCB ThinkSystem 1U/2U 2x7mm SATA/NVMe Rear Backplane 1 1

For OS boot functions, the systems also support one or two 7mm hot-swap drives at the rear of the server, or one or two M.2 drives installed on an adapter internal to the server. The following table lists the supported controllers/enablement kits for M.2 and 7mm boot drives.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#internal-storage



Table 10. Boot Drive Enablement
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
M.2 enablement kits
4Y37A09750 B8P9 ThinkSystem M.2 NVMe 2-Bay RAID Adapter 1 1
4Y37A90063 BYFF ThinkSystem M.2 RAID B540i-2i SATA/NVMe Adapter 1 1
7mm enablement kits
4XH7A61058 B8Q2 ThinkSystem 1U 7mm Drive Kit w/ NVMe RAID 1 1
4Y37A90062 BYFG ThinkSystem 7mm SATA/NVMe 2-Bay Rear Hot-Swap RAID Enablement Kit 1 1

Controllers for internal storage

The VX630 V3 support the following storage controller options.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#controllers-for-internal-storage

Table 11. Controllers for internal storage
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
SAS/SATA HBA - PCIe 4.0
4Y37A78601 BM50 ThinkSystem 440-16i SAS/SATA PCIe Gen4 12Gb HBA 1 1
4Y37A78602 BM51 ThinkSystem 440-8i SAS/SATA PCIe Gen4 12Gb HBA 1 1
4Y37A09725 B8P1 ThinkSystem 440-16i SAS/SATA PCIe Gen4 12Gb Internal HBA 1 1
SAS/SATA HBA - PCIe 3.0
4Y37A72481 BJHJ ThinkSystem 4350-16i SAS/SATA 12Gb HBA 1 1
4Y37A72480 BJHH ThinkSystem 4350-8i SAS/SATA 12Gb HBA 1 1
NVMe adapters
4C57A65446 B98C ThinkSystem 4-Port PCIe Gen4 NVMe Retimer Adapter 1 1

Internal drive options

This section lists the supported drives:

Configuration Note:

  • VMware will no longer support higher capacity hard drives greater than 8TB
  • Express Storage Architecture (ESA) supports a minimum of 2 drives and a maximum of 24 drives.  Please reference the vSAN ESA ReadyNode Hardware Guidance for additional requirements.
  • VMware vSAN certification for Generic NVMe drives: The drives are listed in the VMware Compatibility Guide (VCG) under the drive vendor company name instead of Lenovo. To check a drive for vSAN certification, search the VCG using the Supplier part number. Part numbers can be found using the Product Guide for the corresponding Drive Family on Lenovo Press https://lenovopress.lenovo.com/servers/options/drives#sort=last_update

Boot drives

The VX630 V3 systems support the following drive for boot functions.

Table 12. Boot drives
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
7mm 6 Gb SATA SSDs
4XB7A82264 BQ1U ThinkSystem 7mm 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD 2 2
4XB7A82265 BQ1V ThinkSystem 7mm 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD 2 2
4XB7A82266 BQ1W ThinkSystem 7mm 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD 2 2
4XB7A17106 BK79 ThinkSystem 7mm S4520 240GB Read Intensive SATA 6Gb HS SSD 2 2
4XB7A17107 BK7A ThinkSystem 7mm S4520 480GB Read Intensive SATA 6Gb HS SSD 2 2
4XB7A17108 BK7B ThinkSystem 7mm S4520 960GB Read Intensive SATA 6Gb HS SSD 2 2
7mm PCIe 4.0 NVMe Drives
4XB7A82853 BPZ4 ThinkSystem 7mm U.3 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 HS SSD 2 2
4XB7A82855 BPZ5 ThinkSystem 7mm U.3 7450 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 2 2
4XB7A82856 BPZ6 ThinkSystem 7mm U.3 7450 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 2 2
M.2 6 Gb SATA SSDs
4XB7A82286 BQ1Z ThinkSystem M.2 5400 PRO 240GB Read Intensive SATA 6Gb NHS SSD 2 2
4XB7A82287 BQ1Y ThinkSystem M.2 5400 PRO 480GB Read Intensive SATA 6Gb NHS SSD 2 2
4XB7A82288 BQ20 ThinkSystem M.2 5400 PRO 960GB Read Intensive SATA 6Gb NHS SSD 2 2
4XB7A89422 BYF7 ThinkSystem M.2 ER3 240GB Read Intensive SATA 6Gb NHS SSD 2 2
4XB7A90049 BYF8 ThinkSystem M.2 ER3 480GB Read Intensive SATA 6Gb NHS SSD 2 2
4XB7A90230 BYF9 ThinkSystem M.2 ER3 960GB Read Intensive SATA 6Gb NHS SSD 2 2
M.2 PCIe 4.0 NVMe Drives
4XB7A13999 BKSR ThinkSystem M.2 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 NHS SSD 2 2
4XB7A90102 BXMH ThinkSystem M.2 PM9A3 960GB Read Intensive NVMe PCIe 4.0 x4 NHS SSD 2 2

Internal drives for VX630 V3 Integrated System

The following table lists the drives supported in the VX630 V3 Integrated System. For both All Flash Storage and Hybrid Storage configurations, drives are classified as either Cache drives, Capacity drives, or both.

Table 13. Drives supported in the VX630 V3 Integrated System
Part number Feature Description All Flash All Flash Hybrid
ESA Cache Capacity Cache Capacity
2.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00027 AUM1 ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD No No No No 12
7XB7A00028 AUM2 ThinkSystem 2.5" 1.8TB 10K SAS 12Gb Hot Swap 512e HDD No No No No 12
4XB7A83970 BRG7 ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD v2 No No No No 12
2.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80318 BNWC ThinkSystem 2.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80319 BNWE ThinkSystem 2.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80320 BNWF ThinkSystem 2.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80321 BP3E ThinkSystem 2.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80322 BP3J ThinkSystem 2.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80323 BP3D ThinkSystem 2.5" PM1653 30.72TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80340 BNW8 ThinkSystem 2.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
4XB7A80341 BNW9 ThinkSystem 2.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
4XB7A80342 BNW6 ThinkSystem 2.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
4XB7A80343 BP3K ThinkSystem 2.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
2.5-inch hot-swap 6 Gb SAS SSDs
4XB7A82289 BQ21 ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82290 BQ24 ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82291 BQ22 ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82292 BQ23 ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82258 BQ1Q ThinkSystem 2.5" 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82259 BQ1P ThinkSystem 2.5" 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82260 BQ1R ThinkSystem 2.5" 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82261 BQ1X ThinkSystem 2.5" 5400 PRO 1.92TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82262 BQ1S ThinkSystem 2.5" 5400 PRO 3.84TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82263 BQ1T ThinkSystem 2.5" 5400 PRO 7.68TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17101 BA7G ThinkSystem 2.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17102 BA7H ThinkSystem 2.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17103 BA7J ThinkSystem 2.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17104 BK77 ThinkSystem 2.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17105 BK78 ThinkSystem 2.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17125 BA7Q ThinkSystem 2.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
4XB7A17126 BA4T ThinkSystem 2.5" S4620 960GB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
4XB7A17127 BA4U ThinkSystem 2.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
4XB7A17128 BK7L ThinkSystem 2.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
2.5-inch hot-swap PCIe 4.0 NVMe SSDs
4XB7A13941 BMGD ThinkSystem 2.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A13942 BMGE ThinkSystem 2.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A13943 BNEF ThinkSystem 2.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A13631 BNEQ ThinkSystem 2.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A17129 BNEG ThinkSystem 2.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 12 No
4XB7A17130 BNEH ThinkSystem 2.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 12 No
4XB7A17133 BNEZ ThinkSystem 2.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 12 No
4XB7A17136 BA4V ThinkSystem 2.5" U.2 P5620 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A17158 BKKY ThinkSystem 2.5" U.2 P5800X 400GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A17159 BKKZ ThinkSystem 2.5" U.2 P5800X 800GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A17160 BMM8 ThinkSystem 2.5" U.2 P5800X 1.6TB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A79639 BNF1 ThinkSystem 2.5" U.3 7450 MAX 800GB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A13967 BNEJ ThinkSystem 2.5" U.3 7450 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A13970 BNEY ThinkSystem 2.5" U.3 7450 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A13971 BNEL ThinkSystem 2.5" U.3 7450 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A84056 BRG0 ThinkSystem 2.5" U.3 7450 MAX 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95055 C2BV ThinkSystem 2.5" U.3 7500 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A95056 C2BW ThinkSystem 2.5" U.3 7500 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A95057 C2BF ThinkSystem 2.5" U.3 7500 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A95058 C2BX ThinkSystem 2.5" U.3 7500 MAX 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A79646 BNF3 ThinkSystem 2.5" U.3 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 12 No No
4XB7A79647 BNF2 ThinkSystem 2.5" U.3 7450 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A79648 BNF5 ThinkSystem 2.5" U.3 7450 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A79649 BNF4 ThinkSystem 2.5" U.3 7450 PRO 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A83097 BQAV ThinkSystem 2.5" U.3 7450 PRO 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95050 C2BR ThinkSystem 2.5" U.3 7500 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95051 C2BS ThinkSystem 2.5" U.3 7500 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95052 C2BT ThinkSystem 2.5" U.3 7500 PRO 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95053 C2BU ThinkSystem 2.5" U.3 7500 PRO 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
3.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00042 AUU5 ThinkSystem 3.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No No 4
7XB7A00043 AUU6 ThinkSystem 3.5" 4TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No No 4
7XB7A00044 AUU7 ThinkSystem 3.5" 6TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No No 4
7XB7A00045 B0YR ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No No 4
3.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80324 BNWD ThinkSystem 3.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80325 BNWG ThinkSystem 3.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80326 BNWH ThinkSystem 3.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80327 BP3F ThinkSystem 3.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80328 BP3H ThinkSystem 3.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80345 BNWA ThinkSystem 3.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD No 4 4 4 No
4XB7A80346 BNWB ThinkSystem 3.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD No 4 4 4 No
4XB7A80347 BP3G ThinkSystem 3.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD No 4 4 4 No
3.5-inch hot-swap 6 Gb SAS SSDs
4XB7A17119 BA7L ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17120 BA7M ThinkSystem 3.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17121 BA7N ThinkSystem 3.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17122 BK7F ThinkSystem 3.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17123 BK7G ThinkSystem 3.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17137 BA4W ThinkSystem 3.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
4XB7A17138 BA4X ThinkSystem 3.5" S4620 960GB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
4XB7A17139 BA4Y ThinkSystem 3.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
4XB7A17140 BK7P ThinkSystem 3.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
3.5-inch hot-swap PCIe 4.0 NVMe SSDs
4XB7A13632 BNES ThinkSystem 3.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A76777 BNET ThinkSystem 3.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A76778 BNEU ThinkSystem 3.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A76779 BNF0 ThinkSystem 3.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A17141 BNEK ThinkSystem 3.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17143 BNEM ThinkSystem 3.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17144 BNEN ThinkSystem 3.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17148 BNEP ThinkSystem 3.5" U.2 P5620 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A17161 BMM7 ThinkSystem 3.5" U.2 P5800X 400GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17162 BMM5 ThinkSystem 3.5" U.2 P5800X 800GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A77070 BMM6 ThinkSystem 3.5" U.2 P5800X 1.6TB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 4 4 No No

Internal drives for VX630 V3 Certified Node

The following table lists the drives supported in the VX630 V3 Certified Node. For both All Flash Storage and Hybrid Storage configurations, drives are classified as either Cache drives, Capacity drives, or both.

Table 14. Drives supported in the VX630 V3 Certified Node
Part number Feature Description All Flash All Flash Hybrid
ESA Cache Capacity Cache Capacity
2.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00027 AUM1 ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD No No No No 12
7XB7A00028 AUM2 ThinkSystem 2.5" 1.8TB 10K SAS 12Gb Hot Swap 512e HDD No No No No 12
4XB7A83970 BRG7 ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD v2 No No No No 12
2.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80318 BNWC ThinkSystem 2.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80319 BNWE ThinkSystem 2.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80320 BNWF ThinkSystem 2.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80321 BP3E ThinkSystem 2.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80322 BP3J ThinkSystem 2.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80323 BP3D ThinkSystem 2.5" PM1653 30.72TB Read Intensive SAS 24Gb HS SSD No No 12 No No
4XB7A80340 BNW8 ThinkSystem 2.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
4XB7A80341 BNW9 ThinkSystem 2.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
4XB7A80342 BNW6 ThinkSystem 2.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
4XB7A80343 BP3K ThinkSystem 2.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD No 12 12 12 No
2.5-inch hot-swap 6 Gb SAS SSDs
4XB7A82289 BQ21 ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82290 BQ24 ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82291 BQ22 ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82292 BQ23 ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD No No 12 12 No
4XB7A82258 BQ1Q ThinkSystem 2.5" 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82259 BQ1P ThinkSystem 2.5" 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82260 BQ1R ThinkSystem 2.5" 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82261 BQ1X ThinkSystem 2.5" 5400 PRO 1.92TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82262 BQ1S ThinkSystem 2.5" 5400 PRO 3.84TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A82263 BQ1T ThinkSystem 2.5" 5400 PRO 7.68TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17101 BA7G ThinkSystem 2.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17102 BA7H ThinkSystem 2.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17103 BA7J ThinkSystem 2.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17104 BK77 ThinkSystem 2.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17105 BK78 ThinkSystem 2.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No No 12 No No
4XB7A17125 BA7Q ThinkSystem 2.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
4XB7A17126 BA4T ThinkSystem 2.5" S4620 960GB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
4XB7A17127 BA4U ThinkSystem 2.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
4XB7A17128 BK7L ThinkSystem 2.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD No 12 12 12 No
2.5-inch hot-swap PCIe 4.0 NVMe SSDs
4XB7A13941 BMGD ThinkSystem 2.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A13942 BMGE ThinkSystem 2.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A13943 BNEF ThinkSystem 2.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A13631 BNEQ ThinkSystem 2.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A17129 BNEG ThinkSystem 2.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 12 No
4XB7A17130 BNEH ThinkSystem 2.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 12 No
4XB7A17133 BNEZ ThinkSystem 2.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 12 No
4XB7A17136 BA4V ThinkSystem 2.5" U.2 P5620 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A17158 BKKY ThinkSystem 2.5" U.2 P5800X 400GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A17159 BKKZ ThinkSystem 2.5" U.2 P5800X 800GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A17160 BMM8 ThinkSystem 2.5" U.2 P5800X 1.6TB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A79639 BNF1 ThinkSystem 2.5" U.3 7450 MAX 800GB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 12 12 No No
4XB7A13967 BNEJ ThinkSystem 2.5" U.3 7450 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A13970 BNEY ThinkSystem 2.5" U.3 7450 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A13971 BNEL ThinkSystem 2.5" U.3 7450 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A84056 BRG0 ThinkSystem 2.5" U.3 7450 MAX 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95055 C2BV ThinkSystem 2.5" U.3 7500 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A95056 C2BW ThinkSystem 2.5" U.3 7500 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A95057 C2BF ThinkSystem 2.5" U.3 7500 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 12 12 No No
4XB7A95058 C2BX ThinkSystem 2.5" U.3 7500 MAX 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A79646 BNF3 ThinkSystem 2.5" U.3 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 12 No No
4XB7A79647 BNF2 ThinkSystem 2.5" U.3 7450 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A79648 BNF5 ThinkSystem 2.5" U.3 7450 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A79649 BNF4 ThinkSystem 2.5" U.3 7450 PRO 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A83097 BQAV ThinkSystem 2.5" U.3 7450 PRO 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95050 C2BR ThinkSystem 2.5" U.3 7500 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95051 C2BS ThinkSystem 2.5" U.3 7500 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95052 C2BT ThinkSystem 2.5" U.3 7500 PRO 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
4XB7A95053 C2BU ThinkSystem 2.5" U.3 7500 PRO 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD 12 No 12 No No
3.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00042 AUU5 ThinkSystem 3.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No No 4
7XB7A00043 AUU6 ThinkSystem 3.5" 4TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No No 4
7XB7A00044 AUU7 ThinkSystem 3.5" 6TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No No 4
7XB7A00045 B0YR ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No No 4
3.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80324 BNWD ThinkSystem 3.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80325 BNWG ThinkSystem 3.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80326 BNWH ThinkSystem 3.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80327 BP3F ThinkSystem 3.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80328 BP3H ThinkSystem 3.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD No No 4 No No
4XB7A80345 BNWA ThinkSystem 3.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD No 4 4 4 No
4XB7A80346 BNWB ThinkSystem 3.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD No 4 4 4 No
4XB7A80347 BP3G ThinkSystem 3.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD No 4 4 4 No
3.5-inch hot-swap 6 Gb SAS SSDs
4XB7A17119 BA7L ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17120 BA7M ThinkSystem 3.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17121 BA7N ThinkSystem 3.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17122 BK7F ThinkSystem 3.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17123 BK7G ThinkSystem 3.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No No 4 No No
4XB7A17137 BA4W ThinkSystem 3.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
4XB7A17138 BA4X ThinkSystem 3.5" S4620 960GB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
4XB7A17139 BA4Y ThinkSystem 3.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
4XB7A17140 BK7P ThinkSystem 3.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD No 4 4 4 No
3.5-inch hot-swap PCIe 4.0 NVMe SSDs
4XB7A13632 BNES ThinkSystem 3.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A76777 BNET ThinkSystem 3.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A76778 BNEU ThinkSystem 3.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A76779 BNF0 ThinkSystem 3.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A17141 BNEK ThinkSystem 3.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17143 BNEM ThinkSystem 3.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17144 BNEN ThinkSystem 3.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17148 BNEP ThinkSystem 3.5" U.2 P5620 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD No No 4 No No
4XB7A17161 BMM7 ThinkSystem 3.5" U.2 P5800X 400GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A17162 BMM5 ThinkSystem 3.5" U.2 P5800X 800GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 4 4 No No
4XB7A77070 BMM6 ThinkSystem 3.5" U.2 P5800X 1.6TB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 4 4 No No

Network adapters

The VX630 V3 systems support the following networking options.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#i-o-expansion
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#network-adapters

Table 15. OCP network adapters
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
Gigabit Ethernet
4XC7A88428 BW97 ThinkSystem Intel I350 1GbE RJ45 4-Port OCP Ethernet Adapter V2 1 1
4XC7A08235 B5T1 ThinkSystem Broadcom 5719 1GbE RJ45 4-port OCP Ethernet Adapter 1 1
4XC7A08277 B93E ThinkSystem Intel I350 1GbE RJ45 4-port OCP Ethernet Adapter 1 1
10 Gb Ethernet
4XC7A08236 B5ST ThinkSystem Broadcom 57416 10GBASE-T 2-port OCP Ethernet Adapter 1 1
4XC7A08240 B5T4 ThinkSystem Broadcom 57454 10GBASE-T 4-port OCP Ethernet Adapter 1 1
4XC7A08278 BCD5 ThinkSystem Intel X710-T2L 10GBASE-T 2-port OCP Ethernet Adapter 1 1
4XC7A80268 BPPY ThinkSystem Intel X710-T4L 10GBase-T 4-Port OCP Ethernet Adapter 1 1
25 Gb Ethernet
4XC7A08237 BN2T ThinkSystem Broadcom 57414 10/25GbE SFP28 2-Port OCP Ethernet Adapter 1 1
4XC7A62582 BE4T ThinkSystem Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-Port OCP Ethernet Adapter 1 1
4XC7A80567 BPPW ThinkSystem Broadcom 57504 10/25GbE SFP28 4-Port OCP Ethernet Adapter 1 1
4XC7A08294 BCD4 ThinkSystem Intel E810-DA2 10/25GbE SFP28 2-Port OCP Ethernet Adapter 1 1
4XC7A80269 BP8L ThinkSystem Intel E810-DA4 10/25GbE SFP28 4-Port OCP Ethernet Adapter 1 1
100 Gb Ethernet
4XC7A08243 BPPX ThinkSystem Broadcom 57508 100GbE QSFP56 2-Port OCP Ethernet Adapter 1 1
Table 16. PCIe network adapters
Part number Feature Description Maximum supported
VX630 V3 IS VX630 V3 CN
Gigabit Ethernet
7ZT7A00535 AUZW ThinkSystem I350-T4 PCIe 1Gb 4-Port RJ45 Ethernet Adapter 3 3
7ZT7A00484 AUZV ThinkSystem Broadcom 5719 1GbE RJ45 4-Port PCIe Ethernet Adapter 3 3
10GBASE-T Ethernet
4XC7A80266 BNWL ThinkSystem Intel X710-T2L 10GBase-T 2-Port PCIe Ethernet Adapter 3 3
4XC7A79699 BMXB ThinkSystem Intel X710-T4L 10GBase-T 4-Port PCIe Ethernet Adapter 3 3
7ZT7A00496 AUKP ThinkSystem Broadcom 57416 10GBASE-T 2-Port PCIe Ethernet Adapter 3 3
4XC7A08245 B5SU ThinkSystem Broadcom 57454 10GBASE-T 4-port PCIe Ethernet Adapter 3 3
25 Gb Ethernet
4XC7A80566 BNWM ThinkSystem Broadcom 57504 10/25GbE SFP28 4-Port PCIe Ethernet Adapter 1 1
4XC7A08238 BK1H ThinkSystem Broadcom 57414 10/25GbE SFP28 2-port PCIe Ethernet Adapter 3 3
4XC7A08295 BCD6 ThinkSystem Intel E810-DA2 10/25GbE SFP28 2-Port PCIe Ethernet Adapter 3 3
4XC7A80267 BP8M ThinkSystem Intel E810-DA4 10/25GbE SFP28 4-Port PCIe Ethernet Adapter 3 3
4XC7A62580 BE4U ThinkSystem Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-Port PCIe Ethernet Adapter 3 3
100 Gb Ethernet
4XC7A08248 B8PP ThinkSystem Mellanox ConnectX-6 Dx 100GbE QSFP56 2-port PCIe Ethernet Adapter 3 3
4XC7A08297 BK1J ThinkSystem Broadcom 57508 100GbE QSFP56 2-port PCIe 4 Ethernet Adapter 3 3
4C57A14177 B4R9 ThinkSystem Mellanox ConnectX-6 HDR100/100GbE QSFP56 1-port PCIe VPI Adapter 3 3
4C57A14178 B4RA ThinkSystem Mellanox ConnectX-6 HDR100/100GbE QSFP56 2-port PCIe VPI Adapter 3 3
200 Gb Ethernet
4C57A15326 B4RC ThinkSystem Mellanox ConnectX-6 HDR/200GbE QSFP56 1-port PCIe 4 VPI Adapter 3 3
200 Gb Ethernet / NDR InfiniBand
4XC7A81883 BQBN ThinkSystem Nvidia ConnectX-7 NDR200/HDR QSFP112 2-Port PCIe Gen5 x16 InfiniBand Adapter 3 3
400 Gb / NDR InfiniBand
4XC7A80289 BQ1N ThinkSystem NVIDIA ConnectX-7 NDR400 OSFP 1-Port PCIe Gen5 Adapter 3 3

GPU adapters

The VX630 V3 systems support the following GPU options.

For details about these options, including configuration rules, see the SR630 V3 product guide:
https://lenovopress.com/lp1600-thinksystem-sr630-v3-server#gpu-adapters

Table 17. GPU adapters
Part number Feature Description Maximum supported
VX630 V3 IS  VX630 V3 CN
4X67A81547 BQZT ThinkSystem NVIDIA A2 16GB PCIe Gen4 Passive GPU w/o CEC 3 3
4X67A84824 BS2C ThinkSystem NVIDIA L4 24GB PCIe Gen4 Passive GPU 3 3

Fibre Channel host bus adapters

Table 18. Fibre Channel host bus adapters
Part number Feature Description Maximum supported
VX630 V3 IS  VX630 V3 CN
64 Gb Fibre Channel HBAs
4XC7A77485 BLC1 ThinkSystem Emulex LPe36002 64Gb 2-port PCIe Fibre Channel Adapter 3 3
32 Gb Fibre Channel HBAs
4XC7A76498 BJ3G ThinkSystem Emulex LPe35000 32Gb 1-port PCIe Fibre Channel Adapter v2 3 3
4XC7A76525 BJ3H ThinkSystem Emulex LPe35002 32Gb 2-port PCIe Fibre Channel Adapter V2 3 3
4XC7A08279 BA1G ThinkSystem QLogic QLE2770 32Gb 1-Port PCIe Fibre Channel Adapter 3 3
4XC7A08276 BA1F ThinkSystem QLogic QLE2772 32Gb 2-Port PCIe Fibre Channel Adapter 3 3
16 Gb Fibre Channel HBAs
01CV840 ATZV Emulex 16Gb Gen6 FC Dual-port HBA 3 3
01CV830 ATZU Emulex 16Gb Gen6 FC Single-port HBA 3 3
01CV760 ATZC QLogic 16Gb Enhanced Gen5 FC Dual-port HBA 3 3
01CV750 ATZB QLogic 16Gb Enhanced Gen5 FC Single-port HBA 3 3

Operating system support

The ThinkAgile VX630 V3 Integrated System supports the following operating systems:

  • ESXi 7.0u3 (Factory Installed)
  • ESXi 8.0u1 (Factory Installed)
  • ESXi 8.0u3 (Factory Installed)

The ThinkAgile VX630 V3 Certified Node supports the following operating systems:

  • ESXi 7.0u3 (Factory Installed)
  • ESXi 8.0u1 (Factory Installed)
  • ESXi 8.0u2 (Factory Installed)
  • ESXi 8.0u3 (Factory Installed)

Configuration Note:

VMware vSAN certification for Generic NVMe drives: The drives are listed in the VMware Compatibility Guide (VCG) under the drive vendor company name instead of Lenovo. To check a drive for vSAN certification, search the VCG using the Supplier part number. Part numbers can be found using the Product Guide for the corresponding Drive Family on Lenovo Press https://lenovopress.lenovo.com/servers/options/drives#sort=last_update

For further details, including any restrictions, see the OS Interoperability Guide:
https://lenovopress.lenovo.com/osig#term=vx&support=all

Software

ThinkAgile VX Series offerings are available with the VMware Cloud Foundation (VCF) and VMware vSphere Foundation (VVF) primary software stack options.  Licenses can be purchased through flexible term subscription-based models with 3-year or 5-year durations. In addition to the primary stack options, advanced service add-on options are available for features like vSAN additional capacity, Live Recovery, Firewall with Advanced Threat Prevention, Avi Load Balancer and Private AI Foundation.

Customers who have purchased VMware Licenses directly from Broadcom or an approved distributor can receive the experience of the certified node by choosing “Customer has VMware by Broadcom Software License” in their DCSC configuration.

Lenovo offers the following VMware software license and support options for ThinkAgile VX Series systems:

  • Primary Software
  1. VMware Cloud Foundation  (VCF)
  2. VMware vSphere Foundation (VVF)
  • Add-On Options (requires purchase of a Primary Software version)
  1. VMware vSAN (for capacity over TiB allocation from primary SKU)
  2. VMware Live Recovery
  3. VMware vDefend Firewall Bundle (requires VCF)
  4. VMware vDefend Firewall with Advanced Threat Prevention Bundle (requires VCF)
  5. VMware Avi Load Balancer
  6. VMware Private AI Foundation (requires VCF)

For details and ordering information, see the VMware Software Solution Product Guide:
https://lenovopress.com/lp1265-vmware-software-solution-product-guide

Configuration notes:

  • VMware software licenses that are available for selection include  3-year, or 5-year software support (matches the duration of the selected solution-level warranty period).
  • The quantity of processor core count-based licenses is derived by the configuration tool based on the number of processors selected.
  • The quantity of VM-based licenses is specified based on VM requirements.

ThinkAgile VX Deployer Tool

The ThinkAgile VX Deployer tool is a web-based UI used to simplify and automate the deployment of Lenovo ThinkAgile VX systems within VMware vSAN clusters. The ThinkAgile VX Deployer tool can install and configure the following software:

VMware ESXi

VMware ESXi is a bare-metal hypervisor that the ThinkAgile VX Deployer tool installs on the hardware of each host in the cluster. ESXi translates requests between the physical and virtual resources, making virtualization possible.

VMware vCenter Server

VMware vCenter Server is a management console that provides a centralized platform for controlling VMware vSphere environments. One service that runs in VMware vCenter Server is VMware vLCM, which provides centralized and simplified management to install software, maintain that software through updates and upgrades, and decommission it.

Lenovo® XClarity Integrator

Lenovo XClarity Integrator is the hardware support manager (HSM) used by vCenter for firmware upgrades. Lenovo XClarity Integrator fully integrates with VMware vLCM to give the VMware vCenter Server software visibility into Lenovo hardware. The interface for the ThinkAgile VX Deployer tool is a straightforward web-based installation wizard with three top-level options:

  • Install a new cluster (using the wizard).
  • Add nodes to an existing cluster (using the wizard).
  • Use a configuration file to install a new cluster or add nodes to an existing cluster.

Prowess testing included all three of these options, plus some key lifecycle-management features in VMware vCenter Server. To view the results of our testing please use the link https://www.lenovo.com/content/dam/lenovo/dcg/global/en/products/software-defined-infrastructure/Prowess_Measuring_the_Ease_of_Deployment_of_ThinkAgile_VX.pdf

Warranty and Support

The VX630 V3 have a 3-year warranty based on the machine type:

  • 7D6X - 3 year warranty

The ThinkAgile VX Series Integrated Systems can be configured with a three- or five-year hardware warranty with 24x7 ThinkAgile Advantage Single Point of Support (Lenovo server hardware and VMware software; requires an active software support contract purchased either from VMware or Lenovo) and various levels of coverage with a well-defined scope of services, including service hours, response time, term of service, and service agreement terms and conditions.

The Lenovo local support centers perform Premier determination and resolution for hardware-related issues and escalate to VMware, on behalf of the customer, for software-related problem determination. VMware will contact the customer and will own the software-related problem resolution until closure.

The standard warranty terms are customer-replaceable unit (CRU) and onsite (for field-replaceable units FRUs only) with standard call center support during normal business hours and 9x5 Next Business Day Parts Delivered.

Lenovo’s additional support services provide a sophisticated, unified support structure for your data center, with an experience consistently ranked number one in customer satisfaction worldwide. Available offerings include:

  • Premier Support

    Premier Support provides a Lenovo-owned customer experience and delivers direct access to technicians skilled in hardware, software, and advanced troubleshooting, in addition to the following:

    • Direct technician-to-technician access through a dedicated phone line
    • 24x7x365 remote support
    • Single point of contact service
    • End to end case management
    • Third-party collaborative software support
    • Online case tools and live chat support
    • On-demand remote system analysis
  • Warranty Upgrade (Preconfigured Support)

    Services are available to meet the on-site response time targets that match the criticality of your systems.

    • 3, 4, or 5 years of service coverage
    • 1-year or 2-year post-warranty extensions
    • Foundation Service: 9x5 service coverage with next business day onsite response. YourDrive YourData is an optional extra (see below).
    • Essential Service: 24x7 service coverage with 4-hour onsite response or 24-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
    • Advanced Service: 24x7 service coverage with 2-hour onsite response or 6-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
  • Managed Services

    Lenovo Managed Services provides continuous 24x7 remote monitoring (plus 24x7 call center availability) and proactive management of your data center using state-of-the-art tools, systems, and practices by a team of highly skilled and experienced Lenovo services professionals.

    Quarterly reviews check error logs, verify firmware & OS device driver levels, and software as needed. We’ll also maintain records of latest patches, critical updates, and firmware levels, to ensure you systems are providing business value through optimized performance.

  • Technical Account Management (TAM)

    A Lenovo Technical Account Manager helps you optimize the operation of your data center based on a deep understanding of your business. You gain direct access to your Lenovo TAM, who serves as your single point of contact to expedite service requests, provide status updates, and furnish reports to track incidents over time. In addition, your TAM will help proactively make service recommendations and manage your service relationship with Lenovo to make certain your needs are met.

  • Enterprise Server Software Support

    Enterprise Software Support is an additional support service providing customers with software support on Microsoft, Red Hat, SUSE, and VMware applications and systems. Around the clock availability for critical problems plus unlimited calls and incidents helps customers address challenges fast, without incremental costs. Support staff can answer troubleshooting and diagnostic questions, address product comparability and interoperability issues, isolate causes of problems, report defects to software vendors, and more.

  • YourDrive YourData

    Lenovo’s YourDrive YourData is a multi-drive retention offering that ensures your data is always under your control, regardless of the number of drives that are installed in your Lenovo server. In the unlikely event of a drive failure, you retain possession of your drive while Lenovo replaces the failed drive part. Your data stays safely on your premises, in your hands. The YourDrive YourData service can be purchased in convenient bundles and is optional with Foundation Service. It is bundled with Essential Service and Advanced Service.

  • Health Check

    Having a trusted partner who can perform regular and detailed health checks is central to maintaining efficiency and ensuring that your systems and business are always running at their best. Health Check supports Lenovo-branded server, storage, and networking devices, as well as select Lenovo-supported products from other vendors that are sold by Lenovo or a Lenovo-Authorized Reseller.

Examples of region-specific warranty terms are second or longer business day parts delivery or parts-only base warranty.

If warranty terms and conditions include onsite labor for repair or replacement of parts, Lenovo will dispatch a service technician to the customer site to perform the replacement. Onsite labor under base warranty is limited to labor for replacement of parts that have been determined to be field-replaceable units (FRUs). Parts that are determined to be customer-replaceable units (CRUs) do not include onsite labor under base warranty.

If warranty terms include parts-only base warranty, Lenovo is responsible for delivering only replacement parts that are under base warranty (including FRUs) that will be sent to a requested location for self-service. Parts-only service does not include a service technician being dispatched onsite. Parts must be changed at customer’s own cost and labor and defective parts must be returned following the instructions supplied with the spare parts.

Lenovo Service offerings are region-specific. Not all preconfigured support and upgrade options are available in every region. For information about Lenovo service upgrade offerings that are available in your region, refer to the following resources:

For service definitions, region-specific details, and service limitations, please refer to the following documents:

Software maintenance

The ThinkAgile VX Series Integrated Systems (appliances) or Certified Nodes can include three-, or five-year software subscription (matches the duration of the selected warranty period) that entitles customers to submit service requests to troubleshoot VMware software issues and receive code updates, including fixes, patches, and new software releases.

The Lenovo local support centers perform problem determination and resolution for hardware-related issues and escalate to VMware, on behalf of the customer, for software-related problem determination. Lenovo will contact the customer and will own the software-related problem resolution until closure.

For the VMware by Broadcom license purchased from Lenovo together with the ThinkAgile VX Series Certifed Nodes, software support that is provided by VMware includes Production-level support with 24x7 phone and web coverage with the following target response times (priorities are defined by VMware based on the impact on productivity):

  • Severity 1 (Critical: Substantial loss or disruption of service, significant risk of data loss): 30 minutes
  • Severity 2 (Major: Operations are severely constrained, significant impact): 4 business hours
  • Severity 3 (Minor: Non-critical loss of functionality, minimal impact): 8 business hours
  • Severity 4 (Cosmetic: General questions): 12 business hours

For the VMware software and subscription licenses provided by the customer, software support that is provided by VMware is based on the support level included with these licenses. VMware by Broadcom will contact the customer and will own the software-related problem resolution until closure.

Deployment services

The following optional Lenovo basic installation services are available for the ThinkAgile VX Series Integrated Systems (appliances):

  • Unpacking and inspecting the systems
  • Mounting the systems in a rack cabinet
  • Connecting the systems to electrical power and network
  • Checking and updating firmware to the latest levels
  • Verifying operations
  • Disposal of the packaging materials (within the customer site)

ThinkAgile VX Integrated Systems include deployment services delivered by Lenovo Professional Services for the ultimate customer experience. However, “Channel Partner Provided” option is also available on DCSC. By choosing this option, Lenovo Customer or Lenovo Business Partner assumes the full responsibility to perform the deployment services for the quoted system. It is strongly recommended that Lenovo Professional Services or approved business partners are used to perform the deployment services.

The following additional Lenovo deployment services are available for the ThinkAgile VX Series with VMware vSphere Foundation solution to get customers up and running quickly. You can use the table below to add these services:

  • Conducting remote preparation and planning
  • Verifying firmware versions and performing firmware updates, if needed
  • Configuring XCC management settings
  • Configuring hypervisor settings
  • Configuring vSAN
  • Configuring VMware vCenter Server and discovering hosts and storage
  • Configuring Lenovo XClarity network settings and performing discovery and inventory
  • Transferring knowledge
  • Developing post-installation documentation

The following Lenovo deployment services are provided with the ThinkAgile VX Series with VMware Cloud Foundation co-engineered solution to get customers up and running quickly:

  • Planning and Design
    • Collect technical details for hardware and VMware environment
    • Plan the architecture based on Customer’s business and tech requirements
    • Fill the VCF Plan, Prepare Workbook
  • Implementation
    • Configure hardware (XCC IP, UEFI), upgrade firmware via OneCLI or BoMC
    • Deploy & Configure ESXi, Cloud Builder & import VCF Workbook, Lenovo xClarity software components
    • Check compliance with VX Best Recipes
  • Handover
    • BAU updates based on VCF releases and VX Best Recipes
    • VMware Async Patch Tool (if required)
  • Readiness Handover
    • Create handover document and knowledge transfer
    • Includes details for each deployed component

The following table lists ThinkAgile Health Check & Deployment offerings are available for ThinkAgile VX customers. These offerings are performed by Lenovo Professional Services.

  • Onsite Deployment: Install, configure, and validate solution on-site, and conduct knowledge transfer.
  • Remote Deployment: Install, configure, and validate solution remotely, and conduct knowledge transfer.
  • Remote Health Check: Report & remediation of hardware and cluster health issues, including firmware and software updates.
Table 19. ThinkAgile Deployment offerings
Part number Description
Onsite deployment services
5MS7B00082 ThinkAgile VX Onsite Deployment (up to 4 nodes)
5MS7B00083 ThinkAgile VX Onsite Deployment (additional node)
Remote deployment services
5MS7A87711 ThinkAgile VX Remote Deployment (up to 4 nodes)
5MS7A87712 ThinkAgile VX Remote Deployment (additional node)
Remote Health Check
5MS7B00178 ThinkAgile VX 1X Remote Health Check (up to 4 node cluster)
5MS7B00179 ThinkAgile VX 1X Remote Health Check (additional node)
5MS7B00059 ThinkAgile VX 1X Remote Health Check & Update (up to 4 node cluster)
5MS7B00060 ThinkAgile VX 1X Remote Health Check & Update (additional node)

For more information, refer to the Data Center Implementation Services web page:
https://www.lenovo.com/us/en/data-center/services/implementation-services/

Regulatory compliance

The server conforms to the following standards:

  • Energy Star 3.0
  • FCC: Verified to comply with Part 15 of the FCC Rules, Class A
  • Canada ICES-003, issue 6, Class A
  • UL/IEC 62368-1
  • CAN/CSA-C22.2 No. 62368-1
  • NOM-019
  • Argentina IEC 62368-1
  • Japan VCCI, Class A
  • Australia/New Zealand AS/NZS CISPR 32, Class A; AS/NZS 60950.1
  • IEC 60950-1 & IEC 62368-1 (CB Certificate and CB Test Report)
  • China CCC (GB4943.1), GB9254 Class A, GB17625.1
  • Taiwan BSMI CNS13438, Class A; CNS14336-1; section 5 of CNS15663
  • Korea KN32, Class A; KN35
  • Russia, Belorussia and Kazakhstan, EAC: TP TC 004/2011 (for Safety); TP TC 020/2011 (for EMC); TP EAC 037/2016 (for RoHS)
  • CE Mark (EN55032 Class A, EN60950-1, EN62368-1, EN55024, EN55035, EN61000-3-2, (EU) 2019/424, EN 50581-1 and EN61000-3-3)
  • CISPR 32, Class A
  • TUV-GS (EN62368-1, EK1-ITB2000, AfPS GS 01 PAK Par. 3.1)
  • India BIS certification

Lenovo Financial Services

Lenovo Financial Services reinforces Lenovo’s commitment to deliver pioneering products and services that are recognized for their quality, excellence, and trustworthiness. Lenovo Financial Services offers financing solutions and services that complement your technology solution anywhere in the world.

We are dedicated to delivering a positive finance experience for customers like you who want to maximize your purchase power by obtaining the technology you need today, protect against technology obsolescence, and preserve your capital for other uses.

We work with businesses, non-profit organizations, governments and educational institutions to finance their entire technology solution. We focus on making it easy to do business with us. Our highly experienced team of finance professionals operates in a work culture that emphasizes the importance of providing outstanding customer service. Our systems, processes and flexible policies support our goal of providing customers with a positive experience.

We finance your entire solution. Unlike others, we allow you to bundle everything you need from hardware and software to service contracts, installation costs, training fees, and sales tax. If you decide weeks or months later to add to your solution, we can consolidate everything into a single invoice.

Our Premier Client services provide large accounts with special handling services to ensure these complex transactions are serviced properly. As a premier client, you have a dedicated finance specialist who manages your account through its life, from first invoice through asset return or purchase. This specialist develops an in-depth understanding of your invoice and payment requirements. For you, this dedication provides a high-quality, easy, and positive financing experience.

For your region-specific offers, please ask your Lenovo sales representative or your technology provider about the use of Lenovo Financial Services. For more information, see the following Lenovo website:

https://www.lenovo.com/us/en/landingpage/lenovo-financial-services/

Related product families

Product families related to this document are the following:

Trademarks

Lenovo and the Lenovo logo are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. A current list of Lenovo trademarks is available on the Web at https://www.lenovo.com/us/en/legal/copytrade/.

The following terms are trademarks of Lenovo in the United States, other countries, or both:
Lenovo®
AnyBay®
ThinkAgile®
ThinkSystem®
XClarity®

The following terms are trademarks of other companies:

Intel® and Xeon® are trademarks of Intel Corporation or its subsidiaries.

Microsoft®, SQL Server®, and SharePoint® are trademarks of Microsoft Corporation in the United States, other countries, or both.

Other company, product, or service names may be trademarks or service marks of others.
