Abstract

The Lenovo ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node are 2-socket 1U systems that feature the 2nd Generation Intel Xeon Scalable processors. These systems are based on the ThinkSystem SR630 with up to 28 cores per processor, up to 3 TB of TruDDR4 memory with up to 2933 MHz memory speeds, and an extensive selection of internal storage and networking options. VMware offers a unique, software-defined approach to hyperconvergence, leveraging the hypervisor to deliver compute, storage and management in a tightly integrated software stack.

This product guide provides essential pre-sales information to understand the VX systems, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the VX systems and consider their use in IT solutions.

Tip: This product guide combines all four 1U VX systems with 2nd Generation Intel Xeon ("Cascade Lake") processors into the one document.

Change History

Changes in the June 1, 2023 update:

  • Added support for the following chassis - Model options section:
    • ThinkAgile VX 1U 2.5" 10 Bay Chassis v2, BMWB
    • ThinkAgile VX 1U 2.5" 10 Bay Chassis v2, BVL5
    • ThinkAgile VX 1U 3.5" 4 Bay Chassis v2, BMWC
    • ThinkAgile VX 1U 3.5" 4 Bay Chassis v2, BVL8

Introduction

The Lenovo ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node are 2-socket 1U systems that feature the 2nd Generation Intel Xeon Scalable processors. These systems are based on the ThinkSystem SR630 with up to 28 cores per processor, up to 3 TB of TruDDR4 memory with up to 2933 MHz memory speeds, and an extensive selection of internal storage and networking options. VMware offers a unique, software-defined approach to hyperconvergence, leveraging the hypervisor to deliver compute, storage and management in a tightly integrated software stack.

The 1U systems are available either as an appliance or certified node:

  • VX2320 for workloads used by small-to-medium businesses
  • VX3320 for compute-heavy workloads
  • VX7320-N for high performance workloads benefiting from all-NVMe storage
  • VX 1U Certified Node

Suggested uses: Inference, virtualization, VDI, HPC, Hyperconverged infrastructure

Lenovo ThinkAgile VX with 3.5-inch drive bays
Figure 1. Lenovo ThinkAgile VX with 3.5-inch drive bays

Did you know?

The ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node are built on the Lenovo ThinkSystem SR630 server that features enterprise-class reliability, management, and security.

The VX2320, VX3320, VX7320-N Appliances offer ThinkAgile Advantage Single Point of Support for quick 24/7 problem reporting and resolution.

Key features

The ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node offer the following key features:

  • Factory-integrated, pre-configured ready-to-go appliances built on proven and reliable Lenovo ThinkSystem servers that provide compute power for a variety of workloads and applications and powered by industry-leading hyperconverged infrastructure software from VMware.
  • Provide quick and convenient path to implement a hyperconverged solution powered by VMware vSAN with "one stop shop" and a single point of contact provided by Lenovo for purchasing, deploying, and supporting the solution.
  • Meet various workload demands with cost-efficient hybrid or performance-optimized all-flash storage configurations.
  • Deliver fully validated and integrated hardware and firmware that is certified with VMware software.
  • Appliances include Lenovo ThinkAgile Advantage Single Point of Support for quick 24/7 problem reporting and resolution.
  • Offer Lenovo deployment services to get customers up and running quickly.

The VMware software running on ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node delivers the following key features:

  • Distributed architecture that allows "pay-as-you-grow", non-disruptive scaling by adding new nodes to the cluster (scale-out) to increase capacity and performance.
  • Advanced capacity management, including deduplication, compression, and erasure coding (RAID 5/6), which helps deliver greater storage utilization with dramatically lower storage capacity and costs.
  • Automation of VM storage provisioning and control of storage service levels (capacity, performance, availability) with VM-centric policies to load balance storage resources.
  • Native HCI security solution with two-factor authentication (SecurID and CAC) and data-at-rest encryption that does not require self-encrypting drives (SEDs).
  • Stretched cluster with local and site failure protection between two geographically dispersed sites for higher level of availability with near zero downtime.
  • Centralized management with provisioning, administering, and monitoring virtual resources across multiple hosts and clusters from a centralized interface.
  • Rapid workload provisioning, simplified data center operations, increased business efficiency, and decreased CAPEX and OPEX costs.
  • VM and data protection with agent-less, image-level virtual machine backups and application-aware protection for business-critical Microsoft applications (Exchange, SQL Server, SharePoint) along with WAN-efficient, encrypted backup data replication.
  • Reduced unplanned downtime and virtually eliminated planned downtime for server and storage maintenance with live workload migration, high availability, and fault tolerance.
  • Enhanced application performance and availability with resource management, load balancing, and access prioritization.
  • Intelligent operations management and automation to proactively monitor and manage compute, storage, and networking resources, identify performance bottlenecks, and re-balance workloads by leveraging predictive analytics.
  • Capacity planning and optimization guidance to address future needs with performance trends, projections and extended forecasts.
  • Managing remote offices and branch offices with rapid provisioning of servers through virtualization, minimization of host configuration drift, and enhanced visibility into regulatory compliance, across multiple sites.

Components and connectors

The ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node are based on the ThinkSystem SR630 server.

The following figure shows the front view of the VX2320 Appliance and VX 1U Certified Node with 4x 3.5-inch front drive bays.

VX2320 front view
Figure 2. Front view with 3.5-inch drive bays

The following figure shows the front view of the VX3320 Appliance, VX7320-N Appliance and VX 1U Certified Node with 10x 2.5-inch drive bays.

VX3320 front view
Figure 3. Front view with 2.5-inch drive bays

The following figure shows the rear view of all VX systems. The VX 1U Certified Node optionally supports 2x 2.5-inch drive bays in the place of 2 of the PCIe slots.

VX 1U Certified Node rear view
Figure 4. Rear view

Standard specifications

The ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node are based on the ThinkSystem SR630 server.

The following table provides an overview comparison between the VX systems.

Table 1. Comparison of features
  VX2320 VX3320 VX7320-N VX 1U
VX offering type Appliance Appliance Appliance Certified Node
Target workloads SMB Compute heavy High performance Compute heavy
Base MTM 7Y93CTO2WW 7Y93CTO1WW 7Y93CTO3WW 7Y93CTO4WW
Form Factor 1U 1U 1U 1U
Base platform SR630 SR630 SR630 SR630
CPU 1x or 2x Intel Xeon SP Gen 2 1x or 2x Intel Xeon SP Gen 2 2x Intel Xeon SP Gen 2 1x or 2x Intel Xeon SP Gen 2
Memory 24x DDR4 2933 MHz (3TB max) 24x DDR4 2933 MHz (3TB max) 24x DDR4 2933 MHz (3TB max) 24x DDR4 2933 MHz (3TB max)
Drive Bays
  • 4x 3.5" SAS/SATA (front)
  • 6x 2.5" SAS/SATA & 4x 2.5" AnyBay (front)
  • 10x 2.5" NVMe (front)
  • 4x 3.5" SAS/SATA (front) + 2x 2.5" SAS/SATA (rear)
  • 4x 3.5" AnyBay (front)
  • 6x 2.5" SAS/SATA & 4x 2.5" AnyBay (front) + 2x 2.5" SAS/SATA (rear)
  • 10x 2.5" NVMe (front)
Drive Configuration All Flash
Hybrid		 All Flash
Hybrid		 All Flash All Flash
Hybrid
HBA 430-8i HBA 430-16i HBA No support* 430-8i HBA
430-16i HBA
Boot drives 2x M.2 SATA 2x M.2 SATA 2x M.2 SATA 2x M.2 SATA
LOM networking 1x LOM adapter, 1Gb or 10Gb 1x LOM adapter, 10Gb 1x LOM adapter, 10Gb 1x LOM adapter, 1Gb or 10Gb
PCIe networking Up to 3x adapters
10Gb, 25Gb		 Up to 3x adapters
10Gb, 25Gb		 Up to 3x adapters
10Gb, 25Gb		 Up to 3x adapters
1Gb, 10Gb, 25Gb, 40Gb, 100Gb
GPUs No support No support No support Up to 3x GPUs
Hypervisor VMware ESXi VMware ESXi VMware ESXi VMware ESXi

* NVMe ports and switch adapters are used instead of a SAS HBA

The following table lists the standard specifications.

Table 2. Standard specifications
Components Specification
Machine types 7Y93 - 3 year warranty
Form factor 1U rack.
Processor One or two 2nd Gen Intel Xeon Scalable processors (formerly codenamed "Cascade Lake")
Chipset Intel C624 chipset, part of the platform codenamed "Purley"
Memory 24 DIMM slots (up to 12 DIMMs per processor; six memory channels per processor with two DIMMs per channel) with support for RDIMMs and 3DS RDIMM at up to 2933 MHz.
Persistent memory VX 1U Certified Node support up to 12x TruDDR4 2666 MHz DCPMMs in the DIMM slots.
Memory maximum

Up to 3 TB with 128 GB 3DS RDIMMs and two processors.

Memory DIMMs and persistent memory modules (Memory Mode): Up to 6 TB with 12x 512 GB DCPMMs (Up to 3 TB per processor).

Note: Systems with more than 1 TB of memory capacity per socket require processors with an L suffix.
Memory protection Error correction code (ECC), Single Device Data Correction (SDDC; for x4-based memory DIMMs), Adaptive Double Device Data Correction (ADDDC; for x4-based memory DIMMs, requires Intel Xeon Gold or Platinum processors), patrol scrubbing, and demand scrubbing.
Hot-swap drive bays
  • VX2320: 4x 3.5" SAS/SATA (front)
  • VX3320: 6x 2.5" SAS/SATA & 4x 2.5" AnyBay (front)
  • VX7320-N: 10x 2.5" NVMe (front)
  • VX 1U Certified Node:
    • 4x 3.5" SAS/SATA (front) + 2x 2.5" SAS/SATA (rear)
    • 4x 3.5" AnyBay (front)
    • 6x 2.5" SAS/SATA & 4x 2.5" AnyBay (front) + 2x 2.5" SAS/SATA (rear)
    • 10x 2.5" NVMe (front)
Internal storage
  • 1 drive group: 1 cache drive + 2-7 capacity drives
  • 2 drive groups: 1 cache drive + 2-6 capacity drives in each group
Note: The quantity of the capacity drives in each drive group must be the same.
Storage controller
  • 12 Gbps SAS/6 Gbps SATA non-RAID:
    • 430-8i HBA (VX2320 and VX 1U Certified Node)
    • 430-16i HBA (VX3320 and VX 1U Certified Node)
  • NVMe PCIe non-RAID (VX7320-N and VX 1U Certified Node)
    • Onboard NVMe
    • 810-4P NVMe Switch Adapter
    • 1610-4P NVMe Switch Adapter
Network interfaces Onboard LOM slot for an adapter with up to 4x 1Gb or 10 Gb Ethernet ports
Additional network adapters in PCIe slots
PCI Expansion slots Up to four slots. Slot 4 is the fixed slot on the system planar, and the remaining slots depend on the riser cards installed. The slots are as follows:
  • Slot 1: PCIe 3.0 x8, ML2 x8, or ML2 x16; low profile (for a network adapter)
  • Slot 2: PCIe 3.0 x16 or x8; low profile or full-height, half-length (for a network adapter)
  • Slot 3: PCIe 3.0 x16; low profile (for a network adapter)
  • Slot 4: PCIe 3.0 x8 (for an internal storage controller)
GPU support VX 1U Certified Node supports up to 3x single-wide GPUs
Boot drives 2x M.2 non-hot-swap SSDs (RAID-1)
Ports
  • Front: 1x USB 2.0 port with XClarity Controller access, 1x USB 3.0 port, 1x VGA port (optional).
  • Rear: 2x USB 3.0 ports, 1x VGA port, 1x RJ-45 10/100/1000 Mb Ethernet port for systems management.
Cooling Five (one processor) or seven (two processors) hot-swap system fans with N+1 redundancy.
Power supply One or two redundant hot-swap 750 W or 1100 W (100 - 240 V) High Efficiency Platinum power supplies, or 750 W (200 - 240 V) High Efficiency Titanium power supplies.
Video G200 graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller. Maximum resolution is 1920x1200 32bpp at 60Hz.
Hot-swap parts Drives, power supplies, and fans.
Systems management Lenovo XClarity Controller (XCC) Enterprise (Pilot 4 chip), proactive platform alerts, light path diagnostics, Lenovo XClarity Administrator with Integrator for VMware vCenter, Lenovo XClarity Energy Manager (optional).
Security features Power-on password, administrator's password, secure firmware updates, Trusted Platform Module (TPM) 1.2 or 2.0 (configurable UEFI setting). Optional lockable front bezel.
Software

Software licenses that can be purchased from Lenovo or provided by the customer:

  • VMware vSAN: Standard, Advanced, Enterprise, Enterprise Plus, ROBO or Desktop
  • VMware vSphere: Standard, Enterprise Plus or ROBO
  • HCI Kit: Essentials, Standard, Advanced, Enterprise or ROBO
  • VMware Horizon: Standard, Advanced or Enterprise
  • VMware Cloud Foundation (VCF): Basic, Standard, Advanced, Enterprise or for VDI
  • VMware vCenter Server: Foundation or Standard
Hypervisors VMware ESXi. See Operating system support section for details.
Warranty and support Three- or five-year customer-replaceable unit and onsite limited hardware warranty with ThinkAgile Advantage Support and selectable service levels: 9x5 next business day (NBD) parts delivered, 9x5 NBD onsite response, 24x7 coverage with 2-hour or 4-hour onsite response, or 6-hour or 24-hour committed repair (select areas). Also available are YourDrive YourData, Premier Support, and Enterprise Software Support.
Software maintenance One- (PRC only), three-, or five-year software support and subscription (matches the duration of the selected warranty period).
Dimensions Width: 435 mm (17.1 in.), height: 43 mm (1.7 in.), depth: 750 mm (29.5 in.).
Weight Minimum configuration: 11.9 kg (26.2 lb), maximum: 18.8 kg (41.4 lb)

Models

Factory-integrated models of the ThinkAgile VX Series Appliances are configured by using the Lenovo Data Center Solution Configurator (DCSC), http://dcsc.lenovo.com.

During the configuration process, you are selecting one of the Configure-to-Order (CTO) base models first, and then you are adding components (processors, memory, drives, and network adapters) to the selected model.

Note: You are required to engage a Lenovo representative in the project that includes the ThinkAgile VX Series Appliances. ThinkAgile VX certified nodes do not have this requirement.

The following table lists the CTO base models.

Table 3. CTO base models
Machine Type/Model Description
7Y93CTO2WW ThinkAgile VX2320 Appliance
7Y93CTO1WW ThinkAgile VX3320 Appliance
7Y93CTO3WW ThinkAgile VX7320-N Appliance
7Y93CTO4WW ThinkAgile VX 1U Certified Node

Models of the VX systems are defined based on whether the systems have 10x 2.5-inch drive bays at the front (called the 2.5-inch chassis) or whether they have 4x 3.5-inch drive bays at the front (called the 3.5-inch chassis). For models, the feature codes for these chassis bases are as listed in the following table.

Table 4. Chassis base feature codes
Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
BMWB ThinkAgile VX 1U 2.5" 10 Bay Chassis v2 No 1 1 1
BVL5 ThinkAgile VX 1U 2.5" 10 Bay Chassis v2 No 1 1 1
BMWC ThinkAgile VX 1U 3.5" 4 Bay Chassis v2 1 No No 1
BVL8 ThinkAgile VX 1U 3.5" 4 Bay Chassis v2 1 No No 1



Comparison with the ThinkSystem SR630

The ThinkAgile VX2320, VX3320, VX7320-N Appliances and VX 1U Certified Node are based on the ThinkSystem SR630 server, however there are key differences:

  • No onboard SATA controller support
  • No RAID adapter support
  • No SATA HDDs
  • No EDSFF drives support
  • No SED drive support
  • No Fibre Channel support
  • No InfiniBand support
  • Drives are categorized as Cache or Capacity drives and are formed as disk groups (up to 2 disk groups)

For details about the ThinkSystem SR630, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server

To verify what specific hardware components are supported with the VX2320, VX3320, VX7320-N, and 1U Certified Node, see the DCSC configurator:
https://dcsc.lenovo.com

Processors

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following processors.

For details about these options, including configuration rules, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server#processors

Table 5. Processor choices
Part number Feature Description Maximum supported
VX2320
VX3320
VX7320-N
VX 1U
Intel Xeon Bronze processors
4XG7A37939 B4HU Intel Xeon Bronze 3204 6C 85W 1.9GHz Processor 2 2 2 2
4XG7A37990 B7N3 Intel Xeon Bronze 3206R 8C 85W 1.9GHz Processor 2 2 2 2
Intel Xeon Silver processors
4XG7A37936 B4HT Intel Xeon Silver 4208 8C 85W 2.1GHz Processor 2 2 2 2
4XG7A37933 B4HS Intel Xeon Silver 4210 10C 85W 2.2GHz Processor 2 2 2 2
4XG7A37988 B7N5 Intel Xeon Silver 4210R 10C 100W 2.4GHz Processor 2 2 2 2
4XG7A63300 BAZT Intel Xeon Silver 4210T 10C 95W 2.3GHz Processor 2 2 2 2
4XG7A37930 B4HR Intel Xeon Silver 4214 12C 85W 2.2GHz Processor 2 2 2 2
4XG7A37987 B7N6 Intel Xeon Silver 4214R 12C 100W 2.4GHz Processor 2 2 2 2
4XG7A37942 B4NW Intel Xeon Silver 4214Y 12/10/8C 85W 2.2GHz Processor 2 2 2 2
4XG7A37927 B4HQ Intel Xeon Silver 4215 8C 85W 2.5GHz Processor 2 2 2 2
4XG7A63298 BAZU Intel Xeon Silver 4215R 8C 130W 3.2GHz Processor 2 2 2 2
4XG7A37924 B4HP Intel Xeon Silver 4216 16C 100W 2.1GHz Processor 2 2 2 2
Intel Xeon Gold processors
4XG7A37917 B4HN Intel Xeon Gold 5215 10C 85W 2.5GHz Processor 2 2 2 2
4XG7A37911 B4P9 Intel Xeon Gold 5215L 10C 85W 2.5GHz Processor 2 2 2 2
4XG7A37920 B4HM Intel Xeon Gold 5217 8C 115W 3.0GHz Processor 2 2 2 2
4XG7A37896 B4HL Intel Xeon Gold 5218 16C 125W 2.3GHz Processor 2 2 2 2
4XG7A37959 B6BS Intel Xeon Gold 5218B 16C 125W 2.3GHz Processor 2 2 2 2
4XG7A63296 BAZS Intel Xeon Gold 5218R 20C 125W 2.1GHz Processor 2 2 2 2
4XG7A37966 B4P3 Intel Xeon Gold 5218T 16C 105W 2.1GHz Processor 2 2 2 2
4XG7A37893 B4HK Intel Xeon Gold 5220 18C 125W 2.2GHz Processor 2 2 2 2
4XG7A37984 B7N9 Intel Xeon Gold 5220R 24C 150W 2.2GHz Processor 2 2 2 2
4XG7A38018 B6CW Intel Xeon Gold 5220S 18C 125W 2.7GHz Processor 2 2 2 2
4XG7A15809 B6CQ Intel Xeon Gold 5220T 18C 105W 1.9GHz Processor 2 2 2 2
4XG7A37952 B5S1 Intel Xeon Gold 5222 4C 105W 3.8GHz Processor 2 2 2 2
CTO only BAZV Intel Xeon Gold 6208U 16C 150W 2.9GHz Processor 1 1 1 1
4XG7A38022 B6CV Intel Xeon Gold 6222V 20C 115W 1.8GHz Processor 2 2 2 2
4XG7A38020 B6CL Intel Xeon Gold 6226 12C 125W 2.7GHz Processor 2 2 2 2
4XG7A63292 BAZW Intel Xeon Gold 6226R 16C 150W 2.9GHz Processor 2 2 2 2
4XG7A37890 B4HJ Intel Xeon Gold 6230 20C 125W 2.1GHz Processor 2 2 2 2
4XG7A15720 B5RY Intel Xeon Gold 6230N 20C 125W 2.3GHz Processor 2 2 2 2
4XG7A63290 BAZX Intel Xeon Gold 6230R 26C 150W 2.1GHz Processor 2 2 2 2
4XG7A15808 B6CP Intel Xeon Gold 6230T 20C 125W 2.1GHz Processor 2 2 2 2
4XG7A38000 B6CK Intel Xeon Gold 6234 8C 130W 3.3GHz Processor 2 2 2 2
4XG7A38024 B6CJ Intel Xeon Gold 6238 22C 140W 2.1GHz Processor 2 2 2 2
4XG7A38002 B6CR Intel Xeon Gold 6238L 22C 140W 2.1GHz Processor 2 2 2 2
4XG7A63288 BAZL Intel Xeon Gold 6238R 28C 165W 2.2GHz Processor 2 2 2 2
4XG7A37884 B4HH Intel Xeon Gold 6240 18C 150W 2.6GHz Processor 2 2 2 2
4XG7A38014 B6CS Intel Xeon Gold 6240L 18C 150W 2.6GHz Processor 2 2 2 2
4XG7A63286 BAZM Intel Xeon Gold 6240R 24C 165W 2.4GHz Processor 2 2 2 2
4XG7A37904 B4NV Intel Xeon Gold 6240Y 18/14/8C 150W 2.6GHz Processor No 2 2 2
4XG7A37887 B4HG Intel Xeon Gold 6242 16C 150W 2.8GHz Processor 2 2 2 2
4XG7A63284 BAZN Intel Xeon Gold 6242R 20C 205W 3.1GHz Processor No 2 2 2
4XG7A15875 B4HF Intel Xeon Gold 6244 8C 150W 3.6GHz Processor 2 2 2 2
4XG7A63282 BAZP Intel Xeon Gold 6246R 16C 205W 3.4GHz Processor 2 2 2 2
4XG7A15893 B4HE Intel Xeon Gold 6248 20C 150W 2.5GHz Processor 2 2 2 2
4XG7A63280 BAZQ Intel Xeon Gold 6248R 24C 205W 3.0GHz Processor No 2 2 2
4XG7A15890 B4HC Intel Xeon Gold 6252 24C 150W 2.1GHz Processor 2 2 2 2
4XG7A15812 B6CT Intel Xeon Gold 6252N 24C 150W 2.3GHz Processor 2 2 2 2
4XG7A15873 B4HD Intel Xeon Gold 6254 18C 200W 3.1GHz Processor No 2 2 2
4XG7A63278 BAZR Intel Xeon Gold 6258R 28C 205W 2.7GHz Processor No 2 2 2
4XG7A38009 B6CU Intel Xeon Gold 6262V 24C 135W 1.9GHz Processor 2 2 2 2
Intel Xeon Platinum processors
4XG7A37899 B5RZ Intel Xeon Platinum 8253 16C 125W 2.2GHz Processor 2 2 2 2
4XG7A37948 B5S2 Intel Xeon Platinum 8256 4C 105W 3.8GHz Processor 2 2 2 2
4XG7A15888 B4HB Intel Xeon Platinum 8260 24C 165W 2.4GHz Processor 2 2 2 2
4XG7A15886 B4P7 Intel Xeon Platinum 8260L 24C 165W 2.4GHz Processor 2 2 2 2
4XG7A37902 B4NU Intel Xeon Platinum 8260Y 24/20/16C 165W 2.4GHz Processor 2 2 2 2
4XG7A15871 B4HA Intel Xeon Platinum 8268 24C 205W 2.9GHz Processor No 2 2 2
4XG7A15869 B4H9 Intel Xeon Platinum 8270 26C 205W 2.7GHz Processor No 2 2 2
4XG7A15882 B4H8 Intel Xeon Platinum 8276 28C 165W 2.2GHz Processor 2 2 2 2
4XG7A15878 B4P6 Intel Xeon Platinum 8276L 28C 165W 2.2GHz Processor 2 2 2 2
4XG7A15867 B4H7 Intel Xeon Platinum 8280 28C 205W 2.7GHz Processor No 2 2 2
4XG7A15863 B4P5 Intel Xeon Platinum 8280L 28C 205W 2.7GHz Processor No 2 2 2

Memory

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following memory options.

For details about these options, including configuration rules, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server#memory-options

Table 6. Memory options
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
RDIMMs - 2933 MHz Performance+
4X77A12184 B5N6 ThinkSystem 16GB TruDDR4 Performance+ 2933MHz (2Rx8 1.2V) RDIMM 24 24 24 24
4X77A12185 B5N7 ThinkSystem 32GB TruDDR4 Performance+ 2933MHz (2Rx4 1.2V) RDIMM 24 24 24 24
4X77A12186 B5N8 ThinkSystem 64GB TruDDR4 Performance+ 2933MHz (2Rx4 1.2V) RDIMM 24 24 24 24
RDIMMs - 2933 MHz
4ZC7A08706 B4H1 ThinkSystem 8GB TruDDR4 2933MHz (1Rx8 1.2V) RDIMM 24 24 24 24
4ZC7A08707 B4LY ThinkSystem 16GB TruDDR4 2933 MHz (1Rx4 1.2V) RDIMM 24 24 24 24
4ZC7A08708 B4H2 ThinkSystem 16GB TruDDR4 2933MHz (2Rx8 1.2V) RDIMM 24 24 24 24
4ZC7A08709 B4H3 ThinkSystem 32GB TruDDR4 2933MHz (2Rx4 1.2V) RDIMM 24 24 24 24
4ZC7A08710 B4H4 ThinkSystem 64GB TruDDR4 2933MHz (2Rx4 1.2V) RDIMM 24 24 24 24
RDIMMs - 2666 MHz
7X77A01302 AUNB ThinkSystem 16GB TruDDR4 2666 MHz (1Rx4 1.2V) RDIMM 24 24 24 24
7X77A01303 AUNC ThinkSystem 16GB TruDDR4 2666 MHz (2Rx8 1.2V) RDIMM 24 24 24 24
7X77A01304 AUND ThinkSystem 32GB TruDDR4 2666 MHz (2Rx4 1.2V) RDIMM 24 24 24 24
3DS RDIMMs - 2933 MHz Performance+
4X77A12187 B5N9 ThinkSystem 128GB TruDDR4 Performance+ 2933MHz (4Rx4 1.2V) 3DS RDIMM 24 24 24 24
3DS RDIMMs - 2933 MHz
4ZC7A15113 B587 ThinkSystem 128GB TruDDR4 2933MHz (4Rx4 1.2V) 3DS RDIMM No No No 24

Persistent Memory

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following persistent memory options.

For details about these options, including configuration rules, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server#persistent-memory

Table 7. Persistent memory options
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
4ZC7A15110 B4LV ThinkSystem 128GB TruDDR4 2666MHz (1.2V) Intel Optane DC Persistent Memory No No No 12
4ZC7A15111 B4LW ThinkSystem 256GB TruDDR4 2666MHz (1.2V) Intel Optane DC Persistent Memory No No No 12
4ZC7A15112 B4LX ThinkSystem 512GB TruDDR4 2666MHz (1.2V) Intel Optane DC Persistent Memory No No No 12

Internal storage

Internal storage configurations of the VX2320, VX3320, VX7320-N, and 1U Certified Node are as follows. All drives are hot-swap and are accessible from the front or rear of the system:

  • ThinkAgile VX2330 Appliance
    • Front drive bays: 4x 3.5-inch SAS/SATA
    • Rear drive bays: None
  • ThinkAgile VX3330 Appliance
    • Front drive bays: 6x 2.5-inch SAS/SATA & 4x 2.5-inch AnyBay
    • Rear drive bays: None
  • ThinkAgile VX7330-N Appliance
    • Front drive bays: 10x 2.5-inch NVMe
    • Rear drive bays: None
  • ThinkAgile VX3331 Certified Node
    • 4x 3.5" SAS/SATA (front) + 2x 2.5" SAS/SATA (rear)
    • 4x 3.5" AnyBay (front)
    • 6x 2.5" SAS/SATA & 4x 2.5" AnyBay (front) + 2x 2.5" SAS/SATA (rear)
    • 10x 2.5" NVMe (front)

The server also supports one or two M.2 drives for OS boot purposes, installed in an M.2 adapter internal to the server.

Ordering information is listed in the following table.

Table 8. Drive backplanes
Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
Front 3.5-inch drive backplanes
AUW8 ThinkSystem 3.5" SATA/SAS 4-Bay Backplane (4x SAS/SATA) 1 No No 1
B0WJ ThinkSystem SR630 3.5" AnyBay 4-Bay Backplane (4x AnyBay) No No No 1
Front 2.5-inch drive backplanes
AUW9 ThinkSystem 1U 10x2.5" (6x SAS/SATA 4x AnyBay) Backplane No 1 No 1
AVKF ThinkSystem SR630 2.5" U.2 10-Bay Backplane Kit (10x NVMe) No No 1 1
Rear 2.5-inch drive backplane
AUWJ ThinkSystem SR630 Rear HDD/SSD Kit (2x SAS/SATA) No No No 1

For details about these components, including configuration rules, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server#internal-storage

The following figure shows the internal drive bay configurations.

Internal drive bay configurations
Figure 5. Internal drive bay configurations

Disk Groups

The following table lists the supported Disk Groups for each VX system.

Table 9. Disk Groups
Drive Selection Rules VX2320 Appliance VX3320 Appliance VX7320-N Appliance VX 1U Certified Node
Model Type Hybrid (HY)
All Flash (AF)		 Hybrid (HY)
All Flash (AF)		 All Flash (AF) Hybrid (HY)
All Flash (AF)
Maximum number of drives 4 10 10 10
Number of Disk Groups 1 1 or 2 1 or 2 1 or 2
Number of Cache Drives per Disk Group 1 1 1 1
Number of Capacity Drives per Disk Group 2 - 3 2 - 7 2 - 7 2 - 7
Allowed Capacity Drive Quantities:
1 Disk Group (1 Cache Drive) 2 or 3 2, 3, 4, 5, 6 or 7 2, 3, 4, 5, 6 or 7 2, 3, 4, 5, 6 or 7
2 Disk Groups (2 Cache Drives) 4 4, 6 or 8 4, 6 or 8 4, 6 or 8
3 Disk Groups (3 Cache Drives) Not supported 6 6 6

Controllers for internal storage

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following storage controller options.

Table 10. Controllers for internal storage
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
12 Gb SAS/SATA non-RAID HBAs
7Y37A01088 AUNL ThinkSystem 430-8i SAS/SATA 12Gb HBA 1 No No 1
4Y37A72480 BJHH ThinkSystem 4350-8i SAS/SATA 12Gb HBA 1 1 No 1
4Y37A78601 BM51 ThinkSystem 440-8i SAS/SATA PCIe Gen4 12Gb HBA 1 1 No 1
7Y37A01089 AUNM ThinkSystem 430-16i SAS/SATA 12Gb HBA No 1 No 1
4Y37A72481 BJHJ ThinkSystem 4350-16i SAS/SATA 12Gb HBA No 1 No 1
4Y37A78602 BM50 ThinkSystem 440-16i SAS/SATA PCIe Gen4 12Gb HBA No 1 No 1
NVMe PCIe interfaces
7Y37A01081 AUV2 ThinkSystem 1610-4P NVMe Switch Adapter No No 2 2
4Y37A09719 B22D ThinkSystem 810-4P NVMe Switch Adapter No No 2 2

Internal drive options

This section lists the supported drives:

Configuration Note: VMware will no longer support higher capacity drives greater than 8TB

Boot drives

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following drive for boot functions.

Table 11. Boot drives
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
M.2 SSDs - 6 Gb SATA
4XB7A82286 BQ1Z ThinkSystem M.2 5400 PRO 240GB Read Intensive SATA 6Gb NHS SSD 2 2 2 2
4XB7A82287 BQ1Y ThinkSystem M.2 5400 PRO 480GB Read Intensive SATA 6Gb NHS SSD 2 2 2 2
4XB7A82288 BQ20 ThinkSystem M.2 5400 PRO 960GB Read Intensive SATA 6Gb NHS SSD 2 2 2 2

Internal drives for VX2320 Appliance

The following table lists the drives supported in the VX2320 Appliance. For both All Flash Storage and Hybrid Storage configurations, drives are classified as either Cache drives, Capacity drives, or both.

Table 12. Drives supported in the VX2320 Appliance
Part number Feature Description All Flash Storage Hybrid Storage
Cache Capacity Cache Capacity
3.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00042 AUU5 ThinkSystem 3.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 4
7XB7A00043 AUU6 ThinkSystem 3.5" 4TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 4
7XB7A00044 AUU7 ThinkSystem 3.5" 6TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No 4
7XB7A00045 B0YR ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No 4
3.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80324 BNWD ThinkSystem 3.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80325 BNWG ThinkSystem 3.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80326 BNWH ThinkSystem 3.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80327 BP3F ThinkSystem 3.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80328 BP3H ThinkSystem 3.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80344 BNW7 ThinkSystem 3.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD 4 4 4 No
4XB7A80345 BNWA ThinkSystem 3.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD 4 4 4 No
4XB7A80346 BNWB ThinkSystem 3.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD 4 4 4 No
4XB7A80347 BP3G ThinkSystem 3.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD 4 4 4 No
3.5-inch hot-swap 12 Gb SAS SSDs
4XB7A83218 BR0W ThinkSystem 3.5" Nytro 3750 400GB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A83219 BR0V ThinkSystem 3.5" Nytro 3750 800GB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A83220 BR0U ThinkSystem 3.5" Nytro 3750 1.6TB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A83221 BR0T ThinkSystem 3.5" Nytro 3750 3.2TB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A17066 B8HT ThinkSystem 3.5" PM1645a 800GB Mainstream SAS 12Gb Hot Swap SSD 4 4 4 No
3.5-inch hot-swap 6 Gb SAS SSDs
4XB7A17099 B8HR ThinkSystem 3.5" 5300 1.92TB Mainstream SATA 6Gb Hot Swap SSD 4 4 4 No
4XB7A17100 B8HX ThinkSystem 3.5" 5300 3.84TB Mainstream SATA 6Gb Hot Swap SSD 4 4 4 No
4XB7A17098 B8J0 ThinkSystem 3.5" 5300 960GB Mainstream SATA 6Gb Hot Swap SSD 4 4 4 No
4XB7A17119 BA7L ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No 4 No No
4XB7A17120 BA7M ThinkSystem 3.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No 4 No No
4XB7A17121 BA7N ThinkSystem 3.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No 4 No No
4XB7A17122 BK7F ThinkSystem 3.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No 4 No No
4XB7A17123 BK7G ThinkSystem 3.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No 4 No No
4XB7A13643 B49V ThinkSystem 3.5" S4610 3.84TB Mixed Use SATA 6Gb HS SSD 4 4 4 No
4XB7A17137 BA4W ThinkSystem 3.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 4 4 No
4XB7A17138 BA4X ThinkSystem 3.5" S4620 960GB Mixed Use SATA 6Gb HS SSD 4 4 4 No
4XB7A17139 BA4Y ThinkSystem 3.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD 4 4 4 No
4XB7A17140 BK7P ThinkSystem 3.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD 4 4 4 No

Internal drives for VX3320 Appliance

The following table lists the drives supported in the VX3320 Appliance. For both All Flash Storage and Hybrid Storage configurations, drives are classified as either Cache drives, Capacity drives, or both.

Table 13. Drives supported in the VX3320 Appliance
Part number Feature Description All Flash Storage Hybrid Storage
Cache Capacity Cache Capacity
2.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00034 AUM6 ThinkSystem 2.5" 1TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 10
7XB7A00035 AUM7 ThinkSystem 2.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 10
7XB7A00027 AUM1 ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD No No No 10
7XB7A00028 AUM2 ThinkSystem 2.5" 1.8TB 10K SAS 12Gb Hot Swap 512e HDD No No No 10
7XB7A00069 B0YS ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD No No No 10
7XB7A00026 AUM0 ThinkSystem 2.5" 900GB 10K SAS 12Gb Hot Swap 512n HDD No No No 10
7XB7A00023 AULX ThinkSystem 2.5" 900GB 15K SAS 12Gb Hot Swap 512e HDD No No No 10
2.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80318 BNWC ThinkSystem 2.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80319 BNWE ThinkSystem 2.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80320 BNWF ThinkSystem 2.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80321 BP3E ThinkSystem 2.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80322 BP3J ThinkSystem 2.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80340 BNW8 ThinkSystem 2.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD 12 12 12 No
4XB7A80341 BNW9 ThinkSystem 2.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD 12 12 12 No
4XB7A80342 BNW6 ThinkSystem 2.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD 12 12 12 No
4XB7A80343 BP3K ThinkSystem 2.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD 12 12 12 No
2.5-inch hot-swap 12 Gb SAS SSDs
4XB7A83214 BR10 ThinkSystem 2.5" Nytro 3750 400GB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A83215 BR0Z ThinkSystem 2.5" Nytro 3750 800GB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A83216 BR0Y ThinkSystem 2.5" Nytro 3750 1.6TB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A83217 BR0X ThinkSystem 2.5" Nytro 3750 3.2TB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A17062 B8HU ThinkSystem 2.5" PM1645a 800GB Mainstream SAS 12Gb Hot Swap SSD 10 10 10 No
4XB7A38175 B91A ThinkSystem 2.5" PM1643a 960GB Entry SAS 12Gb Hot Swap SSD No 10 No No
4XB7A17056 BC4R ThinkSystem 2.5" PM1643a 15.36TB Entry SAS 12Gb Hot Swap SSD 10 10 10 No
2.5-inch hot-swap 6 Gb SAS SSDs
4XB7A17080 B8J2 ThinkSystem 2.5" 5300 7.68TB Entry SATA 6Gb Hot Swap SSD No 10 No No
4XB7A17089 B8J6 ThinkSystem 2.5" 5300 960GB Mainstream SATA 6Gb Hot Swap SSD 10 10 10 No
4XB7A17090 B8JE ThinkSystem 2.5" 5300 1.92TB Mainstream SATA 6Gb Hot Swap SSD 10 10 10 No
4XB7A17091 B8J7 ThinkSystem 2.5" 5300 3.84TB Mainstream SATA 6Gb Hot Swap SSD 10 10 10 No
4XB7A13637 B49Q ThinkSystem 2.5" S4610 3.84TB Mixed Use SATA 6Gb HS SSD 10 10 10 No
4XB7A17125 BA7Q ThinkSystem 2.5" S4620 480GB Mixed Use SATA 6Gb HS SSD 10 10 10 No
4XB7A17126 BA4T ThinkSystem 2.5" S4620 960GB Mixed Use SATA 6Gb HS SSD 10 10 10 No
4XB7A17127 BA4U ThinkSystem 2.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD 10 10 10 No
4XB7A17128 BK7L ThinkSystem 2.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD 10 10 10 No
4XB7A82289 BQ21 ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82290 BQ24 ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82291 BQ22 ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82292 BQ23 ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82258 BQ1Q ThinkSystem 2.5" 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82259 BQ1P ThinkSystem 2.5" 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82260 BQ1R ThinkSystem 2.5" 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82261 BQ1X ThinkSystem 2.5" 5400 PRO 1.92TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82262 BQ1S ThinkSystem 2.5" 5400 PRO 3.84TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82263 BQ1T ThinkSystem 2.5" 5400 PRO 7.68TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A72438 BM8B ThinkSystem 2.5" PM893 480GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A72439 BM8A ThinkSystem 2.5" PM893 960GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A72440 BM89 ThinkSystem 2.5" PM893 1.92TB Read Intensive SATA 6Gb HS SSD No 12 12 No
4XB7A72441 BM88 ThinkSystem 2.5" PM893 3.84TB Read Intensive SATA 6Gb HS SSD 12 12 12 No
4XB7A72442 BM87 ThinkSystem 2.5" PM893 7.68TB Read Intensive SATA 6Gb HS SSD 12 12 12 No
4XB7A17101 BA7G ThinkSystem 2.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No 10 No No
4XB7A17102 BA7H ThinkSystem 2.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No 10 No No
4XB7A17103 BA7J ThinkSystem 2.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No 10 No No
4XB7A17104 BK77 ThinkSystem 2.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No 10 No No
4XB7A17105 BK78 ThinkSystem 2.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No 10 No No
2.5-inch PCIe 4.0 NVMe SSDs
4XB7A17129 BNEG ThinkSystem 2.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A17130 BNEH ThinkSystem 2.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A17133 BNEZ ThinkSystem 2.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A79639 BNF1 ThinkSystem 2.5" U.3 7450 MAX 800GB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A13967 BNEJ ThinkSystem 2.5" U.3 7450 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A13970 BNEY ThinkSystem 2.5" U.3 7450 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A13971 BNEL ThinkSystem 2.5" U.3 7450 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A38197 BC4Z ThinkSystem U.2 PM1733 3.84TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10 No No
4XB7A38283 BE2E ThinkSystem U.2 PM1733 7.68TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10 No No
4XB7A38284 BE2F ThinkSystem U.2 PM1733 15.36TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10 No No

Internal drives for VX7320-N Appliance

The following table lists the drives supported in the VX7320-N Appliance. The VX7320-N Appliance only supports an All Flash Storage configuration, and drives are classified as either Cache drives, Capacity drives, or both.

Table 14. Drives supported in the VX7320-N Appliance
Part number Feature Description All Flash Storage
Cache Capacity
2.5-inch hot-swap 6 Gb SAS SSDs
4XB7A82289 BQ21 ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD 12 12
4XB7A82290 BQ24 ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD 12 12
4XB7A82291 BQ22 ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD 12 12
4XB7A82292 BQ23 ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD 12 12
2.5-inch PCIe 4.0 NVMe SSDs
4XB7A17145 BCFT ThinkSystem 2.5" U.2 P5500 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A13941 BMGD ThinkSystem 2.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A13942 BMGE ThinkSystem 2.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A13943 BNEF ThinkSystem 2.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A13631 BNEQ ThinkSystem 2.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A17129 BNEG ThinkSystem 2.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A17130 BNEH ThinkSystem 2.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A17133 BNEZ ThinkSystem 2.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A79639 BNF1 ThinkSystem 2.5" U.3 7450 MAX 800GB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A13967 BNEJ ThinkSystem 2.5" U.3 7450 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A13970 BNEY ThinkSystem 2.5" U.3 7450 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A13971 BNEL ThinkSystem 2.5" U.3 7450 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10
4XB7A38197 BC4Z ThinkSystem U.2 PM1733 3.84TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10
4XB7A38283 BE2E ThinkSystem U.2 PM1733 7.68TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10
4XB7A38284 BE2F ThinkSystem U.2 PM1733 15.36TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10
4XB7A81951 BPKX ThinkSystem 2.5" U.3 PM1733a 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A81952 BPKY ThinkSystem 2.5" U.3 PM1733a 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A81953 BPKZ ThinkSystem 2.5" U.3 PM1733a 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10
4XB7A81954 BPL0 ThinkSystem 2.5" U.3 PM1733a 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 32

Internal drives for VX 1U Certified Node

The following table lists the drives supported in the VX 1U Certified Node. For both All Flash Storage and Hybrid Storage configurations, drives are classified as either Cache drives, Capacity drives, or both.

Table 15. Drives supported in the VX 1U Certified Node
Part number Feature Description All Flash Storage Hybrid Storage
Cache Capacity Cache Capacity
2.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00034 AUM6 ThinkSystem 2.5" 1TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 12
7XB7A00035 AUM7 ThinkSystem 2.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 12
7XB7A00027 AUM1 ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD No No No 12
7XB7A00028 AUM2 ThinkSystem 2.5" 1.8TB 10K SAS 12Gb Hot Swap 512e HDD No No No 12
7XB7A00069 B0YS ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD No No No 12
7XB7A00026 AUM0 ThinkSystem 2.5" 900GB 10K SAS 12Gb Hot Swap 512n HDD No No No 12
7XB7A00023 AULX ThinkSystem 2.5" 900GB 15K SAS 12Gb Hot Swap 512e HDD No No No 12
2.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80318 BNWC ThinkSystem 2.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80319 BNWE ThinkSystem 2.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80320 BNWF ThinkSystem 2.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80321 BP3E ThinkSystem 2.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80322 BP3J ThinkSystem 2.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD No 12 No No
4XB7A80340 BNW8 ThinkSystem 2.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD 12 12 12 No
4XB7A80341 BNW9 ThinkSystem 2.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD 12 12 12 No
4XB7A80342 BNW6 ThinkSystem 2.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD 12 12 12 No
4XB7A80343 BP3K ThinkSystem 2.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD 12 12 12 No
2.5-inch hot-swap 12 Gb SAS SSDs
4XB7A83214 BR10 ThinkSystem 2.5" Nytro 3750 400GB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A83215 BR0Z ThinkSystem 2.5" Nytro 3750 800GB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A83216 BR0Y ThinkSystem 2.5" Nytro 3750 1.6TB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A83217 BR0X ThinkSystem 2.5" Nytro 3750 3.2TB Write Intensive SAS 12Gb HS SSD 12 12 12 No
4XB7A17062 B8HU ThinkSystem 2.5" PM1645a 800GB Mainstream SAS 12Gb Hot Swap SSD 12 12 12 No
4XB7A38175 B91A ThinkSystem 2.5" PM1643a 960GB Entry SAS 12Gb Hot Swap SSD No 12 No No
4XB7A17056 BC4R ThinkSystem 2.5" PM1643a 15.36TB Entry SAS 12Gb Hot Swap SSD 12 12 12 No
2.5-inch hot-swap 6 Gb SAS SSDs
4XB7A17080 B8J2 ThinkSystem 2.5" 5300 7.68TB Entry SATA 6Gb Hot Swap SSD No 12 No No
4XB7A17089 B8J6 ThinkSystem 2.5" 5300 960GB Mainstream SATA 6Gb Hot Swap SSD 12 12 12 No
4XB7A17090 B8JE ThinkSystem 2.5" 5300 1.92TB Mainstream SATA 6Gb Hot Swap SSD 12 12 12 No
4XB7A17091 B8J7 ThinkSystem 2.5" 5300 3.84TB Mainstream SATA 6Gb Hot Swap SSD 12 12 12 No
4XB7A13637 B49Q ThinkSystem 2.5" S4610 3.84TB Mixed Use SATA 6Gb HS SSD 10 10 10 No
4XB7A17125 BA7Q ThinkSystem 2.5" S4620 480GB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A17126 BA4T ThinkSystem 2.5" S4620 960GB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A17127 BA4U ThinkSystem 2.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A17128 BK7L ThinkSystem 2.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82289 BQ21 ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82290 BQ24 ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82291 BQ22 ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82292 BQ23 ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD 12 12 12 No
4XB7A82258 BQ1Q ThinkSystem 2.5" 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82259 BQ1P ThinkSystem 2.5" 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82260 BQ1R ThinkSystem 2.5" 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82261 BQ1X ThinkSystem 2.5" 5400 PRO 1.92TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82262 BQ1S ThinkSystem 2.5" 5400 PRO 3.84TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A82263 BQ1T ThinkSystem 2.5" 5400 PRO 7.68TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A72438 BM8B ThinkSystem 2.5" PM893 480GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A72439 BM8A ThinkSystem 2.5" PM893 960GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A72440 BM89 ThinkSystem 2.5" PM893 1.92TB Read Intensive SATA 6Gb HS SSD No 12 12 No
4XB7A72441 BM88 ThinkSystem 2.5" PM893 3.84TB Read Intensive SATA 6Gb HS SSD 12 12 12 No
4XB7A72442 BM87 ThinkSystem 2.5" PM893 7.68TB Read Intensive SATA 6Gb HS SSD 12 12 12 No
4XB7A17101 BA7G ThinkSystem 2.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A17102 BA7H ThinkSystem 2.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A17103 BA7J ThinkSystem 2.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A17104 BK77 ThinkSystem 2.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No 12 No No
4XB7A17105 BK78 ThinkSystem 2.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No 12 No No
2.5-inch PCIe 4.0 NVMe SSDs
4XB7A17145 BCFT ThinkSystem 2.5" U.2 P5500 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A13941 BMGD ThinkSystem 2.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A13942 BMGE ThinkSystem 2.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A13943 BNEF ThinkSystem 2.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A13631 BNEQ ThinkSystem 2.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A17129 BNEG ThinkSystem 2.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A17130 BNEH ThinkSystem 2.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A17133 BNEZ ThinkSystem 2.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A79639 BNF1 ThinkSystem 2.5" U.3 7450 MAX 800GB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A13967 BNEJ ThinkSystem 2.5" U.3 7450 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A13970 BNEY ThinkSystem 2.5" U.3 7450 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A13971 BNEL ThinkSystem 2.5" U.3 7450 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD 10 10 No No
4XB7A38197 BC4Z ThinkSystem U.2 PM1733 3.84TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10 No No
4XB7A38283 BE2E ThinkSystem U.2 PM1733 7.68TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10 No No
4XB7A38284 BE2F ThinkSystem U.2 PM1733 15.36TB Entry NVMe PCIe 4.0 x4 Hot Swap SSD 10 10 No No
4XB7A81951 BPKX ThinkSystem 2.5" U.3 PM1733a 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A81952 BPKY ThinkSystem 2.5" U.3 PM1733a 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A81953 BPKZ ThinkSystem 2.5" U.3 PM1733a 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 10 No No
4XB7A81954 BPL0 ThinkSystem 2.5" U.3 PM1733a 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD No 32 No No
3.5-inch hot-swap 12 Gb SAS HDDs
7XB7A00042 AUU5 ThinkSystem 3.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 4
7XB7A00043 AUU6 ThinkSystem 3.5" 4TB 7.2K SAS 12Gb Hot Swap 512n HDD No No No 4
7XB7A00044 AUU7 ThinkSystem 3.5" 6TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No 4
7XB7A00045 B0YR ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD No No No 4
3.5-inch hot-swap 24 Gb SAS SSDs
4XB7A80324 BNWD ThinkSystem 3.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80325 BNWG ThinkSystem 3.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80326 BNWH ThinkSystem 3.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80327 BP3F ThinkSystem 3.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80328 BP3H ThinkSystem 3.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD 4 4 4 No
4XB7A80344 BNW7 ThinkSystem 3.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD 4 4 4 No
4XB7A80345 BNWA ThinkSystem 3.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD 4 4 4 No
4XB7A80346 BNWB ThinkSystem 3.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD 4 4 4 No
4XB7A80347 BP3G ThinkSystem 3.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD 4 4 4 No
3.5-inch hot-swap 12 Gb SAS SSDs
4XB7A83218 BR0W ThinkSystem 3.5" Nytro 3750 400GB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A83219 BR0V ThinkSystem 3.5" Nytro 3750 800GB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A83220 BR0U ThinkSystem 3.5" Nytro 3750 1.6TB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A83221 BR0T ThinkSystem 3.5" Nytro 3750 3.2TB Write Intensive SAS 12Gb HS SSD 4 4 4 No
4XB7A17066 B8HT ThinkSystem 3.5" PM1645a 800GB Mainstream SAS 12Gb Hot Swap SSD 8 8 8 No
3.5-inch hot-swap 6 Gb SAS SSDs
4XB7A17081 B8JB ThinkSystem 3.5" 5300 240GB Entry SATA 6Gb Hot Swap SSD No 8 No No
4XB7A17086 B8J3 ThinkSystem 3.5" 5300 7.68TB Entry SATA 6Gb Hot Swap SSD No 8 No No
4XB7A17099 B8HR ThinkSystem 3.5" 5300 1.92TB Mainstream SATA 6Gb Hot Swap SSD 8 8 8 No
4XB7A17100 B8HX ThinkSystem 3.5" 5300 3.84TB Mainstream SATA 6Gb Hot Swap SSD 8 8 8 No
4XB7A17098 B8J0 ThinkSystem 3.5" 5300 960GB Mainstream SATA 6Gb Hot Swap SSD 8 8 8 No
4XB7A13643 B49V ThinkSystem 3.5" S4610 3.84TB Mixed Use SATA 6Gb HS SSD 4 4 4 No

Network adapters

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following networking options.

For details about these options, including configuration rules, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server#i-o-expansion
https://lenovopress.com/lp1049-thinksystem-sr630-server#network-adapters

Table 16. LOM network adapters
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
LOM cards - Gigabit Ethernet
7ZT7A00544 AUKG ThinkSystem 1Gb 2-port RJ45 LOM 1 No No 1
7ZT7A00545 AUKH ThinkSystem 1Gb 4-port RJ45 LOM 1 No No 1
LOM cards - 10 Gb Ethernet
7ZT7A00548 AUKL ThinkSystem 10Gb 2-port Base-T LOM 1 1 1 1
7ZT7A00546 AUKJ ThinkSystem 10Gb 2-port SFP+ LOM 1 1 1 1
7ZT7A00549 AUKM ThinkSystem 10Gb 4-port Base-T LOM 1 1 1 1
7ZT7A00547 AUKK ThinkSystem 10Gb 4-port SFP+ LOM 1 1 1 1
Table 17. PCIe network adapters
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
ML2 adapters - 10 Gb Ethernet
01CV770 AU7Z Emulex VFA5.2 ML2 2x10 GbE SFP+ Adapter and FCoE/iSCSI SW No No No 1
00JY940 ATRH Intel X710-DA2 ML2 2x10GbE SFP+ Adapter No No No 1
ML2 adapters - 25 Gb Ethernet
00MN990 ATZR Mellanox ConnectX-4 Lx 10/25GbE SFP28 1-port ML2 Adapter No No No 3
7ZT7A00507 AUKU ThinkSystem Mellanox ConnectX-4 Lx 10/25GbE SFP28 2-Port ML2 Ethernet Adapter No No No 3
PCIe Low Profile adapters - 1 Gb Ethernet
7ZT7A00482 AUZX ThinkSystem Broadcom 5720 1GbE RJ45 2-Port PCIe Ethernet Adapter No No No 3
7ZT7A00484 AUZV ThinkSystem Broadcom 5719 1GbE RJ45 4-Port PCIe Ethernet Adapter No No No 3
7ZT7A00534 AUZY ThinkSystem I350-T2 PCIe 1Gb 2-Port RJ45 Ethernet Adapter No No No 3
7ZT7A00535 AUZW ThinkSystem I350-T4 PCIe 1Gb 4-Port RJ45 Ethernet Adapter No No No 3
PCIe Low Profile adapters - 10 Gb Ethernet
4XC7A79699 BMXB ThinkSystem Intel X710-T4L 10GBase-T 4-Port PCIe Ethernet Adapter 3 3 3 3
7ZT7A00496 AUKP ThinkSystem Broadcom 57416 10GBASE-T 2-Port PCIe Ethernet Adapter No No No 3
00AG570 AT7S Emulex VFA5.2 2x10 GbE SFP+ PCIe Adapter 3 3 3 3
00MM860 ATPX Intel X550-T2 Dual Port 10GBase-T Adapter 3 3 3 3
PCIe Full Height adapters - 10 Gb Ethernet
7ZT7A00537 AUKX ThinkSystem Intel X710-DA2 PCIe 10Gb 2-Port SFP+ Ethernet Adapter 3 3 3 3
7ZT7A00493 AUKN ThinkSystem Emulex OCe14104B-NX PCIe 10Gb 4-Port SFP+ Ethernet Adapter No No No 1
PCIe Low Profile adapters - 25 Gb Ethernet
7ZT7A00505 AUKS ThinkSystem Broadcom 57412 25GbE SFP28 1-Port PCIe Ethernet Adapter 3 3 3 3
4XC7A08238 B5T0 ThinkSystem Broadcom 57414 10/25GbE SFP28 2-port PCIe Ethernet Adapter 3 3 3 3
4XC7A08316 BD49 ThinkSystem Broadcom 57454 10/25GbE SFP28 4-port PCIe Ethernet Adapter V2 1 1 1 1
7XC7A05523 B0WY ThinkSystem Intel XXV710-DA2 10/25GbE SFP28 2-Port PCIe Ethernet Adapter 3 3 3 3
01GR250 AUAJ Mellanox ConnectX-4 Lx 10/25GbE SFP28 2-port PCIe Ethernet Adapter 3 3 3 3
4XC7A62580 BE4U ThinkSystem Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-Port PCIe Ethernet Adapter 3 3 No 3
4XC7A08228 B21R ThinkSystem QLogic QL41262 10/25GbE SFP28 2-Port PCIe Ethernet Adapter No No No 3
PCIe Low Profile adapters - 40 Gb Ethernet
00MM950 ATRN Mellanox ConnectX-4 Lx 1x40GbE QSFP+ Adapter No No No 3
4XC7A08229 B31C ThinkSystem Mellanox ConnectX-5 Ex 25/40GbE 2-port Low-Latency Adapter No No No 2
PCIe x16 Low Profile adapters - 100 Gb Ethernet
00MM960 ATRP Mellanox ConnectX-4 2x100GbE/EDR IB QSFP28 VPI Adapter No No No 3
4XC7A08248 B8PP ThinkSystem Mellanox ConnectX-6 Dx 100GbE QSFP56 2-port PCIe Ethernet Adapter 2 2 No 2
4C57A14177 B4R9 ThinkSystem Mellanox ConnectX-6 HDR100/100GbE QSFP56 1-port PCIe VPI Adapter 2 2 No 2
4C57A14178 B4RA ThinkSystem Mellanox ConnectX-6 HDR100/100GbE QSFP56 2-port PCIe VPI Adapter 2 2 No 2
PCIe x16 Low Profile adapters - 200 Gb Ethernet
4C57A15326 B4RC ThinkSystem Mellanox ConnectX-6 HDR/200GbE QSFP56 1-port PCIe 4 VPI Adapter No 1 1 1

GPU adapters

The VX2320, VX3320, VX7320-N, and 1U Certified Node systems support the following GPU options.

For details about these options, including configuration rules, see the SR630 product guide:
https://lenovopress.com/lp1049-thinksystem-sr630-server#gpu-adapters

Table 18. GPU adapters
Part number Feature Description Maximum supported
VX2320 VX3320 VX7320-N VX 1U
4X67A11584 B31D ThinkSystem NVIDIA Quadro P620 2GB PCIe Active GPU No No No 3
4X67A14926 B4YB ThinkSystem NVIDIA T4 16GB PCIe Passive GPU No No No 2
4X67A81547 BP05 ThinkSystem NVIDIA A2 16GB PCIe Gen4 Passive GPU No No No 2
CTO Only BQZT ThinkSystem NVIDIA A2 16GB PCIe Gen4 Passive GPU w/o CEC No No No 2

Operating system support

The VX2320 Appliance supports the following operating systems:

  • VMware ESXi 6.5 U2
  • VMware ESXi 6.5 U3
  • VMware ESXi 6.7 U1
  • VMware ESXi 6.7 U2
  • VMware ESXi 6.7 U3
  • VMware ESXi 7.0
  • VMware ESXi 7.0 U1
  • VMware ESXi 7.0 U2
  • VMware ESXi 7.0 U3
  • VMware ESXi 8.0
  • VMware ESXi 8.0 U1
  • VMware ESXi 8.0 U2

The VX3320 Appliance supports the following operating systems:

  • VMware ESXi 6.5 U2
  • VMware ESXi 6.5 U3
  • VMware ESXi 6.7 U1
  • VMware ESXi 6.7 U2
  • VMware ESXi 6.7 U3
  • VMware ESXi 7.0
  • VMware ESXi 7.0 U1
  • VMware ESXi 7.0 U2
  • VMware ESXi 7.0 U3
  • VMware ESXi 8.0
  • VMware ESXi 8.0 U1
  • VMware ESXi 8.0 U2

The VX7320-N Appliance supports the following operating systems:

  • VMware ESXi 6.5 U2
  • VMware ESXi 6.5 U3
  • VMware ESXi 6.7 U1
  • VMware ESXi 6.7 U2
  • VMware ESXi 6.7 U3
  • VMware ESXi 7.0
  • VMware ESXi 7.0 U1
  • VMware ESXi 7.0 U2
  • VMware ESXi 7.0 U3
  • VMware ESXi 8.0
  • VMware ESXi 8.0 U1
  • VMware ESXi 8.0 U2

The VX 1U Certified Node supports the following operating systems:

  • VMware ESXi 6.5 U2
  • VMware ESXi 6.5 U3
  • VMware ESXi 6.7 U1
  • VMware ESXi 6.7 U2
  • VMware ESXi 6.7 U3
  • VMware ESXi 7.0
  • VMware ESXi 7.0 U1
  • VMware ESXi 7.0 U2
  • VMware ESXi 7.0 U3
  • VMware ESXi 8.0
  • VMware ESXi 8.0 U1
  • VMware ESXi 8.0 U2

For further details, including any restrictions, see the OS Interoperability Guide:
https://lenovopress.com/osig#term=vx%2520purley%25201u%2520%2522gen%25202%2522&support=all

Software

VMware vSAN, vSphere, and vCenter Server software are required for ThinkAgile VX Series Integrated Systems and Certified Nodes. For Integrated Systems, you are required to purchase VMware vSAN licenses for VX Series from Lenovo. Customers have the option to transfer the license after it has initially landed on Lenovo VX Integrated System. For Certified Nodes, you can purchase the vSAN licenses from Lenovo or from VMware, or you can use your existing licenses. For vSphere and vCenter Server, you can use the existing VMware software licenses and active support contracts, or you can purchase software licenses and support from Lenovo or VMware.

Lenovo offers the following VMware software license and support options for ThinkAgile VX Series systems:

  • VMware vSAN License and Subscription
  • VMware vSphere License and Subscription
  • VMware HCI Kit License and Subscription
  • VMware Horizon License and Subscription
  • VMware Cloud Foundation License and Subscription
  • VMware vCenter Server License and Subscription

For details and ordering information, see the VMware Software Solution Product Guide:
https://lenovopress.com/lp1265-vmware-software-solution-product-guide

Configuration notes:

  • The selection of vSAN licenses is required: Standalone licenses, HCI bundle licenses, VDI solution licenses, or VCF licenses.
  • VMware software licenses that are available for selection include 1-year, 3-year, or 5-year software support (matches the duration of the selected solution-level warranty period).
  • The quantity of processor-based licenses is derived by the configuration tool based on the number of processors selected.
  • The quantity of VM-based licenses is specified based on VM requirements.
  • The quantity of CCU-based licenses is specified based on the concurrent user requirements.

Warranty and Support

The VX2320, VX3320, VX7320-N, and 1U Certified Node have a 3-year warranty based on the machine type:

  • 7Y93 - 3 year warranty

The ThinkAgile VX Series Appliances can be configured with a three- or five-year hardware warranty with 24x7 ThinkAgile Advantage Single Point of Support (Lenovo server hardware and VMware software; requires an active software support contract purchased either from VMware or Lenovo) and various levels of coverage with a well-defined scope of services, including service hours, response time, term of service, and service agreement terms and conditions.

The Lenovo local support centers perform problem determination and resolution for hardware-related issues and escalate to VMware, on behalf of the customer, for software-related problem determination. VMware will contact the customer and will own the software-related problem resolution until closure.

The standard warranty terms are customer-replaceable unit (CRU) and onsite (for field-replaceable units FRUs only) with standard call center support during normal business hours and 9x5 Next Business Day Parts Delivered.

Lenovo’s additional support services provide a sophisticated, unified support structure for your data center, with an experience consistently ranked number one in customer satisfaction worldwide. Available offerings include:

  • Premier Support

    Premier Support provides a Lenovo-owned customer experience and delivers direct access to technicians skilled in hardware, software, and advanced troubleshooting, in addition to the following:

    • Direct technician-to-technician access through a dedicated phone line
    • 24x7x365 remote support
    • Single point of contact service
    • End to end case management
    • Third-party collaborative software support
    • Online case tools and live chat support
    • On-demand remote system analysis
  • Warranty Upgrade (Preconfigured Support)

    Services are available to meet the on-site response time targets that match the criticality of your systems.

    • 3, 4, or 5 years of service coverage
    • 1-year or 2-year post-warranty extensions
    • Foundation Service: 9x5 service coverage with next business day onsite response. YourDrive YourData is an optional extra (see below).
    • Essential Service: 24x7 service coverage with 4-hour onsite response or 24-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
    • Advanced Service: 24x7 service coverage with 2-hour onsite response or 6-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
  • Managed Services

    Lenovo Managed Services provides continuous 24x7 remote monitoring (plus 24x7 call center availability) and proactive management of your data center using state-of-the-art tools, systems, and practices by a team of highly skilled and experienced Lenovo services professionals.

    Quarterly reviews check error logs, verify firmware & OS device driver levels, and software as needed. We’ll also maintain records of latest patches, critical updates, and firmware levels, to ensure you systems are providing business value through optimized performance.

  • Technical Account Management (TAM)

    A Lenovo Technical Account Manager helps you optimize the operation of your data center based on a deep understanding of your business. You gain direct access to your Lenovo TAM, who serves as your single point of contact to expedite service requests, provide status updates, and furnish reports to track incidents over time. In addition, your TAM will help proactively make service recommendations and manage your service relationship with Lenovo to make certain your needs are met.

  • Enterprise Server Software Support

    Enterprise Software Support is an additional support service providing customers with software support on Microsoft, Red Hat, SUSE, and VMware applications and systems. Around the clock availability for critical problems plus unlimited calls and incidents helps customers address challenges fast, without incremental costs. Support staff can answer troubleshooting and diagnostic questions, address product comparability and interoperability issues, isolate causes of problems, report defects to software vendors, and more.

  • YourDrive YourData

    Lenovo’s YourDrive YourData is a multi-drive retention offering that ensures your data is always under your control, regardless of the number of drives that are installed in your Lenovo server. In the unlikely event of a drive failure, you retain possession of your drive while Lenovo replaces the failed drive part. Your data stays safely on your premises, in your hands. The YourDrive YourData service can be purchased in convenient bundles and is optional with Foundation Service. It is bundled with Essential Service and Advanced Service.

  • Health Check

    Having a trusted partner who can perform regular and detailed health checks is central to maintaining efficiency and ensuring that your systems and business are always running at their best. Health Check supports Lenovo-branded server, storage, and networking devices, as well as select Lenovo-supported products from other vendors that are sold by Lenovo or a Lenovo-Authorized Reseller.

Examples of region-specific warranty terms are second or longer business day parts delivery or parts-only base warranty.

If warranty terms and conditions include onsite labor for repair or replacement of parts, Lenovo will dispatch a service technician to the customer site to perform the replacement. Onsite labor under base warranty is limited to labor for replacement of parts that have been determined to be field-replaceable units (FRUs). Parts that are determined to be customer-replaceable units (CRUs) do not include onsite labor under base warranty.

If warranty terms include parts-only base warranty, Lenovo is responsible for delivering only replacement parts that are under base warranty (including FRUs) that will be sent to a requested location for self-service. Parts-only service does not include a service technician being dispatched onsite. Parts must be changed at customer’s own cost and labor and defective parts must be returned following the instructions supplied with the spare parts.

Lenovo Service offerings are region-specific. Not all preconfigured support and upgrade options are available in every region. For information about Lenovo service upgrade offerings that are available in your region, refer to the following resources:

For service definitions, region-specific details, and service limitations, please refer to the following documents:

Software maintenance

The ThinkAgile VX Series Integrated Systems (appliances) include one- (PRC only), three-, or five-year software support and subscription (matches the duration of the selected warranty period) that entitles customers to submit service requests to troubleshoot VMware software issues and receive code updates, including fixes, patches, and new software releases.

The Lenovo local support centers perform problem determination and resolution for hardware-related issues and escalate to VMware, on behalf of the customer, for software-related problem determination. VMware will contact the customer and will own the software-related problem resolution until closure.

For the VMware vSphere, vSAN, and vCenter Server software and subscription licenses purchased from Lenovo together with the ThinkAgile VX Series Integrated Systems, software support that is provided by VMware includes Production-level support with 24x7 phone and web coverage with the following target response times (priorities are defined by VMware based on the impact on productivity):

  • Severity 1 (Critical: Substantial loss or disruption of service, significant risk of data loss): 30 minutes
  • Severity 2 (Major: Operations are severely constrained, significant impact): 4 business hours
  • Severity 3 (Minor: Non-critical loss of functionality, minimal impact): 8 business hours
  • Severity 4 (Cosmetic: General questions): 12 business hours

For the VMware software and subscription licenses provided by the customer, software support that is provided by VMware is based on the support level included with these licenses.

Deployment services

The following optional Lenovo basic installation services are available for the ThinkAgile VX Series Integrated Systems (appliances):

  • Unpacking and inspecting the systems
  • Mounting the systems in a rack cabinet
  • Connecting the systems to electrical power and network
  • Checking and updating firmware to the latest levels
  • Verifying operations
  • Disposal of the packaging materials (within the customer site)

The following Lenovo deployment services are available for the ThinkAgile VX Series Integrated Systems to get customers up and running quickly:

  • Conducting remote preparation and planning
  • Verifying firmware versions and performing firmware updates, if needed
  • Configuring XCC management settings
  • Configuring hypervisor settings
  • Configuring vSAN
  • Configuring VMware vCenter Server and discovering hosts and storage
  • Configuring Lenovo XClarity network settings and performing discovery and inventory
  • Transferring knowledge
  • Developing post-installation documentation

The following table lists ThinkAgile Health Check & Deployment offerings are available for ThinkAgile VX customers. These offerings are performed by Lenovo Professional Services.

  • Onsite Deployment: Install, configure, and validate solution on-site, and conduct knowledge transfer.
  • Remote Deployment: Install, configure, and validate solution remotely, and conduct knowledge transfer.
  • Remote Health Check: Report & remediation of hardware and cluster health issues, including firmware and software updates.
Table 19. ThinkAgile Deployment offerings
Part number Description
Onsite deployment services
5MS7B00082 ThinkAgile VX Onsite Deployment (up to 4 nodes)
5MS7B00083 ThinkAgile VX Onsite Deployment (additional node)
Remote deployment services
5MS7A87711 ThinkAgile VX Remote Deployment (up to 4 nodes)
5MS7A87712 ThinkAgile VX Remote Deployment (additional node)
Remote Health Check
5MS7B00178 ThinkAgile VX 1X Remote Health Check (up to 4 node cluster)
5MS7B00179 ThinkAgile VX 1X Remote Health Check (additional node)
5MS7B00059 ThinkAgile VX 1X Remote Health Check & Update (up to 4 node cluster)
5MS7B00060 ThinkAgile VX 1X Remote Health Check & Update (additional node)

For more information, refer to the Data Center Implementation Services web page:
https://www.lenovo.com/us/en/data-center/services/implementation-services/

Regulatory compliance

The server conforms to the following standards:

  • Energy Star 3.0
  • FCC: Verified to comply with Part 15 of the FCC Rules, Class A
  • Canada ICES-003, issue 6, Class A
  • UL/IEC 62368-1
  • CAN/CSA-C22.2 No. 62368-1
  • NOM-019
  • Argentina IEC 62368-1
  • Japan VCCI, Class A
  • Australia/New Zealand AS/NZS CISPR 32, Class A; AS/NZS 60950.1
  • IEC 60950-1 & IEC 62368-1 (CB Certificate and CB Test Report)
  • China CCC (GB4943.1), GB9254 Class A, GB17625.1
  • Taiwan BSMI CNS13438, Class A; CNS14336-1; section 5 of CNS15663
  • Korea KN32, Class A; KN35
  • Russia, Belorussia and Kazakhstan, EAC: TP TC 004/2011 (for Safety); TP TC 020/2011 (for EMC); TP EAC 037/2016 (for RoHS)
  • CE Mark (EN55032 Class A, EN60950-1, EN62368-1, EN55024, EN55035, EN61000-3-2, (EU) 2019/424, EN 50581-1 and EN61000-3-3)
  • CISPR 32, Class A
  • TUV-GS (EN62368-1, EK1-ITB2000, AfPS GS 01 PAK Par. 3.1)
  • India BIS certification

Lenovo Financial Services

Lenovo Financial Services reinforces Lenovo’s commitment to deliver pioneering products and services that are recognized for their quality, excellence, and trustworthiness. Lenovo Financial Services offers financing solutions and services that complement your technology solution anywhere in the world.

We are dedicated to delivering a positive finance experience for customers like you who want to maximize your purchase power by obtaining the technology you need today, protect against technology obsolescence, and preserve your capital for other uses.

We work with businesses, non-profit organizations, governments and educational institutions to finance their entire technology solution. We focus on making it easy to do business with us. Our highly experienced team of finance professionals operates in a work culture that emphasizes the importance of providing outstanding customer service. Our systems, processes and flexible policies support our goal of providing customers with a positive experience.

We finance your entire solution. Unlike others, we allow you to bundle everything you need from hardware and software to service contracts, installation costs, training fees, and sales tax. If you decide weeks or months later to add to your solution, we can consolidate everything into a single invoice.

Our Premier Client services provide large accounts with special handling services to ensure these complex transactions are serviced properly. As a premier client, you have a dedicated finance specialist who manages your account through its life, from first invoice through asset return or purchase. This specialist develops an in-depth understanding of your invoice and payment requirements. For you, this dedication provides a high-quality, easy, and positive financing experience.

For your region-specific offers, please ask your Lenovo sales representative or your technology provider about the use of Lenovo Financial Services. For more information, see the following Lenovo website:

https://www.lenovo.com/us/en/landingpage/lenovo-financial-services/

Related product families

Product families related to this document are the following:

Trademarks

Lenovo and the Lenovo logo are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. A current list of Lenovo trademarks is available on the Web at https://www.lenovo.com/us/en/legal/copytrade/.

The following terms are trademarks of Lenovo in the United States, other countries, or both:
Lenovo®
AnyBay®
Lenovo Services
ThinkAgile®
ThinkSystem®
TruDDR4
XClarity®

The following terms are trademarks of other companies:

Intel®, Intel Optane™, and Xeon® are trademarks of Intel Corporation or its subsidiaries.

Microsoft®, SQL Server®, and SharePoint® are trademarks of Microsoft Corporation in the United States, other countries, or both.

Other company, product, or service names may be trademarks or service marks of others.

[]
© 2024 Lenovo. All rights reserved.
Privacy Site Map Terms of Use External Submission Policy Sales terms and conditions Anti-Slavery and Human Trafficking Statement
