Abstract

The Lenovo ThinkSystem SR655 V3 is a 1-socket 2U server that features the AMD EPYC 9004 "Genoa" family of processors. With up to 128 cores per processor and support for the new PCIe 5.0 standard for I/O, the SR655 V3 offers the ultimate in one-socket server performance in a 2U form factor.

This product guide provides essential pre-sales information to understand the ThinkSystem SR655 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR655 V3 and consider its use in IT solutions.

Change History

Changes in the August 29, 2023 update:

  • Added the following memory DIMMs - Memory options section:
    • ThinkSystem 96GB TruDDR5 4800MHz (2Rx4) 10x4 RDIMM-A, 4X77A81448
    • ThinkSystem 128GB TruDDR5 4800MHz (4Rx4) 3DS RDIMM-A, BYEE (CTO only)

Introduction

The Lenovo ThinkSystem SR655 V3 is a 1-socket 2U server that features the AMD EPYC 9004 "Genoa" family of processors. With up to 128 cores per processor and support for the new PCIe 5.0 standard for I/O, the SR655 V3 offers the ultimate in one-socket server performance in a 2U form factor. The server is ideal for dense workloads that can take advantage of GPU processing and high-performance NVMe drives.

Suggested uses: AI Inference, VDI, OLTP, Analytics, software-defined storage

Lenovo ThinkSystem SR655 V3
Figure 1. Lenovo ThinkSystem SR655 V3

Did you know?

The SR655 V3 server is a very configuration-rich offering, supporting 31 different drive bay configurations in the front, middle and rear of the server and 6 different slot configurations at the rear of the server. This level of flexibility ensures that you can configure the server exactly the way your workload requires.

Key features

Combining performance and flexibility, the SR655 V3 server is a great choice for enterprises of all sizes. The server offers a broad selection of drive and slot configurations and offers high performance features that industries such as finance, healthcare and telco need. Outstanding reliability, availability, and serviceability (RAS) and high-efficiency design can improve your business environment and can help save operational costs.

Scalability and performance

The following features boost performance, improve scalability and reduce costs:

  • Supports one fourth-generation AMD EPYC 9004 processor
    • Up to 128 cores and 256 threads
    • Core speed of up to 4.1 GHz
    • TDP rating of up to 360 W
  • Support for DDR5 memory DIMMs to maximize the performance of the memory subsystem:
    • 12 DDR5 memory DIMMs
    • 12 memory channels (1 DIMM per channel)
    • DIMM speeds up to 4800 MHz
    • Using 128GB 3DS RDIMMs, the server supports up to 1.5TB of system memory
  • Supports up to eight single-width GPUs or three double-wide GPUs, for substantial processing power in a 2U system.
  • The server is Compute Express Link (CXL) v1.1 Ready. With CXL 1.1 for next-generation workloads, you can reduce compute latency in the data center and lower TCO. CXL is a protocol that runs across the standard PCIe physical layer and can support both standard PCIe devices as well as CXL devices on the same link.
  • Supports up to 40x 2.5-inch hot-swap drive bays, by using combinations of front-accessible (up to 24 bays), mid bays (8 bays) and rear-accessible (8 bays).
  • Supports 20x 3.5-inch drive bays for lower-cost high-capacity HDD storage. 2.5-inch and 3.5-inch drive bays can be mixed if desired.
  • Supports up to 24x NVMe drives without oversubscription of PCIe lanes (1:1 connectivity), or up to 32 NVMe drives with oversubscription. The use of NVMe drives maximizes drive I/O performance, in terms of throughput, bandwidth, and latency.
  • Supports up to 20x SATA drives using the onboard SATA controller (no additional adapter needed), enabling lower cost, high capacity storage solution for cold storage workloads.
  • Supports high-speed RAID controllers from Lenovo and Broadcom providing 12 Gb SAS connectivity to the drive backplanes. A variety of PCIe 3.0 and PCIe 4.0 RAID adapters are available.
  • Supports two externally accessible 7mm hot-swap drives for operating system boot functions or data storage. Optional RAID with the addition of a RAID adapter installed in a slot.
  • Supports M.2 drives for convenient operating system boot functions or data storage. Available M.2 adapters support either one M.2 drive or two M.2 drives. Optional RAID with the addition of a RAID adapter installed in a slot.
  • Up to 10x total PCIe slots (either 10x rear, or 6x rear + 2x front), plus a slot dedicated to the OCP adapter (rear or front). 2.5-inch drive configurations also support an additional internal bay for a cabled RAID adapter or HBA.
  • The server has a dedicated industry-standard OCP 3.0 small form factor (SFF) slot, with a PCIe 4.0 x16 interface, supporting a variety of Ethernet network adapters. Simple-swap mechanism with thumbscrews and pull-tab enables tool-less installation and removal of the adapter. Supports shared BMC network sideband connectivity to enable out-of-band systems management.
  • The server offers PCI Express 5.0 (PCIe Gen 5) I/O expansion capabilities that doubles the theoretical maximum bandwidth of PCIe 4.0 (32GT/s in each direction for PCIe 5.0, compared to 16 GT/s with PCIe 4.0). A PCIe 5.0 x16 slot provides 128 GB/s bandwidth, enough to support a 400GbE network connection.

Availability and serviceability

The server provides many features to simplify serviceability and increase system uptime:

  • Designed to run 24 hours a day, 7 days a week
  • The server uses ECC memory and supports memory RAS features including Single Device Data Correction (SDDC, also known as Chipkill), Patrol/Demand Scrubbing, Bounded Fault, DRAM Address Command Parity with Replay, DRAM Uncorrected ECC Error Retry, On-die ECC, ECC Error Check and Scrub (ECS), and Post Package Repair.
  • The server offers hot-swap drives, supporting RAID redundancy for data protection and greater system uptime.
  • Available M.2 configuration with RAID support which can enable two SATA or two NVMe M.2 drives to be configured as a redundant pair.
  • The server has up to two hot-swap redundant power supplies and up to six hot-swap redundant fans to provide availability for business-critical applications.
  • Optional front-accessible slots and drives so that most major components and cables (except power) are located at the front of the server
  • The power-source-independent light path diagnostics uses LEDs to lead the technician to failed (or failing) components, which simplifies servicing, speeds up problem resolution, and helps improve system availability.
  • Solid-state drives (SSDs) offer more reliability than traditional mechanical HDDs for greater uptime.
  • Proactive Platform Alerts (including PFA and SMART alerts): Processors, voltage regulators, memory, internal storage (SAS/SATA HDDs and SSDs, NVMe SSDs, M.2 storage, flash storage adapters), fans, power supplies, RAID controllers, server ambient and subcomponent temperatures. Alerts can be surfaced through the XClarity Controller to managers such as Lenovo XClarity Administrator, VMware vCenter, and Microsoft System Center. These proactive alerts let you take appropriate actions in advance of possible failure, thereby increasing server uptime and application availability.
  • The built-in XClarity Controller 2 continuously monitors system parameters, triggers alerts, and performs recovery actions in case of failures to minimize downtime.
  • Built-in diagnostics in UEFI, using Lenovo XClarity Provisioning Manager, speed up troubleshooting tasks to reduce service time.
  • Lenovo XClarity Provisioning Manager supports diagnostics and can save service data to a USB key drive or remote CIFS share folder for troubleshooting and reduce service time.
  • Auto restart in the event of a momentary loss of AC power (based on power policy setting in the XClarity Controller service processor)
  • Offers a diagnostics port on the front of the server to allow you to attach an external diagnostics handset for enhanced systems management capabilities.
  • Support for the XClarity Administrator Mobile app running on a supported smartphone and connected to the server through the service-enabled USB port, enables additional local systems management functions.
  • Three-year or one-year customer-replaceable unit and onsite limited warranty, 9 x 5 next business day. Optional service upgrades are available.

Manageability and security

Systems management features simplify local and remote management:

  • The server includes an XClarity Controller 2 (XCC2) to monitor server availability. Optional upgrade to XCC Platinum to provide remote control (keyboard video mouse) functions, support for the mounting of remote media files, FIPS 140-3 security, enhanced NIST 800-193 support, boot capture, power capping, and other management and security features.
  • Lenovo XClarity Administrator offers comprehensive hardware management tools that help to increase uptime, reduce costs and improve productivity through advanced server management capabilities.
  • UEFI-based Lenovo XClarity Provisioning Manager, accessible from F1 during boot, provides system inventory information, graphical UEFI Setup, platform update function, RAID Setup wizard, operating system installation function, and diagnostic functions.
  • Support for Lenovo XClarity Energy Manager which captures real-time power and temperature data from the server and provides automated controls to lower energy costs.
  • An integrated industry-standard Unified Extensible Firmware Interface (UEFI) enables improved setup, configuration, and updates, and simplifies error handling.
  • Support for industry standard management protocols, IPMI 2.0, SNMP 3.0, Redfish REST API, serial console via IPMI
  • An integrated hardware Trusted Platform Module (TPM) supporting TPM 2.0 enables advanced cryptographic functionality, such as digital signatures and remote attestation.
  • Administrator and power-on passwords help protect from unauthorized access to the server.
  • Supports AMD Secure Root-of-Trust, Secure Run and Secure Move features to minimize potential attacks and protect data as the OS is booted, as applications are run and as applications are migrated from server to server.
  • Supports Secure Boot to ensure only a digitally signed operating system can be used.
  • Industry-standard Advanced Encryption Standard (AES) NI support for faster, stronger encryption.
  • Additional physical security features are a chassis intrusion switch and a lockable front bezel.

Energy efficiency

The following energy-efficiency features help save energy, reduce operational costs, and increase energy availability:

  • Energy-efficient planar components help lower operational costs.
  • High-efficiency power supplies with 80 PLUS Titanium certifications
  • Low-voltage 1.1V DDR5 memory offers energy savings compared to 1.2V DDR4 DIMMs, an approximately 20% decrease in power consumption
  • Solid-state drives (SSDs) consume as much as 80% less power than traditional spinning 2.5-inch HDDs.
  • The server uses hexagonal ventilation holes, which can be grouped more densely than round holes, providing more efficient airflow through the system and thus keeping your system cooler.
  • Optional Lenovo XClarity Energy Manager provides advanced data center power notification and analysis to help achieve lower heat output and reduced cooling needs.

Comparing the SR655 V3 to the SR655

The ThinkSystem SR655 V3 improves on the previous generation SR655, as summarized in the following table.

Table 1. Comparing the SR655 V3 to the SR655
Feature SR655 SR655 V3 Benefits
Processor
  • 1x 2nd or 3rd Gen AMD EPYC processor
  • Up to 64 cores
  • TDP ratings up to 280W
  • 64x PCIe 4.0 lanes per processor
  • 1x 4th Gen AMD EPYC processor
  • Up to 128 cores
  • TDP ratings up to 360W
  • 64x PCIe 5.0 lanes per processor
  • Significant increase in cores per processor
  • Increased performance
  • Consolidation of more apps on same number of servers, reducing costs
  • New PCIe 5.0 support means higher performance networking and NVMe storage
Memory
  • DDR4 memory operating up to 2933 MHz
  • 8 channels per CPU
  • 16 DIMMs, 2 DIMMs per channel
  • Supports RDIMMs and 3DS RDIMMs
  • Up to 2TB of system memory (16x 128GB)
  • DDR5 memory operating up to 4800 MHz
  • 12 channels per CPU
  • 12 DIMMs, 1 DIMM per channel
  • Supports RDIMMs, 3DS RDIMMs and 9x4 RDIMMs
  • Up to 1.5TB of system memory (12x 128GB)
  • New DDR5 memory offers significant performance improvements over DDR4
  • More memory channels means greater memory bandwidth
  • Support for lower-cost 9x4 DIMMs
Internal storage
  • 20x 3.5” SAS/SATA/NVMe (12 front, 4 mid, 4 rear)
  • Up to 32x 2.5” SAS/SATA/NVMe (24 front + 8 mid, or 24 front + 4 rear)
  • Up to 4x 3.5” or 8x 2.5” mid-chassis drive bays
  • Up to 4x 3.5” or 4x 2.5” rear drive bays
  • 2x Internal M.2 with optional RAID
  • 16x onboard NVMe ports
  • 20x 3.5” SAS/SATA/NVMe (12 front, 4 mid, 4 rear)
  • 40x 2.5” SAS/SATA/NVMe (24 front, 8 mid, 8 rear)
  • Up to 4x 3.5” or 8x 2.5” mid-chassis drive bays
  • Up to 4x 3.5” or 8x 2.5” rear drive bays
  • 2x Internal M.2 with optional RAID 1 (RAID support via a separate adapter)
  • 12x onboard NVMe ports
  • 2x rear 7mm hot swap SAS/SATA/NVMe (RAID support via a separate adapter)
  • Flexible storage offerings
  • Up to 32x NVMe drives for high-performance storage
  • 7mm hot swap drives as boot drives
RAID
  • 8-port and 16-port RAID adapters with up to 8GB flash
  • Support for Lenovo and Broadcom adapters
  • Support for PCIe or Internal cabled (CFF) form factor adapters
  • Support for NVMe drives connected to 940 RAID adapters (Tri-Mode)
  • Storage HBAs available
  • PCIe 3.0 and PCIe 4.0 adapter choices
  • 8-port and 16-port RAID adapters with up to 8GB flash
  • Support for Lenovo and Broadcom adapters
  • Support for PCIe or Internal cabled (CFF) form factor adapters
  • Support for NVMe drives connected to 940 RAID adapters (Tri-Mode)
  • Storage HBAs available
  • PCIe 3.0 and PCIe 4.0 adapter choices with support for Gen 5 adapters when available
  • Consistent RAID/HBA support
  • Flexible config solution
  • PCIe Gen 5 allows for greater storage performance
Networking
  • OCP 3.0 slot with PCIe Gen4 x16 interface (rear of server)
  • Additional PCIe adapters supported up to PCIe Gen4
  • 1GbE dedicated Management port
  • OCP 3.0 slot with PCIe Gen4 x16 interface (rear or front of server)
  • Additional PCIe adapters supported up to PCIe Gen5
  • 1GbE dedicated Management port
  • Improved performance with PCIe Gen 5
  • Optional front-accessible OCP slot
PCIe
  • Supports PCIe 4.0
  • Up to 8x PCIe slots (all full-height slots)
  • Supports a RAID/HBA in CFF form factor (does not occupy a PCIe slot)
  • Additional OCP 3.0 slot
  • Supports PCIe 5.0
  • Up to 10x PCIe slots (6x full height, 4x low-profile) or 8x PCIe slots (all full-height slots)
  • Up to 9x slots can be PCIe 5.0
  • Supports a RAID/HBA in CFF form factor (does not occupy a PCIe slot)
  • Additional OCP 3.0 slot
  • Support for 3x front-accessible slots (2x FH PCIe + 1x OCP) with 16 drive bays
  • PCIe Gen 5 allows for greater I/O performance
  • Flexible PCIe offerings
  • Front-accessible slots available
  • More PCIe connections for greater PCIe/NVMe support
Management and security
  • Limited XClarity support with ASPEED 2500 BMC
  • Tamper Switch security solution (intrusion switch)
  • Integrated XClarity Controller 2
  • Support for full XClarity toolset including XClarity Administrator
  • Platform Firmware Resiliency (PFR) hardware Root of Trust (RoT)
  • Tamper Switch security solution (intrusion switch)
  • New XCC2 offers improved management capabilities
  • Support for full XClarity toolset
  • Silicon-level security solution
Power
  • 500W, 750W, 1100W AC Platinum/Titanium Hot Plug PSU
  • 1100W -48VDC Platinum general support
  • 240V HVDC support for PRC customers
  • Active-Standby mode
  • 750W, 1100W, 1800W AC Platinum/Titanium Hot Plug PSU
  • 1100W -48VDC Platinum general support
  • 240V HVDC support for PRC customers
  • Active-Standby mode
  • Multiple PSU offerings to suit the configuration selected
  • New ErP Lot 9-compliant offerings
  • Support for Telco customers with -48V requirements

Components and connectors

The following figure shows the front of the server.

Front view of the Lenovo ThinkSystem SR655 V3
Figure 2. Front view of the Lenovo ThinkSystem SR655 V3

The following figure shows the components visible from the rear of the server. The figure shows one configuration, with eight PCIe slots, however there are additional rear configurations which include 3.5-inch drive bays, 2.5-inch drive bays, or 7mm drive bays.

Rear view of the Lenovo ThinkSystem SR655 V3
Figure 3. Rear view of the Lenovo ThinkSystem SR655 V3 (configuration with eight PCIe slots)

The following figure shows the locations of key components inside the server.

Internal view of the Lenovo ThinkSystem SR655 V3
Figure 4. Internal view of the Lenovo ThinkSystem SR655 V3

System architecture

The following figure shows the architectural block diagram of the SR655 V3, showing the major components and their connections.

SR655 V3 system architectural block diagram
Figure 5. SR655 V3 system architectural block diagram

Standard specifications

The following table lists the standard specifications.

Table 2. Standard specifications
Components Specification
Machine types 7D9F - 1 year warranty
7D9E - 3 year warranty
Form factor 2U rack.
Processor One AMD EPYC 9004 Series processor (formerly codenamed "Genoa"). Supported processors up to 128 cores, core speeds of up to 4.1 GHz, and TDP ratings of up to 360W. Supports PCIe 5.0 for high performance I/O.
Chipset Not applicable (platform controller hub functions are integrated into the processor)
Memory 12 DIMM slots. The processor has 12 memory channels, with 1 DIMM per channel (DPC). Lenovo TruDDR5 RDIMMs, 3DS RDIMMs, and 9x4 RDIMMs are supported, up to 4800 MHz
Memory maximum Up to 1.5TB with 12x 128GB 3DS RDIMMs
Persistent memory Not supported.
Memory protection ECC, SDDC, Patrol/Demand Scrubbing, Bounded Fault, DRAM Address Command Parity with Replay, DRAM Uncorrected ECC Error Retry, On-die ECC, ECC Error Check and Scrub (ECS), Post Package Repair
Disk drive bays

Up to 20x 3.5-inch or 40x 2.5-inch hot-swap drive bays:

  • Front bays can be 3.5-inch (8 or 12 bays) or 2.5-inch (8, 16 or 24 bays)
  • Middle bays can be 3.5-inch (4 bays) or 2.5-inch (8 bays)
  • Rear bays can be 3.5-inch (2 or 4 bays) or 2.5-inch (4 or 8 bays)
  • Combinations of SAS/SATA, NVMe, or AnyBay (supporting SAS, SATA or NVMe) are available

The server also supports these drives for OS boot or drive storage:

  • Two 7mm drives at the rear of the server (optional RAID)
  • Internal M.2 module supporting up to two M.2 drives (optional RAID)

See Storage configurations for details.

Maximum internal storage
  • 2.5-inch drives:
    • 1228.8TB using 40x 30.72TB 2.5-inch SAS/SATA SSDs
    • 491.52TB using 32x 15.36TB 2.5-inch NVMe SSDs
    • 96TB using 40x 2.4TB 2.5-inch HDDs
  • 3.5-inch drives:
    • 400TB using 20x 20TB 3.5-inch HDDs
    • 307.2TB using 20x 15.36TB 3.5-inch SAS/SATA SSDs
    • 153.6TB using 12x 12.8TB 3.5-inch NVMe SSDs
Storage controller
  • Up to 16x Onboard SATA ports (non-RAID)
  • Up to 12x Onboard NVMe ports (non-RAID)
  • NVMe Retimer Adapter (PCIe 4.0 or PCIe 5.0)
  • NVMe Switch Adapter (PCIe 4.0)
  • 12 Gb SAS/SATA RAID adapters
    • 8, 16 or 32 ports
    • Up to 8GB flash-backed cache
    • PCIe 4.0 or PCIe 3.0 host interface
  • 12 Gb SAS/SATA HBA (non-RAID)
    • 8-port and 16-port
    • PCIe 4.0 or PCIe 3.0 host interface
Optical drive bays No internal optical drive
Tape drive bays No internal backup drive
Network interfaces Dedicated OCP 3.0 SFF slot with PCIe 4.0 x16 host interface, either at the rear of the server (rear-accessible) for the front of the server (front-accessible). Supports a variety of 2-port and 4-port adapters with 1GbE, 10GbE and 25GbE network connectivity. One port can optionally be shared with the XClarity Controller 2 (XCC2) management processor for Wake-on-LAN and NC-SI support. Additional PCIe network adapters supported in PCIe slots.
PCI Expansion slots

Up to 10x total PCIe slots (either 10x rear, or 6x rear + 2x front), plus a slot dedicated to the OCP adapter (rear or front). 2.5-inch drive configurations also support an additional internal bay for a cabled RAID adapter or HBA.

Rear: Up to 10x PCIe slots, plus a slot dedicated to the OCP adapter. Slots are either PCIe 5.0 or 4.0 depending on riser selection and rear drive bay selection. OCP slot is PCIe 4.0.

Slots are configured using three riser cards. Riser 1 (slots 1-3) and Riser 2 (slots 4-6) are installed in slots in the system board, Riser 3 (slots 7-8) and Riser 4 (9-10) are cabled to ports on the system board. A variety of riser cards are available. See the I/O expansion for details.

Front: The server supports slots at the front of the server (configurations with up to 16 drive bays), as an alternative to rear slots in Riser 3 (and Riser 4). Front slots are 2x PCIe x16 full-height half-length slots plus 1x OCP slot. OCP slot is PCIe 4.0.

Internal: For 2.5-inch front drive configurations, the server supports the installation of a RAID adapter or HBA in a dedicated area that does not consume any of the PCIe slots.

Ports

Front: 1x USB 3.1 G1 (5 Gb/s) port, 1x USB 2.0 port (also for XCC local management), External diagnostics port, optional VGA port.

Rear: 3x USB 3.1 G1 (5 Gb/s) ports, 1x VGA video port, 1x RJ-45 1GbE systems management port for XCC remote management. Optional 2nd XCC remote management port (installs in OCP slot). Optional DB-9 COM serial port (installs in slot 3).

Internal: 1x USB 3.1 G1 (5 Gb/s) connector for operating system or license key purposes.

Cooling Up to 6x N+1 redundant hot swap 60 mm fans, configuration dependent. One fan integrated in each power supply.
Power supply Up to two hot-swap redundant AC power supplies, 80 PLUS Platinum or 80 PLUS Titanium certification. 750 W, 1100 W, 1800 W, 2400 W, and 2600 W AC, supporting 220 V AC. 750 W and 1100 W options also support 110V input supply. In China only, all power supply options support 240 V DC. Also available is a 1100W power supply with a -48V DC input.
Video Embedded video graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller. Maximum resolution is 1920x1200 32bpp at 60Hz.
Hot-swap parts Drives, power supplies, and fans.
Systems management Operator panel with status LEDs. Optional External Diagnostics Handset with LCD display. Models with 16x 2.5-inch front drive bays can optionally support an Integrated Diagnostics Panel. XClarity Controller 2 (XCC2) embedded management based on the ASPEED AST2600 baseboard management controller (BMC). Dedicated rear Ethernet port for XCC2 remote access for management. Optional 2nd redundant XCC2 remote port supported, installs in the OCP slot. XClarity Administrator for centralized infrastructure management, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XCC Platinum to enable remote control functions and other features.
Security features Chassis intrusion switch, Power-on password, administrator's password, Root of Trust module supporting TPM 2.0 and Platform Firmware Resiliency (PFR). Optional lockable front security bezel.
Operating systems supported Microsoft Windows Server, Microsoft Windows 10 & 11, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server. See the Operating system support section for specifics.
Limited warranty Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
Service and support Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications.
Dimensions Width: 445 mm (17.5 in.), height: 87 mm (3.4 in.), depth: 766 mm (30.1 in.). See Physical and electrical specifications for details.
Weight Maximum: 38.8 kg (85.5 lb)

Models

ThinkSystem SR655 V3 models can be configured by using the Lenovo Data Center Solution Configurator (DCSC).

Configure-to-order (CTO) models are used to create models with factory-integrated server customizations. For CTO models, two base CTO models are available for the SR655 V3 as listed in the following table, CTO1WW and CTOLWW:

  • The CTO1WW base CTO model is for general business and is selectable by choosing General Purpose mode in DCSC.
  • The CTOLWW base model is intended for High Performance Computing (HPC) and Artificial Intelligence (AI) configurations and solutions, including configurations for Lenovo Scalable Infrastructure (LeSI), and is enabled using either the HPC & AI LeSI Solutions mode or HPC & AI Hardware mode in DCSC. CTOLWW configurations can also be built using System x and Cluster Solutions Configurator (x-config).

Preconfigured server models may also be available for the SR655 V3, however these are region-specific; that is, each region may define their own server models, and not all server models are available in every region.

The following table lists the base CTO models of the ThinkSystem SR655 V3 server.

Table 3. Base CTO models
Machine Type/Model
General purpose
Machine Type/Model
for HPC and AI
Description
7D9ECTO1WW 7D9ECTOLWW ThinkSystem SR655 V3 – 3-year Warranty
7D9FCTO1WW 7D9FCTOLWW ThinkSystem SR655 V3 – 1-year Warranty

The SR655 V3 can now run Windows 10 and Windows 11, however only a subset of adapters and drives can be installed. For ease of configuration, the following Base CTO models have been announced to assist building a configuration that can be used with the client operating systems. For more information, see the Windows 10 and Windows 11 section.

Table 4. Base CTO models for SR655 V3 with Windows 10 and Windows 11
Machine Type/Model
General purpose
Description
7D9ECTO2WW ThinkSystem SR655 V3 Workstation - 3 year Warranty
7D9FCTO2WW ThinkSystem SR655 V3 Workstation - 1 year Warranty

Models of the SR655 V3 are defined based on whether the server has 2.5-inch drive bays at the front (called the 2.5-inch chassis) or whether it has 3.5-inch drive bays at the front (called the 3.5-inch chassis). For models, the feature codes for these chassis bases are as listed in the following table.

Table 5. Chassis base feature codes
Feature code Description
BLKJ ThinkSystem V3 2U 12x3.5" Chassis
BLKK ThinkSystem V3 2U 24x2.5" Chassis

The following tables list the available models, grouped by region.

Refer to the Specifications section for information about standard features of the server.

Common to all models:

  • Power supplies are Platinum unless otherwise stated
  • All models include a Toolless Slide Rail Kit

Models for Australia and New Zealand

Common to all Australia and New Zealand models:

  • All models include a Toolless Slide Rail Kit and Cable Management Arm
Table 6. Models for Australia and New Zealand
Model AMD EPYC processor† Memory RAID Drive bays OCP Slots Power
supply
Fans
Front VGA
Front diag
XCC2
Intru switch
TopSeller models with a 3-year warranty (machine type 7D76)

7D9EA00ZAU

1x 9124 16C 200W 3.0G 1x16GB 5350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x750W 6x Perf Yes Yes Std Opt

7D9EA010AU

1x 9124 16C 200W 3.0G 1x32GB 2Rx8 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x750W 6x Perf Yes Yes Std Opt

† Processor description: Processor model, number of cores, thermal design power (TDP), core frequency

Models for EMEA region

Table 7. Models for EMEA region
Model AMD EPYC processor† Memory RAID Drive bays OCP Slots Power
supply
Fans
Front VGA
Front diag
XCC2
Intru switch
Standard models with a 3-year warranty (machine type 7D76)

7D9EA00NEA

1x 9124 16C 200W 3.0G 1x64GB 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x1100W Titanium 5x Perf Opt Yes Std Opt

7D9EA00REA

1x 9254 24C 200W 2.9G 1x64GB 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x1100W Titanium 5x Perf Opt Yes Std Opt

7D9EA00QEA

1x 9354P 32C 280W 3.25G 1x64GB 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x1100W Titanium 5x Perf Opt Yes Std Opt

7D9EA00TEA

1x 9454P 48C 290W 2.75G 1x64GB 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x1100W Titanium 5x Perf Opt Yes Std Opt

7D9EA00SEA

1x 9554P 64C 360W 3.1G 1x64GB 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x1100W Titanium 5x Perf Opt Yes Std Opt

7D9EA00PEA

1x 9654P 96C 360W 2.4G 1x64GB 9350-8i 8x 2.5" SAS Open bay Open 3 (x16, x8, x8) Gen4 1x1100W Titanium 5x Perf Opt Yes Std Opt

† Processor description: Processor model, number of cores, thermal design power (TDP), core frequency

Processors

The SR655 V3 supports processors in the fourth-generation AMD EPYC family of processors. The server supports one processor.

Topics in this section:

Processor options

The table below lists the AMD processors that are currently supported by the SR655 V3.

All supported processors have the following characteristics:

  • Fourth-generation AMD EPYC processors (formerly codenamed "Genoa")
  • Also support
  • 12 DDR5 memory channels
  • 128 PCIe 5.0 I/O lanes, 64 lanes available for PCIe and NVMe devices

The SR655 V3 also supports the new 4th Gen AMD EPYC processors with "Zen 4c" architecture (formerly codenamed "Bergamo"). These processors have higher core counts, up to 128 cores, targeted at cloud native applications that are designed to exploit the scale, elasticity, resiliency, and flexibility of private & public clouds.

Table 8. SR655 V3 processor support
Feature
code
SKU Description Quantity
supported
4th Gen AMD EPYC processors ("Genoa")
BREE 9124 ThinkSystem AMD EPYC 9124 16C 200W 3.0GHz Processor 1
BREJ 9174F ThinkSystem AMD EPYC 9174F 16C 320W 4.1GHz Processor 1
BREH 9224 ThinkSystem AMD EPYC 9224 24C 200W 2.5GHz Processor 1
BRED 9254 ThinkSystem AMD EPYC 9254 24C 200W 2.9GHz Processor 1
BREF 9274F ThinkSystem AMD EPYC 9274F 24C 320W 4.05GHz Processor 1
BREC 9334 ThinkSystem AMD EPYC 9334 32C 210W 2.7GHz Processor 1
BR30 9354 ThinkSystem AMD EPYC 9354 32C 280W 3.25GHz Processor 1
BREG 9354P ThinkSystem AMD EPYC 9354P 32C 280W 3.25GHz Processor 1
BR32 9374F ThinkSystem AMD EPYC 9374F 32C 320W 3.85GHz Processor 1
BREB 9454 ThinkSystem AMD EPYC 9454 48C 290W 2.75GHz Processor 1
BREM 9454P ThinkSystem AMD EPYC 9454P 48C 290W 2.75GHz Processor 1
BR31 9474F ThinkSystem AMD EPYC 9474F 48C 360W 3.6GHz Processor 1
BREA 9534 ThinkSystem AMD EPYC 9534 64C 280W 2.45GHz Processor 1
BPVJ 9554 ThinkSystem AMD EPYC 9554 64C 360W 3.1GHz Processor 1
BREL 9554P ThinkSystem AMD EPYC 9554P 64C 360W 3.1GHz Processor 1
BR2Z 9634 ThinkSystem AMD EPYC 9634 84C 290W 2.25GHz Processor 1
BPVK 9654 ThinkSystem AMD EPYC 9654 96C 360W 2.4GHz Processor 1
BREK 9654P ThinkSystem AMD EPYC 9654P 96C 360W 2.4GHz Processor 1
4th Gen AMD EPYC processors with Zen 4c architecture ("Bergamo")
BW9S 9734 ThinkSystem AMD EPYC 9734 112C 340W 2.2GHz Processor 1
BW9T 9754 ThinkSystem AMD EPYC 9754 128C 360W 2.25GHz Processor 1

Processor features

The following table lists the features of the supported processors.

Table 9. Processor specifications
EPYC
model
Cores /
Threads
Base
Frequency
Max Boost
Frequency†
L3 Cache Memory
channels
Memory
bus
TDP
4th Gen AMD EPYC processors ("Genoa")
9124 16 / 32 3.0 GHz 3.7 GHz 64 MB 12 4800 MHz 200W
9174F 16 / 32 4.1 GHz 4.4 GHz 256 MB 12 4800 MHz 320W
9224 24 / 48 2.5 GHz 3.7 GHz 64 MB 12 4800 MHz 200W
9254 24 / 48 2.9 GHz 4.15 GHz 128 MB 12 4800 MHz 200W
9274F 24 / 48 4.05 GHz 4.3 GHz 256 MB 12 4800 MHz 320W
9334 32 / 64 2.7 GHz 3.9 GHz 128 MB 12 4800 MHz 210W
9354 32 / 64 3.25 GHz 3.8 GHz 256 MB 12 4800 MHz 280W
9354P 32 / 64 3.25 GHz 3.8 GHz 256 MB 12 4800 MHz 280W
9374F 32 / 64 3.85 GHz 4.3 GHz 256 MB 12 4800 MHz 320W
9454 48 / 96 2.75 GHz 3.8 GHz 256 MB 12 4800 MHz 290W
9454P 48 / 96 2.75 GHz 3.8 GHz 256 MB 12 4800 MHz 290W
9474F 48 / 96 3.6 GHz 4.1 GHz 256 MB 12 4800 MHz 360W
9534 64 / 128 2.45 GHz 3.7 GHz 256 MB 12 4800 MHz 280W
9554 64 / 128 3.1 GHz 3.75 GHz 256 MB 12 4800 MHz 360W
9554P 64 / 128 3.1 GHz 3.75 GHz 256 MB 12 4800 MHz 360W
9634 84 / 168 2.25 GHz 3.7 GHz 384 MB 12 4800 MHz 290W
9654 96 / 192 2.4 GHz 3.7 GHz 384 MB 12 4800 MHz 360W
9654P 96 / 192 2.4 GHz 3.7 GHz 384 MB 12 4800 MHz 360W
4th Gen AMD EPYC processors with Zen 4c architecture ("Bergamo")
9734 112 / 224 2.2 GHz 3.0 GHz 256 MB 12 4800 MHz 340W
9754 128 / 256 2.25 GHz 3.2 GHz 256 MB 12 4800 MHz 360W

† The maximum single-core frequency that the processor is capable of operating

Thermal requirements by processor

In the SR655 V3, the processor either uses a standard heatsink or a performance heatsink depending on the TDP of the processor. Performance heatsinks include two satellite heatsinks that connect to the main heatsink via liquid filled copper tubes.

Additional ambient temperature restrictions may apply. See the Operating environment section for details.

UEFI operating modes

The SR655 V3 offers preset operating modes that affect energy consumption and performance. These modes are a collection of predefined low-level UEFI settings that simplify the task of tuning the server to suit your business and workload requirements.

The following table lists the feature codes that allow you to specify the mode you wish to preset in the factory for CTO orders.

Table 10. UEFI operating mode presets in DCSC
Feature code Description
BFYA Operating mode selection for: "Maximum Efficiency Mode"
BFYB Operating mode selection for: "Maximum Performance Mode"

The preset modes for the SR655 V3 are as follows:

  • Maximum Efficiency Mode (feature BFYA): Maximizes performance/watt efficiency while maintaining reasonable performance
  • Maximum Performance Mode (feature BFYB): Achieves maximum performance but with higher power consumption and lower energy efficiency.

For details about these preset modes, and all other performance and power efficiency UEFI settings offered in the SR655 V3, see the paper "Tuning UEFI Settings for Performance and Energy Efficiency on AMD Processor-Based ThinkSystem Servers", available from https://lenovopress.lenovo.com/lp1267.

Memory options

The SR655 V3 uses Lenovo TruDDR5 memory operating at up to 4800 MHz. The server supports up to 12 DIMMs. The processor has 12 memory channels and supports 1 DIMM per channel. The server supports up to 1.5TB of memory using 12x 128GB 3DS RDIMMs.

The following table lists the memory options that are available for the server.

Lenovo TruDDR5 memory uses the highest quality components that are sourced from Tier 1 DRAM suppliers and only memory that meets the strict requirements of Lenovo is selected. It is compatibility tested and tuned to maximize performance and reliability. From a service and support standpoint, Lenovo TruDDR5 memory automatically assumes the system warranty, and Lenovo provides service and support worldwide.

Table 11. Memory options
Part number Feature code Description
9x4 RDIMMs
4X77A81439 BQ3E ThinkSystem 32GB TruDDR5 4800MHz (1Rx4) 9x4 RDIMM-A
4X77A81442 BQ36 ThinkSystem 64GB TruDDR5 4800MHz (2Rx4) 9x4 RDIMM-A
10x4 RDIMMs
4X77A81438 BQ39 ThinkSystem 32GB TruDDR5 4800MHz (1Rx4) 10x4 RDIMM-A
4X77A81441 BQ3D ThinkSystem 64GB TruDDR5 4800MHz (2Rx4) 10x4 RDIMM-A
4X77A81448 BUVV ThinkSystem 96GB TruDDR5 4800MHz (2Rx4) 10x4 RDIMM-A
x8 RDIMMs
4X77A81437 BQ3C ThinkSystem 16GB TruDDR5 4800MHz (1Rx8) RDIMM-A
4X77A81440 BQ37 ThinkSystem 32GB TruDDR5 4800MHz (2Rx8) RDIMM-A
10x4 3DS RDIMMs
4X77A81443 BQ3A ThinkSystem 128GB TruDDR5 4800MHz (4Rx4) 3DS RDIMM-A
CTO only BYEE ThinkSystem 128GB TruDDR5 5600MHz (4Rx4) 3DS RDIMM-A

9x4 RDIMMs (also known as Optimized or EC4 RDIMMs) are a new lower-cost DDR5 memory option supported in ThinkSystem V3 servers. 9x4 DIMMs offer the same performance as standard RDIMMs (known as 10x4 or EC8 modules), however they support lower fault-tolerance characteristics. Standard RDIMMs and 3DS RDIMMs support two 40-bit subchannels (that is, a total of 80 bits), whereas 9x4 RDIMMs support two 36-bit subchannels (a total of 72 bits). The extra bits in the subchannels allow standard RDIMMs and 3DS RDIMMs to support Single Device Data Correction (SDDC), however 9x4 RDIMMs do not support SDDC. Note, however, that all DDR5 DIMMs, including 9x4 RDIMMs, support Bounded Fault correction, which enables the server to correct most common types of DRAM failures.

For more information on DDR5 memory, see the Lenovo Press paper, Introduction to DDR5 Memory, available from https://lenovopress.com/lp1618.

The following rules apply when selecting the memory configuration:

  • The SR655 V3 supports quantities 1, 2, 4, 6, 8, 10, 12 DIMMs per processor; other quantities not supported
  • The server supports four types of DIMMs: 9x4 RDIMMs, 10x4 RDIMMs, x8 RDIMMs and 3DS RDIMMs; UDIMMs and LRDIMMs are not supported
  • Mixing of DIMM types is not supported (for example, 9x4 DIMMs with 10x4 RDIMMs)
  • Mixing x4 and x8 DIMMs is not supported
  • Mixing of DIMM rank counts is supported. Follow the required installation order installing the DIMMs with the higher rank counts first.
  • Mixing of DIMM capacities is supported, however only two different capacities are supported across all channels of the processor (eg 16GB and 32GB). Follow the required installation order installing the larger DIMMs first.

Note: Memory mirroring and memory rank sparing are not supported.

For best performance, consider the following:

  • Ensure the memory installed is at least the same speed as the memory bus of the selected processor.
  • Populate all 12 memory channels with identical DIMMs (same Lenovo part number)

The following memory protection technologies are supported:

  • ECC detection/correction
  • Bounded Fault detection/correction
  • SDDC (for x4-based memory DIMMs; look for "x4" in the DIMM description. Not supported with 9x4 RDIMMs)
  • Patrol/Demand Scrubbing
  • DRAM Address Command Parity with Replay
  • DRAM Uncorrected ECC Error Retry
  • On-die ECC
  • ECC Error Check and Scrub (ECS)
  • Post Package Repair

Internal storage

The SR655 V3 has three drive bay zones and supports up to 20x 3.5-inch or 40x 2.5-inch hot-swap drive bays or a combination of drive bays, depending on the selected chassis and backplane configuration. The server also supports configurations without any drive bays if desired.

The three drive bay zones are as follows:

  • Front:
    • Up to 12x 3.5-inch hot-swap bays, or
    • Up to 24x 2.5-inch hot-swap bays
  • Middle:
    • 4x 3.5-inch hot-swap bays, or
    • 8x 2.5-inch hot-swap bays
  • Rear:
    • Up to 4x 3.5-inch hot-swap bays, or
    • Up to 8x 2.5-inch hot-swap bays
    • Also supports 2x 7mm hot-swap drives bays

All drives are hot-swap and are accessible from the front, from the rear, or from drive bays that are located in the middle of the server (accessible when you remove the top cover of the server).

The server also supports one or two M.2 drives, installed in an M.2 adapter internal to the server.

In this section:

NVMe drive support

The SR655 V3 supports NVMe drives to maximize storage performance.

  • Up to 24 NVMe drives in a 2.5-inch drive configuration, without oversubscription (that is, each x4 drive has a dedicated x4 (4 lanes) connection to the processor, either direct to the processor or via a retimer adapter)
    • Up to 24 installed in front bays
  • Up to 32 NVMe drives in a 2.5-inch drive configuration, with oversubscription (using NVMe switch adapters)
    • 24 installed in front bays
    • 8 installed in mid-chassis bays
  • Up to 8 NVMe drives in a 3.5-inch drive configuration, without oversubscription
    • All installed in mid bays

Riser 3 support: The use of the onboard NVMe ports is mutually exclusive with Riser 3, as these use the same PCIe connectors. See the System architecture section.

The specifics of these configurations are covered in the Storage configurations section. The tables in those sections indicate the number of NVMe drives in each configuration.

In addition, the SR655 V3 supports two 7mm NVMe drives for use as boot drives. These two drives optionally support RAID via a separate RAID adapter installed in a PCIe slot.

The RAID 940-8i and RAID 940-16i adapters also support NVMe through a feature named Tri-Mode support (or Trimode support). This feature enables the use of NVMe U.3 drives at the same time as SAS and SATA drives. Cabling of the controller to the backplanes is the same as with SAS/SATA drives, and the NVMe drives are connected via a PCIe x1 link to the controller.

NVMe drives connected using Tri-Mode support provide better performance than SAS or SATA drives: A SATA SSD has a data rate of 6Gbps, a SAS SSD has a data rate of 12Gbps, whereas an NVMe U.3 Gen 4 SSD with a PCIe x1 link will have a data rate of 16Gbps. NVMe drives typically also have lower latency and higher IOPS compared to SAS and SATA drives. Tri-Mode is supported with U.3 NVMe drives in either 2.5-inch and 3.5-inch form factor and requires an AnyBay backplane.

Tri-Mode requires U.3 drives: Only NVMe drives with a U.3 interface are supported. U.2 drives are not supported. See the Internal drive options section for the U.3 drives supported by the server.

Front drive bays

The front drive bay zone supports the following configurations:

  • 8x or 12x 3.5-inch drive bays (all hot-swap)
  • 8x, 16x or 24x 2.5-inch drive bays (all hot-swap)
  • 4x 2.5-inch drive bays (all hot-swap) with support for front PCIe slots (planned for 2Q/2023)
  • No backplanes and no drives (supports field upgrades)

The specific combinations that are supported in the SR655 V3 are shown in the following figures. The feature codes listed in the figures are the backplane feature codes when ordering CTO and correspond to the feature codes listed in the table below the figure. In the figures, G4 refers to PCIe Gen4 and G5 refers to PCIe Gen5.

SR655 V3 front drive bay configurations - 3.5-inch drive bays
Figure 6. SR655 V3 front drive bay configurations - 3.5-inch drive bays

SR655 V3 front drive bay configurations - 2.5-inch drive bays, all the same drive type
Figure 7. SR655 V3 front drive bay configurations - 2.5-inch drive bays, all the same drive type

SR655 V3 front drive bay configurations - 2.5-inch drive bays, combinations
Figure 8. SR655 V3 front drive bay configurations - 2.5-inch drive bays, combinations

SR655 V3 front drive bay configurations - 2.5-inch drive bays with front PCIe slots
Figure 9. SR655 V3 front drive bay configurations - 2.5-inch drive bays with front PCIe slots

The backplanes used to provide these drive bays are listed in the following table.

Field upgrades: All front backplanes are available as part numbers for field upgrades along with require cable option kits, as described in the Field upgrades section below.

Table 12. Backplanes for front drive bays
Feature Description Bays PCIe
Gen
Maximum
supported
Front 3.5-inch drive backplanes
B8LP ThinkSystem 2U 8x3.5" SAS/SATA Backplane 8 - 1
B8LT ThinkSystem 2U 12x3.5" SAS/SATA Backplane 12 - 1
BPL8 ThinkSystem 2U 8x3.5" SAS/SATA+4 AnyBay Backplane 12 Gen4 1
BPL9 ThinkSystem 2U 8x3.5" SAS/SATA+4 NVMe Backplane 12 Gen4 1
BQ2S ThinkSystem 2U 12x3.5" SAS/SATA with Rear 4-Bay Expander Backplane 12* - 1
BH8C ThinkSystem 2U 12x3.5" AnyBay Backplane 12 Gen4 1
Front 2.5-inch backplanes
B8LU ThinkSystem 2U 8x2.5" SAS/SATA Backplane 8 - 3
BQ2T ThinkSystem 2U 24x2.5" SAS/SATA with Rear 4-Bay Expander Backplane 24 - 1
BH8D ThinkSystem 2U/4U 8x2.5" NVMe Backplane 8 Gen4 3
BS7Y ThinkSystem V3 2U 8x2.5" NVMe Gen5 Backplane 8 Gen5 3
BH8B ThinkSystem 2U/4U 8x2.5" AnyBay Backplane 8 Gen4 3
BLL2 ThinkSystem V3 2U 8x2.5" AnyBay Gen5 Backplane 8 Gen5 1
BPL7 ThinkSystem 2U 6x2.5" SAS/SATA+2 AnyBay Backplane 8 Gen4 1
BS7Z ThinkSystem 2U 6x2.5" SAS/SATA+2 AnyBay Gen5 Backplane 8 Gen5 1
BQQD ThinkSystem 2U 2.5" 6 SAS/SATA+2 NVMe Backplane 8 Gen4 1
BS80 ThinkSystem 2U 6x2.5" SAS/SATA+2 NVMe Gen5 Backplane 8 Gen5 1
Integrated Diagnostics Panel (for 2.5-inch configurations with 8 or 16 bays only)
BMJA ThinkSystem 2U 16x2.5" Front Operator Panel v2 - - 1

* Backplane has an onboard SAS expander that provides connectivity to SAS/SATA drive bays in a separate rear backplane (order the rear backplane separately). See also note below for BQ2T.

The use of front drive bays has the following configuration rules:

  • The SR655 V3 also supports configurations without any drive bays, allowing for drive bay upgrades as described in the field upgrades section.
  • If 3.5-inch front drive bays are used, an internal (CFF) RAID adapter or HBA is not supported as the adapter and bays occupy the same physical space
  • Any 8x 2.5-inch and 16x 2.5-inch drive configuration (SAS/SATA, AnyBay, or NVMe) can optionally be configured for use with the Integrated Diagnostics Panel as described in the Local management section. 3.5-inch drive configurations do not support the Integrated Diagnostics Panel. With the Integrated Diagnostics Display, 8-bay configurations can be upgrade to 16 bays, however 16-bay configurations cannot be upgrade to 24 bays.
  • If you are building a server configuration that includes the ThinkSystem 2U 24x2.5" SAS/SATA with Rear 4-Bay Expander Backplane (feature BQ2T) and the order also includes a rack cabinet, then you can configure at most 6 drives to be installed in the factory. The remaining drives must be ordered separately using the option part numbers for the drives. This requirement does not apply if the order does not include a rack cabinet. The requirement is due to the shock/vibration limits of the 24x 2.5-inch backplane.

Mid drive bays

The SR655 V3 supports hot-swap drives installed in the middle of the server chassis. The drive bays are accessible by removing the top lid of the server and levering the mid drive chassis up at the front.

The following configurations are supported:

  • 4x 3.5-inch hot-swap SAS/SATA drive bays
  • 8x 2.5-inch hot-swap SAS/SATA drive bays
  • 8x 2.5-inch hot-swap NVMe drive bays

The drive bays in the open position are shown in the following figure.

M.2 support: When mid drive bays are configured, the M.2 adapter is installed on the mid drive bay mechanical as shown in the images.

SR665 Mid-chassis drive bays
Figure 10. Mid-chassis drive bays

The backplanes used to provide these drive bays are listed in the following table.

Table 13. Backplanes for mid drive bays
Feature Description Bays PCIe
Gen
Maximum
supported
Mid 3.5-inch backplanes
BCQK ThinkSystem 2U 4x3.5" SAS/SATA Middle Backplane 4 - 1
Mid 2.5-inch backplanes
BCQL ThinkSystem 2U 4x2.5" SAS/SATA Middle Backplane 4 - 2‡
BDY7 ThinkSystem 2U 4x2.5" Middle NVMe Backplane 4 Gen4 2‡
BS81 ThinkSystem 2U 4x2.5" Middle NVMe Gen5 Backplane 4 Gen5 2‡

‡ 2.5-inch drive backplanes for the mid-chassis area must be installed in pairs and cannot be mixed.

Field upgrades: Backplanes are available as part numbers for field upgrades along with require cable option kits, as described in the Field upgrades section below.

The use of drive bays in the mid-chassis area has the following configuration rules:

  • All processors are supported. Higher TDP processors will require the performance heatsinks.
  • Full-length adapter cards are not supported
  • GPUs (including low profile GPUs such as the T4) are not supported
  • The use of mid drive bays may require Riser 1 or Riser 2 be installed, since power for the mid bay backplanes comes from a riser

Rear drive bays

The SR655 V3 supports hot-swap drives installed at the rear of the server chassis. Supported configurations are as follows:

  • 3.5-inch hot-swap drives
    • 2x SAS/SATA drive bays
    • 4x SAS/SATA drive bays
  • 2.5-inch hot-swap drives
    • 4x SAS/SATA drive bays
    • 4x AnyBay drive bays
    • 8x SAS/SATA drive bays

The configurations are shown in the following figure.

SR655 V3 rear drive bay configurations
Figure 11. Rear 2.5-inch and 3.5-inch drive bay configurations

The backplanes used to provide these drive bays are listed in the following table.

Table 14. Backplanes for rear drive bays
Feature Description Bays PCIe
Gen
Maximum
supported
Rear 3.5-inch backplanes
B8L3 ThinkSystem 1U/2U 4x3.5" SAS/SATA Backplane 4 - 1
BAG7 ThinkSystem 2U 2x3.5" SAS/SATA Rear Backplane 2 - 1
Rear 2.5-inch backplanes
B8LV ThinkSystem 2U 4x2.5" SAS/SATA Backplane 4 - 1
B97X ThinkSystem 2U 8x2.5" SAS/SATA Rear Backplane 8 - 1
BQ2U ThinkSystem V3 1U/2U 4x2.5" AnyBay Backplane 4 Gen4 1
BSE3 ThinkSystem 4x2.5" AnyBay Gen5 Backplane 4 Gen5 1

Field upgrades: Backplanes are available as part numbers for field upgrades along with require cable option kits, as described in the Field upgrades section below.

In addition, the server supports two 7mm-thickness hot-swap SSDs which are installed in place of either slot 3 or slot 6 (not both). These 7mm drives can be used in conjunction with any rear drive 2.5-inch or 3.5-inch bay combination. See the 7mm drives section for details.

The use of rear drive bays has the following configuration rules:

  • The use of rear bays restricts the number of slots and the choice of risers that are supported. See the I/O expansion section for details.
  • The 7mm rear drive kit is supported in either slot 3 or slot 6 but not both at the same time.
  • The 7mm drive enclosure is connected to an onboard connectors and cannot be connected to any installed RAID adapter or HBA.

Storage configurations

This section describes the various combinations of front and rear drives that the server supports, as well as M.2 support.

Tip: These tables are based on TRD V2.6

In this section:

The following tables summarize the storage configurations for the SR655 V3. For details, including processor requirements, M.2 and 7mm support, and controller selections, see each of the Details tables.

Overview - 3.5-inch front drives

The following table summarizes the configurations that use 3.5-inch front drive bays.

Click to jump down to the details of the 3.5-inch front drive configurations.

Return to Storage configurations.

Table 15. Overview - 3.5-inch front drives
Config Total
drives
(NVMe)
Front Middle Rear Backplanes
SAS/SATA
AnyBay
NVMe
EDSFF
3.5" SAS/SATA
2.5" SAS/SATA
2.5" NVMe
3.5" SAS/SATA
2.5" SAS/SATA
2.5" AnyBay
2.5" NVMe
1 8 (0) 8 0 0 0 0 0 0 0 0 0 0 8x3.5" SAS/SATA (B8LP)
2 12 (0) 12 0 0 0 0 0 0 0 0 0 0 12x3.5" SAS/SATA (B8LT)
2 12 (0) 12 0 0 0 0 0 0 0 0 0 0 12x3.5" SAS/SATA with Expander (BQ2S)
3 14 (0) 12 0 0 0 0 0 0 2 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 2x3.5" SAS/SATA (BAG7)
3 14 (0) 12 0 0 0 0 0 0 2 0 0 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 2x3.5" SAS/SATA (BAG7)
4 16 (0) 12 0 0 0 0 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x3.5" SAS/SATA (B8L3)
4 16 (0) 12 0 0 0 0 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 4x3.5" SAS/SATA (B8L3)
4 16 (0) 12 0 0 0 0 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x3.5" SAS/SATA (B8L3)
4 16 (4) 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 4x2.5" AnyBay G4 (BQ2U)
5 16 (0) 12 0 0 0 4 0 0 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 4x3.5" SAS/SATA (BCQK)
6 16 (0) 12 0 0 0 0 4 0 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 4x2.5" SAS/SATA (BCQL)
7 16 (4) 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x2.5" AnyBay G4 (BQ2U)
8 20 (8) 12 0 0 0 0 0 8 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 2x 4x2.5" NVMe G4 (BPC9)
9 20 (0) 12 0 0 0 4 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 4x3.5" SAS/SATA (BCQK); Rear: 4x3.5" SAS/SATA (B8L3)
9 20 (0) 12 0 0 0 4 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Mid: 4x3.5" SAS/SATA (BCQK); Rear: 4x3.5" SAS/SATA (B8L3)
10 12 (4) 8 4 0 0 0 0 0 0 0 0 0 12x3.5" (8xSAS/SATA 4xAnyBay G4) (BPL8)
11 12 (4) 8 0 4 0 0 0 0 0 0 0 0 12x3.5" (8xSAS/SATA 4xNVMe G4) (BPL9)
36 16 (4) 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 4x2.5" AnyBay G4 (BQ2U)
37 16 (4) 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x2.5" AnyBay G4 (BQ2U)
38 20 (8) 12 0 0 0 0 0 8 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 2x 4x2.5" NVMe G5 (BS81)

Overview - 2.5-inch front drives

The following table summarizes the configurations that use 2.5-inch front drives.

Click to jump down to the details of the 2.5-inch front drive configurations.

Return to Storage configurations.

Front PCI slots: Front PCIe slots can be selected with configurations of 8x 2.5-inch or 16x 2.5-inch front drive bays.

Table 16. Overview - 2.5-inch front drives
Config Total
drives
(NVMe)
Front Middle Rear Backplanes
SAS/SATA
AnyBay
NVMe
EDSFF
3.5" SAS/SATA
2.5" SAS/SATA
2.5" NVMe
3.5" SAS/SATA
2.5" SAS/SATA
2.5" AnyBay
2.5" NVMe
13 8 (0) 8 0 0 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU)
14 8 (8) 0 8 0 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B)
14 8 (2) 6 2 0 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xAnyBay G4) (BPL7)
14 8 (2) 6 0 2 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xNVMe G4) (BQQD)
15 8 (8) 0 0 8 0 0 0 0 0 0 0 0 8x2.5" NVMe G4 (BH8D)
16 16 (0) 16 0 0 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU)
17 16 (16) 0 8 8 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B) + 8x2.5" NVMe G4 (BH8D)
18 16 (16) 0 0 16 0 0 0 0 0 0 0 0 2x 8x2.5" NVMe G4 (BH8D)
19 16 (8) 8 8 0 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G4 (BH8B)
20 16 (8) 8 0 8 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G4 (BH8D)
21 24 (8) 16 8 0 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G4 (BH8B)
22 24 (8) 16 0 8 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G4 (BH8D)
23 24 (0) 24 0 0 0 0 0 0 0 0 0 0 3x 8x2.5" SAS/SATA (B8LU)
24 24 (0) 24 0 0 0 0 0 0 0 0 0 0 24x2.5" SAS/SATA with Expander (BQ2T)
25 28 (0) 24 0 0 0 0 4 0 0 0 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 4x2.5" SAS/SATA (BCQL)
26 32 (0) 24 0 0 0 0 8 0 0 0 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 2x 4x2.5" SAS/SATA (BCQL)
27 24 (24) 0 0 24 0 0 0 0 0 0 0 0 3x 8x2.5" NVMe G4 (BH8D)
28 24 (24) 0 8 16 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B) + 2x 8x2.5" NVMe G4 (BH8D)
29 28 (0) 24 0 0 0 0 0 0 0 4 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 4x2.5" SAS/SATA (B8LV)
29 28 (0) 24 0 0 0 0 0 0 0 4 0 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 4x2.5" SAS/SATA (B8LV)
29 28 (4) 24 0 0 0 0 0 0 0 0 4 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 4x2.5" AnyBay G4 (BQ2U)
29 28 (4) 24 0 0 0 0 0 0 0 0 4 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 4x2.5" AnyBay G4 (BQ2U)
30 32 (0) 24 0 0 0 0 0 0 0 8 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 8x2.5" SAS/SATA (B97X)
30 32 (0) 24 0 0 0 0 0 0 0 8 0 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 8x2.5" SAS/SATA (B97X)
31 32 (32) 0 0 24 0 0 0 8 0 0 0 0 Front: 3x 8x2.5" NVMe G4 (BH8D); Mid: 2x 4x2.5" NVMe G4 (BPC9)
32 36 (0) 24 0 0 0 0 8 0 0 4 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 2x 4x2.5" SAS/SATA (BCQL); Rear: 4x2.5" SAS/SATA (B8LV)
33 40 (0) 24 0 0 0 0 8 0 0 8 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 2x 4x2.5" SAS/SATA (BCQL); Rear: 8x2.5" SAS/SATA (B97X)
35 8 (8) 0 8 0 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B)
35 16 (16) 0 16 0 0 0 0 0 0 0 0 0 2x 8x2.5" AnyBay G4 (BH8B)
35 24 (24) 0 24 0 0 0 0 0 0 0 0 0 3x 8x2.5" AnyBay G4 (BH8B)
39 8 (8) 0 8 0 0 0 0 0 0 0 0 0 8x2.5" AnyBay G5 (BLL2)
39 8 (2) 6 2 0 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xAnyBay G5) (BS7Z)
39 8 (2) 6 0 2 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xNVMe G5) (BS80)
40 8 (8) 0 0 8 0 0 0 0 0 0 0 0 8x2.5" NVMe G5 (BS7Y)
40 16 (16) 0 8 8 0 0 0 0 0 0 0 0 8x2.5" AnyBay G5 (BLL2) + 8x2.5" NVMe G5 (BS7Y)
41 16 (16) 0 0 16 0 0 0 0 0 0 0 0 2x 8x2.5" NVMe G5 (BS7Y)
42 16 (8) 8 8 0 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G5 (BLL2)
43 16 (8) 8 0 8 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G5 (BS7Y)
45 24 (8) 16 8 0 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G5 (BLL2)
46 24 (8) 16 0 8 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G5 (BS7Y)
47 24 (24) 0 0 24 0 0 0 0 0 0 0 0 3x 8x2.5" NVMe G5 (BS7Y)
48 24 (24) 0 8 16 0 0 0 0 0 0 0 0 8x2.5" AnyBay G5 (BLL2) + 2x 8x2.5" NVMe G5 (BS7Y)
49 28 (4) 24 0 0 0 0 0 0 0 0 4 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 4x2.5" AnyBay G4 (BQ2U)
49 28 (4) 24 0 0 0 0 0 0 0 0 4 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 4x2.5" AnyBay G4 (BQ2U)

Details - 3.5-inch front bays

The following table details the configurations that use 3.5-inch front drive bays.

Click to go to the overview of the 3.5-inch front drive configurations.

Return to Storage configurations.

Table 17. Details - 3.5-inch front bays
Cfg Front Middle Rear Backplanes M.2 Supported controllers
SAS/SATA
AnyBay
NVMe
EDSFF
3.5" SAS/SATA
2.5" SAS/SATA
2.5" NVMe
3.5" SAS/SATA
2.5" SAS/SATA
2.5" AnyBay
2.5" NVMe
1a 8 0 0 0 0 0 0 0 0 0 0 8x3.5" SAS/SATA (B8LP) Yes OB SATA
1b Yes 5350-8i or 9350-8i
1c Yes 4350-8i
1d Yes 440-8i or 540-8i or 940-8i
2a 12 0 0 0 0 0 0 0 0 0 0 12x3.5" SAS/SATA (B8LT) Yes (no M.2 x4 NVMe) OB SATA
2b Yes 9350-16i
2c Yes 4350-16i
2d Yes 440-16i or 540-16i or 940-16i
2e 12 0 0 0 0 0 0 0 0 0 0 12x3.5" SAS/SATA with Expander (BQ2S) Yes 5350-8i or 9350-8i
2f Yes 4350-8i
2g Yes 440-8i or 540-8i or 940-8i
3a 12 0 0 0 0 0 0 2 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 2x3.5" SAS/SATA (BAG7) Yes (no M.2 x4) OB SATA
3b Yes 9350-16i
3c Yes 4350-16i
3d Yes 440-16i or 540-16i or 940-16i
3g 12 0 0 0 0 0 0 2 0 0 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 2x3.5" SAS/SATA (BAG7) Yes 5350-8i or 9350-8i
3h Yes 440-8i or 540-8i or 940-8i
3i Yes 4350-8i
4a 12 0 0 0 0 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x3.5" SAS/SATA (B8L3) Yes 9350-16i
4b Yes 440-16i or 540-16i or 940-16i
4c Yes 4350-16i
4d 12 0 0 0 0 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 4x3.5" SAS/SATA (B8L3) Yes 5350-8i or 9350-8i
4e Yes 440-8i or 540-8i or 940-8i
4f Yes 4350-8i
4g 12 0 0 0 0 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x3.5" SAS/SATA (B8L3) Yes (no M.2 x4 NVMe) OB SATA + 440-8i or 540-8i or 940-8i
4h Yes (no M.2 x4) OB SATA
4i 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 5350-8i or 9350-8i
4j Yes OB NVMe + 440-8i or 540-8i or 940-8i
4k Yes OB NVMe + 4350-8i
5a 12 0 0 0 4 0 0 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 4x3.5" SAS/SATA (BCQK) Yes (no M.2 x4) 9350-16i
5b Yes (no M.2 x4) 440-16i or 540-16i or 940-16i
5c Yes (no M.2 x4) 4350-16i
6a 12 0 0 0 0 4 0 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 4x2.5" SAS/SATA (BCQL) Yes 9350-16i
6b Yes 440-16i or 540-16i or 940-16i
6c Yes 4350-16i
7a 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 9350-16i
7b Yes OB NVMe + 440-16i or 540-16i or 940-16i
7c Yes OB NVMe + 4350-16i
8a 12 0 0 0 0 0 8 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 2x 4x2.5" NVMe G4 (BPC9) Yes OB NVMe + 440-16i or 540-16i or 940-16i
8b Yes OB NVMe + 4350-16i
9a 12 0 0 0 4 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 4x3.5" SAS/SATA (BCQK); Rear: 4x3.5" SAS/SATA (B8L3) Yes (no M.2 x4) 940-32i
9p 12 0 0 0 4 0 0 4 0 0 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Mid: 4x3.5" SAS/SATA (BCQK); Rear: 4x3.5" SAS/SATA (B8L3) Yes (no M.2 x4) 440-16i or 540-16i or 940-16i
9q Yes (no M.2 x4) 9350-16i
9r Yes (no M.2 x4) 4350-16i
10a 8 4 0 0 0 0 0 0 0 0 0 12x3.5" (8xSAS/SATA 4xAnyBay G4) (BPL8) Yes OB NVMe + 9350-16i
10b Yes OB NVMe + 440-16i or 540-16i or 940-16i
10c Yes OB NVMe + 4350-16i
11a 8 0 4 0 0 0 0 0 0 0 0 12x3.5" (8xSAS/SATA 4xNVMe G4) (BPL9) Yes OB NVMe + 5350-8i or 9350-8i
11b Yes OB NVMe + 440-8i or 540-8i or 940-8i
11c Yes OB NVMe + 4350-8i
11d Yes OB SATA + OB NVMe
36a 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA with Expander (BQ2S); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 5350-8i or 9350-8i
36b Yes OB NVMe + 440-8i or 540-8i or 940-8i
36c Yes OB NVMe + 4350-8i
37a 12 0 0 0 0 0 0 0 0 4 0 Front: 12x3.5" SAS/SATA (B8LT); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 9350-16i
37b Yes OB NVMe + 440-16i or 540-16i or 940-16i
37c Yes OB NVMe + 4350-16i
38a 12 0 0 0 0 0 8 0 0 0 0 Front: 12x3.5" SAS/SATA (B8LT); Mid: 2x 4x2.5" NVMe G5 (BS81) Yes OB NVMe + 440-16i or 540-16i or 940-16i
38b Yes OB NVMe + 4350-16i

Details - 2.5-inch front bays

The following table details the configurations that use 2.5-inch front bays.

Click to go to the overview of the 2.5-inch front drive configurations.

Return to Storage configurations.

Front PCI slots: Front PCIe slots can be selected with configurations of 8x 2.5-inch or 16x 2.5-inch front drive bays.

Table 18. Details - 2.5-inch front bays
Cfg Front Middle Rear Backplanes M.2 Supported controllers
SAS/SATA
AnyBay
NVMe
EDSFF
3.5" SAS/SATA
2.5" SAS/SATA
2.5" NVMe
3.5" SAS/SATA
2.5" SAS/SATA
2.5" AnyBay
2.5" NVMe
13a 8 0 0 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) Yes OB SATA
13b Yes 5350-8i or 9350-8i
13c Yes 440-8i or 540-8i or 940-8i
13d Yes 4350-8i
13e Yes 9350-16i
13f Yes 440-16i or 540-16i or 940-16i
13g Yes 4350-16i
13h Yes 940-16i CFF or 9350-16i CFF
14a 0 8 0 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B) Yes OB NVMe + 5350-8i or 9350-8i
14b Yes OB NVMe + 440-8i or 540-8i or 940-8i
14c Yes OB NVMe + 4350-8i
14d Yes OB NVMe + 9350-16i
14e Yes OB NVMe + 440-16i or 540-16i or 940-16i
14f Yes OB NVMe + 4350-16i
14g 6 2 0 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xAnyBay G4) (BPL7) Yes OB NVMe + 5350-8i or 9350-8i
14h Yes OB NVMe + 440-8i or 540-8i or 940-8i
14i Yes OB NVMe + 4350-8i
14j 6 0 2 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xNVMe G4) (BQQD) Yes OB SATA + OB NVMe
15a 0 0 8 0 0 0 0 0 0 0 0 8x2.5" NVMe G4 (BH8D) Yes OB NVMe
16a 16 0 0 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) Yes (no M.2 x4) OB SATA
16b Yes 9350-16i
16c Yes 440-16i or 540-16i or 940-16i
16d Yes 4350-16i
16e Yes 940-16i CFF or 9350-16i CFF
16f Yes 440-16i
17a 0 8 8 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B) + 8x2.5" NVMe G4 (BH8D) Yes (no M.2 x4) OB NVMe + 5350-8i or 9350-8i + Retimer G4
17b Yes (no M.2 x4) OB NVMe + 440-8i or 540-8i or 940-8i + Retimer G4
17c Yes (no M.2 x4) OB NVMe + 4350-8i + Retimer G4
18a 0 0 16 0 0 0 0 0 0 0 0 2x 8x2.5" NVMe G4 (BH8D) Yes (no M.2 x4) OB NVMe + Retimer G4
19a 8 8 0 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G4 (BH8B) Yes (no M.2 x4) OB SATA + OB NVMe
19b Yes OB NVMe + 9350-16i
19c Yes OB NVMe + 440-16i or 540-16i or 940-16i
19d Yes OB NVMe + 4350-16i
19e Yes OB NVMe + 2x (5350-8i or 9350-8i)
19f Yes OB NVMe + 2x (440-8i or 540-8i or 940-8i)
19g Yes OB NVMe + 2x 4350-8i
20a 8 0 8 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G4 (BH8D) Yes OB SATA + OB NVMe
20b Yes OB NVMe + 5350-8i or 9350-8i
20c Yes OB NVMe + 440-8i or 540-8i or 940-8i
20d Yes OB NVMe + 4350-8i
21a 16 8 0 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G4 (BH8B) Yes OB NVMe + 940-32i
21b Yes OB NVMe + 3x (5350-8i or 9350-8i)
21c Yes OB NVMe + 3x (440-8i or 540-8i or 940-8i)
21d Yes OB NVMe + 3x 4350-8i
22a 16 0 8 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G4 (BH8D) Yes OB NVMe + 940-16i CFF or 9350-16i CFF
22b Yes OB NVMe + 440-16i
22c Yes OB NVMe + 440-16i or 540-16i or 940-16i
22d Yes OB NVMe + 4350-16i
22e Yes OB NVMe + 9350-16i
22f Yes OB NVMe + 2x (440-8i or 540-8i or 940-8i)
22g Yes OB NVMe + 2x 4350-8i
22h Yes OB NVMe + 2x (5350-8i or 9350-8i)
23a 24 0 0 0 0 0 0 0 0 0 0 3x 8x2.5" SAS/SATA (B8LU) Yes 940-32i
23e Yes 3x (5350-8i or 9350-8i)
23f Yes 3x (440-8i or 540-8i or 940-8i)
23g Yes 4350-8i + 4350-16i
23h Yes 440-8i or 540-8i or 940-8i + 440-16i or 540-16i or 940-16i
23i Yes 5350-8i or 9350-8i + 9350-16i
24a 24 0 0 0 0 0 0 0 0 0 0 24x2.5" SAS/SATA with Expander (BQ2T) Yes 5350-8i or 9350-8i
24b Yes 440-8i or 540-8i or 940-8i
24c Yes 4350-8i
25a 24 0 0 0 0 4 0 0 0 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 4x2.5" SAS/SATA (BCQL) Yes 940-32i
25b Yes 2x (440-16i or 540-16i or 940-16i)
25c Yes 2x 4350-16i
25d Yes 2x 9350-16i
26a 24 0 0 0 0 8 0 0 0 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 2x 4x2.5" SAS/SATA (BCQL) Yes 940-32i
26b Yes 2x (440-16i or 540-16i or 940-16i)
26c Yes 2x 4350-16i
26d Yes 2x 9350-16i
27a 0 0 24 0 0 0 0 0 0 0 0 3x 8x2.5" NVMe G4 (BH8D) Yes (no M.2 x4) OB NVMe + 3x Retimer G4
28a 0 8 16 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B) + 2x 8x2.5" NVMe G4 (BH8D) Yes (no M.2 x4) OB NVMe + 440-8i or 540-8i or 940-8i + 3x Retimer G4
28b Yes (no M.2 x4) OB NVMe + 4350-8i + 3x Retimer G4
28c Yes (no M.2 x4) OB NVMe + 5350-8i or 9350-8i + 3x Retimer G4
29a 24 0 0 0 0 0 0 0 4 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 4x2.5" SAS/SATA (B8LV) Yes 940-32i
29b Yes Exp-44i CFF + 940-16i CFF or 9350-16i CFF
29c Yes Exp-44i CFF + 5350-8i or 9350-8i
29d Yes Exp-44i CFF + 440-16i
29e Yes 9350-16i + Exp-44i CFF
29f Yes 440-16i or 540-16i or 940-16i + Exp-44i CFF
29g Yes 4350-16i + Exp-44i CFF
29h Yes 5350-8i or 9350-8i + Exp-44i CFF
29i Yes 440-8i or 540-8i or 940-8i + Exp-44i CFF
29j Yes 4350-8i + Exp-44i CFF
29k 24 0 0 0 0 0 0 0 4 0 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 4x2.5" SAS/SATA (B8LV) Yes 5350-8i or 9350-8i
29l Yes 440-8i or 540-8i or 940-8i
29m Yes 4350-8i
29n 24 0 0 0 0 0 0 0 0 4 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 940-32i
29o Yes OB NVMe + Exp-44i CFF + 940-16i CFF or 9350-16i CFF
29p Yes OB NVMe + Exp-44i CFF + 5350-8i or 9350-8i
29q Yes OB NVMe + Exp-44i CFF + 440-16i
29r Yes OB NVMe + 9350-16i + Exp-44i CFF
29s Yes OB NVMe + 440-16i or 540-16i or 940-16i + Exp-44i CFF
29t Yes OB NVMe + 4350-16i + Exp-44i CFF
29u Yes OB NVMe + 5350-8i or 9350-8i + Exp-44i CFF
29v Yes OB NVMe + 440-8i or 540-8i or 940-8i + Exp-44i CFF
29w Yes OB NVMe + 4350-8i + Exp-44i CFF
29x 24 0 0 0 0 0 0 0 0 4 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 5350-8i or 9350-8i
29y Yes OB NVMe + 440-8i or 540-8i or 940-8i
29z Yes OB NVMe + 4350-8i
30a 24 0 0 0 0 0 0 0 8 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 8x2.5" SAS/SATA (B97X) Yes 940-32i
30b Yes 2x (440-16i or 540-16i or 940-16i)
30c Yes 2x 4350-16i
30d Yes 2x 9350-16i
30e Yes Exp-44i CFF + 940-16i CFF or 9350-16i CFF
30f Yes Exp-44i CFF + 5350-8i or 9350-8i
30g Yes Exp-44i CFF + 440-16i
30h Yes 9350-16i + Exp-44i CFF
30i Yes 440-16i or 540-16i or 940-16i + Exp-44i CFF
30j Yes 4350-16i + Exp-44i CFF
30k Yes 5350-8i or 9350-8i + Exp-44i CFF
30l Yes 440-8i or 540-8i or 940-8i + Exp-44i CFF
30m Yes 4350-8i + Exp-44i CFF
30n Yes 440-16i or 540-16i or 940-16i + 940-16i CFF or 9350-16i CFF
30o 24 0 0 0 0 0 0 0 8 0 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 8x2.5" SAS/SATA (B97X) Yes 9350-16i
30p Yes 440-16i or 540-16i or 940-16i
30q Yes 4350-16i
30r Yes 940-16i CFF or 9350-16i CFF
30s Yes 440-16i
31a 0 0 24 0 0 0 8 0 0 0 0 Front: 3x 8x2.5" NVMe G4 (BH8D); Mid: 2x 4x2.5" NVMe G4 (BPC9) Yes (no M.2 x4) OB NVMe + Retimer G4 + 2x NVMe Switch
32a 24 0 0 0 0 8 0 0 4 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 2x 4x2.5" SAS/SATA (BCQL); Rear: 4x2.5" SAS/SATA (B8LV) Yes 440-8i or 540-8i or 940-8i + 940-32i
32b Yes Exp-44i CFF + 940-16i CFF or 9350-16i CFF
32c Yes Exp-44i CFF + 5350-8i or 9350-8i
32d Yes Exp-44i CFF + 440-16i
32e Yes 9350-16i + Exp-44i CFF
32f Yes 5350-8i or 9350-8i + Exp-44i CFF
32g Yes 440-8i or 540-8i or 940-8i + Exp-44i CFF
32h Yes 4350-8i + Exp-44i CFF
33a 24 0 0 0 0 8 0 0 8 0 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Mid: 2x 4x2.5" SAS/SATA (BCQL); Rear: 8x2.5" SAS/SATA (B97X) Yes Exp-44i CFF + 940-16i CFF or 9350-16i CFF
33b Yes 4350-16i + Exp-44i CFF
33c Yes 440-16i or 540-16i or 940-16i + Exp-44i CFF
33d Yes 9350-16i + Exp-44i CFF
33e Yes Exp-44i CFF + 440-16i
35a 0 8 0 0 0 0 0 0 0 0 0 8x2.5" AnyBay G4 (BH8B) Yes 940-8i Tri-Mode
35b 0 16 0 0 0 0 0 0 0 0 0 2x 8x2.5" AnyBay G4 (BH8B) Yes 2x 940-8i Tri-Mode
35c Yes 940-16i Tri-Mode
35d 0 24 0 0 0 0 0 0 0 0 0 3x 8x2.5" AnyBay G4 (BH8B) Yes 940-16i Tri-Mode + 940-8i Tri-Mode
35e Yes 3x 940-8i Tri-Mode
39a 0 8 0 0 0 0 0 0 0 0 0 8x2.5" AnyBay G5 (BLL2) Yes OB NVMe + 5350-8i or 9350-8i
39b Yes OB NVMe + 440-8i or 540-8i or 940-8i
39c Yes OB NVMe + 4350-8i
39d 6 2 0 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xAnyBay G5) (BS7Z) Yes OB NVMe + 5350-8i or 9350-8i
39e Yes OB NVMe + 440-8i or 540-8i or 940-8i
39f Yes OB NVMe + 4350-8i
39g 6 0 2 0 0 0 0 0 0 0 0 8x2.5" (6xSAS/SATA 2xNVMe G5) (BS80) Yes OB SATA + OB NVMe
40a 0 0 8 0 0 0 0 0 0 0 0 8x2.5" NVMe G5 (BS7Y) Yes OB NVMe
40b 0 8 8 0 0 0 0 0 0 0 0 8x2.5" AnyBay G5 (BLL2) + 8x2.5" NVMe G5 (BS7Y) Yes (no M.2 x4) OB NVMe + 5350-8i or 9350-8i + Retimer G5
40c Yes (no M.2 x4) OB NVMe + 440-8i or 540-8i or 940-8i + Retimer G5
40d Yes (no M.2 x4) OB NVMe + 4350-8i + Retimer G5
41a 0 0 16 0 0 0 0 0 0 0 0 2x 8x2.5" NVMe G5 (BS7Y) Yes (no M.2 x4) OB NVMe + Retimer G5
42a 8 8 0 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G5 (BLL2) Yes (no M.2 x4) OB SATA + OB NVMe
42b Yes OB NVMe + 9350-16i
42c Yes OB NVMe + 440-16i or 540-16i or 940-16i
42d Yes OB NVMe + 4350-16i
42e Yes OB NVMe + 2x (5350-8i or 9350-8i)
42f Yes OB NVMe + 2x (440-8i or 540-8i or 940-8i)
42g Yes OB NVMe + 2x 4350-8i
43a 8 0 8 0 0 0 0 0 0 0 0 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G5 (BS7Y) Yes OB SATA + OB NVMe
43b Yes OB NVMe + 5350-8i or 9350-8i
43c Yes OB NVMe + 440-8i or 540-8i or 940-8i
43d Yes OB NVMe + 4350-8i
45a 16 8 0 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" AnyBay G5 (BLL2) Yes OB NVMe + 940-32i
45b Yes OB NVMe + 3x (5350-8i or 9350-8i)
45c Yes OB NVMe + 3x (440-8i or 540-8i or 940-8i)
45d Yes OB NVMe + 3x 4350-8i
46a 16 0 8 0 0 0 0 0 0 0 0 2x 8x2.5" SAS/SATA (B8LU) + 8x2.5" NVMe G5 (BS7Y) Yes OB NVMe + 940-16i CFF or 9350-16i CFF
46b Yes OB NVMe + 440-16i
46c Yes OB NVMe + 440-16i or 540-16i or 940-16i
46d Yes OB NVMe + 4350-16i
46e Yes OB NVMe + 9350-16i
46f Yes OB NVMe + 2x (440-8i or 540-8i or 940-8i)
46g Yes OB NVMe + 2x 4350-8i
46h Yes OB NVMe + 2x (5350-8i or 9350-8i)
47a 0 0 24 0 0 0 0 0 0 0 0 3x 8x2.5" NVMe G5 (BS7Y) Yes (no M.2 x4) OB NVMe + 3x Retimer G5
48a 0 8 16 0 0 0 0 0 0 0 0 8x2.5" AnyBay G5 (BLL2) + 2x 8x2.5" NVMe G5 (BS7Y) Yes (no M.2 x4) OB NVMe + 440-8i or 540-8i or 940-8i + 3x Retimer G5
48b Yes (no M.2 x4) OB NVMe + 4350-8i + 3x Retimer G5
48c Yes (no M.2 x4) OB NVMe + 5350-8i or 9350-8i + 3x Retimer G5
49a 24 0 0 0 0 0 0 0 0 4 0 Front: 3x 8x2.5" SAS/SATA (B8LU); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 940-32i
49b Yes OB NVMe + Exp-44i CFF + 940-16i CFF or 9350-16i CFF
49c Yes OB NVMe + Exp-44i CFF + 5350-8i or 9350-8i
49d Yes OB NVMe + Exp-44i CFF + 440-16i
49e Yes OB NVMe + 9350-16i + Exp-44i CFF
49f Yes OB NVMe + 440-16i or 540-16i or 940-16i + Exp-44i CFF
49g Yes OB NVMe + 4350-16i + Exp-44i CFF
49h Yes OB NVMe + 5350-8i or 9350-8i + Exp-44i CFF
49i Yes OB NVMe + 440-8i or 540-8i or 940-8i + Exp-44i CFF
49j Yes OB NVMe + 4350-8i + Exp-44i CFF
49k 24 0 0 0 0 0 0 0 0 4 0 Front: 24x2.5" SAS/SATA with Expander (BQ2T); Rear: 4x2.5" AnyBay G4 (BQ2U) Yes OB NVMe + 5350-8i or 9350-8i
49l Yes OB NVMe + 440-8i or 540-8i or 940-8i
49m Yes OB NVMe + 4350-8i

Field upgrades

The SR655 V3 is orderable without drive bays, allowing you to add a backplane, cabling and controllers as field upgrades. The server also supports upgrading some configurations by adding additional front drive bays (for example, upgrading from 8 to 16x 2.5-inch drive bays).

For more information about the backplane kits and cable kits, see the Lenovo server options site:
https://serveroption.lenovo.com/cable_kit_options/

2.5-inch and 3.5-inch chassis drive bay upgrades

To add drive bays you will need to order both drive backplanes and cable kits. Backplane kits do not include cables.

In the case of 8x2.5" backplanes, there are cable kits for BP1, BP2 and BP3, which correspond to the backplanes as shown in the following figure. Select the cables related to the backplane location you wish to upgrade.

Backplane numbering
Figure 12. Backplane numbering

Table 19. Field upgrades
Drive bays Backplane and Cable Kit part numbers
Front 2.5-inch drive bays
4x2.5-inch Front AnyBay Gen4 drive bays
  • 4XH7A85893 , ThinkSystem SR665 V3/SR655 V3 4x2.5" Anybay Backplane Option Kit
  • 4X97A87729, ThinkSystem SR655 V3 2.5" Chassis Rear AnyBay Backplane Gen5 Cable Kit
8x2.5-inch Front AnyBay Gen4 drive bays

Select BP1/BP2/BP3 cable kits based on location of the backplane to be installed

  • 4XH7A82913, ThinkSystem SR650 V3 8x2.5" AnyBay Backplane Option Kit
  • 4X97A86423, ThinkSystem SR655 V3 2.5" Chassis Front BP1 NVMe Cable Kit
  • 4X97A86424, ThinkSystem SR655 V3 2.5" Chassis Front BP1 SAS/SATA Cable Kit
  • 4X97A86425, ThinkSystem SR655 V3 2.5" Chassis Front BP2 NVMe Cable Kit
  • 4X97A86426, ThinkSystem SR655 V3 2.5" Chassis Front BP2 SAS/SATA Cable Kit
  • 4X97A86427, ThinkSystem SR655 V3 2.5" Chassis Front BP3 NVMe Cable Kit
  • 4X97A86428, ThinkSystem SR655 V3 2.5" Chassis Front BP3 SAS/SATA Cable Kit
8x2.5-inch Front AnyBay Gen5 drive bays

Select BP1/BP2/BP3 cable kits based on location of the backplane to be installed

  • 4XH7A86759, ThinkSystem SR655 V3 8x2.5" Gen5 AnyBay Backplane Option Kit
  • 4X97A86423, ThinkSystem SR655 V3 2.5" Chassis Front BP1 NVMe Cable Kit
  • 4X97A86424, ThinkSystem SR655 V3 2.5" Chassis Front BP1 SAS/SATA Cable Kit
  • 4X97A86425, ThinkSystem SR655 V3 2.5" Chassis Front BP2 NVMe Cable Kit
  • 4X97A86426, ThinkSystem SR655 V3 2.5" Chassis Front BP2 SAS/SATA Cable Kit
  • 4X97A86427, ThinkSystem SR655 V3 2.5" Chassis Front BP3 NVMe Cable Kit
  • 4X97A86428, ThinkSystem SR655 V3 2.5" Chassis Front BP3 SAS/SATA Cable Kit
8x2.5-inch Front NVMe Gen4 drive bays

Select BP1/BP2/BP3 cable kits based on location of the backplane to be installed

  • 4XH7A61076, ThinkSystem SR650 V2 8x2.5" NVMe Backplane Option Kit
  • 4X97A86423, ThinkSystem SR655 V3 2.5" Chassis Front BP1 NVMe Cable Kit
  • 4X97A86425, ThinkSystem SR655 V3 2.5" Chassis Front BP2 NVMe Cable Kit
  • 4X97A86427, ThinkSystem SR655 V3 2.5" Chassis Front BP3 NVMe Cable Kit
8x2.5-inch Front SAS/SATA drive bays

Select BP1/BP2/BP3 cable kits based on location of the backplane to be installed

  • 4XH7A60930, ThinkSystem V3 2U 8x2.5" SAS/SATA Backplane Option Kit
  • 4X97A86424, ThinkSystem SR655 V3 2.5" Chassis Front BP1 SAS/SATA Cable Kit
  • 4X97A86426, ThinkSystem SR655 V3 2.5" Chassis Front BP2 SAS/SATA Cable Kit
  • 4X97A86428, ThinkSystem SR655 V3 2.5" Chassis Front BP3 SAS/SATA Cable Kit
24x2.5-inch Front SAS/SATA drive bays with SAS Expander
  • 4XH7A86134, ThinkSystem SR665 V3/SR655 V3 24x2.5" Expander Backplane Option Kit
  • 4X97A87730, ThinkSystem SR655 V3 12x3.5" + 24x2.5" Expander Backplane Cable Option Kit
Front 3.5-inch drive bays
8x3.5-inch Front SAS/SATA drive bays
  • 4XH7A60932, ThinkSystem SR650 V2/SR665 8x3.5" SAS/SATA Backplane Option Kit
  • 4X97A86419, ThinkSystem SR655 V3 3.5" Chassis Front Backplane SAS/SATA Cable Kit
12x3.5-inch Front SAS/SATA drive bays
  • 4XH7A60929, ThinkSystem V2/V3 2U 12x3.5" SAS/SATA Backplane Option Kit
  • 4X97A86419, ThinkSystem SR655 V3 3.5" Chassis Front Backplane SAS/SATA Cable Kit
12x3.5-inch Front SAS/SATA/AnyBay Gen4 drive bays
  • 4XH7A87507, ThinkSystem V3 2U 8xSAS/SATA+4xAnyBay 3.5" Backplane Option Kit
  • 4X97A86420, ThinkSystem SR655 V3 3.5" Chassis Front Backplane AnyBay Cable Kit
12x3.5-inch Front SAS/SATA/NVMe Gen4 drive bays
  • 4XH7A87508, ThinkSystem V3 2U 8xSAS/SATA+4xNVMe 3.5" Backplane Option Kit
  • 4X97A86420, ThinkSystem SR655 V3 3.5" Chassis Front Backplane AnyBay Cable Kit
12x3.5-inch Front SAS/SATA drive bays with SAS Expander
  • 4XH7A86133, ThinkSystem SR665 V3/SR655 V3 12x3.5" Expander Backplane Option Kit
  • 4X97A87730, ThinkSystem SR655 V3 12x3.5" + 24x2.5" Expander Backplane Cable Option Kit
Mid 2.5-inch drive bays
8x2.5-inch Mid NVMe Gen4 drive bays
  • 4XH7A86756, ThinkSystem SR655 V3 8x2.5" NVMe Gen4 Middle Backplane Kit
  • 4X97A86432, ThinkSystem SR655 V3 2.5" Chassis Middle Backplane NVMe Cable Kit
8x2.5-inch Mid NVMe Gen5 drive bays
  • 4XH7A86757, ThinkSystem SR655 V3 8x2.5" NVMe Gen5 Middle Backplane Kit
  • 4X97A86432, ThinkSystem SR655 V3 2.5" Chassis Middle Backplane NVMe Cable Kit
8x2.5-inch Mid SAS/SATA drive bays
  • 4XH7A86755, ThinkSystem SR655 V3 8x2.5" SAS/SATA Middle Backplane Option Kit
  • 4X97A86431, ThinkSystem SR655 V3 2.5" Chassis Middle Backplane SAS/SATA Cable Kit
Mid 3.5-inch drive bays
4x3.5-inch Mid SAS/SATA drive bays
  • 4XH7A86758, ThinkSystem SR655 V3 4x3.5" SAS/SATA Middle Backplane Option Kit
  • 4X97A86422, ThinkSystem SR655 V3 3.5" Chassis Middle Backplane SAS/SATA Cable Kit
Rear 2.5-inch drive bays
4x2.5-inch Rear SAS/SATA drive bays
  • 4XH7A60938, ThinkSystem V3 2U 4x2.5" SAS/SATA Rear Backplane Option Kit
  • 4X97A86429, ThinkSystem SR655 V3 2.5" Chassis Rear Backplane SAS/SATA Cable Kit
8x2.5-inch Rear SAS/SATA drive bays
  • 4XH7A60941, ThinkSystem SR650 V2/SR665 Rear 8x2.5" SAS/SATA Backplane Option Kit
  • 4X97A86429, ThinkSystem SR655 V3 2.5" Chassis Rear Backplane SAS/SATA Cable Kit
Rear 3.5-inch drive bays
2x3.5-inch Rear SAS/SATA drive bays
  • 4XH7A60940, ThinkSystem SR650 V2/SR665 Rear 2x3.5" SAS/SATA Backplane Option Kit
  • 4X97A86421, ThinkSystem SR655 V3 3.5" Chassis Rear Backplane SAS/SATA Cable Kit
4x3.5-inch Rear SAS/SATA drive bays
  • 4XH7A60939, ThinkSystem V2/V3 2U Rear 4x3.5" SAS/SATA Rear Backplane Option Kit
  • 4X97A86421, ThinkSystem SR655 V3 3.5" Chassis Rear Backplane SAS/SATA Cable Kit

When adding drive bays, you will also need to add the appropriate storage controller(s). Consult the tables in the Storage configurations section to determine what controller sections are supported and what additional controllers you will need. Controllers are described in the Controllers for internal storage section.

Upgrades to Retimer adapters

If you are upgrading to a configuration that includes a Retimer adapter (see the Detailed tables in the Storage configurations section), then you will need to also order one of the following cable kits.

Table 20. Cable kits when upgrading to a Retimer configuration
Part number Description Quantity
required
4X97A86434 ThinkSystem SR655 V3 24 NVMe Cable Kit 1
4X97A86435 ThinkSystem SR655 V3 32 NVMe Cable Kit 1

Upgrades to an Internal (CFF) HBA/RAID adapter

If you want to add an internal (CFF) storage adapter (HBA, RAID adapter or SAS expander) to a configuration, you will need to order the cable kit as listed in the following table. Suitable upgrades are either replacing an existing adapter in a rear PCIe slot, or adding the CFF adapter to a server without any storage adapter installed.

The cable kit to order is listed in the following table.

Table 21. Cable kit when upgrading to an Internal HBA/RAID adapter
Part number Description Quantity
required
4X97A86433 ThinkSystem SR655 V3 Internal Raid Adapter Cable Kit 1

RAID flash power module (supercap) support

If you plan to add one of the RAID adapters that includes a RAID flash power module (supercap) as a field upgrade, then you may also need to order a Supercap installation kit for the supercap, depending on the location where the supercap will be installed. For CTO orders, the components needed are automatically derived when you select the RAID adapter.

The adapters that this applies to are as follows:

  • Any supported RAID 9350 adapter
  • Any supported RAID 940 adapter

The location of the supercaps depends on the mid-chassis drive cage used in the server, as shown in the following table.

Table 22. Supercap support
Mid drive cage Supercaps
supported
Location of supercaps Supercap holder
No mid drive cage 4 Mounted on the air baffle Not needed
2.5-inch drives 2 Mounted on the left side of the mid drive cage Integrated into the left side of the 2.5-inch mid drive cage
3.5-inch drives 2 Mounted under the system fan cage Included with ThinkSystem SR655 V3 4x3.5" SAS/SATA Middle Backplane Option Kit (4XH7A86758) or order separately (see below)

When adding a RAID 9350 or 940 adapter as a field upgrade to a configuration with existing 3.5-inch mid drive bays, order one supercap holder. Ordering information is in the following table. You do not need to order this supercap holder if you are also adding the mid-chassis drive bays as a field upgrade, since ThinkSystem SR655 V3 4x3.5" SAS/SATA Middle Backplane Option Kit (4XH7A86758) already includes the supercap holder.

Table 23. Supercap holder for 3.5-inch mid drive bay config
Part number Feature Description Maximum supported
4XH7A86163 BLL8 ThinkSystem V3 2U Supercap Holder Kit 1 (holds 2 supercaps)

7mm drives

The SR655 V3 supports two 7mm drives, either both SATA or both NVMe, at the rear of the server. These drives go in place of either PCIe slot 3 (Riser 1) or PCIe slot 6 (Riser 2) as shown in the following figure.

SR665 rear 7mm drive bay configurations
Figure 13. Rear 7mm drive bay configurations

For CTO orders, the configuration includes the drive bays and the cage the the drive bays are mounted on to.The cage required depends on where the 7mm drives are located (Riser 1 or Riser 2) and whether there are PCIe slots above the 7mm drive bays. The following table lists the ordering information.

Tip for 4x 3.5-inch rear drives: If you wish to configure 4x 3.5-inch rear drives plus 7mm drives in a CTO configuration, the 7mm drives will install in slot 6. You should specify riser card BLKP for Riser 1 and then leave Riser 2 without a riser selected.

Table 24. CTO feature codes for 7mm drives
Feature
code
Description Maximum
supported
Backplane - 7mm drives
BU0N ThinkSystem 7mm SATA/NVMe 2-Bay Rear Enablement Kit v2 1
B8P3 ThinkSystem 2U 7mm Drive Kit w/ NVMe RAID 1
Hardware RAID support for ThinkSystem 7mm SATA/NVMe 2-Bay Rear Enablement Kit v2 (BU0N)
BT7N ThinkSystem RAID 5350-8i for M.2/7mm SATA Boot Enablement 1
BT7P ThinkSystem RAID 540-8i for M.2/7mm NVMe Boot Enablement 1

The use of the 7mm rear drive bays has the following configuration rules:

  • The 7mm rear drive kit is supported in either slot 3 or slot 6 but not both at the same time.
  • M.2 RAID and 7mm RAID are mutually exclusive: they are not supported together in the same configuration
  • For ThinkSystem 7mm SATA/NVMe 2-Bay Rear Enablement Kit v2 (feature BU0N):
    • The 7mm drive bays support either SATA drives or NVMe drives but not both. You specify SATA or NVMe in the configurator using feature codes BTTV (SATA) or BTTW (NVMe).
    • If RAID support is not required, the 7mm drives connect to an onboard port; No additional adapter is required
    • If RAID support is required, select feature code BS7A in the configurator to enable RAID
    • The support of RAID-1 with the 7mm drives requires an additional RAID adapter that is installed in PCIe slot 3:
      • RAID support for 7mm SATA drives requires a RAID 5350-8i adapter (feature BT7N)
      • RAID support for 7mm NVMe drives requires a RAID 540-8i adapter operating in Tri-Mode (feature BT7P)
    • The RAID adapter used for 7mm drive support cannot be configured for use with other drive bays (not even with M.2)
  • For ThinkSystem 2U 7mm Drive Kit w/ NVMe RAID (feature B8P3)
    • The adapter only supports NVMe drives
    • RAID functionality is integrated into the M.2 adapter using a Marvell 88NR2241 NVMe RAID Controller

7mm drive field upgrades

For field upgrades, using the following ordering information. The kits include two cages for use depending on your PCIe slot configuration. The cages are for either Riser 1 or Riser 2. The part numbers also include the cables necessary to connect the 7mm backplane to either the system board or RAID adapter.

Table 25. Field upgrade part numbers for 7mm drives
Part number Description Purpose
7mm Enablement Kits
4XH7A87560

ThinkSystem SR655 V3 7mm SATA/NVMe 2-Bay Non-RAID Enablement Kit

  • 2-bay hot-swap drive enclosure
  • 2FH+7mm SSD Riser Cage (with 2 FH PCIe slots)
  • 7mm SSD Riser Cage (without PCIe slots)
  • 2x 7mm drive bay fillers
  • Signal and power cables for onboard connections
7mm drive bays for SATA or NVMe drive support with no RAID support (does not include cables needed for RAID support with a separate adapter)
4XH7A87561

ThinkSystem SR655 V3 7mm SATA/NVME 2-Bay RAID Enablement Kit

  • 2-bay SATA hot-swap drive enclosure
  • 2FH+7mm SSD Riser Cage (with 2 FH PCIe slots)
  • 7mm SSD Riser Cage (without PCIe slots)
  • 2x 7mm drive bay fillers
  • Signal and power cables for RAID adapter connectivity
7mm drive bays for SATA or NVMe drives, plus cables for use with a RAID adapter. Requires a separate RAID adapter for RAID support.
4X97A88531 ThinkSystem SR655 V3 7mm NVMe 2-Bay RAID Enablement Kit 7mm drive bays for NVMe drive support. RAID support is integrated into the adapter using an onboard Marvell 88NR2241 NVMe RAID controller.
RAID adapters for optional 7mm HW RAID support (for use with 4XH7A87561)
4Y37A72482 ThinkSystem RAID 5350-8i PCIe 12Gb Adapter RAID adapter needed for SATA RAID-1 with 2x 7mm SATA drives
4Y37A78834 ThinkSystem RAID 540-8i PCIe Gen4 12Gb Adapter

RAID adapter needed for NVMe RAID-1 with 2x 7mm NVMe drives

Tip: Once the 540-8i adapter is installed, it will need to be configured to operate in Tri-mode to enable NVMe RAID.

M.2 drives

The SR655 V3 supports one or two M.2 form-factor SATA or NVMe drives for use as an operating system boot solution or as additional storage.

The M.2 drives install into an M.2 module which is mounted horizontally in the server:

  • In servers without mid-chassis drives, the M.2 module is mounted on the air baffle
  • With a mid-chassis drive cage (2.5-inch or 3.5-inch), the M.2 module is mounted on the drive cage, as shown in the Mid drive bays section.

The supported M.2 modules are listed in the following table. For field upgrades see the M.2 field upgrades section below.

Table 26. M.2 modules
Part
number
Feature
code
Description SATA
drives
NVMe
drives
RAID Maximum
supported
Windows 10/11
support
4Y37A09738 B5XJ ThinkSystem M.2 SATA/NVMe 2-Bay Enablement Kit Yes Yes (x1 lane) No 1 Supported
4Y37A79663 BM8X ThinkSystem M.2 SATA/x4 NVMe 2-Bay Enablement Kit Yes Yes (x4 lanes) Optional 1 Supported
4Y37A09750 B8P9 ThinkSystem M.2 NVMe 2-Bay RAID Enablement Kit No Yes (x1 lane) Integrated 1 No

ThinkSystem M.2 SATA/x4 NVMe 2-Bay Enablement Kit (4Y37A79663) optionally supports RAID with the addition of a separate RAID adapter is required. For CTO orders, ordering information is listed in the following table to derive the required RAID adapter.

Table 27. CTO feature codes to select M.2 RAID (ThinkSystem M.2 SATA/x4 NVMe 2-Bay Enablement Kit only)
Feature
code
Description RAID
support
Maximum
supported
BT7N ThinkSystem RAID 5350-8i for M.2/7mm SATA Boot Enablement SATA 1
BT7P ThinkSystem RAID 540-8i for M.2/7mm NVMe Boot Enablement NVMe 1

Configuration notes:

  • M.2 is not supported with all storage configurations - see Storage configurations for details.
  • M.2 RAID and 7mm RAID are mutually exclusive: they are not supported together in the same configuration
  • For field upgrades, an additional cable is needed as described in the M.2 field upgrades section below
  • For ThinkSystem M.2 SATA/NVMe 2-Bay Enablement Kit (4Y37A09738):
    • RAID is not supported
    • The installation of at least one M.2 drive is required. In the configurator, at least one M.2 drive must be selected
  • For ThinkSystem M.2 SATA/x4 NVMe 2-Bay Enablement Kit (4Y37A79663):
    • The support of RAID-1 with the M.2 drives requires an additional RAID adapter that is installed in PCIe slot 3:
      • RAID support for M.2 SATA drives requires a RAID 5350-8i adapter (feature BT7N)
      • RAID support for M.2 NVMe drives requires a RAID 540-8i adapter operating in Tri-Mode (feature BT7P)
    • The RAID adapter used for M.2 drive support cannot be configured for use with other drive bays (not even with 7mm)
    • If RAID support is not required, the M.2 adapter connects to an onboard port. No additional adapter is required
  • For ThinkSystem M.2 NVMe 2-Bay RAID Enablement Kit (4Y37A09750):
    • RAID is implemented using an onboard Marvell 88NR2241 NVMe RAID controller

Supported drives are listed in the Internal drive options section.

The ThinkSystem M.2 SATA/NVMe 2-Bay Enablement Kit has the following features:

  • Supports one or two M.2 drives, either SATA or NVMe
  • When two drives installed, they must be either both SATA or both NVMe
  • Support 42mm, 60mm, 80mm and 110mm drive form factors (2242, 2260, 2280 and 22110)
  • On the SR655 V3, no RAID support
  • No onboard RAID; RAID functionality is provided by a separate adapter (SATA or NVMe)
  • Either 6Gbps SATA or PCIe 3.0 x1 interface to the drives depending on the drives installed
  • Supports monitoring and reporting of events and temperature through I2C
  • Firmware update via Lenovo firmware update tools

The ThinkSystem M.2 SATA/x4 NVMe 2-Bay Enablement Kit has the following features:

  • Supports one or two M.2 drives, either SATA or NVMe
  • When two drives installed, they must be either both SATA or both NVMe
  • Support 42mm, 60mm, 80mm and 110mm drive form factors (2242, 2260, 2280 and 22110)
  • No onboard RAID; RAID functionality is provided by a separate adapter (SATA or NVMe)
  • Either 6Gbps SATA or PCIe 4.0 x4 interface to the drives depending on the drives installed
  • Supports monitoring and reporting of events and temperature through I2C
  • Firmware update via Lenovo firmware update tools

The ThinkSystem M.2 NVMe 2-Bay RAID Enablement Kit (4Y37A09750) has the following features:

  • Supports one or two NVMe M.2 drives
  • Support 42mm, 60mm, 80mm and 110mm drive form factors (2242, 2260, 2280 and 22110)
  • RAID support via an onboard Marvell 88NR2241 NVMe RAID Controller
  • With 1 drive, supports single-drive RAID-0
  • With 2 drives, supports 2-drive RAID-0, 2-drive RAID-1, or two single-drive RAID-0 arrays
  • PCIe 3.0 x2 host interface; PCIe 3.0 x1 connection to each drive
  • Management and configuration support via UEFI and OS-based tools
  • Supports monitoring and reporting of events and temperature through I2C
  • Firmware update via Lenovo firmware update tools

M.2 field upgrades

For field upgrades, the SR655 V3 also requires additional cables necessary to connect the M.2 to either the system board or RAID adapter. Ordering information is listed in the following table.

Table 28. Cable kit for M.2 drive support
Part number Description Purpose
M.2 Cable Kit - cables for use with RAID adapters or with onboard (non-RAID) connectivity
4X97A87726 ThinkSystem SR655 V3 M.2 x4 SATA/NVMe Cable Kit Cable kit for ThinkSystem M.2 SATA/x4 NVMe 2-Bay Enablement Kit (4Y37A79663)
4X97A87559 ThinkSystem SR655 V3 M.2 SATA/NVMe Cable Kit Cable kit for ThinkSystem M.2 SATA/NVMe 2-Bay Enablement Kit (4Y37A09738) or ThinkSystem M.2 NVMe 2-Bay RAID Enablement Kit (4Y37A09750)
RAID adapters for M.2 RAID support (4Y37A79663 only)
4Y37A72482 ThinkSystem RAID 5350-8i PCIe 12Gb Adapter (SATA M.2 support) RAID adapter to provide M.2 SATA RAID support
4Y37A78834 ThinkSystem RAID 540-8i PCIe Gen4 12Gb Adapter (NVMe M.2 support using Tri-Mode)

RAID adapter to provide M.2 NVMe support using Tri-Mode

Tip: Once the 540-8i adapter is installed, it will need to be configured to operate in Tri-mode to enable NVMe RAID.

SED encryption key management with ISKLM

The server supports self-encrypting drives (SEDs) as listed in the Internal drive options section. To effectively manage a large deployment of these drives in Lenovo servers, IBM Security Key Lifecycle Manager (SKLM) offers a centralized key management solution. A Lenovo Feature on Demand (FoD) upgrade is used to enable this SKLM support in the management processor of the server.

The following table lists the part numbers and feature codes for the upgrades.

Table 29. FoD upgrades for SKLM support
Part number Feature code Description
Security Key Lifecycle Manager - FoD (United States, Canada, Asia Pacific, and Japan)
00D9998 A5U1 SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 1 year S&S
00D9999 AS6C SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 3 year S&S
Security Key Lifecycle Manager - FoD (Latin America, Europe, Middle East, and Africa)
00FP648 A5U1 SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 1 year S&S
00FP649 AS6C SKLM for System x/ThinkSystem w/SEDs - FoD per Install with 3 year S&S

The IBM Security Key Lifecycle Manager software is available from Lenovo using the ordering information listed in the following table.

Table 30. IBM Security Key Lifecycle Manager licenses
Part number Description
7S0A007FWW IBM Security Key Lifecycle Manager Basic Edition Install License + SW Subscription & Support 12 Months
7S0A007HWW IBM Security Key Lifecycle Manager For Raw Decimal Terabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months
7S0A007KWW IBM Security Key Lifecycle Manager For Raw Decimal Petabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months
7S0A007MWW IBM Security Key Lifecycle Manager For Usable Decimal Terabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months
7S0A007PWW IBM Security Key Lifecycle Manager For Usable Decimal Petabyte Storage Resource Value Unit License + SW Subscription & Support 12 Months

Controllers for internal storage

The SR655 V3 offers a variety of controller options for internal drives:

  • For 2.5-inch and 3.5-inch drives:
    • Onboard SATA ports (feature AVUX)
    • Onboard NVMe ports (feature BC4V)
    • NVMe switch and retimer adapters (PCIe slot-based)
    • RAID adapters and HBAs for SAS/SATA drives (PCIe slot-based)
    • RAID adapters, SAS Expander, and HBAs for SAS/SATA drives (cabled in a dedicated space)
  • For 7mm drive bays in the rear of the server (see the 7mm drives section)
    • SATA controller integrated into the 7mm drive bay enclosure
    • NVMe controller integrated into the 7mm drive bay enclosure
  • For M.2 drives internal to the server (see M.2 drives section)
    • SATA controller integrated on the M.2 SATA 2-Bay RAID Enablement Kit
    • NVMe controller integrated on the M.2 NVMe 2-Bay RAID Enablement Kit

As well as supporting RAID adapters and HBAs that install in a PCIe slot, the SR655 V3 with 2.5-inch front drive bays supports a custom form factor (CFF) adapter that is mounted in the server and cabled to one of the onboard NVMe ports. These Internal Adapters are not supported with 3.5-inch front drives due to a lack of physical space.

The following table lists the adapters used for the internal storage of the server.

Table 31. Internal Storage adapter support
Part
number
Feature
code
Description Power module
(supercap)
PCIe
lanes
Max
qty
Slots
supported
Windows 10/11
support
Onboard controllers
CTO only AVUX Onboard SATA AHCI Mode No   1 N/A Supported
CTO only BC4V Non RAID NVMe (Onboard NVMe) No   1 N/A Supported
SAS HBA - PCIe Gen 3
4Y37A72480 BJHH ThinkSystem 4350-8i SAS/SATA 12Gb HBA No Gen3 x8 4 1 - 6 No
4Y37A72481 BJHJ ThinkSystem 4350-16i SAS/SATA 12Gb HBA No Gen3 x8 2 1 - 6 No
SAS HBA - PCIe Gen 4
4Y37A78601 BM51 ThinkSystem 440-8i SAS/SATA PCIe Gen4 12Gb HBA No Gen4 x8 4 1 - 6 No
4Y37A78602 BM50 ThinkSystem 440-16i SAS/SATA PCIe Gen4 12Gb HBA No Gen4 x8 2 1 - 6 No
4Y37A09725 B8P1 ThinkSystem 440-16i SAS/SATA PCIe Gen4 12Gb Internal HBA No Gen4 x8 1 Cabled No
NVMe adapters - PCIe Gen 4
4C57A65446 B98C ThinkSystem 4-Port PCIe Gen4 NVMe Retimer Adapter No Gen4 x16 3 1,3,2,4 Supported
4Y37A09737 B8P5 ThinkSystem 1611-8P PCIe Gen4 Switch Adapter No Gen4 x16 2 4,5 Supported
CTO only BGM1 ThinkSystem RAID 940-8i 4GB Flash PCIe Gen4 12Gb Adapter for U.3 No Gen4 x8 3 1 - 6 Supported
CTO only BM36 ThinkSystem RAID 940-16i 4GB Flash PCIe Gen4 12Gb Adapter for U.3 No Gen4 x8 1 1 - 6 Supported
CTO only BDY4 ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Adapter for U.3 No Gen4 x8 1 1 - 6 Supported
RAID controllers - PCIe Gen 3
4Y37A72482 BJHK ThinkSystem RAID 5350-8i PCIe 12Gb Adapter No Gen3 x8 4 1 - 6 Supported
4Y37A84028 BRQV ThinkSystem RAID 5350-8i PCIe 12Gb Internal Adapter No Gen3 x8 1 Cabled Supported
4Y37A72483 BJHL ThinkSystem RAID 9350-8i 2GB Flash PCIe 12Gb Adapter Included Gen3 x8 4 1 - 6 Supported
4Y37A72484 BJHM ThinkSystem RAID 9350-8i 2GB Flash PCIe 12Gb Internal Adapter Included Gen3 x8 1 Cabled Supported
4Y37A72485 BJHN ThinkSystem RAID 9350-16i 4GB Flash PCIe 12Gb Adapter Included Gen3 x8 2 1 - 6 Supported
4Y37A72486 BJHP ThinkSystem RAID 9350-16i 4GB Flash PCIe 12Gb Internal Adapter Included Gen3 x8 1 Cabled Supported
RAID controllers - PCIe Gen 4
4Y37A78834 BMFT ThinkSystem RAID 540-8i PCIe Gen4 12Gb Adapter No Gen4 x8 4 1 - 6 Supported
4Y37A78835 BNAX ThinkSystem RAID 540-16i PCIe Gen4 12Gb Adapter No Gen4 x8 2 1 - 6 Supported
4Y37A09728 B8NY ThinkSystem RAID 940-8i 4GB Flash PCIe Gen4 12Gb Adapter Included Gen4 x8 4 1 - 6 Supported
4Y37A78600 BM35 ThinkSystem RAID 940-16i 4GB Flash PCIe Gen4 12Gb Adapter Included Gen4 x8 2 1 - 6 Supported
4Y37A09730 B8NZ ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Adapter Included Gen4 x8 2 1 - 6 Supported
4Y37A09735 B8P0 ThinkSystem RAID 940-16i 8GB Flash PCIe Gen4 12Gb Internal Adapter Included Gen4 x8 1 Cabled Supported
4Y37A09733 B8P8 ThinkSystem RAID 940-32i 8GB Flash PCIe Gen4 12Gb Adapter Included Gen4 x8 1 1 - 6 Supported
SAS expanders
4Y37A09736 B8P6 ThinkSystem 48 port 12Gb Internal Expander No Gen4 x8 1 Cabled Supported

‡ These custom form factor (CFF) adapters are only supported with 2.5-inch front drive bays. Not supported in configurations with 3.5-inch front drive bays.
† Adapter also supports PCIe 4.0 x1 connectivity to NVMe drives (requires NVMe drives with U.3 interface)

Configuration notes:

  • Supercap support limits the number of RAID adapters installable: The table lists whether the adapter includes a power module (supercap) to power the flash memory. The server supports between 1 and 4 supercaps depending on the server configuration as described in the RAID flash power module (supercap) support section. The number of supercaps supported also determines the maximum number of RAID adapters with flash that can be installed in the server.
  • Field upgrades: If you are adding a RAID adapter with supercap to the server as a field upgrade, you may need a supercap holder as described in the RAID flash power module (supercap) support section.
  • 7mm drive support: The storage adapters listed in the table below do not provide connectivity to the 7mm drive bays. The 7mm drives have their own independent RAID controller. See the 7mm drives section for details.
  • E810 Ethernet and X350 RAID/HBAs: The use of both an Intel E810 network adapter and an X350 HBA/RAID adapter (9350, 5350 and 4350) is currently not supported in ThinkSystem servers. For details see Support Tip HT513226. Planned support for this combination of adapters is 4Q/2023 (SI 23-2).

The RAID 940-8i and RAID 940-16i adapters also support NVMe through a feature named Tri-Mode support (or Trimode support). This feature enables the use of NVMe U.3 drives at the same time as SAS and SATA drives. Cabling of the controller to the backplanes is the same as with SAS/SATA drives, and the NVMe drives are connected via a PCIe x1 link to the controller.

NVMe drives connected using Tri-Mode support provide better performance than SAS or SATA drives: A SATA SSD has a data rate of 6Gbps, a SAS SSD has a data rate of 12Gbps, whereas an NVMe U.3 Gen 4 SSD with a PCIe x1 link will have a data rate of 16Gbps. NVMe drives typically also have lower latency and higher IOPS compared to SAS and SATA drives. Tri-Mode is supported with U.3 NVMe drives in either 2.5-inch and 3.5-inch form factor and requires an AnyBay backplane.

Tri-Mode requires U.3 drives: Only NVMe drives with a U.3 interface are supported. U.2 drives are not supported. See the Internal drive options section for the U.3 drives supported by the server.

The onboard SATA controller has the following features:

  • Controller integrated into the AMD processor
  • JBOD only; no RAID support
  • Supports up to 16 SATA drives in the SR655 V3
  • Supports HDDs and SSDs; can be mixed

The onboard NVMe support has the following features:

  • Controller integrated into the AMD processor
  • Supports up to 12 NVMe drives direct connected to onboard ports; additional drives through retimer/switch adapters
  • Each drive has PCIe 5.0 x4 host interface
  • Supports JBOD
  • No support for RAID

For specifications about the RAID adapters and HBAs supported by the SR655 V3, see the ThinkSystem RAID Adapter and HBA Reference, available from:
https://lenovopress.lenovo.com/lp1288-thinksystem-raid-adapter-and-hba-reference#sr655-v3-support=SR655%2520V3

For more information about each of the adapters, see the product guides in the RAID adapters or HBA sections of the Lenovo Press web site:
https://lenovopress.com/servers/options/raid
https://lenovopress.com/servers/options/hba

Internal drive options

The following tables list the drive options for internal storage of the server.

M.2 drive support: The use of M.2 drives requires an additional adapter as described in the M.2 drives subsection.

SED support: The tables include a column to indicate which drives support SED encryption. The encryption functionality can be disabled if needed. Note: Not all SED-enabled drives have "SED" in the description.

Table 32. 2.5-inch hot-swap 12 Gb SAS HDDs
Part number Feature
code
Description SED
support
Max
Qty
2.5-inch hot-swap HDDs - 12 Gb SAS 15K
7XB7A00021 AULV ThinkSystem 2.5" 300GB 15K SAS 12Gb Hot Swap 512n HDD No 40
7XB7A00022 AULW ThinkSystem 2.5" 600GB 15K SAS 12Gb Hot Swap 512n HDD No 40
7XB7A00023 AULX ThinkSystem 2.5" 900GB 15K SAS 12Gb Hot Swap 512e HDD No 40
2.5-inch hot-swap HDDs - 12 Gb SAS 10K
7XB7A00025 AULZ ThinkSystem 2.5" 600GB 10K SAS 12Gb Hot Swap 512n HDD No 40
7XB7A00027 AUM1 ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD No 40
7XB7A00028 AUM2 ThinkSystem 2.5" 1.8TB 10K SAS 12Gb Hot Swap 512e HDD No 40
4XB7A83970 BRG7 ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD v2 No 40
2.5-inch hot-swap SED HDDs - 12 Gb SAS 10K
7XB7A00031 AUM5 ThinkSystem 2.5" 600GB 10K SAS 12Gb Hot Swap 512n HDD SED Support 40
7XB7A00033 B0YX ThinkSystem 2.5" 1.2TB 10K SAS 12Gb Hot Swap 512n HDD SED Support 40
4XB7A84038 BRG8 ThinkSystem 2.5" 2.4TB 10K SAS 12Gb Hot Swap 512e HDD FIPS v2 Support 40
Table 33. 2.5-inch hot-swap 24 Gb SAS SSDs
Part number Feature
code
Description SED
support
Max
Qty
2.5-inch hot-swap SSDs - 24 Gb SAS - Mixed Use/Mainstream (3-5 DWPD)
4XB7A80340 BNW8 ThinkSystem 2.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD Support 40
4XB7A80341 BNW9 ThinkSystem 2.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD Support 40
4XB7A80342 BNW6 ThinkSystem 2.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD Support 40
4XB7A80343 BP3K ThinkSystem 2.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD Support 40
2.5-inch hot-swap SSDs - 24 Gb SAS - Read Intensive/Entry/Capacity (<3 DWPD)
4XB7A80318 BNWC ThinkSystem 2.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD Support 40
4XB7A80319 BNWE ThinkSystem 2.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD Support 40
4XB7A80320 BNWF ThinkSystem 2.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD Support 40
4XB7A80321 BP3E ThinkSystem 2.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD Support 40
4XB7A80322 BP3J ThinkSystem 2.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD Support 40
4XB7A80323 BP3D ThinkSystem 2.5" PM1653 30.72TB Read Intensive SAS 24Gb HS SSD Support 40
Table 34. 2.5-inch hot-swap 12 Gb SAS SSDs
Part number Feature
code
Description SED
support
Max
Qty
2.5-inch hot-swap SSDs - 12 Gb SAS - Write Intensive/Performance (10+ DWPD)
4XB7A70006 BG07 ThinkSystem 2.5" Nytro 3732 400GB Performance SAS 12Gb Hot Swap SSD No 40
4XB7A70005 BG06 ThinkSystem 2.5" Nytro 3732 800GB Performance SAS 12Gb Hot Swap SSD No 40
4XB7A70004 BG05 ThinkSystem 2.5" Nytro 3732 1.6TB Performance SAS 12Gb Hot Swap SSD No 40
4XB7A70003 BG04 ThinkSystem 2.5" Nytro 3732 3.2TB Performance SAS 12Gb Hot Swap SSD No 40
Table 35. 2.5-inch hot-swap 6 Gb SATA SSDs
Part number Feature
code
Description SED
support
Max
Qty
2.5-inch hot-swap SSDs - 6 Gb SATA - Mixed Use/Mainstream (3-5 DWPD)
4XB7A82289 BQ21 ThinkSystem 2.5" 5400 MAX 480GB Mixed Use SATA 6Gb HS SSD Support 40
4XB7A82290 BQ24 ThinkSystem 2.5" 5400 MAX 960GB Mixed Use SATA 6Gb HS SSD Support 40
4XB7A82291 BQ22 ThinkSystem 2.5" 5400 MAX 1.92TB Mixed Use SATA 6Gb HS SSD Support 40
4XB7A82292 BQ23 ThinkSystem 2.5" 5400 MAX 3.84TB Mixed Use SATA 6Gb HS SSD Support 40
4XB7A17125 BA7Q ThinkSystem 2.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 40
4XB7A17126 BA4T ThinkSystem 2.5" S4620 960GB Mixed Use SATA 6Gb HS SSD No 40
4XB7A17127 BA4U ThinkSystem 2.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD No 40
4XB7A17128 BK7L ThinkSystem 2.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD No 40
2.5-inch hot-swap SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD)
4XB7A82258 BQ1Q ThinkSystem 2.5" 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD Support 40
4XB7A82259 BQ1P ThinkSystem 2.5" 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD Support 40
4XB7A82260 BQ1R ThinkSystem 2.5" 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD Support 40
4XB7A82261 BQ1X ThinkSystem 2.5" 5400 PRO 1.92TB Read Intensive SATA 6Gb HS SSD Support 40
4XB7A82262 BQ1S ThinkSystem 2.5" 5400 PRO 3.84TB Read Intensive SATA 6Gb HS SSD Support 40
4XB7A82263 BQ1T ThinkSystem 2.5" 5400 PRO 7.68TB Read Intensive SATA 6Gb HS SSD Support 40
4XB7A72438 BM8B ThinkSystem 2.5" PM893 480GB Read Intensive SATA 6Gb HS SSD No 40
4XB7A72439 BM8A ThinkSystem 2.5" PM893 960GB Read Intensive SATA 6Gb HS SSD No 40
4XB7A72440 BM89 ThinkSystem 2.5" PM893 1.92TB Read Intensive SATA 6Gb HS SSD No 40
4XB7A72441 BM88 ThinkSystem 2.5" PM893 3.84TB Read Intensive SATA 6Gb HS SSD No 40
4XB7A72442 BM87 ThinkSystem 2.5" PM893 7.68TB Read Intensive SATA 6Gb HS SSD No 40
4XB7A17072 B99D ThinkSystem 2.5" S4520 240GB Read Intensive SATA 6Gb HS SSD No 40
4XB7A17101 BA7G ThinkSystem 2.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No 40
4XB7A17102 BA7H ThinkSystem 2.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No 40
4XB7A17103 BA7J ThinkSystem 2.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No 40
4XB7A17104 BK77 ThinkSystem 2.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No 40
4XB7A17105 BK78 ThinkSystem 2.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No 40
Table 36. 2.5-inch hot-swap PCIe 4.0 NVMe SSDs
Part number Feature
code
Description SED
support
Max
Qty
2.5-inch SSDs - U.2 PCIe 4.0 NVMe - Write Intensive/Performance (10+ DWPD)
4XB7A17158 BKKY ThinkSystem 2.5" U.2 P5800X 400GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 32
4XB7A17159 BKKZ ThinkSystem 2.5" U.2 P5800X 800GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 32
4XB7A17160 BMM8 ThinkSystem 2.5" U.2 P5800X 1.6TB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 32
2.5-inch SSDs - U.2 PCIe 4.0 NVMe - Mixed Use/Mainstream (3-5 DWPD)
4XB7A17129 BNEG ThinkSystem 2.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A17130 BNEH ThinkSystem 2.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A17133 BNEZ ThinkSystem 2.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A17136 BA4V ThinkSystem 2.5" U.2 P5620 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
2.5-inch SSDs - U.3 PCIe 4.0 NVMe - Mixed Use/Mainstream (3-5 DWPD)
4XB7A79639 BNF1 ThinkSystem 2.5" U.3 7450 MAX 800GB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A13967 BNEJ ThinkSystem 2.5" U.3 7450 MAX 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A13970 BNEY ThinkSystem 2.5" U.3 7450 MAX 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A13971 BNEL ThinkSystem 2.5" U.3 7450 MAX 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 32
2.5-inch SSDs - U.2 PCIe 4.0 NVMe - Read Intensive/Entry (<3 DWPD)
4XB7A13941 BMGD ThinkSystem 2.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A13942 BMGE ThinkSystem 2.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A13943 BNEF ThinkSystem 2.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A13631 BNEQ ThinkSystem 2.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
2.5-inch SSDs - U.3 PCIe 4.0 NVMe - Read Intensive/Entry (<3 DWPD)
4XB7A79646 BNF3 ThinkSystem 2.5" U.3 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A79647 BNF2 ThinkSystem 2.5" U.3 7450 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A79648 BNF5 ThinkSystem 2.5" U.3 7450 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32
4XB7A79649 BNF4 ThinkSystem 2.5" U.3 7450 PRO 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 32

Note: NVMe PCIe SSDs support surprise hot removal and hot insertion, provided the operating system supports PCIe SSD hot-swap.

Table 37. 7mm 2.5-inch hot-swap 6 Gb SATA SSDs
Part number Feature
code
Description SED
support
Max
Qty
7mm 2.5-inch hot-swap SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD)
4XB7A82264 BQ1U ThinkSystem 7mm 5400 PRO 240GB Read Intensive SATA 6Gb HS SSD Support 2
4XB7A82265 BQ1V ThinkSystem 7mm 5400 PRO 480GB Read Intensive SATA 6Gb HS SSD Support 2
4XB7A82266 BQ1W ThinkSystem 7mm 5400 PRO 960GB Read Intensive SATA 6Gb HS SSD Support 2
4XB7A17106 BK79 ThinkSystem 7mm S4520 240GB Read Intensive SATA 6Gb HS SSD No 2
4XB7A17107 BK7A ThinkSystem 7mm S4520 480GB Read Intensive SATA 6Gb HS SSD No 2
4XB7A17108 BK7B ThinkSystem 7mm S4520 960GB Read Intensive SATA 6Gb HS SSD No 2
Table 38. 7mm 2.5-inch hot-swap PCIe 4.0 NVMe SSDs
Part number Feature
code
Description SED
support
Max
Qty
7mm 2.5-inch hot-swap SSDs - PCIe 4.0 NVMe - Read Intensive/Entry (<3 DWPD)
4XB7A82853 BPZ4 ThinkSystem 7mm U.3 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 2
4XB7A82855 BPZ5 ThinkSystem 7mm U.3 7450 PRO 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 2
4XB7A82856 BPZ6 ThinkSystem 7mm U.3 7450 PRO 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 2

Note: NVMe PCIe SSDs support surprise hot removal and hot insertion, provided the operating system supports PCIe SSD hot-swap.

Table 39. 3.5-inch hot-swap 12 Gb SAS HDDs
Part number Feature
code
Description SED
support
Max
Qty
3.5-inch hot-swap HDDs - 12 Gb NL SAS
7XB7A00042 AUU5 ThinkSystem 3.5" 2TB 7.2K SAS 12Gb Hot Swap 512n HDD No 20
7XB7A00043 AUU6 ThinkSystem 3.5" 4TB 7.2K SAS 12Gb Hot Swap 512n HDD No 20
7XB7A00044 AUU7 ThinkSystem 3.5" 6TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
7XB7A00045 B0YR ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
7XB7A00046 AUUG ThinkSystem 3.5" 10TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
7XB7A00067 B117 ThinkSystem 3.5" 12TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
4XB7A13906 B496 ThinkSystem 3.5" 14TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
4XB7A13911 B7EZ ThinkSystem 3.5" 16TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
4XB7A38266 BCFP ThinkSystem 3.5" 18TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
4XB7A80353 BPKU ThinkSystem 3.5" 20TB 7.2K SAS 12Gb Hot Swap 512e HDD No 20
3.5-inch hot-swap SED HDDs - 12 Gb NL SAS
7XB7A00066 B0YQ ThinkSystem 3.5" 8TB 7.2K SAS 12Gb Hot Swap 512e HDD FIPS Support 20
Table 40. 3.5-inch hot-swap 6 Gb SATA HDDs
Part number Feature
code
Description SED
support
Max
Qty
3.5-inch hot-swap HDDs - 6 Gb NL SATA
7XB7A00049 AUUF ThinkSystem 3.5" 1TB 7.2K SATA 6Gb Hot Swap 512n HDD No 20
7XB7A00050 AUUD ThinkSystem 3.5" 2TB 7.2K SATA 6Gb Hot Swap 512n HDD No 20
7XB7A00051 AUU8 ThinkSystem 3.5" 4TB 7.2K SATA 6Gb Hot Swap 512n HDD No 20
7XB7A00052 AUUA ThinkSystem 3.5" 6TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
7XB7A00053 AUU9 ThinkSystem 3.5" 8TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
7XB7A00054 AUUB ThinkSystem 3.5" 10TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
7XB7A00068 B118 ThinkSystem 3.5" 12TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
4XB7A13907 B497 ThinkSystem 3.5" 14TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
4XB7A13914 B7F0 ThinkSystem 3.5" 16TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
4XB7A38130 BCFH ThinkSystem 3.5" 18TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
4XB7A80354 BPKV ThinkSystem 3.5" 20TB 7.2K SATA 6Gb Hot Swap 512e HDD No 20
Table 41. 3.5-inch hot-swap 24 Gb SAS SSDs
Part number Feature
code
Description SED
support
Max
Qty
3.5-inch hot-swap SSDs - 24 Gb SAS - Mixed Use/Mainstream (3-5 DWPD)
4XB7A80344 BNW7 ThinkSystem 3.5" PM1655 800GB Mixed Use SAS 24Gb HS SSD Support 20
4XB7A80345 BNWA ThinkSystem 3.5" PM1655 1.6TB Mixed Use SAS 24Gb HS SSD Support 20
4XB7A80346 BNWB ThinkSystem 3.5" PM1655 3.2TB Mixed Use SAS 24Gb HS SSD Support 20
4XB7A80347 BP3G ThinkSystem 3.5" PM1655 6.4TB Mixed Use SAS 24Gb HS SSD Support 20
3.5-inch hot-swap SSDs - 24 Gb SAS - Read Intensive/Entry/Capacity (<3 DWPD)
4XB7A80324 BNWD ThinkSystem 3.5" PM1653 960GB Read Intensive SAS 24Gb HS SSD Support 20
4XB7A80325 BNWG ThinkSystem 3.5" PM1653 1.92TB Read Intensive SAS 24Gb HS SSD Support 20
4XB7A80326 BNWH ThinkSystem 3.5" PM1653 3.84TB Read Intensive SAS 24Gb HS SSD Support 20
4XB7A80327 BP3F ThinkSystem 3.5" PM1653 7.68TB Read Intensive SAS 24Gb HS SSD Support 20
4XB7A80328 BP3H ThinkSystem 3.5" PM1653 15.36TB Read Intensive SAS 24Gb HS SSD Support 20
Table 42. 3.5-inch hot-swap 12 Gb SAS SSDs
Part number Feature
code
Description SED
support
Max
Qty
3.5-inch hot-swap SSDs - 12 Gb SAS - Write Intensive/Performance (10+ DWPD)
4XB7A70011 BG03 ThinkSystem 3.5" Nytro 3732 400GB Performance SAS 12Gb Hot Swap SSD No 20
4XB7A70010 BG02 ThinkSystem 3.5" Nytro 3732 800GB Performance SAS 12Gb Hot Swap SSD No 20
4XB7A70009 BG01 ThinkSystem 3.5" Nytro 3732 1.6TB Performance SAS 12Gb Hot Swap SSD No 20
4XB7A70008 BG00 ThinkSystem 3.5" Nytro 3732 3.2TB Performance SAS 12Gb Hot Swap SSD No 20
Table 43. 3.5-inch hot-swap 6 Gb SATA SSDs
Part number Feature
code
Description SED
support
Max
Qty
3.5-inch hot-swap SSDs - 6 Gb SATA - Mixed Use/Mainstream (3-5 DWPD)
4XB7A17137 BA4W ThinkSystem 3.5" S4620 480GB Mixed Use SATA 6Gb HS SSD No 20
4XB7A17138 BA4X ThinkSystem 3.5" S4620 960GB Mixed Use SATA 6Gb HS SSD No 20
4XB7A17139 BA4Y ThinkSystem 3.5" S4620 1.92TB Mixed Use SATA 6Gb HS SSD No 20
4XB7A17140 BK7P ThinkSystem 3.5" S4620 3.84TB Mixed Use SATA 6Gb HS SSD No 20
3.5-inch hot-swap SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD)
4XB7A17118 BA7K ThinkSystem 3.5" S4520 240GB Read Intensive SATA 6Gb HS SSD No 20
4XB7A17119 BA7L ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb HS SSD No 20
4XB7A17120 BA7M ThinkSystem 3.5" S4520 960GB Read Intensive SATA 6Gb HS SSD No 20
4XB7A17121 BA7N ThinkSystem 3.5" S4520 1.92TB Read Intensive SATA 6Gb HS SSD No 20
4XB7A17122 BK7F ThinkSystem 3.5" S4520 3.84TB Read Intensive SATA 6Gb HS SSD No 20
4XB7A17123 BK7G ThinkSystem 3.5" S4520 7.68TB Read Intensive SATA 6Gb HS SSD No 20
Table 44. 3.5-inch hot-swap PCIe 4.0 NVMe SSDs
Part number Feature
code
Description SED
support
Max
Qty
3.5-inch SSDs - U.2 PCIe 4.0 NVMe - Write Intensive/Performance (10+ DWPD)
4XB7A17161 BMM7 ThinkSystem 3.5" U.2 P5800X 400GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12
4XB7A17162 BMM5 ThinkSystem 3.5" U.2 P5800X 800GB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12
4XB7A77070 BMM6 ThinkSystem 3.5" U.2 P5800X 1.6TB Write Intensive NVMe PCIe 4.0 x4 HS SSD No 12
3.5-inch SSDs - U.2 PCIe 4.0 NVMe - Mixed Use/Mainstream (3-5 DWPD)
4XB7A17141 BNEK ThinkSystem 3.5" U.2 P5620 1.6TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 12
4XB7A17143 BNEM ThinkSystem 3.5" U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 12
4XB7A17144 BNEN ThinkSystem 3.5" U.2 P5620 6.4TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 12
4XB7A17148 BNEP ThinkSystem 3.5" U.2 P5620 12.8TB Mixed Use NVMe PCIe 4.0 x4 HS SSD Support 12
3.5-inch SSDs - U.2 PCIe 4.0 NVMe - Read Intensive/Entry (<3 DWPD)
4XB7A13632 BNES ThinkSystem 3.5" U.2 P5520 1.92TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 12
4XB7A76777 BNET ThinkSystem 3.5" U.2 P5520 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 12
4XB7A76778 BNEU ThinkSystem 3.5" U.2 P5520 7.68TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 12
4XB7A76779 BNF0 ThinkSystem 3.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD Support 12

Note: NVMe PCIe SSDs support surprise hot removal and hot insertion, provided the operating system supports PCIe SSD hot-swap.

Table 45. M.2 SATA drives
Part number Feature
code
Description SED
support
Max
Qty
M.2 SSDs - 6 Gb SATA - Read Intensive/Entry (<3 DWPD)
4XB7A82286 BQ1Z ThinkSystem M.2 5400 PRO 240GB Read Intensive SATA 6Gb NHS SSD Support 2
4XB7A82287 BQ1Y ThinkSystem M.2 5400 PRO 480GB Read Intensive SATA 6Gb NHS SSD Support 2
4XB7A82288 BQ20 ThinkSystem M.2 5400 PRO 960GB Read Intensive SATA 6Gb NHS SSD Support 2
7N47A00130 AUUV ThinkSystem M.2 128GB SATA 6Gbps Non-Hot Swap SSD No 2
Table 46. M.2 PCIe 4.0 NVMe drives
Part number Feature
code
Description SED
support
Max
Qty
M.2 SSDs - PCIe 4.0 NVMe - Read Intensive/Entry (<3 DWPD)
4XB7A13999 BKSR ThinkSystem M.2 7450 PRO 960GB Read Intensive NVMe PCIe 4.0 x4 NHS SSD Support 2

USB memory key

For general portable storage needs, the server also supports the USB memory key option that is listed in the following table.

Table 47. USB memory key
Part number Feature Description
4X77A77065 BNWN ThinkSystem USB 32GB USB 3.0 Flash Drive

Internal backup units

The server does not supports any internal backup units, such as tape drives or RDX drives. External backup units are available as described in the External backup units section.

Optical drives

The server supports the external USB optical drive listed in the following table.

Table 48. External optical drive
Part number Feature code Description
7XA7A05926 AVV8 ThinkSystem External USB DVD RW Optical Disk Drive

The drive is based on the Lenovo Slim DVD Burner DB65 drive and supports the following formats: DVD-RAM, DVD-RW, DVD+RW, DVD+R, DVD-R, DVD-ROM, DVD-R DL, CD-RW, CD-R, CD-ROM.

I/O expansion

The server supports up to 10x total PCIe slots, plus a slot dedicated to the OCP adapter (rear or front). The 10x slots are either 10x rear-facing slots, or a combination of 6x rear + 2x front PCIe slots.

The server also offers a dedicated OCP 3.0 SFF slot for networking, located either at the rear or front of the server. Slot availability is based on riser selection.

Topics in this section:

Slot layout and connections

The slots at the rear are provided by riser cards as follows:

  • Riser 1: Slots 1, 2 and 3, all full-height slots
  • Riser 2: Slots 4, 5, and 6, all full-height slots
  • Riser 3: Slot 7 and 8
    • Without Riser 4: both full-height slots
    • With Riser 4: both low-profile slots
  • Riser 4: Slots 9 and 10, both low-profile slots

The slots in each riser are either PCIe x16 or PCIe x8 depending on the riser card selected as listed in the table below. All x8 slots are open-ended and physically support x16 adapters. Depending on the risers selected, slots are either PCIe 5.0 or PCIe 4.0. OCP slot is PCIe 4.0 x16.

The SR655 V3 also supports front-accessible PCIe slots: 2x PCIe 4.0 x16 slots plus a dedicated OCP 3.0 SFF slot (PCIe 4.0 x16) for networking. When front slots are used, rear slots 7-10 (Riser 3 & Riser 4) are not available as they use the same connectors. Front-accessible slots are as follows:

  • Slot 11: PCIe 4.0 x16 FHHL
  • Slot 12: PCIe 4.0 x16 FHHL

Onboard NVMe support: When Riser 3 (or Riser 3+4) is configured, only 4 NVMe drives can be connected using onboard NVMe connectors.

As discussed in the Internal storage section, the server supports drive bays in the rear of the server. Depending on the drive bays selected, the number of slots available for adapters is reduced. The figure below shows the supported combinations of slots and drive bays.

Internal HBA/RAID adapter: For configurations with 2.5-inch front drive bays, an internal RAID adapter or HBA can be installed in a dedicated space and cabled to a PCIe x8 connector, thereby freeing up a slot for other purposes.

The following figure shows the locations of the rear-accessible slots for each configuration selection. The OCP slot in located in the lower-left corner.

SR655 V3 slots
Figure 14. SR655 V3 rear slot configurations

The following figure shows the locations of the front-accessible slots.

SR655 V3 front slots
Figure 15. SR655 V3 front slots

Ordering information

The following table lists the riser cards available for CTO builds and for field upgrades.

No slots: It is also possible to build a configuration without any slots, in which case slot fillers will be derived in the configurator. Slots can be added later as field upgrades using option part numbers as listed in the table.

Table 49. Riser cards
Part
number
Feature
code
Description Slot configuration*
(Green = Gen5, Blue = Gen4)
Purpose
Rear Riser 1 (FH slots) Slot 1 Slot 2 Slot 3
4XH7A82898 BPQU ThinkSystem V3 2U x16/x8/x8 PCIe Gen5 Riser 1 or 2 Gen5 x16 Gen5 x8 Gen5 x8   3 slots PCIe 5.0
4XH7A82896 BLKL ThinkSystem V3 2U x16/x8/x8 PCIe Gen4 Riser1 or 2 Gen4 x16 Gen4 x8 Gen4 x8   3 slots PCIe 4.0
4XH7A82900 BPQV ThinkSystem V3 2U x16/x16/E PCIe Gen5 Riser1 or 2 Gen5 x16 Gen5 x16 No slot   2 slots PCIe 5.0; COM port or 7mm drives in slot 3
4XH7A82892 BLKM ThinkSystem V3 2U x16/x16/E PCIe Gen4 Riser1 or 2 Gen4 x16 Gen4 x16 No slot   2 slots PCIe 4.0; COM port or 7mm drives in slot 3
4XH7A82902 BPQW ThinkSystem V3 2U E/x16/x16 PCIe Gen5 Riser1 or 2 No slot Gen5 x16 Gen4 x16   PCIe 5.0 in slot 2; DW GPU in slot 2
4XH7A82894 BLKN ThinkSystem V3 2U G4 E/x16/x16 PCIe Riser1 or 2 No slot Gen4 x16 Gen4 x16   2 slots PCIe 4.0; DW GPU in slot 2
4XH7A82890 BLKP ThinkSystem V3 2U x16 PCIe Gen4 Riser1 or 2 No slot No slot Gen4 x16   1 slot PCIe 4.0; For 4x 3.5-inch rear drives
Rear Riser 2 (FH slots) Slot 4 Slot 5 Slot 6
4XH7A82898 BPQU ThinkSystem V3 2U x16/x8/x8 PCIe Gen5 Riser 1 or 2 Gen5 x16 Gen5 x8 Gen5 x8   3 slots PCIe 5.0
4XH7A82896 BLKL ThinkSystem V3 2U x16/x8/x8 PCIe Gen4 Riser1 or 2 Gen4 x16 Gen4 x8 Gen4 x8   3 slots PCIe 4.0
4XH7A82900 BPQV ThinkSystem V3 2U x16/x16/E PCIe Gen5 Riser1 or 2 Gen5 x16 Gen5 x16 No slot   2 slots PCIe 5.0; COM port or 7mm drives in slot 6
4XH7A82892 BLKM ThinkSystem V3 2U x16/x16/E PCIe Gen4 Riser1 or 2 Gen4 x16 Gen4 x16 No slot   2 slots PCIe 4.0; COM port or 7mm drives in slot 6
4XH7A82902 BPQW ThinkSystem V3 2U E/x16/x16 PCIe Gen5 Riser1 or 2 No slot Gen5 x16 Gen4 x16   PCIe 5.0 in slot 5; DW GPU in slot 5
4XH7A82894 BLKN ThinkSystem V3 2U G4 E/x16/x16 PCIe Riser1 or 2 No slot Gen4 x16 Gen4 x16   2 slots PCIe 4.0; DW GPU in slot 5
4XH7A82890 BLKP ThinkSystem V3 2U x16 PCIe Gen4 Riser1 or 2 No slot No slot Gen4 x16   1 slot PCIe 4.0; For 2x or 4x 3.5-inch rear drives
Rear Riser 3 (2x FH slots) Slot 7 Slot 8
4XH7A86399 BLL9 ThinkSystem V3 2U x16/x16 PCIe Gen5 Riser3 Kit Gen5 x16 Gen4 x16     2x PCIe 5.0 x16 slots; DW GPU in slot 7
4XH7A86397 BPKG ThinkSystem V3 2U x16/x16 PCIe Gen4 Riser3 Kit with Cage Gen4 x16 Gen4 x16     2x PCIe 4.0 x16 slots; DW GPU in slot 7
4XH7A86398 BPKH ThinkSystem V3 2U x8/x8 PCIe Gen5 Riser3 Kit with Cage Gen5 x8 Gen4 x8     2x PCIe 5.0 x8 slots
4XH7A86396 BPKF ThinkSystem V3 2U x8/x8 PCIe Gen4 Riser3 Kit with Cage Gen4 x8 Gen4 x8     2x PCIe 4.0 x8 slots
Rear Riser 3 & 4 (4x LP slots) Slot 7 Slot 8 Slot 9 Slot 10

4XH7A87546

BQ2W† ThinkSystem V3 Rear PCIe Gen5 2x8 w/o Retimer HS Riser Gen5 x8 Gen5 x8     2x PCIe 5.0 x8 slots
BTMS† ThinkSystem V3 2U PCIe Gen5 Riser 3/4 Option Kit     Gen5 x8 Gen4 x8 2x PCIe x8 slots (Gen 5, Gen4)
Front Riser Slot 11 Slot 12
CTO only BQ2X + BQB4‡ ThinkSystem V3 2U Front x16/x16 PCIe G4 Riser Gen4 x16 Gen4 x16     2x PCIe 4.0 x16 front-accessible slots

* All PCIe x8 slots are open ended and will physically support x16 adapters
† In the configurator, when feature BQ2W is selected, BTMS is automatically derived and provides slots 9 & 10. 4XH7A87546 contains both risers.
‡ When selecting the front riser BQ2X, you will also need to select feature BQB4 (ThinkSystem V3 2U Front I/O Module in the Others section of the configurator.

Configuration rules:

  • For best performance, install PCIe 5.0 adapters in PCIe 5.0 (Gen5) slots
  • The server only supports one OCP slot, either in the rear of the server or the front of the server, not both
  • Front slots are supported only with rear slots in Riser 1 and 2. Front slots cannot be used in combination with Riser 3 (or Riser 4) as they use the same connectors.
  • If you want to configure 4x low profile slots for slots 7-10, select feature BQ2W which provides riser 3 (slots 7, 8). Feature BTMS will then be automatically derived to provide riser 4 (slots 9 & 10), along with the necessary cables. Option part number 4XH7A87546 contains both of these risers and the cables.
  • If you want to add both a 7mm drive enclosure plus 2x PCIe slots above it, you will need to order the 7mm drive option (either 4XH7A85898 or 4XH7A85899) plus the x16/x16/E riser kit (4XH7A82900 for PCIe Gen 5 or 4XH7A82892 for Gen 4). The riser kit part number provides the 2-slot riser card.
  • All PCIe x8 slots are open ended and will physically support x16 adapters
  • To support Riser 3 (or Riser 3+4), the following must both apply:
    • No rear drives are configured
    • If the Onboard NVMe ports are used, then no more than 4 NVMe or AnyBay drive bays are configured (eg a 3.5-inch backplane of 8x SAS/SATA + 4x AnyBay is supported, or a 2.5-inch backplane of 6x SAS/SATA + 2x AnyBay is supported)
  • In the configurator, when you configure front PCIe slots, you will need to select two separate components:
    • ThinkSystem V3 2U Front x16/x16 PCIe G4 Riser, BQ2X (from the PCIe > Risers tab in DCSC)
    • ThinkSystem V3 2U Front I/O Module, BQB4 (from the Other tab in the Front IO section in DCSC)

Serial port

The SR655 V3 optionally supports a RS-232 serial port by adding a COM port bracket to either slot 3 or slot 6. Ordering information is shown in the following table.

Front PCIe slots: The serial port is not supported in the front PCIe slots

Table 50. Serial port
Part number Feature code Description
4X97A82921 BMNJ ThinkSystem V2/V3 1U COM Port Upgrade Kit

The bracket is shown in the following figure. The option part number includes both Low Profile and Full Height brackets.

ThinkSystem COM Port Upgrade Kit
Figure 16. ThinkSystem COM Port Upgrade Kit v2

Network adapters

The server has a dedicated OCP 3.0 SFF slot with PCIe 4.0 x16 host interface. See Figure 3 for the location of the OCP slot.

The following table lists the supported OCP adapters. One port can optionally be shared with the XCC management processor for Wake-on-LAN and NC-SI support. Only 1 OCP card can be installed in the server, either rear-accessible or front-accessible.

Table 51. Supported OCP adapters
Part
number
Feature
code
Description Maximum
supported
Windows 10/11
support
Gigabit Ethernet
4XC7A08235 B5T1 ThinkSystem Broadcom 5719 1GbE RJ45 4-port OCP Ethernet Adapter 1 Supported
4XC7A08277 B93E ThinkSystem Intel I350 1GbE RJ45 4-port OCP Ethernet Adapter 1 Supported
10 Gb Ethernet - 10GBASE-T
4XC7A08236 B5ST ThinkSystem Broadcom 57416 10GBASE-T 2-port OCP Ethernet Adapter 1 Supported
4XC7A08240 B5T4 ThinkSystem Broadcom 57454 10GBASE-T 4-port OCP Ethernet Adapter 1 Supported
4XC7A08278 BCD5 ThinkSystem Intel X710-T2L 10GBASE-T 2-port OCP Ethernet Adapter 1 Supported
4XC7A80268 BPPY ThinkSystem Intel X710-T4L 10GBase-T 4-Port OCP Ethernet Adapter 1 Supported
25 Gb Ethernet
4XC7A08237 BN2T ThinkSystem Broadcom 57414 10/25GbE SFP28 2-port OCP Ethernet Adapter 1 Supported
4XC7A80567 BPPW ThinkSystem Broadcom 57504 10/25GbE SFP28 4-Port OCP Ethernet Adapter 1 Supported
4XC7A08294 BCD4 ThinkSystem Intel E810-DA2 10/25GbE SFP28 2-Port OCP Ethernet Adapter 1 Supported
4XC7A80269 BP8L ThinkSystem Intel E810-DA4 10/25GbE SFP28 4-Port OCP Ethernet Adapter 1 Supported
4XC7A62582 BE4T ThinkSystem Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-Port OCP Ethernet Adapter 1 Supported
100 Gb Ethernet
4XC7A08243 BPPX ThinkSystem Broadcom 57508 100GbE QSFP56 2-Port OCP Ethernet Adapter 1 Supported

Configuration rules:

  • The ThinkSystem Broadcom 5719 1GbE RJ45 4-port OCP Ethernet Adapter (4XC7A08235, B5T1) is currently not supported with the following CPUs. The incompatibility is planned to be resolved in a future update to XCC firmware in December 2023.
    • ThinkSystem AMD EPYC 9124 16C 200W 3.0GHz Processor
    • ThinkSystem AMD EPYC 9224 24C 200W 2.5GHz Processor
    • ThinkSystem AMD EPYC 9254 24C 200W 2.9GHz Processor
    • ThinkSystem AMD EPYC 9334 32C 210W 2.7GHz Processor

The following table lists additional supported network adapters that can be installed in the regular PCIe slots.

Table 52. Supported PCIe Network Adapters
Part
number
Feature
code
Description PCIe
lanes
Max
Qty
Slots
supported
Windows 10/11
support
Gigabit Ethernet
7ZT7A00484 AUZV ThinkSystem Broadcom 5719 1GbE RJ45 4-Port PCIe Ethernet Adapter Gen3 x8 10 1-12 Supported
7ZT7A00535 AUZW ThinkSystem I350-T4 PCIe 1Gb 4-Port RJ45 Ethernet Adapter Gen2 x4 10 1-12 Supported
10 Gb Ethernet - 10GBASE-T
7ZT7A00496 AUKP ThinkSystem Broadcom 57416 10GBASE-T 2-Port PCIe Ethernet Adapter Gen3 x8 10 All FH slots Supported
4XC7A08245 B5SU ThinkSystem Broadcom 57454 10GBASE-T 4-port PCIe Ethernet Adapter Gen3 x8 10 All FH slots Supported
4XC7A80266 BNWL ThinkSystem Intel X710-T2L 10GBase-T 2-Port PCIe Ethernet Adapter Gen3 x8 10 1-12 Supported
4XC7A79699 BMXB ThinkSystem Intel X710-T4L 10GBase-T 4-Port PCIe Ethernet Adapter Gen3 x8 10 1-12 Supported
25 Gb Ethernet
4XC7A08238 BK1H ThinkSystem Broadcom 57414 10/25GbE SFP28 2-port PCIe Ethernet Adapter Gen3 x8 10 1-12 Supported
4XC7A80566 BNWM ThinkSystem Broadcom 57504 10/25GbE SFP28 4-Port PCIe Ethernet Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12 (FH slots) Supported
4XC7A08295 BCD6 ThinkSystem Intel E810-DA2 10/25GbE SFP28 2-Port PCIe Ethernet Adapter Gen4 x8 10 1-12 Supported
4XC7A80267 BP8M ThinkSystem Intel E810-DA4 10/25GbE SFP28 4-Port PCIe Ethernet Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12 (FH slots) Supported
4XC7A62580 BE4U ThinkSystem Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-Port PCIe Ethernet Adapter Gen4 x8 10 1-12 Supported
100 Gb Ethernet / HDR100 InfiniBand
4XC7A08297 BK1J ThinkSystem Broadcom 57508 100GbE QSFP56 2-port PCIe 4 Ethernet Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12 (FH slots) Supported
4XC7A08248 B8PP ThinkSystem Mellanox ConnectX-6 Dx 100GbE QSFP56 2-port PCIe 4 Ethernet Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12, (FH slots) Supported
4C57A14177 B4R9 ThinkSystem Mellanox ConnectX-6 HDR100/100GbE QSFP56 1-port PCIe VPI Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12 (FH slots) No
4C57A14178 B4RA ThinkSystem Mellanox ConnectX-6 HDR100/100GbE QSFP56 2-port PCIe VPI Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12 (FH slots) No
200 Gb Ethernet / HDR InfiniBand
4C57A15326 B4RC ThinkSystem Mellanox ConnectX-6 HDR/200GbE QSFP56 1-port PCIe 4 VPI Adapter Gen4 x16 6 1,2,4,5,7,8, 11,12 (FH slots) No
4XC7A81883 BQBN ThinkSystem NVIDIA ConnectX-7 NDR200/HDR QSFP112 2-Port PCIe Gen5 x16 InfiniBand Adapter Gen5 x16 5 1,2,4,5,7 (FH slots) No
400 Gb Ethernet / NDR InfiniBand
4XC7A80289 BQ1N ThinkSystem NVIDIA ConnectX-7 NDR OSFP400 1-Port PCIe Gen5 x16 InfiniBand Adapter Gen5 x16 5 1,2,4,5,7 (FH slots) No

For more information, including the transceivers and cables that each adapter supports, see the list of Lenovo Press Product Guides in the Networking adapters category:
https://lenovopress.com/servers/options/ethernet

Configuration requirements:

  • Adapters with a x16 host interface require a x16 slot to maximize performance
  • PCIe Gen5 adapters will require a Gen5 riser to maximize performance
  • E810 Ethernet and X350 RAID/HBAs: The use of both an Intel E810 network adapter and an X350 HBA/RAID adapter (9350, 5350 and 4350) is currently not supported in ThinkSystem servers. For details see Support Tip HT513226. Planned support for this combination of adapters is 4Q/2023 (SI 23-2).

  • The ThinkSystem Broadcom 5719 1GbE RJ45 4-Port PCIe Ethernet Adapter (7ZT7A00484, AUZV) is currently not supported with the following CPUs. The incompatibility is planned to be resolved in a future update to XCC firmware in December 2023.
    • ThinkSystem AMD EPYC 9124 16C 200W 3.0GHz Processor
    • ThinkSystem AMD EPYC 9224 24C 200W 2.5GHz Processor
    • ThinkSystem AMD EPYC 9254 24C 200W 2.9GHz Processor
    • ThinkSystem AMD EPYC 9334 32C 210W 2.7GHz Processor

Fibre Channel host bus adapters

The following table lists the Fibre Channel HBAs supported by the SR655 V3.

No Windows 10/11 support: None of the adapters listed in the table are supported with Windows 10 or Windows 11.

Table 53. Fibre Channel HBAs
Part
number
Feature
code
Description PCIe
lanes
Max
qty
Slots
supported
64 Gb Fibre Channel HBAs
4XC7A77485 BLC1 ThinkSystem Emulex LPe36002 64Gb 2-port PCIe Fibre Channel Adapter Gen4 x8 10 1-12
32 Gb Fibre Channel HBAs
4XC7A76498 BJ3G ThinkSystem Emulex LPe35000 32Gb 1-port PCIe Fibre Channel Adapter v2 Gen4 x8 10 1-12
4XC7A76525 BJ3H ThinkSystem Emulex LPe35002 32Gb 2-port PCIe Fibre Channel Adapter V2 Gen4 x8 10 1-12
4XC7A08279 BA1G ThinkSystem QLogic QLE2770 32Gb 1-Port PCIe Fibre Channel Adapter Gen4 x8 10 1-12
4XC7A08276 BA1F ThinkSystem QLogic QLE2772 32Gb 2-Port PCIe Fibre Channel Adapter Gen4 x8 10 1-12
16 Gb Fibre Channel HBAs
01CV840 ATZV Emulex 16Gb Gen6 FC Dual-port HBA Gen3 x8 10 1-12
01CV830 ATZU Emulex 16Gb Gen6 FC Single-port HBA Gen3 x8 10 1-12
01CV760 ATZC QLogic 16Gb Enhanced Gen5 FC Dual-port HBA Gen3 x8 10 1-12
01CV750 ATZB QLogic 16Gb Enhanced Gen5 FC Single-port HBA Gen3 x8 10 1-12

For more information, see the list of Lenovo Press Product Guides in the Host bus adapters category:
https://lenovopress.com/servers/options/hba

SAS adapters for external storage

The following table lists SAS HBAs and RAID adapters supported by SR655 V3 server for use with external storage.

No Windows 10/11 support: None of the adapters listed in the table are supported with Windows 10 or Windows 11.

Table 54. Adapters for external storage
Part
number
Feature
code
Description PCIe
lanes
Max
qty
Slots
supported
SAS HBAs
4Y37A09724 B8P7 ThinkSystem 440-16e SAS/SATA PCIe Gen4 12Gb HBA Gen4 x8 10 1-10
4Y37A78837 BNWK ThinkSystem 440-8e SAS/SATA PCIe Gen4 12Gb HBA Gen4 x8 10 1-10
External RAID adapters
4Y37A78836 BNWJ ThinkSystem RAID 940-8e 4GB Flash PCIe Gen4 12Gb Adapter Gen4 x8 4 1-10

* See below regarding supercap requirements

For a comparison of the functions of the supported storage adapters, see the ThinkSystem RAID Adapter and HBA Reference:
https://lenovopress.lenovo.com/lp1288#sr655-v3-support=SR655%2520V3&internal-or-external-ports=External

The RAID 940-8e uses a flash power module (supercap), which can be installed in one of up to four locations in the server depending on the server configuration. See the RAID flash power module (supercap) support section for details. The number of 940-8e RAID adapters supported is based on how many supercaps can be installed in the server. If an internal RAID adapter with flash power modules is installed, the maximum number of 940-8e adapters supported is reduced by 1.

For more information, see the list of Lenovo Press Product Guides in the Host bus adapters and RAID adapters categories:

https://lenovopress.com/servers/options/hba
https://lenovopress.com/servers/options/raid

Flash storage adapters

The SR655 V3 currently does not support PCIe Flash Storage adapters.

GPU adapters

GPU part numbers

The SR655 V3 supports the following graphics processing units (GPUs).

Table 55. Supported GPUs
Part
number
Feature
code
Description TDP Aux
power
PCIe
lanes
Max
qty
Slots
supported*
Windows 10/11
support
Single-wide GPUs
4X67A81547 BP05 ThinkSystem NVIDIA A2 16GB PCIe Gen4 Passive GPU w/o CEC 60W No Gen4 x8 8 All FH slots Supported
CTO only BQZT ThinkSystem NVIDIA A2 16GB PCIe Gen4 Passive GPU w/o CEC 60W No Gen4 x8 8 All FH slots Supported
Double-wide GPUs
4X67A81102 BP04 ThinkSystem AMD Instinct MI210 PCIe Gen4 Passive Accelerator 300W Yes Gen4 x16 3 2,5,7 No
4X67A82257 BR9U ThinkSystem NVIDIA H100 80GB PCIe Gen5 Passive GPU 350W Yes Gen5 x16 3 2,5,7 No
4X67A76715 BLK1 ThinkSystem NVIDIA A100 80GB PCIe Gen4 Passive GPU w/o CEC 300W Yes Gen4 x16 3 2,5,7 No
CTO only BQZP ThinkSystem NVIDIA A100 80GB PCIe Gen4 Passive GPU w/o CEC 300W Yes Gen4 x16 3 2,5,7 No
4X67A72593 BEL4 ThinkSystem NVIDIA A40 48GB PCIe Gen4 Passive GPU w/o CEC 300W Yes Gen4 x16 3 2,5,7 Supported
CTO only BQZQ ThinkSystem NVIDIA A40 48GB PCIe Gen4 Passive GPU w/o CEC 300W Yes Gen4 x16 3 2,5,7 Supported
4X67A76581 BJHG ThinkSystem NVIDIA A30 24GB PCIe Gen4 Passive GPU w/o CEC 165W Yes Gen4 x16 3 2,5,7 Supported
CTO only BQZR ThinkSystem NVIDIA A30 24GB PCIe Gen4 Passive GPU w/o CEC 165W Yes Gen4 x16 3 2,5,7 Supported
4X67A76727 BNFE ThinkSystem NVIDIA A16 64GB Gen4 PCIe Passive GPU 250W Yes Gen4 x16 3 2,5,7 Supported
CTO only BQZU ThinkSystem NVIDIA A16 64GB Gen4 PCIe Passive GPU w/o CEC 250W Yes Gen4 x16 3 2,5,7 Supported
4X67A71310 BFT0 ThinkSystem NVIDIA RTX A6000 48GB PCIe Active GPU 300W Yes Gen4 x16 3 2,5,7 Supported
4X67A76726 BNFD ThinkSystem NVIDIA RTX A4500 20GB PCIe Active GPU 200W Yes Gen4 x16 3 2,5,7 Supported
4X67A76720 BMT9 ThinkSystem NVIDIA RTX A2000 12GB PCIe Active GPU 70W Yes Gen4 x16 3 2,5,7 Supported

* When a double-wide GPU is installed in slot 2, 5 or 7, the adjacent slot 1, 4 and 8 respectively is not available

For information about these GPUs, see the ThinkSystem GPU Summary, available at:
https://lenovopress.com/lp0768-thinksystem-thinkagile-gpu-summary

For CTO orders, the SR655 V3 also supports the selection of a "virtual GPU" or placeholder GPU. This selection allows for "GPU ready" configurations; It ensures that the server ships with the components needed for GPU installation (GPU power cables, air ducts, power supplies, fans, etc) without actually including the GPUs themselves. The following table lists the ordering information for CTO orders.

Table 56. Virtual GPU ordering information
Part number Feature code Description
CTO only BW40 ThinkSystem NVIDIA A4500 GPU-Ready Installation
CTO only BVLL ThinkSystem NVIDIA H100 GPU-Ready Installation
CTO only BP4X ThinkSystem DW GPU-Ready Installation (for all other supported DW GPUs)

Configuration rules

The following configuration requirements must be met when installing GPUs:

  • Some NVIDIA A Series GPUs are available as two feature codes, one with a CEC chip and one without a CEC chip (ones without the CEC chip have "w/o CEC" in the name). The CEC is a secondary Hardware Root of Trust (RoT) module that provides an additional layer of security, which can be used by customers who have high regulatory requirements or high security standards. NVIDIA uses a multi-layered security model and hence the protection offered by the primary Root of Trust embedded in the GPU is expected to be sufficient for most customers. The CEC defeatured products still offer Secure Boot, Secure Firmware Update, Firmware Rollback Protection, and In-Band Firmware Update Disable. Specifically, without the CEC chip, the GPU does not support Key Revocation or Firmware Attestation. CEC and non-CEC GPUs of the same type of GPU can be mixed in field upgrades.
  • All GPUs installed must be identical
  • When a double-wide GPU is installed in slot 2, 5 or 7, the adjacent slot 1, 4 and 8 respectively is not available
  • Flash storage adapters are not supported.
  • Middle drive bays and Rear drive bays are not supported
  • GPUs are not supported with CPUs with a TDP of more than 300W

For additional requirements related to GPUs, see the GPU Configuration section of the Thermal Rules page in the Information Center:
https://pubs.lenovo.com/sr655-v3/thermal_rules

Riser selections for double-wide GPUs

When a double-wide GPU is installed in slot 2, 5 or 7, the adjacent slot 1, 4 and 8 respectively is not available. The riser cards listed in the following table are used with double-wide GPUs.

Table 57. Risers needed for double-wide GPUs
Riser Part number Feature code Description
PCIe Gen 5 slots
Riser 1 (GPU in slot 2) 4XH7A82902 BPQW ThinkSystem V3 2U E/x16/x16 PCIe G5 Riser 1/2 Option Kit
Riser 2 (GPU in slot 5) 4XH7A82902 BPQW ThinkSystem V3 2U E/x16/x16 PCIe G5 Riser 1/2 Option Kit
Riser 3 (GPU in slot 7) 4XH7A86399 BLL9 ThinkSystem SR655 V3 x16/x16 PCIe G5 Riser3 Option Kit
PCIe Gen 4 slots
Riser 1 (GPU in slot 2) 4XH7A82894 BLKN ThinkSystem V3 2U E/x16/x16 PCIe G4 Riser 1/2 Option Kit
Riser 2 (GPU in slot 5) 4XH7A82894 BLKN ThinkSystem V3 2U E/x16/x16 PCIe G4 Riser 1/2 Option Kit
Riser 3 (GPU in slot 7) 4XH7A86397 BPKG ThinkSystem SR655 V3 x16/x16 PCIe G4 Riser3 Option Kit

GPU Enablement Kit

When installing any full-length GPU as a field upgrade, you will also need to order the GPU Enablement Kit as listed in the following table. This kit is not required for the NVIDIA A2 GPU.

Table 58. ThinkSystem SR655 V3 GPU Enablement Kit
Part number Description Maximum
supported
4X67A86438

ThinkSystem SR655 V3 GPU Enablement Kit (for double-wide GPUs)

  • 1x 2U performance heatsink
  • 1x ThinkSystem 2U GPU air duct
  • 3x GPU extension air ducts
  • 3x Air duct fillers
  • 3x GPU power cables for single-wide GPUs (SBB7A44786)
  • 3x GPU power Y-cables when 2x single-wide GPUs installed on one riser (SBB7A23757)
  • 3x GPU power cables for double-wide GPUs (SBB7A49792)
  • 3x GPU power cables for double-wide GPUs that use NVIDIA Form Factor 5.5 (NVFF5.5) (SBB7A66338)
1

The following figure shows the GPU air duct with GPU air duct fillers and GPU extend air ducts installed. Note that the drawings might not 100% reflect the shipping components.

SR655 V3 GPU air duct
Figure 17. SR655 V3 GPU air duct

GPU cable kits

The following cable kits are offered to provide auxiliary power cables for GPUs that require one. See the Supported GPUs table to see which GPUs require an auxiliary power cable.

Configuration notes:

  • This cable kits are only required for field upgrades; factory (CTO) orders will automatically include any required cables.
  • For double-wide GPUs, The DW (double-wide) cable kit is only required if you are adding additional double-wide GPUs to a server that already has a DW GPU installed from a CTO order. If you are doing a field upgrade to install the first DW GPU to a server, order the ThinkSystem SR655 V3 GPU Enablement Kit, 4X67A86438 instead, since the Enablement Kit includes the necessary power cables.
  • The SW (single-wide) cable kit is required if you are doing any field upgrades to add a single-wide GPU that requires an auxiliary power cable (GPU power > 75 W), however, all currently supported GPUs do not require auxiliary power cables.

Table 59. GPU cable kits
Part number Description
4X97A86165

ThinkSystem SR665 V3/SR655 V3 DW GPU Cable Option Kit

  • 3x Power cables for double-wide GPU (SBB7A49792)
4X97A86166

ThinkSystem SR665 V3/SR655 V3 SW GPU Cable Option Kit

  • 3x Power cables for single-wide GPU (SBB7A44786)
  • 3x Power Y-cable when 2x single-wide GPUs installed on one riser (SBB7A23757)

Cooling

The SR655 V3 server has up to six 60 mm hot-swap variable-speed fans. The server offers N+1 redundancy. The server also has one or two additional fans integrated in each of the two power supplies. Most configurations require 6 system fans. If Riser 3 is not configured, then only 4 system fans are needed.

Depending on the configuration, the server will need either Standard fans (single-rotor 17K RPM) or Performance fans (dual-rotor 20K RPM).

Under all of the following conditions, standard fans can be used:

  • CPU with TDP ≤ 240W
  • No GPUs
  • No 100GbE or higher network adapters
  • No 3DS RDIMMs
  • No mid-chassis drive bays
  • No rear drive bays

If any conditions are not met, Performance fans are required.

Ordering information for the fans is listed in the following table.

Table 60. Fan ordering information
Part number Feature
code
Description Quantity
required
4F17A14497 BH8F ThinkSystem V3 2U Standard Fan Option Kit 4 or 6*
4F17A82884 BLL6 ThinkSystem V3 2U Performance Fan Option Kit 4 or 6*

* 6 fans required if Riser 3 is configured

Power supplies

The SR655 V3 supports up to two redundant hot-swap power supplies.

The power supply choices are listed in the following table. Both power supplies used in server must be identical.

Tip: When configuring a server in the DCSC configurator, power consumption is calculated precisely by interfacing with Lenovo Capacity Planner. You can therefore select the appropriate power supply for your configuration. However, do consider future upgrades that may require additional power needs.

Table 61. Power supply options
Part number Feature
code
Description Connector Max
quantity
110V AC 220V AC 240V DC
PRC only
-48V DC
AC input power - 80 PLUS Titanium efficiency
4P57A82019 BR1X ThinkSystem 750W 230V Titanium Hot-Swap Gen2 Power Supply v3 C13 2 No Yes Yes No
4P57A72666 BLKH ThinkSystem 1100W 230V Titanium Hot-Swap Gen2 Power Supply C13 2 No Yes Yes No
4P57A78359 BPK9 ThinkSystem 1800W 230V Titanium Hot-Swap Gen2 Power Supply C13 2 No Yes Yes No
4P57A72667 BKTJ ThinkSystem 2600W 230V Titanium Hot-Swap Gen2 Power Supply C19 2 No Yes Yes No
AC input power - 80 PLUS Platinum efficiency
4P57A72670 BNFG ThinkSystem 750W 230V/115V Platinum Hot-Swap Gen2 Power Supply v3 C13 2 Yes Yes Yes No
4P57A72671 BNFH ThinkSystem 1100W 230V/115V Platinum Hot-Swap Gen2 Power Supply v3 C13 2 Yes Yes Yes No
4P57A26294



BMUF ThinkSystem 1800W 230V Platinum Hot-Swap Gen2 Power Supply v2 C13 2 No Yes Yes No
4P57A26295 B962 ThinkSystem 2400W 230V Platinum Hot-Swap Gen2 Power Supply C19 2 No Yes Yes No
-48V DC input power
4P57A26296 B8QE ThinkSystem 1100W -48V DC Hot-Swap Gen2 Power Supply DC 2 No No No Yes

Supported power supplies are auto-sensing dual-voltage units, supporting both 110V AC (100-127V 50/60 Hz) and 220V AC (200-240V 50/60 Hz) power. For China customers, all power supplies support 240V DC.

AC power supplies up to 1800W have a C14 connector. AC power supplies 2400W and above have a C19 connector.

The supported -48V DC power supply has a Weidmuller TOP 4GS/3 7.6 terminal as shown in the following figure.

ThinkSystem 1100W -48V DC v2 Power Supply
Figure 18. Connector on the ThinkSystem 1100W -48V DC Hot-Swap Gen2 Power Supply

Power supply options do not include a line cord. For server configurations, the inclusion of a power cord is model dependent. Configure-to-order models can be configured without power cords if desired.

Power supply LEDs

The supported hot-swap power supplies have the following LEDs:

  • Power input LED:
    • Green: The power supply is connected to the AC power source
    • Off: The power supply is disconnected from the AC power source or a power problem has occurred
  • Power output LED:
    • Green: The server is on and the power supply is working normally
    • Blinking green: The power supply is in Zero-output/Standby mode (see below)
    • Off: The server is powered off, or the power supply is not working properly
  • Power supply error LED:
    • Off: The power supply is working normally
    • Yellow: The power supply has failed

Zero-output mode: When Zero-output mode (also known as Standby mode or Cold Redundancy mode) is configured in XCC and the server power load is sufficiently low, one of the installed power supplies enters into the Standby state while the other one delivers entire load. When the power load increases, the standby power supply will switch to Active state to provide sufficient power to the server. Zero-output mode can be enabled or disabled in the XClarity Controller web interface, Server Configuration > Power Policy. If you select Disable, then both power supplies will be in the Active state.

Power cords

Line cords and rack power cables with C13 connectors can be ordered as listed in the following table.

110V customers: If you plan to use the 1100W power supply with a 110V power source, select a power cable that is rated above 10A. Power cables that are rated at 10A or below are not supported with 110V power.

Table 62. Power cords
Part number Feature code Description
Rack cables - C13 to C14
SL67B08593 BPHZ 0.5m, 10A/100-250V, C13 to C14 Jumper Cord
00Y3043 A4VP 1.0m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
4L67A08367 B0N5 1.0m, 13A/100-250V, C13 to C14 Jumper Cord
39Y7937 6201 1.5m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
4L67A08368 B0N6 1.5m, 13A/100-250V, C13 to C14 Jumper Cord
4L67A08365 B0N4 2.0m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
4L67A08369 6570 2.0m, 13A/100-250V, C13 to C14 Jumper Cord
4L67A08366 6311 2.8m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
4L67A08370 6400 2.8m, 13A/100-250V, C13 to C14 Jumper Cord
39Y7932 6263 4.3m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
4L67A08371 6583 4.3m, 13A/100-250V, C13 to C14 Rack Power Cable
Rack cables - C13 to C14 (Y-cable)
00Y3046 A4VQ 1.345m, 2X C13 to C14 Jumper Cord, Rack Power Cable
00Y3047 A4VR 2.054m, 2X C13 to C14 Jumper Cord, Rack Power Cable
Rack cables - C13 to C20
39Y7938 6204 2.8m, 10A/100-250V, C13 to IEC 320-C20 Rack Power Cable
Rack cables - C13 to C20 (Y-cable)
47C2491 A3SW 1.2m, 16A/100-250V, 2 Short C13s to Short C20 Rack Power Cable
47C2492 A3SX 2.5m, 16A/100-250V, 2 Long C13s to Short C20 Rack Power Cable
47C2493 A3SY 2.8m, 16A/100-250V, 2 Short C13s to Long C20 Rack Power Cable
47C2494 A3SZ 4.1m, 16A/100-250V, 2 Long C13s to Long C20 Rack Power Cable
Line cords
39Y7930 6222 2.8m, 10A/250V, C13 to IRAM 2073 (Argentina) Line Cord
81Y2384 6492 4.3m 10A/220V, C13 to IRAM 2073 (Argentina) Line Cord
39Y7924 6211 2.8m, 10A/250V, C13 to AS/NZ 3112 (Australia/NZ) Line Cord
81Y2383 6574 4.3m, 10A/230V, C13 to AS/NZS 3112 (Aus/NZ) Line Cord
69Y1988 6532 2.8m, 10A/250V, C13 to NBR 14136 (Brazil) Line Cord
81Y2387 6404 4.3m, 10A/250V, C13 - 2P+Gnd (Brazil) Line Cord
39Y7928 6210 2.8m, 220-240V, C13 to GB 2099.1 (China) Line Cord
81Y2378 6580 4.3m, 10A/220V, C13 to GB 2099.1 (China) Line Cord
39Y7918 6213 2.8m, 10A/250V, C13 to DK2-5a (Denmark) Line Cord
81Y2382 6575 4.3m, 10A/230V, C13 to DK2-5a (Denmark) Line Cord
39Y7917 6212 2.8m, 10A/230V, C13 to CEE7-VII (Europe) Line Cord
81Y2376 6572 4.3m, 10A/230V, C13 to CEE7-VII (Europe) Line Cord
39Y7927 6269 2.8m, 10A/250V, C13(2P+Gnd) (India) Line Cord
81Y2386 6567 4.3m, 10A/240V, C13 to IS 6538 (India) Line Cord
39Y7920 6218 2.8m, 10A/250V, C13 to SI 32 (Israel) Line Cord
81Y2381 6579 4.3m, 10A/230V, C13 to SI 32 (Israel) Line Cord
39Y7921 6217 2.8m, 220-240V, C13 to CEI 23-16 (Italy/Chile) Line Cord
81Y2380 6493 4.3m, 10A/230V, C13 to CEI 23-16 (Italy/Chile) Line Cord
46M2593 A1RE 2.8m, 12A/125V, C13 to JIS C-8303 (Japan) Line Cord
4L67A08362 6495 4.3m, 12A/200V, C13 to JIS C-8303 (Japan) Line Cord
39Y7926 6335 4.3m, 12A/100V, C13 to JIS C-8303 (Japan) Line Cord
39Y7922 6214 2.8m, 10A/250V, C13 to SABS 164 (S Africa) Line Cord
81Y2379 6576 4.3m, 10A/230V, C13 to SABS 164 (South Africa) Line Cord
39Y7925 6219 2.8m, 220-240V, C13 to KETI (S Korea) Line Cord
81Y2385 6494 4.3m, 12A/220V, C13 to KSC 8305 (S. Korea) Line Cord
39Y7919 6216 2.8m, 10A/250V, C13 to SEV 1011-S24507 (Swiss) Line Cord
81Y2390 6578 4.3m, 10A/230V, C13 to SEV 1011-S24507 (Sws) Line Cord
23R7158 6386 2.8m, 10A/125V, C13 to CNS 10917-3 (Taiwan) Line Cord
81Y2375 6317 2.8m, 10A/240V, C13 to CNS 10917-3 (Taiwan) Line Cord
81Y2374 6402 2.8m, 13A/125V, C13 to CNS 60799 (Taiwan) Line Cord
4L67A08363 AX8B 4.3m, 10A 125V, C13 to CNS 10917 (Taiwan) Line Cord
81Y2389 6531 4.3m, 10A/250V, C13 to 76 CNS 10917-3 (Taiwan) Line Cord
81Y2388 6530 4.3m, 13A/125V, C13 to CNS 10917 (Taiwan) Line Cord
39Y7923 6215 2.8m, 10A/250V, C13 to BS 1363/A (UK) Line Cord
81Y2377 6577 4.3m, 10A/230V, C13 to BS 1363/A (UK) Line Cord
90Y3016 6313 2.8m, 10A/120V, C13 to NEMA 5-15P (US) Line Cord
46M2592 A1RF 2.8m, 10A/250V, C13 to NEMA 6-15P Line Cord
00WH545 6401 2.8m, 13A/120V, C13 to NEMA 5-15P (US) Line Cord
4L67A08359 6370 4.3m, 10A/125V, C13 to NEMA 5-15P (US) Line Cord
4L67A08361 6373 4.3m, 10A/250V, C13 to NEMA 6-15P (US) Line Cord
4L67A08360 AX8A 4.3m, 13A/120V, C13 to NEMA 5-15P (US) Line Cord

Power cords (C19 connectors)

Line cords and rack power cables with C19 connectors can be ordered as listed in the following table.

Table 63. Power cords (C19 connectors)
Part number Feature code Description
Rack cables
4L67A86677 BPJ0 0.5m, 16A/100-250V, C19 to IEC 320-C20 Rack Power Cable
4L67A86678 B4L0 1.0m, 16A/100-250V, C19 to IEC 320-C20 Rack Power Cable
4L67A86679 B4L1 1.5m, 16A/100-250V, C19 to IEC 320-C20 Rack Power Cable
4L67A86680 B4L2 2.0m, 16A/100-250V, C19 to IEC 320-C20 Rack Power Cable
39Y7916 6252 2.5m, 16A/100-240V, C19 to IEC 320-C20 Rack Power Cable
4L67A86681 B4L3 4.3m, 16A/100-250V, C19 to IEC 320-C20 Rack Power Cable
Line cords
40K9777 6276 4.3m, 220-240V, C19 to IRAM 2073 (Argentina) Line cord
40K9773 6284 4.3m, 220-240V, C19 to AS/NZS 3112 (Aus/NZ) Line cord
40K9775 6277 4.3m, 250V, C19 to NBR 14136 (Brazil) Line Cord
40K9774 6288 4.3m, 220-240V, C19 to GB2099.1 (China) Line cord
40K9769 6283 4.3m, 16A/230V, C19 to IEC 309-P+N+G (Den/Sws) Line Cord
40K9766 6279 4.3m, 220-240V, C19 to CEE7-VII (European) Line cord
40K9776 6285 4.3m, 220-240V, C19 to IS6538 (India) Line cord
40K9771 6282 4.3m, 220-240V, C19 to SI 32 (Israel) Line cord
40K9768 6281 4.3m, 220-240V, C19 to CEI 23-16 (Italy) Line cord
40K9770 6280 4.3m, 220-240V, C19 to SABS 164 (South Africa) Line cord
41Y9231 6289 4.3m, 15A/250V, C19 to KSC 8305 (S. Korea) Line Cord
81Y2391 6549 4.3m, 16A/230V, C19 to SEV 1011 (Sws) Line Cord
41Y9230 6287 4.3m, 16A/250V, C19 to CNS 10917-3 (Taiwan) Line Cord
40K9767 6278 4.3m, 220-240V, C19 to BS 1363/A w/13A fuse (UK) Line Cord
40K9772 6275 4.3m, 16A/208V, C19 to NEMA L6-20P (US) Line Cord
00D7197 A1NV 4.3m, 15A/250V, C19 to NEMA 6-15P (US) Line Cord

-48V DC power cord

For the -48V DC Power Supply, the following power cable is supported.

Table 64. -48V DC power cable
Part number Feature code Description
4X97A59831 BE4V 2.5m, -48VDC Interconnecting Cable

Systems management

The SR655 V3 contains an integrated service processor, XClarity Controller 2 (XCC), which provides advanced control, monitoring, and alerting functions. The XCC2 is based on the AST2600 baseboard management controller (BMC) using a dual-core ARM Cortex A7 32-bit RISC service processor running at 1.2 GHz.

Topics in this section:

System I/O Board

The SR655 V3 implements a separate System I/O Board that connects to the Processor Board. The location of the System I/O Board is shown in the Components and connectors section. The System I/O Board contains all the connectors visible at the rear of the server as shown in the following figure.

System I/O Board
Figure 19. System I/O Board

The board also has the following components:

  • XClarity Controller 2, implemented using the ASPEED AST2600 baseboard management controller (BMC).
  • Root of Trust (RoT) module - a daughter card that implements Platform Firmware Resiliency (PFR) hardware Root of Trust (RoT) which enables the server to be NIST SP800-193 compliant. For more details about PFR, see the Security section.
  • Connector to enable an additional redundant Ethernet connection to the XCC2 controller. The connector is used in conjuction with the ThinkSystem Redundant System Management Port Adapter. For details, see the Remote management section.
  • Internal USB port - to allow the booting of an operating system from a USB key. The VMware ESXi preloads use this port for example. Preloads are described in the Operating system support section.
  • MicroSD card port to enable the use of a MicroSD card for additional storage for use with the XCC2 controller. XCC2 can use the storage as a Remote Disc on Card (RDOC) device (up to 4GB of storage). It can also be used to store firmware updates (including N-1 firmware history) for ease of deployment.

    Tip: Without a MicroSD card installed, the XCC2 controller will have 100MB of available RDOC storage.

Ordering information for the supported USB drive and Micro SD card are listed in the following table.

Table 65. Media for use with the System I/O Board
Part number Feature code Description
4X77A77065 BNWN ThinkSystem USB 32GB USB 3.0 Flash Drive
4X77A77064 BNWP ThinkSystem MicroSD 32GB Class 10 Flash Memory Card

Local management

The SR655 V3 offers a front operator panel with key LED status indicators, as shown in the following figure.

Tip: The Network LED only shows network activity of the installed OCP network adapter.

SR655 V3 front controls
Figure 20. Front operator controls are on the left and right side of the server

Light path diagnostics

The server offers light path diagnostics. If an environmental condition exceeds a threshold or if a system component fails, XCC lights LEDs inside the server to help you diagnose the problem and find the failing part. The server has fault LEDs next to the following components:

  • Each memory DIMM
  • Each drive bay
  • Each power supply

Front VGA and External Diagnostics ports

The VGA port at the rear of the server is included in all models, however the VGA port at the front of the server is optional. Also optional is the External Diagnostics port which enables the use of the External Diagnostics Handset.

To configure either the VGA port or the External Diagnostics port at the front of the server, select one of the following feature codes when configuring the server.

Table 66. Front VGA port
Part number Feature code Description Front
VGA port
External
diagnostics
port
CTO only BQQ2 ThinkSystem 2U V3 EIA Latch Standard No No
4XH7A86164 BQQ1 ThinkSystem V3 2U EIA Latch with VGA & External Diagnostics Ports Included Included
4XH7A86816 BQQ4 ThinkSystem SR665 V3 EIA Latch with External Diagnostics Port No Included
4XH7A86817 BQQ3 ThinkSystem SR665 V3 EIA Latch with VGA Port Included No

External Diagnostics Handset

The SR655 V3 optionally has a port to connect an External Diagnostics Handset as described in the preceding section. The External Diagnostics Handset has the same functions as the Integrated Diagnostics Panel but has the advantages of not consuming space on the front of the server plus it can be shared among many servers in your data center. The handset has a magnet on the back of it to allow you to easily mount it on a convenient place on any rack cabinet.

External management LCD
Figure 21. External Diagnostics Handset

Ordering information for the External Diagnostics Handset with is listed in the following table.

Table 67. External Diagnostics Handset ordering information
Part number Feature code Description
4TA7A64874 BEUX ThinkSystem External Diagnostics Handset

Integrated Diagnostics Panel for 8x 2.5-inch and 16x 2.5-inch drive bay configurations

For configurations with 8x 2.5-inch or 16x 2.5-inch drive bays at the front, the server can optionally be configured to have a pull-out Integrated Diagnostics Panel. The following figure shows the standard (fixed) operator panel and the optional Integrated Diagnostics Panel.

Operator panel choices for the 8x 2.5-inch and 16x 2.5-inch drive bay configurations
Figure 22. Operator panel choices for the 8x 2.5-inch drive bay configuration

The Integrated Diagnostics Panel allows quick access to system status, firmware, network, and health information. The LCD display on the panel and the function buttons give you access to the following information:

  • Active alerts
  • Status Dashboard
  • System VPD: machine type & mode, serial number, UUID string
  • System firmware levels: UEFI and XCC firmware
  • XCC network information: hostname, MAC address, IP address, DNS addresses
  • Environmental data: Ambient temperature, CPU temperature, AC input voltage, estimated power consumption
  • Active XCC sessions
  • System reset action

The Integrated Diagnostics Panel can be configured as listed in the following table. It is only available configure-to-order (CTO); not available as a field upgrade.

Table 68. Ordering information for the Integrated Diagnostics Panel
Part number Feature code Description
CTO only BMJA ThinkSystem 2U 16x2.5" Front Operator Panel v2

Information pull-out tab

The front of the server also houses an information pull-out tab (also known as the network access tag). See Figure 2 for the location. A label on the tab shows the network information (MAC address and other data) to remotely access the service processor.

System status with XClarity Mobile

The XClarity Mobile app includes a tethering function where you can connect your Android or iOS device to the server via USB to see the status of the server.

The steps to connect the mobile device are as follows:

  1. Enable USB Management on the server, by holding down the ID button for 3 seconds (or pressing the dedicated USB management button if one is present)
  2. Connect the mobile device via a USB cable to the server's USB port with the management symbol USB Management symbol
  3. In iOS or Android settings, enable Personal Hotspot or USB Tethering
  4. Launch the Lenovo XClarity Mobile app

Once connected you can see the following information:

  • Server status including error logs (read only, no login required)
  • Server management functions (XClarity login credentials required)

Remote management

The server offers a dedicated RJ45 port at the rear of the server for remote management via the XClarity Controller management processor. The port supports 10/100/1000 Mbps speeds.

Remote server management is provided through industry-standard interfaces:

  • Intelligent Platform Management Interface (IPMI) Version 2.0
  • Simple Network Management Protocol (SNMP) Version 3 (no SET commands; no SNMP v1)
  • Common Information Model (CIM-XML)
  • Representational State Transfer (REST) support
  • Redfish support (DMTF compliant)
  • Web browser - HTML 5-based browser interface (Java and ActiveX not required) using a responsive design (content optimized for device being used - laptop, tablet, phone) with NLS support

The SR655 V3 also supports the use of an OCP adapter that provides an additional redundant Ethernet connection to the XCC2 controller. Ordering information is listed in the following table.

Table 69. Redundant System Management Port Adapter
Part
number
Feature
code
Description Maximum
quantity
4XC7A85319 BTMQ ThinkSystem V3 Management NIC Adapter Kit 1

The use of this adapter allows concurrent remote access using both the connection on the adapter and the onboard RJ45 remote management port provided by the server. The adapter and onboard port have separate IP addresses.

Configuration rules:

  • The Redundant System Management Port Adapter is installed in the OCP adapter slot at the rear of the server and is mutually exclusive with any OCP network adapter.
  • It is not supported installed in the front OCP slot (if the front OCP slot is configured)
  • If the Redundant System Management Port Adapter is installed in the rear slot, then the front OCP slot (if configured) cannot be used.

The following figure shows the server with the Redundant System Management Port Adapter installed in the OCP slot.

SR655 V3 with the Redundant System Management Port Adapter installed
Figure 23. SR655 V3 with the Redundant System Management Port Adapter installed

IPMI via the Ethernet port (IPMI over LAN) is supported, however it is disabled by default. For CTO orders you can specify whether you want to the feature enabled or disabled in the factory, using the feature codes listed in the following table.

Table 70. IPMI-over-LAN settings
Feature code Description
B7XZ Disable IPMI-over-LAN (default)
B7Y0 Enable IPMI-over-LAN

XCC2 Platinum

The XCC2 service processor in the SR655 V3 supports an upgrade to a Platinum level of features. Compared to the XCC functions of ThinkSystem V2 and earlier systems, Platinum adds the same features as Enterprise and Advanced levels in ThinkSystem V2, plus additional features.

XCC2 Platinum adds the following Enterprise and Advanced functions:

  • Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz with up to 23 bits per pixel, regardless of the system state
  • Remotely accessing the server using the keyboard and mouse from a remote client
  • International keyboard mapping support
  • Syslog alerting
  • Redirecting serial console via SSH
  • Component replacement log (Maintenance History log)
  • Access restriction (IP address blocking)
  • Lenovo SED security key management
  • Displaying graphics for real-time and historical power usage data and temperature
  • Boot video capture and crash video capture
  • Virtual console collaboration - Ability for up to 6 remote users to be log into the remote session simultaneously
  • Remote console Java client
  • Mapping the ISO and image files located on the local client as virtual drives for use by the server
  • Mounting the remote ISO and image files via HTTPS, SFTP, CIFS, and NFS
  • Power capping
  • System utilization data and graphic view
  • Single sign on with Lenovo XClarity Administrator
  • Update firmware from a repository
  • License for XClarity Energy Manager

XCC2 Platinum also adds the following features that are new to XCC2:

  • System Guard - Monitor hardware inventory for unexpected component changes, and simply log the event or prevent booting
  • Enterprise Strict Security mode - Enforces CNSA 1.0 level security
  • Neighbor Group - Enables administrators to manage and synchronize configurations and firmware level across multiple servers

Ordering information is listed in the following table. XCC2 Platinum is a software license upgrade - no additional hardware is required.

Table 71. XCC2 Platinum license upgrade
Part number Feature code Description
7S0X000DWW S91X Lenovo XClarity XCC2 Platinum Upgrade
7S0X000KWW SBCV Lenovo XClarity Controller 2 (XCC2) Platinum Upgrade

With XCC Platinum, for CTO orders, you can request that System Guard be enabled in the factory and the first configuration snapshot be recorded. To add this to an order, select feature code listed in the following table. The selection is made in the Security tab of the DCSC configurator.

Table 72. Enable System Guard in the factory (CTO orders)
Feature code Description
BUT2 Install System Guard

For more information about System Guard, see https://pubs.lenovo.com/xcc2/NN1ia_c_systemguard

Lenovo XClarity Provisioning Manager

Lenovo XClarity Provisioning Manager (LXPM) is a UEFI-based application embedded in ThinkSystem servers and accessible via the F1 key during system boot.

LXPM provides the following functions:

  • Graphical UEFI Setup
  • System inventory information and VPD update
  • System firmware updates (UEFI and XCC)
  • RAID setup wizard
  • OS installation wizard (including unattended OS installation)
  • Diagnostics functions

Lenovo XClarity Administrator

Lenovo XClarity Administrator is a centralized resource management solution designed to reduce complexity, speed response, and enhance the availability of Lenovo systems and solutions. It provides agent-free hardware management for ThinkSystem servers, in addition to ThinkServer, System x, and Flex System servers. The administration dashboard is based on HTML 5 and allows fast location of resources so tasks can be run quickly.

Because Lenovo XClarity Administrator does not require any agent software to be installed on the managed endpoints, there are no CPU cycles spent on agent execution, and no memory is used, which means that up to 1GB of RAM and 1 - 2% CPU usage is saved, compared to a typical managed system where an agent is required.

Lenovo XClarity Administrator is an optional software component for the SR655 V3. The software can be downloaded and used at no charge to discover and monitor the SR655 V3 and to manage firmware upgrades.

If software support is required for Lenovo XClarity Administrator, or premium features such as configuration management and operating system deployment are required, Lenovo XClarity Pro software subscription should be ordered. Lenovo XClarity Pro is licensed on a per managed system basis, that is, each managed Lenovo system requires a license.

The following table lists the Lenovo XClarity software license options.

Table 73. Lenovo XClarity Pro ordering information
Part number Feature code Description
00MT201 1339 Lenovo XClarity Pro, per Managed Endpoint w/1 Yr SW S&S
00MT202 1340 Lenovo XClarity Pro, per Managed Endpoint w/3 Yr SW S&S
00MT203 1341 Lenovo XClarity Pro, per Managed Endpoint w/5 Yr SW S&S
7S0X000HWW SAYV Lenovo XClarity Pro, per Managed Endpoint w/6 Yr SW S&S
7S0X000JWW SAYW Lenovo XClarity Pro, per Managed Endpoint w/7 Yr SW S&S

Lenovo XClarity Administrator offers the following standard features that are available at no charge:

  • Auto-discovery and monitoring of Lenovo systems
  • Firmware updates and compliance enforcement
  • External alerts and notifications via SNMP traps, syslog remote logging, and e-mail
  • Secure connections to managed endpoints
  • NIST 800-131A or FIPS 140-2 compliant cryptographic standards between the management solution and managed endpoints
  • Integration into existing higher-level management systems such as cloud automation and orchestration tools through REST APIs, providing extensive external visibility and control over hardware resources
  • An intuitive, easy-to-use GUI
  • Scripting with Windows PowerShell, providing command-line visibility and control over hardware resources

Lenovo XClarity Administrator offers the following premium features that require an optional Pro license:

  • Pattern-based configuration management that allows to define configurations once and apply repeatedly without errors when deploying new servers or redeploying existing servers without disrupting the fabric
  • Bare-metal deployment of operating systems and hypervisors to streamline infrastructure provisioning

For more information, refer to the Lenovo XClarity Administrator Product Guide:
http://lenovopress.com/tips1200

Lenovo XClarity Integrators

Lenovo also offers software plug-in modules, Lenovo XClarity Integrators, to manage physical infrastructure from leading external virtualization management software tools including those from Microsoft and VMware.

These integrators are offered at no charge, however if software support is required, a Lenovo XClarity Pro software subscription license should be ordered.

Lenovo XClarity Integrators offer the following additional features:

  • Ability to discover, manage, and monitor Lenovo server hardware from VMware vCenter or Microsoft System Center
  • Deployment of firmware updates and configuration patterns to Lenovo x86 rack servers and Flex System from the virtualization management tool
  • Non-disruptive server maintenance in clustered environments that reduces workload downtime by dynamically migrating workloads from affected hosts during rolling server updates or reboots
  • Greater service level uptime and assurance in clustered environments during unplanned hardware events by dynamically triggering workload migration from impacted hosts when impending hardware failures are predicted

For more information about all the available Lenovo XClarity Integrators, see the Lenovo XClarity Administrator Product Guide: https://lenovopress.com/tips1200-lenovo-xclarity-administrator

Lenovo XClarity Essentials

Lenovo offers the following XClarity Essentials software tools that can help you set up, use, and maintain the server at no additional cost:

  • Lenovo Essentials OneCLI

    OneCLI is a collection of server management tools that uses a command line interface program to manage firmware, hardware, and operating systems. It provides functions to collect full system health information (including health status), configure system settings, and update system firmware and drivers.

  • Lenovo Essentials UpdateXpress

    The UpdateXpress tool is a standalone GUI application for firmware and device driver updates that enables you to maintain your server firmware and device drivers up-to-date and help you avoid unnecessary server outages. The tool acquires and deploys individual updates and UpdateXpress System Packs (UXSPs) which are integration-tested bundles.

  • Lenovo Essentials Bootable Media Creator

    The Bootable Media Creator (BOMC) tool is used to create bootable media for offline firmware update.

For more information and downloads, visit the Lenovo XClarity Essentials web page:
http://support.lenovo.com/us/en/documents/LNVO-center

Lenovo XClarity Energy Manager

Lenovo XClarity Energy Manager (LXEM) is a power and temperature management solution for data centers. It is an agent-free, web-based console that enables you to monitor and manage power consumption and temperature in your data center through the management console. It enables server density and data center capacity to be increased through the use of power capping.

LXEM is a licensed product. A single-node LXEM license is included with the XClarity Controller Platinum upgrade as described in the Remote Management section. If your server does not have the XCC Platinum upgrade, Energy Manager licenses can be ordered as shown in the following table.

Table 74. Lenovo XClarity Energy Manager
Part number Description
4L40E51621 Lenovo XClarity Energy Manager Node License (1 license needed per server)

Note: The SR655 V3 does not support the following Energy Manager functions:

  • Power capping
  • Policy-based management

For more information about XClarity Energy Manager, see the following resources:

Lenovo Capacity Planner

Lenovo Capacity Planner is a power consumption evaluation tool that enhances data center planning by enabling IT administrators and pre-sales professionals to understand various power characteristics of racks, servers, and other devices. Capacity Planner can dynamically calculate the power consumption, current, British Thermal Unit (BTU), and volt-ampere (VA) rating at the rack level, improving the planning efficiency for large scale deployments.

For more information, refer to the Capacity Planner web page:
http://datacentersupport.lenovo.com/us/en/solutions/lnvo-lcp

Security

Security features

The SR655 V3 server offers the following electronic security features:

  • Secure Boot function of the AMD EPYC processor
  • Support for Platform Firmware Resiliency (PFR) hardware Root of Trust (RoT) - see the Platform Firmware Resiliency section
  • Firmware signature processes compliant with FIPS and NIST requirements
  • System Guard (part of XCC Platinum) - Proactive monitoring of hardware inventory for unexpected component changes
  • Administrator and power-on password
  • Integrated Trusted Platform Module (TPM) supporting TPM 2.0
  • Self-encrypting drives (SEDs) with support for enterprise key managers - see the SED encryption key management section

The server is NIST SP 800-147B compliant.

The SR655 V3 server also offers the following physical security features:

  • Optional chassis intrusion switch
  • Optional lockable front security bezel

The optional lockable front security bezel is shown in the following figure and includes a key that enables you to secure the bezel over the drives and system controls thereby reducing the chance of unauthorized or accidental access to the server.

Front PCIe slots: The use of the security bezel is not supported when the server has front PCIe slots.

Lockable front security bezel
Figure 24. Lockable front security bezel

The dimensions of the security bezel are:

  • Width: 437 mm (17.2 in.)
  • Height: 87 mm (3.4 in.)
  • Width: 23 mm (0.9 in.)

The following table lists the security options for the SR655 V3.

Table 75. Security features
Part number Feature code Description
4X97A82927 BAJJ ThinkSystem SR650 V3/SR655 V3 Intrusion Cable
4XH7A09886 B8M2 ThinkSystem V2 2U Security Bezel Option Kit
4XH7A90300 BXBQ ThinkSystem V3 2U Security Bezel Option Kit

Tip: The only difference between security bezels 4XH7A09886 and 4XH7A90300 is the Lenovo logo: On 4XH7A09886, the logo is made from plastic; on 4XH7A90300, the logo is made from aluminum alloy.

Platform Firmware Resiliency - Lenovo ThinkShield

Lenovo's ThinkShield Security is a transparent and comprehensive approach to security that extends to all dimensions of our data center products: from development, to supply chain, and through the entire product lifecycle.

The ThinkSystem SR655 V3 includes Platform Firmware Resiliency (PFR) hardware Root of Trust (RoT) which enables the system to be NIST SP800-193 compliant. This offering further enhances key platform subsystem protections against unauthorized firmware updates and corruption, to restore firmware to an integral state, and to closely monitor firmware for possible compromise from cyber attacks.

PFR operates upon the following server components:

  • UEFI image – the low-level server firmware that connects the operating system to the server hardware
  • XCC image – the management “engine” software that controls and reports on the server status separate from the server operating system
  • FPGA image – the code that runs the server’s lowest level hardware controller on the motherboard

The Lenovo Platform Root of Trust Hardware performs the following three main functions:

  • Detection – Measures the firmware and updates for authenticity
  • Recovery – Recovers a corrupted image to a known-safe image
  • Protection – Monitors the system to ensure the known-good firmware is not maliciously written

These enhanced protection capabilities are implemented using a dedicated, discrete security processor whose implementation has been rigorously validated by leading third-party security firms. Security evaluation results and design details are available for customer review – providing unprecedented transparency and assurance.

The SR655 V3 includes support for Secure Boot, a UEFI firmware security feature developed by the UEFI Consortium that ensures only immutable and signed software are loaded during the boot time. The use of Secure Boot helps prevent malicious code from being loaded and helps prevent attacks, such as the installation of rootkits. Lenovo offers the capability to enable secure boot in the factory, to ensure end-to-end protection. Alternatively, Secure Boot can be left disabled in the factory, allowing the customer to enable it themselves at a later point, if desired.

The following table lists the relevant feature code(s).

Table 76. Secure Boot options
Part number Feature code Description Purpose
CTO only BPKQ TPM 2.0 with Secure Boot Configure the system in the factory with Secure Boot enabled.
CTO only BPKR TPM 2.0 Configure the system without Secure Boot enabled. Customers can enable Secure Boot later if desired.

Tip: If Secure Boot is not enabled in the factory, it can be enabled later by the customer. However once Secure Boot is enabled, it cannot be disabled.

Security standards

The SR655 V3 supports the following security standards and capabilities:

  • Industry Standard Security Capabilities
    • AMD CPU Enablement
      • AES-NI (Advanced Encryption Standard New Instructions)
      • GMET (Guest Mode Execute Trap)
      • Hardware-based side channel attack resilience enhancements
      • NX (No eXecute)
      • PSB (Platform Secure Boot)
      • Shadow Stack
      • SEV (Secure Encrypted Virtualization)
      • SEV-ES (Encrypted State register encryption)
      • SEV-SNP (Secure Nested Paging)
      • SVM (Secure Virtual Machine)
      • SME (Secure Memory Encryption)
      • UMIP (User Mode Instruction Prevention)
    • Microsoft Windows Security Enablement
      • Credential Guard
      • Device Guard
      • Host Guardian Service
    • TCG (Trusted Computing Group) TPM (Trusted Platform Module) 2.0
    • UEFI (Unified Extensible Firmware Interface) Forum Secure Boot
  • Hardware Root of Trust and Security
    • Independent security subsystem providing platform-wide NIST SP800-193 compliant Platform Firmware Resilience (PFR)
    • Host domain RoT supplemented by AMD Platform Secure Boot (PSB)
    • Management domain RoT supplemented by the Secure Boot features of XCC
  • Platform Security

    For more information on platform security, see the paper “How to Harden the Security of your ThinkSystem Server and Management Applications” available from https://lenovopress.com/lp1260-how-to-harden-the-security-of-your-thinksystem-server.

    • Boot and run-time firmware integrity monitoring with rollback to known-good firmware (e.g., “self-healing”)
    • Non-volatile storage bus security monitoring and filtering
    • Resilient firmware implementation, such as to detect and defeat unauthorized flash writes or SMM (System Management Mode) memory incursions
    • Patented IPMI KCS channel privileged access authorization (USPTO Patent# 11,256,810)
    • Host and management domain authorization, including integration with CyberArk for enterprise password management
    • KMIP (Key Management Interoperability Protocol) compliant, including support for IBM SKLM and Thales KeySecure
    • Reduced “out of box” attack surface
    • Configurable network services
    • FIPS 140-3 (in progress) validated cryptography for XCC
    • CNSA Suite 1.0 Quantum-resistant cryptography for XCC
    • Lenovo System Guard
  • Standards Compliance and/or Support
    • NIST SP800-131A rev 2 “Transitioning the Use of Cryptographic Algorithms and Key Lengths”
    • NIST SP800-147B “BIOS Protection Guidelines for Servers”
    • NIST SP800-193 “Platform Firmware Resiliency Guidelines”
    • ISO/IEC 11889 “Trusted Platform Module Library”
    • Common Criteria TCG Protection Profile for “PC Client Specific TPM 2.0”
    • European Union Commission Regulation 2019/424 (“ErP Lot 9”) “Ecodesign Requirements for Servers and Data Storage Products” Secure Data Deletion
    • Optional FIPS 140-2 validated Self-Encrypting Disks (SEDs) with external KMIP-based key management
  • Product and Supply Chain Security
    • Suppliers validated through Lenovo’s Trusted Supplier Program
    • Developed in accordance with Lenovo’s Secure Development Lifecycle (LSDL)
    • Continuous firmware security validation through automated testing, including static code analysis, dynamic network and web vulnerability testing, software composition analysis, and subsystem-specific testing, such as UEFI security configuration validation
    • Ongoing security reviews by US-based security experts, with attestation letters available from our third-party security partners
    • Digitally signed firmware, stored and built on US-based infrastructure and signed on US-based Hardware Security Modules (HSMs)
    • Manufacturing transparency via Intel Transparent Supply Chain (for details, see https://lenovopress.com/lp1434-introduction-to-intel-transparent-supply-chain-on-lenovo-thinksystem-servers)
    • TAA (Trade Agreements Act) compliant manufacturing, by default in Mexico for North American markets with additional US and EU manufacturing options
    • US 2019 NDAA (National Defense Authorization Act) Section 889 compliant

Rack installation

The following table lists the rack installation options that are available for the SR655 V3.

Table 77. Rack installation options
Part number Feature Description
Rail Kits
4M17A13564 BK7W ThinkSystem Toolless Friction Rail v2
4M17A11754 B8LA ThinkSystem Toolless Slide Rail Kit v2
4M17A11756 B91Y ThinkSystem Toolless Slide Rail Kit v2 with 2U CMA
Enhanced Rail Kits for > 34 kg server weight*
4M17A11755 B8LB ThinkSystem Toolless Slide Rail Kit v2 Enhanced
4M17A11757 B97N ThinkSystem Toolless Slide Rail Kit v2 Enhanced with 2U CMA
Separate Cable Management Arm
7M27A05698 B135 ThinkSystem 2U CMA Upgrade Kit for Toolless Slide Rail

* The Enhanced Slide Rail Kits are used when the server is shipped in a rack and the server is 34 kg or heavier (configuration with 20x 3.5-inch HDDs for example)

The following table summarizes the rail kit features and specifications.

Table 78. Rail kit features and specifications summary
Feature ThinkSystem Toolless Friction Rail v2 ThinkSystem Toolless Slide Rail Kit v2 ThinkSystem Toolless Slide Rail Kit v2 Enhanced ThinkSystem Toolless Slide Rail Kit v2 with 2U CMA ThinkSystem Toolless Slide Rail Kit v2 Enhanced with 2U CMA
Option part number 4M17A13564 4M17A11754 4M17A11755 4M17A11756 4M17A11757
Rail type Half-out slide rail (friction) Full-out slide rail (ball bearing) Full-out slide rail (ball bearing) Full-out slide rail (ball bearing) Full-out slide rail (ball bearing)
Toolless installation Yes Yes Yes Yes Yes
CMA support No Optional, 7M27A05698* Optional, 7M27A05698* Included Included
Supported rack type Four-post IBM and Lenovo standard rack, complying with the IEC standard Four-post IBM and Lenovo standard rack, complying with the IEC standard Four-post IBM and Lenovo standard rack, complying with the IEC standard Four-post IBM and Lenovo standard rack, complying with the IEC standard Four-post IBM and Lenovo standard rack, complying with the IEC standard
In-rack server maintenance No Yes Yes Yes Yes
1U PDU support Yes Yes Yes Yes Yes
0U PDU support Yes Limited support** Limited support** Limited support** Limited support**
Supported mounting holes Square or round Square or round Square, round, or threaded Square or round Square, round, or threaded
Thickness of mounting flanges 2.0-3.3 mm (0.08-0.13 inches) 2.0-3.3 mm (0.08-0.13 inches) 2.0-3.3 mm (0.08-0.13 inches) 2.0-3.3 mm (0.08-0.13 inches) 2.0-3.3 mm (0.08-0.13 inches)
Supported distance between front and rear mounting flanges‡ 610-864 mm (24-34 inches) 610-813 mm (24-32 inches) 635-813 mm (25-32 inches) 610-813 mm (24-32 inches) 635-813 mm (25-32 inches)
Rail length† 751 mm (29.6 inches) 740 mm (29.1 inches) 740 mm (29.1 inches) 820 mm (32.3 inches) 820 mm (32.3 inches)

* CMA mounting brackets are not preinstalled on the rail. The CMA mounting brackets are contained in the CMA option kit package and you will need to install the CMA mounting brackets first. For detailed instructions, refer to the documentation that comes with the CMA option kit.
** If you want to install the rails and a 0U PDU into the same rack, the rack must meet the height and depth requirements as described in ThinkSystem Rail Support Matrix.
‡ For best performance, it is recommended that you install the rails to the racks with a 719-mm distance (28.31-inch, Lenovo rack default distance) between the front and rear mounting flanges.
† Measured when mounted on the rack, from the front surface of the front mounting flange to the rear most point of the rail. Rail is in closed position.

Operating system support

The SR655 V3 supports the following operating systems:

  • Microsoft Windows 10 Professional (x64)
  • Microsoft Windows 11 Professional (x64)
  • Microsoft Windows Server 2019
  • Microsoft Windows Server 2022
  • Red Hat Enterprise Linux 8.6
  • Red Hat Enterprise Linux 8.7
  • Red Hat Enterprise Linux 8.8
  • Red Hat Enterprise Linux 9.0
  • Red Hat Enterprise Linux 9.1
  • Red Hat Enterprise Linux 9.2
  • SUSE Linux Enterprise Server 15 SP4
  • SUSE Linux Enterprise Server 15 SP5
  • SUSE Linux Enterprise Server 15 Xen SP4
  • SUSE Linux Enterprise Server 15 Xen SP5
  • Ubuntu 20.04 LTS 64-bit
  • Ubuntu 22.04 LTS 64-bit
  • VMware ESXi 7.0 U3
  • VMware ESXi 8.0
  • VMware ESXi 8.0 U1
  • VMware ESXi 8.0 U2

For a complete list of supported, certified and tested operating systems, plus additional details and links to relevant web sites, see the Operating System Interoperability Guide: https://lenovopress.lenovo.com/osig#servers=sr655-v3-7d9f-7d9e&support=all

For configure-to-order configurations, the server can be preloaded with VMware ESXi installed on M.2 cards. Ordering information is listed in the following table.

Table 79. VMware ESXi preload
Feature code Description
BMEY VMware ESXi 7.0 U3 (Factory Installed)
BMT5 VMware ESXi 8.0 (Factory Installed)
BQ8S VMware ESXi 8.0 U1 (Factory Installed)

You can download supported VMware vSphere hypervisor images from the following web page and load it on the M.2 drives or 7mm drives using the instructions provided:
https://vmware.lenovo.com/content/custom_iso/

Windows 10 and Windows 11

The SR655 V3 can now run Windows 10 and Windows 11, however only a subset of adapters and drives can be installed. For ease of configuration, additional Base CTO models 7D9ECTO2WW and 7D9FCTO2WW have been created to assist building a configuration that can be used with the client operating systems. See the Models section for details.

The XClarity management toolset is supported with Windows 10 and Windows 11.

Windows client license: A Windows client license for the system cannot be ordered from Lenovo nor can the OS be preloaded on the system in the factory. For the Windows license and for preloads, please contact your Lenovo business partner. A Windows Pro license is required as a qualifying base OS license in order to use a client Volume License offering.

See the part number tables in the following sections to see which adapters are supported with Windows 10 and Windows 11:

GPU recommended: Lenovo recommends that if you plan to install Windows 10 or 11 on this server to run graphics-intensive applications, then you should selected a dedicated graphics adapter (GPU).

The following components are not supported:

  • Fibre Channel adapters
  • InfiniBand and VPI adapters
  • External storage adapters
  • Flash storage adapters

Physical and electrical specifications

The SR655 V3 has the following overall physical dimensions, excluding components that extend outside the standard chassis, such as EIA flanges, front security bezel (if any), and power supply handles:

  • Width: 445 mm (17.5 inches)
  • Height: 87 mm (3.4 inches)
  • Depth: 766 mm (30.1 inches)

The following table lists the detailed dimensions. See the figure below for the definition of each dimension.

Table 80. Detailed dimensions
Dimension Description
482 mm Xa = Width, to the outsides of the front EIA flanges
435 mm Xb = Width, to the rack rail mating surfaces
445 mm Xc = Width, to the outer most chassis body feature
87 mm Ya = Height, from the bottom of chassis to the top of the chassis
698 mm Za = Depth, from the rack flange mating surface to the rearmost I/O port surface
732 mm Zb = Depth, from the rack flange mating surface to the rearmost feature of the chassis body
727 mm (≤1100W)
755 mm (1800W)
781 mm (2400W)
Zc = Depth, from the rack flange mating surface to the rearmost feature such as power supply handle
34 mm Zd = Depth, from the forwardmost feature on front of EIA flange to the rack flange mating surface
46 mm Ze = Depth, from the front of security bezel (if applicable) or forwardmost feature to the rack flange mating surface

Rack server dimensions
Figure 25. Server dimensions

The shipping dimensions (cardboard packaging) of the SR655 V3 are as follows:

  • Width: 592 mm (23.3 inches)
  • Height: 282 mm (11.1 inches)
  • Depth: 992 mm (39.1 inches)

The server has the following weight:

  • Maximum weight: 38.8 kg (85.5 lb)

Electrical specifications for AC input power supplies:

  • Input voltage:
    • 100 to 127 (nominal) Vac, 50 Hz or 60 Hz
    • 200 to 240 (nominal) Vac, 50 Hz or 60 Hz
    • 180 to 300 Vdc (China only)
  • Inlet current: See the following table.
Table 81. Maximum inlet current
Part number Description 100V AC 200V AC 220V AC 240V DC
AC input power - 80 PLUS Titanium efficiency
4P57A82019 ThinkSystem 750W 230V Titanium Hot-Swap Gen2 Power Supply v3 No support 4A 3.6A 3.3A
4P57A72666 ThinkSystem 1100W 230V Titanium Hot-Swap Gen2 Power Supply No support 5.9A 5.3A 5A
4P57A78359 ThinkSystem 1800W 230V Titanium Hot-Swap Gen2 Power Supply No support 9.7A 8.7A 8.3A
4P57A72667 ThinkSystem 2600W 230V Titanium Hot-Swap Gen2 Power Supply No support 13.2A 13A 11.9A
AC input power - 80 PLUS Platinum efficiency
4P57A72670 ThinkSystem 750W 230V/115V Platinum Hot-Swap Gen2 Power Supply v3 8.4A 4.1A 3.69A 3.5A
4P57A72671 ThinkSystem 1100W 230V/115V Platinum Hot-Swap Gen2 Power Supply v3 12A 6A 5.4A 5.1A
4P57A26294 ThinkSystem 1800W 230V Platinum Hot-Swap Gen2 Power Supply v2 No support 10A 9.1A 9A
4P57A26295 ThinkSystem 2400W 230V Platinum Hot-Swap Gen2 Power Supply No support 14A 12.6A 12A

Electrical specifications for DC input power supply:

  • Input voltage: -48 to -60 Vdc
  • Inlet current (1100W power supply): 26 A

Operating environment

The SR655 V3 server complies with ASHRAE Class A2 specifications with most configurations, and depending on the hardware configuration, also complies with ASHRAE Class A3 and Class A4 specifications.

Depending on the hardware configuration, the SR655 V3 server also complies with ASHRAE Class H1 specification. System performance may be impacted when operating temperature is outside ASHRAE H1 specification.

Topics in this section:

Ambient temperature requirements

Additional restrictions to ASHRAE support, based on server configuration, are as follows:

  • The ambient temperature must be limited to 35°C if the server has any of the following components:
    • Broadcom 57454 10GBASE-T 4-port OCP
    • Broadcom 57416 10GBASE-T 2-port OCP
    • PCIe network interface cards (NICs) at a rate greater than or equal to 100 Gb
    • Parts with active optical cable (AOC) and at a rate of 25 Gb
  • The ambient temperature must be limited to 30°C if the server has any of the following components:
    • 24 x 2.5" or 12 x 3.5" front bay, middle bay, or rear bay
    • GPU adapters
    • Parts with AOC and at a rate of greater than 25 Gb
    • Processors 320W ≤ TDP ≤ 400W

Server shutdown: When the ambient temperature is greater than the supported max temperature, the server will shut down (ASHRAE 45°C). The server will not power on again until the ambient temperature falls within the supported temperature range.

For additional information, see the Environmental specifications and Thermal rules sections in the product documentation:
https://pubs.lenovo.com/sr655-v3/server_specifications_environmental
https://pubs.lenovo.com/sr655-v3/thermal_rules

Temperature and humidity

The server is supported in the following environment:

  • Air temperature:
    • Operating:
      • ASHRAE Class A2: 10°C to 35°C (50°F to 95°F); the maximum ambient temperature decreases by 1°C for every 300 m (984 ft) increase in altitude above 900 m (2,953 ft).
      • ASHRAE Class A3: 5°C to 40°C (41°F to 104°F); the maximum ambient temperature decreases by 1°C for every 175 m (574 ft) increase in altitude above 900 m (2,953 ft).
      • ASHRAE Class A4: 5°C to 45°C (41°F to 113°F); the maximum ambient temperature decreases by 1°C for every 125 m (410 ft) increase in altitude above 900 m (2,953 ft).
      • ASHRAE Class H1: 5 °C to 25 °C (41 °F to 77 °F); Decrease the maximum ambient temperature by 1°C for every 500 m (1640 ft) increase in altitude above 900 m (2,953 ft).
    • Server off: 5°C to 45°C (41°F to 113°F)
    • Shipment/storage: -40°C to 60°C (-40°F to 140°F)
  • Maximum altitude: 3,050 m (10,000 ft)
  • Relative Humidity (non-condensing):
    • Operating
      • ASHRAE Class A2: 8% to 80%; maximum dew point: 21°C (70°F)
      • ASHRAE Class A3: 8% to 85%; maximum dew point: 24°C (75°F)
      • ASHRAE Class A4: 8% to 90%; maximum dew point: 24°C (75°F)
      • ASHRAE Class H1: 8% to 80%; Maximum dew point: 17°C (63°F)
    • Shipment/storage: 8% to 90%

Heat output

The server generates the following heat:

  • Heat/thermal output:
    • Minimum configuration: 2859 BTU/hr, 837 W
    • Maximum configuration: 11,665 BTU/hr, 3419 W

Acoustical noise emissions

The SR655 V3 has the following acoustic noise emissions declaration:

  • Sound power level (LWAd):
    • Idling: 6.6 Bel (Typical), 7.4 Bel (GPU rich), 7.4 Bel (Storage rich)
    • Operating: 8.1 Bel (Typical), 8.6 Bel (GPU rich), 7.5 Bel (Storage rich)
  • Sound pressure level (LpAm):
    • Idling: 49.9 dBA (Typical), 59.5 dBA (GPU rich), 59.5 dBA (Storage rich)
    • Operating: 65.4 dBA (Typical), 71.2 dBA (GPU rich), 61.3 dBA (Storage rich)

Notes:

  • These sound levels were measured in controlled acoustical environments according to procedures specified by ISO7779 and are reported in accordance with ISO 9296.
  • The declared acoustic sound levels are based on the following configurations, which may change depending on configuration/conditions:
    • Typical: 1x 300W CPU, 12x 64GB RDIMM, 16x 2.5 SAS HDD, RAID 940-8i, Intel E810-DA2 10/25GbE SFP28 2-Port OCP, 2x 1800W PSU
    • GPU rich: 1x 300W CPU, 3x A100-80G GPUs, 12x 64GB RDIMM, 16x 2.5 SAS HDD, RAID 940-16i, Intel E810-DA2 10/25GbE SFP28 2-Port OCP, 2x 2400W PSU
    • Storage rich: 1x 240W CPU, 12x 64GB RDIMM, 12x3.5 SAS HDD, RAID 940-8i, Intel E810-DA2 10/25GbE SFP28 2-Port OCP, 2x 1800W PSU
  • Government regulations (such as those prescribed by OSHA or European Community Directives) may govern noise level exposure in the workplace and may apply to you and your server installation. The actual sound pressure levels in your installation depend upon a variety of factors, including the number of racks in the installation; the size, materials, and configuration of the room; the noise levels from other equipment; the room ambient temperature, and employee's location in relation to the equipment. Further, compliance with such government regulations depends on a variety of additional factors, including the duration of employees' exposure and whether employees wear hearing protection. Lenovo recommends that you consult with qualified experts in this field to determine whether you are in compliance with the applicable regulations.

Shock and vibration

The server has the following vibration and shock limits:

  • Vibration:
    • Operating: 0.21 G rms at 5 Hz to 500 Hz for 15 minutes across 3 axes
    • Non-operating: 1.04 G rms at 2 Hz to 200 Hz for 15 minutes across 6 surfaces
  • Shock:
    • Operating: 15 G for 3 milliseconds in each direction (positive and negative X, Y, and Z axes)
    • Non-operating:
      • 23 kg - 31 kg: 35 G for 152 in./sec velocity change across 6 surfaces (3x GPU config, 2.5” config)
      • 32 kg - 68 kg: 35 G for 136 in./sec velocity change across 6 surfaces (20x 3.5” HDD config)

Particulate contamination

Airborne particulates (including metal flakes or particles) and reactive gases acting alone or in combination with other environmental factors such as humidity or temperature might damage the system that might cause the system to malfunction or stop working altogether.

The following specifications indicate the limits of particulates that the system can tolerate:

  • Reactive gases:
    • The reactivity rate of copper coupons shall be less than 200 Angstroms per month (Å/month)
    • The reactivity rate of silver coupons shall be less than 200 Å/month
  • Airborne particulates:
    • The room air should be continuously filtered with MERV 8 filters.
    • Air entering a data center should be filtered with MERV 11 or preferably MERV 13 filters.
    • The deliquescent relative humidity of the particulate contamination should be more than 60% RH
    • Data centers must be free of zinc whiskers

For additional information, see the Specifications section of the Setup Guide for the server, available from the Lenovo Documents site, https://pubs.lenovo.com/

Warranty and Support

The SR655 V3 has a 1-year or 3-year warranty based on the machine type of the system:

  • 7D9F - 1 year warranty
  • 7D9E - 3 year warranty

The standard warranty terms are customer-replaceable unit (CRU) and onsite (for field-replaceable units FRUs only) with standard call center support during normal business hours and 9x5 Next Business Day Parts Delivered.

Lenovo’s additional support services provide a sophisticated, unified support structure for your data center, with an experience consistently ranked number one in customer satisfaction worldwide. Available offerings include:

  • Premier Support

    Premier Support provides a Lenovo-owned customer experience and delivers direct access to technicians skilled in hardware, software, and advanced troubleshooting, in addition to the following:

    • Direct technician-to-technician access through a dedicated phone line
    • 24x7x365 remote support
    • Single point of contact service
    • End to end case management
    • Third-party collaborative software support
    • Online case tools and live chat support
    • On-demand remote system analysis
  • Warranty Upgrade (Preconfigured Support)

    Services are available to meet the on-site response time targets that match the criticality of your systems.

    • 3, 4, or 5 years of service coverage
    • 1-year or 2-year post-warranty extensions
    • Foundation Service: 9x5 service coverage with next business day onsite response. YourDrive YourData is an optional extra (see below).
    • Essential Service: 24x7 service coverage with 4-hour onsite response or 24-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
    • Advanced Service: 24x7 service coverage with 2-hour onsite response or 6-hour committed repair (available only in select markets). Bundled with YourDrive YourData.
  • Managed Services

    Lenovo Managed Services provides continuous 24x7 remote monitoring (plus 24x7 call center availability) and proactive management of your data center using state-of-the-art tools, systems, and practices by a team of highly skilled and experienced Lenovo services professionals.

    Quarterly reviews check error logs, verify firmware & OS device driver levels, and software as needed. We’ll also maintain records of latest patches, critical updates, and firmware levels, to ensure you systems are providing business value through optimized performance.

  • Technical Account Management (TAM)

    A Lenovo Technical Account Manager helps you optimize the operation of your data center based on a deep understanding of your business. You gain direct access to your Lenovo TAM, who serves as your single point of contact to expedite service requests, provide status updates, and furnish reports to track incidents over time. In addition, your TAM will help proactively make service recommendations and manage your service relationship with Lenovo to make certain your needs are met.

  • Enterprise Server Software Support

    Enterprise Software Support is an additional support service providing customers with software support on Microsoft, Red Hat, SUSE, and VMware applications and systems. Around the clock availability for critical problems plus unlimited calls and incidents helps customers address challenges fast, without incremental costs. Support staff can answer troubleshooting and diagnostic questions, address product comparability and interoperability issues, isolate causes of problems, report defects to software vendors, and more.

  • YourDrive YourData

    Lenovo’s YourDrive YourData is a multi-drive retention offering that ensures your data is always under your control, regardless of the number of drives that are installed in your Lenovo server. In the unlikely event of a drive failure, you retain possession of your drive while Lenovo replaces the failed drive part. Your data stays safely on your premises, in your hands. The YourDrive YourData service can be purchased in convenient bundles and is optional with Foundation Service. It is bundled with Essential Service and Advanced Service.

  • Health Check

    Having a trusted partner who can perform regular and detailed health checks is central to maintaining efficiency and ensuring that your systems and business are always running at their best. Health Check supports Lenovo-branded server, storage, and networking devices, as well as select Lenovo-supported products from other vendors that are sold by Lenovo or a Lenovo-Authorized Reseller.

Examples of region-specific warranty terms are second or longer business day parts delivery or parts-only base warranty.

If warranty terms and conditions include onsite labor for repair or replacement of parts, Lenovo will dispatch a service technician to the customer site to perform the replacement. Onsite labor under base warranty is limited to labor for replacement of parts that have been determined to be field-replaceable units (FRUs). Parts that are determined to be customer-replaceable units (CRUs) do not include onsite labor under base warranty.

If warranty terms include parts-only base warranty, Lenovo is responsible for delivering only replacement parts that are under base warranty (including FRUs) that will be sent to a requested location for self-service. Parts-only service does not include a service technician being dispatched onsite. Parts must be changed at customer’s own cost and labor and defective parts must be returned following the instructions supplied with the spare parts.

Lenovo Service offerings are region-specific. Not all preconfigured support and upgrade options are available in every region. For information about Lenovo service upgrade offerings that are available in your region, refer to the following resources:

For service definitions, region-specific details, and service limitations, please refer to the following documents:

Services

Lenovo Services is a dedicated partner to your success. Our goal is to reduce your capital outlays, mitigate your IT risks, and accelerate your time to productivity.

Note: Some service options may not be available in all markets or regions. For more information, go to https://www.lenovo.com/services. For information about Lenovo service upgrade offerings that are available in your region, contact your local Lenovo sales representative or business partner.

Here’s a more in-depth look at what we can do for you:

  • Asset Recovery Services

    Asset Recovery Services (ARS) helps customers recover the maximum value from their end-of-life equipment in a cost-effective and secure way. On top of simplifying the transition from old to new equipment, ARS mitigates environmental and data security risks associated with data center equipment disposal. Lenovo ARS is a cash-back solution for equipment based on its remaining market value, yielding maximum value from aging assets and lowering total cost of ownership for your customers. For more information, see the ARS page, https://lenovopress.com/lp1266-reduce-e-waste-and-grow-your-bottom-line-with-lenovo-ars.

  • Assessment Services

    An Assessment helps solve your IT challenges through an onsite, multi-day session with a Lenovo technology expert. We perform a tools-based assessment which provides a comprehensive and thorough review of a company's environment and technology systems. In addition to the technology based functional requirements, the consultant also discusses and records the non-functional business requirements, challenges, and constraints. Assessments help organizations like yours, no matter how large or small, get a better return on your IT investment and overcome challenges in the ever-changing technology landscape.

  • Design Services

    Professional Services consultants perform infrastructure design and implementation planning to support your strategy. The high-level architectures provided by the assessment service are turned into low level designs and wiring diagrams, which are reviewed and approved prior to implementation. The implementation plan will demonstrate an outcome-based proposal to provide business capabilities through infrastructure with a risk-mitigated project plan.

  • Basic Hardware Installation

    Lenovo experts can seamlessly manage the physical installation of your server, storage, or networking hardware. Working at a time convenient for you (business hours or off shift), the technician will unpack and inspect the systems on your site, install options, mount in a rack cabinet, connect to power and network, check and update firmware to the latest levels, verify operation, and dispose of the packaging, allowing your team to focus on other priorities.

  • Deployment Services

    When investing in new IT infrastructures, you need to ensure your business will see quick time to value with little to no disruption. Lenovo deployments are designed by development and engineering teams who know our Products & Solutions better than anyone else, and our technicians own the process from delivery to completion. Lenovo will conduct remote preparation and planning, configure & integrate systems, validate systems, verify and update appliance firmware, train on administrative tasks, and provide post-deployment documentation. Customer’s IT teams leverage our skills to enable IT staff to transform with higher level roles and tasks.

  • Integration, Migration, and Expansion Services

    Move existing physical & virtual workloads easily, or determine technical requirements to support increased workloads while maximizing performance. Includes tuning, validation, and documenting ongoing run processes. Leverage migration assessment planning documents to perform necessary migrations.

Regulatory compliance

The SR655 V3 conforms to the following standards:

  • ANSI/UL 62368-1
  • IEC 62368-1 (CB Certificate and CB Test Report)
  • FCC - Verified to comply with Part 15 of the FCC Rules, Class A
  • Canada ICES-003, issue 7, Class A
  • CSA C22.2 No. 62368-1
  • CISPR 32, Class A, CISPR 35
  • Japan VCCI, Class A
  • Taiwan BSMI CNS15936, Class A; CNS15598-1; Section 5 of CNS15663
  • CE, UKCA Mark (EN55032 Class A, EN62368-1, EN55024, EN55035, EN61000-3-2, EN61000-3-3, (EU) 2019/424, and EN IEC 63000 (RoHS))
  • Korea KN32, Class A, KN35
  • Russia, Belorussia and Kazakhstan, TP EAC 037/2016 (for RoHS)
  • Russia, Belorussia and Kazakhstan, EAC: TP TC 004/2011 (for Safety); TP TC 020/2011 (for EMC)
  • Australia/New Zealand AS/NZS CISPR 32, Class A; AS/NZS 62368.1
  • UL Green Guard, UL2819
  • Energy Star 3.0
  • EPEAT (NSF/ ANSI 426) Bronze
  • China CCC certificate, GB17625.1; GB4943.1; GB/T9254
  • China CECP certificate, CQC3135
  • China CELP certificate, HJ 2507-2011
  • Japanese Energy-Saving Act
  • Mexico NOM-019
  • TUV-GS (EN62368-1, and EK1-ITB2000)
  • India BIS 13252 (Part 1)
  • Germany GS
  • Ukraine UkrCEPRO
  • Morocco CMIM Certification (CM)
  • EU2019/424 Energy Related Product (ErP Lot9)

External drive enclosures

The server supports attachment to external drive enclosures using a RAID controller with external ports or a SAS host bus adapter. Adapters supported by the server are listed in the SAS adapters for external storage section.

Note: Information provided in this section is for ordering reference purposes only. For the operating system and adapter support details, refer to the interoperability matrix for a particular storage enclosure that can be found on the Lenovo Data Center Support web site:
http://datacentersupport.lenovo.com

Table 82. External drive enclosures
Model Description
4587HC1 Lenovo Storage D1212 Disk Expansion Enclosure (2U enclosure wth 12x LFF drive bays)
4587HC2 Lenovo Storage D1224 Disk Expansion Enclosure (2U enclosure wth 24x SFF drive bays)
6413HC1 Lenovo Storage D3284 High Density Expansion Enclosure (5U enclosure wth 84x LFF drive bays)
7DAHCTO1WW Lenovo ThinkSystem D4390 Direct Attached Storage (4U enclosure wth 90x LFF drive bays)

For details about supported drives, adapters, and cables, see the following Lenovo Press Product Guides:

External storage systems

Lenovo offers the ThinkSystem DE Series and ThinkSystem DM Series external storage systems for high-performance storage. See the DE Series and DM Series product guides for specific controller models, expansion enclosures and configuration options:

External backup units

The following table lists the external backup options that are offered by Lenovo.

Table 83. External backup options
Part number Description
External RDX USB drives
4T27A10725 ThinkSystem RDX External USB 3.0 Dock
External SAS tape backup drives
6160S7E IBM TS2270 Tape Drive Model H7S
6160S8E IBM TS2280 Tape Drive Model H8S
6160S9E IBM TS2290 Tape Drive Model H9S
External SAS tape backup autoloaders
6171S7R IBM TS2900 Tape Autoloader w/LTO7 HH SAS
6171S8R IBM TS2900 Tape Autoloader w/LTO8 HH SAS
6171S9R IBM TS2900 Tape Autoloader w/LTO9 HH SAS
External tape backup libraries
6741A1F IBM TS4300 3U Tape Library-Base Unit
6741A3F IBM TS4300 3U Tape Library-Expansion Unit
Full High 8 Gb Fibre Channel for TS4300
01KP938 LTO 7 FH Fibre Channel Drive
01KP954 LTO 8 FH Fibre Channel Drive
02JH837 LTO 9 FH Fibre Channel Drive
Half High 8 Gb Fibre Channel for TS4300
01KP936 LTO 7 HH Fibre Channel Drive
01KP952 LTO 8 HH Fibre Channel Drive
02JH835 LTO 9 HH Fibre Channel Drive
Half High 6 Gb SAS for TS4300
01KP937 LTO 7 HH SAS Drive
01KP953 LTO 8 HH SAS Drive
02JH836 LTO 9 HH SAS Drive

For more information, see the list of Product Guides in the Backup units category:
https://lenovopress.com/servers/options/backup

Fibre Channel SAN switches

Lenovo offers the ThinkSystem DB Series of Fibre Channel SAN switches for high-performance storage expansion. See the DB Series product guides for models and configuration options:

Uninterruptible power supply units

The following table lists the uninterruptible power supply (UPS) units that are offered by Lenovo.

Table 84. Uninterruptible power supply units
Part number Description
55941AX RT1.5kVA 2U Rack or Tower UPS (100-125VAC)
55941KX RT1.5kVA 2U Rack or Tower UPS (200-240VAC)
55942AX RT2.2kVA 2U Rack or Tower UPS (100-125VAC)
55942KX RT2.2kVA 2U Rack or Tower UPS (200-240VAC)
55943AX RT3kVA 2U Rack or Tower UPS (100-125VAC)
55943KX RT3kVA 2U Rack or Tower UPS (200-240VAC)
55945KX RT5kVA 3U Rack or Tower UPS (200-240VAC)
55946KX RT6kVA 3U Rack or Tower UPS (200-240VAC)
55948KX RT8kVA 6U Rack or Tower UPS (200-240VAC)
55949KX RT11kVA 6U Rack or Tower UPS (200-240VAC)
55948PX RT8kVA 6U 3:1 Phase Rack or Tower UPS (380-415VAC)
55949PX RT11kVA 6U 3:1 Phase Rack or Tower UPS (380-415VAC)
55943KT† ThinkSystem RT3kVA 2U Standard UPS (200-230VAC) (2x C13 10A, 2x GB 10A, 1x C19 16A outlets)
55943LT† ThinkSystem RT3kVA 2U Long Backup UPS (200-230VAC) (2x C13 10A, 2x GB 10A, 1x C19 16A outlets)
55946KT† ThinkSystem RT6kVA 5U UPS (200-230VAC) (2x C13 10A outlets, 1x Terminal Block output)
5594XKT† ThinkSystem RT10kVA 5U UPS (200-230VAC) (2x C13 10A outlets, 1x Terminal Block output)

† Only available in China and the Asia Pacific market.

For more information, see the list of Product Guides in the UPS category:
https://lenovopress.com/servers/options/ups

Power distribution units

The following table lists the power distribution units (PDUs) that are offered by Lenovo.

Table 85. Power distribution units
Part
number
Feature
code
Description
ANZ
ASEAN
Brazil
EET
MEA
RUCIS
WE
HTK
INDIA
JAPAN
LA
NA
PRC
0U Basic PDUs
00YJ776 ATZY 0U 36 C13/6 C19 24A 1 Phase PDU N Y Y N N N N N N Y Y Y N
00YJ779 ATZX 0U 21 C13/12 C19 48A 3 Phase PDU N N Y N N N Y N N Y Y Y N
00YJ777 ATZZ 0U 36 C13/6 C19 32A 1 Phase PDU Y Y N Y Y Y Y Y Y N N Y Y
00YJ778 AU00 0U 21 C13/12 C19 32A 3 Phase PDU Y Y N Y Y Y Y Y Y N N Y Y
0U Switched and Monitored PDUs
00YJ783 AU04 0U 12 C13/12 C19 Switched and Monitored 48A 3 Phase PDU N N Y N N N Y N N Y Y Y N
00YJ781 AU03 0U 20 C13/4 C19 Switched and Monitored 24A 1 Phase PDU N N Y N Y N Y N N Y Y Y N
00YJ782 AU02 0U 18 C13/6 C19 Switched and Monitored 32A 3 Phase PDU Y Y Y Y Y Y Y Y Y N Y N Y
00YJ780 AU01 0U 20 C13/4 C19 Switched and Monitored 32A 1 Phase PDU Y Y Y Y Y Y Y Y Y N Y N Y
1U Switched and Monitored PDUs
4PU7A81117 BNDV 1U 18 C19/C13 switched and monitored 48A 3P WYE PDU - ETL N N N N N N N N N N N Y N
4PU7A77467 BLC4 1U 18 C19/C13 Switched and Monitored 80A 3P Delta PDU N N N N N N N N N Y N Y N
4PU7A77469 BLC6 1U 12 C19/C13 switched and monitored 60A 3P Delta PDU N N N N N N N N N N N Y N
4PU7A77468 BLC5 1U 12 C19/C13 switched and monitored 32A 3P WYE PDU Y Y Y Y Y Y Y Y Y N Y Y Y
4PU7A81118 BNDW 1U 18 C19/C13 switched and monitored 48A 3P WYE PDU - CE Y Y Y Y Y Y Y Y Y N Y N Y
46M4002 5896 1U 9 C19/3 C13 Switched and Monitored DPI PDU Y Y Y Y Y Y Y Y Y Y Y Y Y
46M4004 5894 1U 12 C13 Switched and Monitored DPI PDU Y Y Y Y Y Y Y Y Y Y Y Y Y
46M4003 5897 1U 9 C19/3 C13 Switched and Monitored 60A 3 Phase PDU Y Y Y Y Y Y Y Y Y Y Y Y Y
46M4005 5895 1U 12 C13 Switched and Monitored 60A 3 Phase PDU Y Y Y Y Y Y Y Y Y Y Y Y Y
1U Ultra Density Enterprise PDUs (9x IEC 320 C13 + 3x IEC 320 C19 outlets)
71763NU 6051 Ultra Density Enterprise C19/C13 PDU 60A/208V/3PH N N Y N N N N N N Y Y Y N
71762NX 6091 Ultra Density Enterprise C19/C13 PDU Module Y Y Y Y Y Y Y Y Y Y Y Y Y
1U C13 Enterprise PDUs (12x IEC 320 C13 outlets)
39M2816 6030 DPI C13 Enterprise PDU Plus Module (WW) Y Y Y Y Y Y Y Y Y Y Y Y Y
39Y8941 6010 DPI C13 Enterprise PDU Module (WW) Y Y Y Y Y Y Y Y Y Y Y Y Y
1U C19 Enterprise PDUs (6x IEC 320 C19 outlets)
39Y8948 6060 DPI C19 Enterprise PDU Module (WW) Y Y Y Y Y Y Y Y Y Y Y Y Y
39Y8923 6061 DPI Three-phase 60A/208V C19 Enterprise PDU (US) N N Y N N N Y N N N Y Y N
1U Front-end PDUs (3x IEC 320 C19 outlets)
39Y8938 6002 DPI Single-phase 30A/120V Front-end PDU (US) Y Y Y Y Y Y Y Y Y Y Y Y Y
39Y8939 6003 DPI Single-phase 30A/208V Front-end PDU (US) Y Y Y Y Y Y Y Y Y Y Y Y Y
39Y8934 6005 DPI Single-phase 32A/230V Front-end PDU (International) Y Y Y Y Y Y Y Y Y Y Y Y Y
39Y8940 6004 DPI Single-phase 60A/208V Front-end PDU (US) Y N Y Y Y Y Y N N Y Y Y N
39Y8935 6006 DPI Single-phase 63A/230V Front-end PDU (International) Y Y Y Y Y Y Y Y Y Y Y Y Y
1U NEMA PDUs (6x NEMA 5-15R outlets)
39Y8905 5900 DPI 100-127V NEMA PDU Y Y Y Y Y Y Y Y Y Y Y Y Y
Line cords for 1U PDUs that ship without a line cord
40K9611 6504 4.3m, 32A/380-415V, EPDU/IEC 309 3P+N+G 3ph wye (non-US) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y
40K9612 6502 4.3m, 32A/230V, EPDU to IEC 309 P+N+G (non-US) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y
40K9613 6503 4.3m, 63A/230V, EPDU to IEC 309 P+N+G (non-US) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y
40K9614 6500 4.3m, 30A/208V, EPDU to NEMA L6-30P (US) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y
40K9615 6501 4.3m, 60A/208V, EPDU to IEC 309 2P+G (US) Line Cord N N Y N N N Y N N Y Y Y N
40K9617 6505 4.3m, 32A/230V, Souriau UTG Female to AS/NZ 3112 (Aus/NZ) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y
40K9618 6506 4.3m, 32A/250V, Souriau UTG Female to KSC 8305 (S. Korea) Line Cord Y Y Y Y Y Y Y Y Y Y Y Y Y

For more information, see the Lenovo Press documents in the PDU category:
https://lenovopress.com/servers/options/pdu

Rack cabinets

The following table lists the supported rack cabinets.

Table 86. Rack cabinets
Part number Description
93072RX 25U Standard Rack (1000mm)
93072PX 25U Static S2 Standard Rack (1000mm)
7D6DA007WW ThinkSystem 42U Onyx Primary Heavy Duty Rack Cabinet (1200mm)
7D6DA008WW ThinkSystem 42U Pearl Primary Heavy Duty Rack Cabinet (1200mm)
93604PX 42U 1200mm Deep Dynamic Rack
93614PX 42U 1200mm Deep Static Rack
93634PX 42U 1100mm Dynamic Rack
93634EX 42U 1100mm Dynamic Expansion Rack
93074RX 42U Standard Rack (1000mm)
7D6EA009WW ThinkSystem 48U Onyx Primary Heavy Duty Rack Cabinet (1200mm)
7D6EA00AWW ThinkSystem 48U Pearl Primary Heavy Duty Rack Cabinet (1200mm)
Withdrawn rack cabinets
201886X 11U Office Enablement Kit
93084PX 42U Enterprise Rack
93084EX 42U Enterprise Expansion Rack
93604EX 42U 1200mm Deep Dynamic Expansion Rack
93614EX 42U 1200mm Deep Static Expansion Rack
93074XX 42U Standard Rack Extension
93634BX PureFlex System 42U Expansion Rack
93634DX PureFlex System 42U Expansion Rack
93634AX PureFlex System 42U Rack
93634CX PureFlex System 42U Rack
93624PX 47U 1200mm Deep Static Rack
93624EX 47U 1200mm Deep Static Expansion Rack

For specifications about these racks, see the Lenovo Rack Cabinet Reference, available from:
https://lenovopress.com/lp1287-lenovo-rack-cabinet-reference

For more information, see the list of Product Guides in the Rack cabinets category:
https://lenovopress.com/servers/options/racks

KVM console options

The following table lists the supported KVM consoles.

Table 87. KVM console
Part number Description
Consoles
4XF7A84188 ThinkSystem 18.5" LCD Console (with English keyboard)
4XF7A73009 ThinkSystem 18.5" LCD console (with English keyboard)
17238BX 1U 18.5" Standard Console (without keyboard - see the next table)

The following table lists the keyboards supported with the 1U 18.5" Standard Console (now withdrawn).

Note: These keyboards are not supported with the ThinkSystem 18.5" LCD Console.

Table 88. Keyboards for 1U 18.5" Standard Console
Part number Description
7ZB7A05469 ThinkSystem Keyboard w/ Int.Pointing Device USB - Arabic 253 RoHS v2
7ZB7A05468 ThinkSystem Keyboard w/ Int. Pointing Device USB - Belg/UK 120 RoHS v2
7ZB7A05206 ThinkSystem Keyboard w/ Int. Pointing Device USB - Czech 489 RoHS v2
7ZB7A05207 ThinkSystem Keyboard w/ Int. Pointing Device USB - Danish 159 RoHS v2
7ZB7A05208 ThinkSystem Keyboard w/ Int. Pointing Device USB - Dutch 143 RoHS v2
7ZB7A05210 ThinkSystem Keyboard w/ Int. Pointing Device USB - Fr/Canada 445 RoHS v2
7ZB7A05209 ThinkSystem Keyboard w/ Int. Pointing Device USB - French 189 RoHS v2
7ZB7A05211 ThinkSystem Keyboard w/ Int. Pointing Device USB - German 129 RoHS v2
7ZB7A05212 ThinkSystem Keyboard w/ Int. Pointing Device USB - Greek 219 RoHS v2
7ZB7A05213 ThinkSystem Keyboard w/ Int. Pointing Device USB - Hebrew 212 RoHS v2
7ZB7A05214 ThinkSystem Keyboard w/ Int. Pointing Device USB - Hungarian 208 RoHS v2
7ZB7A05215 ThinkSystem Keyboard w/ Int. Pointing Device USB - Italian 141 RoHS v2
7ZB7A05216 ThinkSystem Keyboard w/ Int. Pointing Device USB - Japanese 194 RoHS v2
7ZB7A05217 ThinkSystem Keyboard w/ Int. Pointing Device USB - Korean 413 RoHS v2
7ZB7A05218 ThinkSystem Keyboard w/ Int. Pointing Device USB - LA Span 171 RoHS v2
7ZB7A05219 ThinkSystem Keyboard w/ Int. Pointing Device USB - Norwegian 155 RoHS v2
7ZB7A05220 ThinkSystem Keyboard w/ Int. Pointing Device USB - Polish 214 RoHS v2
7ZB7A05221 ThinkSystem Keyboard w/ Int. Pointing Device USB - Portugese 163 RoHS v2
7ZB7A05222 ThinkSystem Keyboard w/ Int. Pointing Device USB - Russian 441 RoHS v2
7ZB7A05223 ThinkSystem Keyboard w/ Int. Pointing Device USB - Slovak 245 RoHS v2
7ZB7A05231 ThinkSystem Keyboard w/ Int. Pointing Device USB - Slovenian 234 RoHS v2
7ZB7A05224 ThinkSystem Keyboard w/ Int. Pointing Device USB - Spanish 172 RoHS v2
7ZB7A05225 ThinkSystem Keyboard w/ Int. Pointing Device USB - Swed/Finn 153 RoHS v2
7ZB7A05226 ThinkSystem Keyboard w/ Int. Pointing Device USB - Swiss F/G 150 RoHS v2
7ZB7A05227 ThinkSystem Keyboard w/ Int. Pointing Device USB - Thai 191 RoHS v2
7ZB7A05467 ThinkSystem Keyboard with Int. Pointing Device USB - Trad Chinese/US 467 RoHS v2
7ZB7A05228 ThinkSystem Keyboard w/ Int. Pointing Device USB - Turkish 179 RoHS v2
7ZB7A05229 ThinkSystem Keyboard w/ Int. Pointing Device USB - UK Eng 166 RoHS v2
7ZB7A05470 ThinkSystem Keyboard w/ Int. Pointing Device USB - US Eng 103P RoHS v2
7ZB7A05230 ThinkSystem Keyboard w/ Int. Pointing Device USB - US Euro 103P RoHS v2

The following table lists the available KVM switches and the options that are supported with them.

Table 89. KVM switches and options
Part number Description
KVM Console switches
1754D1T ThinkSystem Digital 2x1x16 KVM Switch (DVI video output port)
1754A1T ThinkSystem Analog 1x8 KVM Switch (DVI video output port)
1754D2X Global 4x2x32 Console Manager (GCM32)
1754D1X Global 2x2x16 Console Manager (GCM16)
1754A2X Local 2x16 Console Manager (LCM16)
1754A1X Local 1x8 Console Manager (LCM8)
Cables for ThinkSystem Digital and Analog KVM Console switches
4X97A11108 ThinkSystem VGA to DVI Conversion Cable
4X97A11109 ThinkSystem Single-USB Conversion Cable for Digital KVM
4X97A11107 ThinkSystem Dual-USB Conversion Cable for Digital KVM
4X97A11106 ThinkSystem USB Conversion Cable for Analog KVM
Cables for GCM and LCM Console switches
43V6147 Single Cable USB Conversion Option (UCO)
39M2895 USB Conversion Option Pack
46M5383 Virtual Media Conversion Option Gen2 (VCO2)
46M5382 Serial Conversion Option (SCO)

For more information, see the list of Product Guides in the KVM Switches and Consoles category:
http://lenovopress.com/servers/options/kvm

Lenovo Financial Services

Lenovo Financial Services reinforces Lenovo’s commitment to deliver pioneering products and services that are recognized for their quality, excellence, and trustworthiness. Lenovo Financial Services offers financing solutions and services that complement your technology solution anywhere in the world.

We are dedicated to delivering a positive finance experience for customers like you who want to maximize your purchase power by obtaining the technology you need today, protect against technology obsolescence, and preserve your capital for other uses.

We work with businesses, non-profit organizations, governments and educational institutions to finance their entire technology solution. We focus on making it easy to do business with us. Our highly experienced team of finance professionals operates in a work culture that emphasizes the importance of providing outstanding customer service. Our systems, processes and flexible policies support our goal of providing customers with a positive experience.

We finance your entire solution. Unlike others, we allow you to bundle everything you need from hardware and software to service contracts, installation costs, training fees, and sales tax. If you decide weeks or months later to add to your solution, we can consolidate everything into a single invoice.

Our Premier Client services provide large accounts with special handling services to ensure these complex transactions are serviced properly. As a premier client, you have a dedicated finance specialist who manages your account through its life, from first invoice through asset return or purchase. This specialist develops an in-depth understanding of your invoice and payment requirements. For you, this dedication provides a high-quality, easy, and positive financing experience.

For your region-specific offers, please ask your Lenovo sales representative or your technology provider about the use of Lenovo Financial Services. For more information, see the following Lenovo website:

https://www.lenovo.com/us/en/landingpage/lenovo-financial-services/

Related product families

Product families related to this document are the following:

Trademarks

Lenovo and the Lenovo logo are trademarks or registered trademarks of Lenovo in the United States, other countries, or both. A current list of Lenovo trademarks is available on the Web at https://www.lenovo.com/us/en/legal/copytrade/.

The following terms are trademarks of Lenovo in the United States, other countries, or both:
Lenovo®
AnyBay®
Bootable Media Creator
Flex System
Lenovo Services
ServerProven®
System x®
ThinkShield®
ThinkServer®
ThinkSystem®
TopSeller
UpdateXpress System Packs
XClarity®

The following terms are trademarks of other companies:

Intel® and Xeon® are trademarks of Intel Corporation or its subsidiaries.

Linux® is the trademark of Linus Torvalds in the U.S. and other countries.

ActiveX®, Dynamics, Microsoft®, PowerShell, Windows PowerShell®, Windows Server®, and Windows® are trademarks of Microsoft Corporation in the United States, other countries, or both.

SPECpower® is a trademark of the Standard Performance Evaluation Corporation (SPEC).

Other company, product, or service names may be trademarks or service marks of others.
